DTC P0744 A/T TCC S/V FUNCTION (LOCK-UP)PFP:31940
DescriptionUCS002ED
This malfunction is detected when the A/T does not shift into 5th gear position or the torque converter clutch
does not lock-up as instructed by the TCM. This is not only caused by electrical malfunction (circuits open or
shorted) but also by mechanical malfunction such as control valve sticking, improper solenoid valve operation,
etc.
CONSULT-II Reference ValueUCS002EE
On Board Diagnosis LogicUCS002EF

This is an OBD-II self-diagnostic item.

Diagnostic trouble code “A/T TCC S/V FNCTN” with CONSULT-II or P0744 without CONSULT-II is
detected under the following conditions.
–When A/T cannot perform lock-up even if electrical circuit is good.
–When TCM detects as irregular by comparing difference value with slip rotation.
Possible CauseUCS002EG

Harness or connectors
(The solenoid circuit is open or shorted.)

Torque converter clutch solenoid valve

Hydraulic control circuit
DTC Confirmation ProcedureUCS002EH
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Start engine and Select “TCC S/V FNCTN CHECK” of “DTC
WORK SUPPORT” mode for “A/T” with CONSULT-II and touch
“START”.
2. Accelerate vehicle to more than 80 km/h (50 MPH) and maintain
the following condition continuously until “TESTING” has turned
to “COMPLETE”. (It will take approximately 30 seconds after
“TESTING” shows.)
ACCELE POSI: More than 1.0/8 (at all times during step 4)
TCC SOLENOID: 0.4 - 0.6 A
Selector lever: “D” position
[Reference speed: Constant speed of more than 80 km/h (50
MPH)]
–Make sure “GEAR” shows “5”.
–For shift schedule, refer to AT- 6 7 , "Vehicle Speed When Performing and Releasing Complete Lock-
up" .
–If “TESTING” does not appear on CONSULT-II for a long time, select “SELF-DIAG RESULTS”. In
case a 1st trip DTC other than P0744 is shown, refer to applicable “TROUBLE DIAGNOSIS FOR
DTC”.
3. Make sure that “OK” is displayed. (If “NG” is displayed, refer to “DIAGNOSTIC PROCEDURE”.)
Refer to AT- 1 2 2 , "
Diagnostic Procedure" .
Refer to shift schedule, AT-67, "
Vehicle Speed When Performing and Releasing Complete Lock-up" .
Item name Condition Display value (Approx.) (A)
TCC SOLENOIDWhen performing slip lock-up 0.2 - 0.4
When performing lock-up 0.4 - 0.6
BCIA0030E

EC-1
ENGINE CONTROL SYSTEM
B ENGINE
CONTENTS
C
D
E
F
G
H
I
J
K
L
M
SECTION EC
A
EC
Revision: August 20072004 QX56 INDEX FOR DTC ........................................................ 8
Alphabetical Index .................................................... 8
DTC No. Index ....................................................... 12
PRECAUTIONS ........................................................ 16
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ................................................................ 16
On Board Diagnostic (OBD) System of Engine and
A/T .......................................................................... 16
Precaution .............................................................. 16
Wiring Diagrams and Trouble Diagnosis ................ 19
PREPARATION ......................................................... 20
Special Service Tools ............................................. 20
Commercial Service Tools ...................................... 22
ENGINE CONTROL SYSTEM .................................. 23
System Diagram ..................................................... 23
Vacuum Hose Drawing ........................................... 24
System Chart ......................................................... 25
Multiport Fuel Injection (MFI) System .................... 26
Electronic Ignition (EI) System ............................... 28
Nissan Torque Demand (NTD) Control System ..... 29
Air Conditioning Cut Control ................................... 30
Fuel Cut Control (at No Load and High Engine
Speed) .................................................................... 30
CAN communication .............................................. 31
BASIC SERVICE PROCEDURE .............................. 32
Idle Speed and Ignition Timing Check .................... 32
Idle Speed/Ignition Timing/Idle Mixture Ratio
Adjustment ............................................................. 33
Accelerator Pedal Released Position Learning ...... 44
Throttle Valve Closed Position Learning ................ 44
Idle Air Volume Learning ........................................ 44
Fuel Pressure Check .............................................. 46
ON BOARD DIAGNOSTIC (OBD) SYSTEM ............ 49
Introduction ............................................................ 49
Two Trip Detection Logic ........................................ 49
Emission-related Diagnostic Information ................ 50
IVIS (Infiniti Vehicle Immobilizer System — NATS) ... 63
Malfunction Indicator Lamp (MIL) ........................... 63
OBD System Operation Chart ................................ 66TROUBLE DIAGNOSIS ............................................ 71
Trouble Diagnosis Introduction ............................... 71
DTC Inspection Priority Chart ................................. 76
Fail-safe Chart ........................................................ 77
Basic Inspection ..................................................... 79
Symptom Matrix Chart ............................................ 84
Engine Control Component Parts Location ............ 88
Circuit Diagram ....................................................... 94
ECM Harness Connector Terminal Layout ............. 96
ECM Terminals and Reference Value ..................... 96
CONSULT-II Function ...........................................103
Generic Scan Tool (GST) Function .......................116
CONSULT-II Reference Value in Data Monitor .....118
Major Sensor Reference Graph in Data Monitor
Mode .....................................................................121
TROUBLE DIAGNOSIS - SPECIFICATION VALUE .123
Description ............................................................123
Testing Condition ..................................................123
Inspection Procedure ............................................123
Diagnostic Procedure ...........................................124
TROUBLE DIAGNOSIS FOR INTERMITTENT INCI-
DENT .......................................................................127
Description ............................................................127
Diagnostic Procedure ...........................................127
POWER SUPPLY AND GROUND CIRCUIT ...........128
Wiring Diagram .....................................................128
Diagnostic Procedure ...........................................129
Ground Inspection ................................................133
DTC U1000, U1001 CAN COMMUNICATION LINE .135
Description ............................................................135
On Board Diagnosis Logic ....................................135
DTC Confirmation Procedure ...............................135
Wiring Diagram .....................................................136
Diagnostic Procedure ...........................................137
DTC P0037, P0038, P0057, P0058 HO2S2 HEATER .138
Description ............................................................138
CONSULT-II Reference Value in Data Monitor Mode
.138
On Board Diagnosis Logic ....................................138
DTC Confirmation Procedure ...............................139

EC-22Revision: August 2007
