Page 753 of 3371
BCS-8
BCM (BODY CONTROL MODULE)
Revision: August 20072004 QX56
CAN Communication System DescriptionEKS007GF
Refer to LAN-5, "CAN COMMUNICATION" .
Power supply (BAT) to power window and
sunroofBattery power supply Power supply to power window and sunroof system
Panic alarm
Key switch
KeyfobIPDM E/R
Auto light system
Auto light sensor
Combination switchIPDM E/R
Battery saver control
Ignition switch
Combination switch
Front door switch LH
Front door switch RHIPDM E/R
Headlamp Combination switch IPDM E/R
Tail lamp Combination switch IPDM E/R
Fog lamp Combination switch IPDM E/R
Turn signal lamp Combination switch
Turn signal lamp
Combination meter
Hazard lamp Hazard switch
Turn signal lamp
Combination meter
Room lamp timer
Key switch
Keyfob
Main power window and door
lock/unlock switch
Front door lock assembly LH
(key cylinder switch)
All door switchInterior room lamp
Key warning chime
Key switch
Front door switch LHCombination meter (warning buzzer)
Light warning chime
Combination switch
Key switch
Front door switch LHCombination meter (warning buzzer)
Vehicle-speed-sensing intermittent wiper
Combination switch
Combination meterIPDM E/R
Rear window defogger Rear window defogger switch IPDM E/R
Air conditioner switch signal Front air control ECM
Blower fan switch signal Front air control ECM
Low tire pressure warning system Remote keyless entry receiver
Combination meter
Display control unit
Trailer tow Combination switch Trailer turn signal lamp
Vehicle security system
Remote keyless entry receiver
(Keyfob)
Main power window and door
lock/unlock switch
Power window and door lock/
unlock switch RH
Front door lock assembly LH
(key cylinder switch)
All door switch
Glass hatch ajar switch
IPDM E/R
Security indicator lamp System Input Output
Page 756 of 3371
BCM (BODY CONTROL MODULE)
BCS-11
C
D
E
F
G
H
I
J
L
MA
B
BCS
Revision: August 20072004 QX56
CONSULT-II Function (BCM)EKS007GH
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
CONSULT-II OPERATION
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
1. With ignition switch OFF, connect CONSULT-II and CONSULT-II
CONVERTER to data link connector and turn ignition switch ON.
2. Touch “START (NISSAN BASED VHCL)”.
3. Touch “BCM” on “SELECT SYSTEM” screen.
If "BCM" is not indicated, go to GI-39, "
CONSULT-II Data Link
Connector (DLC) Circuit" .
BCM diagnostic
test itemDiagnostic mode Content
Inspection by partWORK SUPPORTSupports inspections and adjustments. Commands are transmitted to the BCM
for setting the status suitable for required operation, input/output signals are
received from the BCM and received data is displayed.
DATA MONITOR Displays BCM input/output data in real time.
ACTIVE TEST Operation of electrical loads can be checked by sending drive signal to them.
SELF-DIAG RESULTS Displays BCM self-diagnosis results.
CAN DIAG SUPPORT MNTR The results of transmit/receive diagnosis of CAN communication can be read.
ECU PART NUMBER BCM part number can be read.
CONFIGURATION Performs BCM configuration read/write functions.
BBIA0369E
BCIA0029E
BCIA0030E
Page 758 of 3371
BCM (BODY CONTROL MODULE)
BCS-13
C
D
E
F
G
H
I
J
L
MA
B
BCS
Revision: August 20072004 QX56
Display Item List
CAN Communication Inspection Using CONSULT-II (Self-Diagnosis)EKS007GI
1. SELF-DIAGNOSTIC RESULT CHECK
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
1. Connect to CONSULT-II, and select “BCM” on “SELECT SYSTEM” screen.
2. Select “BCM” on “SELECT TEST ITEM” screen, and select “SELF-DIAG RESULTS”.
3. Check display content in self-diagnostic results.
Contents displayed
No malfunction>>Inspection End
Malfunction in CAN communication system>>After printing the monitor items, go to LAN-5, "
CAN COMMU-
NICATION" .
ConfigurationEKS007GJ
DESCRIPTION
CONFIGURATION has two functions as follows:
READ CONFIGURATION is the function to confirm vehicle configuration of current BCM.
WRITE CONFIGURATION is the function to write vehicle configuration on BCM.
CAUTION:
When replacing BCM, you must perform WRITE CONFIGURATION with CONSULT-II.
Complete the procedure of WRITE CONFIGURATION in order.
If you set incorrect WRITE CONFIGURATION, incidents will occur.
Configuration is different for each vehicle model. Confirm configuration of each vehicle model.
READ CONFIGURATION PROCEDURE
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
1. With ignition switch OFF, connect CONSULT-II and CONSULT-II
CONVERTER to data link connector and turn ignition switch ON.
Item Description
RESET SETTING VALUE Return a value set with WORK SUPPORT of each system to a default value in factory shipment.
CONSULT-II display code Diagnosis item
U1000INITIAL DIAG
TRANSMIT DIAG
ECM
IPDM E/R
METER/M&A
I-KEY
BBIA0369E
Page 761 of 3371
BCS-16
BCM (BODY CONTROL MODULE)
Revision: August 20072004 QX56
WRITE CONFIGURATION PROCEDURE
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
1. With ignition switch OFF, connect CONSULT-II and CONSULT-II
CONVERTER to data link connector and turn ignition switch ON.
2. Touch “START (NISSAN BASED VHCL)”.
3. Touch “BCM” on “SELECT SYSTEM” screen.
If "BCM" is not indicated, go to GI-39, "
CONSULT-II Data Link
Connector (DLC) Circuit" .
4. Touch “BCM” on “SELECT TEST ITEM” screen.
BBIA0369E
BCIA0029E
BCIA0030E
LKIA0183E
Page 766 of 3371
BL-1
BODY, LOCK & SECURITY SYSTEM
I BODY
CONTENTS
C
D
E
F
G
H
J
K
L
M
SECTION BL
A
B
BL
Revision: August 20072004 QX56 PRECAUTIONS .......................................................... 4
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 4
Precautions for work ................................................ 4
Wiring Diagnosis and Trouble Diagnosis ................. 4
PREPARATION ........................................................... 5
Special service tool .................................................. 5
Commercial Service Tool ......................................... 5
SQUEAK AND RATTLE TROUBLE DIAGNOSIS ...... 6
Work Flow ................................................................ 6
CUSTOMER INTERVIEW ..................................... 6
DUPLICATE THE NOISE AND TEST DRIVE ....... 7
CHECK RELATED SERVICE BULLETINS ........... 7
LOCATE THE NOISE AND IDENTIFY THE
ROOT CAUSE ...................................................... 7
REPAIR THE CAUSE ........................................... 7
CONFIRM THE REPAIR ....................................... 8
Generic Squeak and Rattle Troubleshooting ........... 8
INSTRUMENT PANEL .......................................... 8
CENTER CONSOLE ............................................. 8
DOORS ................................................................. 8
BACK DOOR ......................................................... 9
SUNROOF/HEADLINER ....................................... 9
OVERHEAD CONSOLE (FRONT AND REAR) ..... 9
SEATS ................................................................... 9
UNDERHOOD ....................................................... 9
Diagnostic Worksheet ............................................ 10
HOOD ....................................................................... 12
Fitting Adjustment .................................................. 12
CLEARANCE AND SURFACE HEIGHT
ADJUSTMENT .................................................... 13
HOOD LOCK ADJUSTMENT ............................. 13
Removal and Installation of Hood Assembly .......... 13
Removal and Installation of Hood Lock Control ..... 14
REMOVAL ........................................................... 14
INSTALLATION ................................................... 15
Hood Lock Control Inspection ................................ 15
POWER DOOR LOCK SYSTEM .............................. 16
Component Parts and Harness Connector Location ... 16System Description ................................................. 17
OUTLINE ............................................................. 18
Schematic ............................................................... 19
Wiring Diagram — D/LOCK — ............................... 20
Terminals and Reference Value for BCM ............... 25
Work Flow ............................................................... 25
CONSULT–II Function (BCM) ................................ 26
CONSULT–II INSPECTION PROCEDURE ......... 26
DATA MONITOR ................................................. 27
ACTIVE TEST ..................................................... 28
Trouble Diagnoses Symptom Chart ....................... 29
BCM Power Supply and Ground Circuit Check ...... 29
Door Switch Check ................................................. 31
Key Switch (Insert) Check ...................................... 33
Door Lock/Unlock Switch Check ............................ 34
Glass Hatch Switch Circuit Inspection .................... 36
Front Door Lock Assembly LH (Actuator) Check .... 37
Front Door Lock Actuator RH Check ...................... 39
Rear Door Lock Actuator RH/LH Check ................. 40
Glass Hatch Lock Actuator Check .......................... 41
Front Door Lock Assembly LH (Key Cylinder Switch)
Check ..................................................................... 42
REMOTE KEYLESS ENTRY SYSTEM ..................... 44
Component Parts and Harness Connector Location ... 44
System Description ................................................. 45
INPUTS ............................................................... 45
OPERATING PROCEDURE ................................ 46
CAN Communication System Description .............. 48
Schematic ............................................................... 49
Wiring Diagram — KEYLES — ............................... 50
............................................................................ 50
............................................................................ 51
............................................................................ 52
Terminals and Reference Value for BCM ............... 53
Terminals and Reference Value for IPDM E/R ....... 54
CONSULT-II Function (BCM) ................................. 55
CONSULT-II Inspection Procedure ......................... 55
“MULTI REMOTE ENT” ....................................... 55
CONSULT-II Application Items ............................... 56
“MULTI REMOTE ENT” ....................................... 56
Page 767 of 3371
BL-2Revision: August 20072004 QX56 Trouble Diagnosis Procedure ................................. 59
BCM Power Supply and Ground Circuit Check ...... 59
Trouble Diagnoses .................................................. 60
SYMPTOM CHART ............................................. 60
Key Switch (Insert) Check ...................................... 62
Door Switch Check ................................................. 63
Keyfob Battery and Function Check ....................... 65
Remote Keyless Entry Receiver System Check ..... 66
ACC Power Check .................................................. 68
IPDM E/R Operation Check .................................... 68
Check Hazard Function .......................................... 70
Check Horn Function .............................................. 70
Check Headlamp Function ..................................... 70
Check Map Lamp Illumination Function ................. 70
ID Code Entry Procedure ....................................... 71
KEYFOB ID SET UP WITH CONSULT-II ............ 71
KEYFOB ID SET UP WITHOUT CONSULT-II ..... 73
Keyfob Battery Replacement .................................. 74
VEHICLE SECURITY (THEFT WARNING) SYSTEM ... 75
Component Parts and Harness Connector Location ... 75
System Description ................................................. 76
DESCRIPTION .................................................... 76
POWER SUPPLY AND GROUND CIRCUIT ....... 76
INITIAL CONDITION TO ACTIVATE THE SYS-
TEM ..................................................................... 77
VEHICLE SECURITY SYSTEM ALARM OPER-
ATION .................................................................. 78
VEHICLE SECURITY SYSTEM DEACTIVATION ... 78
PANIC ALARM OPERATION ............................... 78
CAN Communication System Description .............. 78
Schematic ............................................................... 79
Wiring Diagram — VEHSEC — .............................. 80
............................................................................. 80
............................................................................. 81
............................................................................. 82
............................................................................. 83
............................................................................. 84
Terminals and Reference Value for BCM ................ 85
Terminals and Reference Value for IPDM E/R ........ 86
CONSULT-II Function (BCM) .................................. 86
CONSULT-II INSPECTION PROCEDURE .......... 87
CONSULT-II APPLICATION ITEM ....................... 89
Trouble Diagnosis ................................................... 90
WORK FLOW ...................................................... 90
Preliminary Check .................................................. 91
Symptom Chart ....................................................... 92
Door Switch Check ................................................. 93
Hood Switch Check ................................................ 95
Combination Meter (Security Indicator Lamp)
Check ..................................................................... 97
Front Door Lock Assembly LH (Key Cylinder Switch)
Check ..................................................................... 98
Vehicle Security Horn Alarm Check ......................100
Vehicle Security Headlamp Alarm Check .............100
Door Lock/Unlock Switch Check ..........................100
AUTOMATIC BACK DOOR SYSTEM .....................101
Component Parts and Harness Connector Location .101
System Description ...............................................102
OPERATION DESCRIPTION ............................102Schematic ............................................................. 107
Wiring Diagram — B/CLOS — .............................. 108
Terminals and Reference Value for Back Door Con-
trol Unit ..................................................................113
Terminals and Reference Value for BCM ..............114
Trouble Diagnosis Procedure ................................115
Self-Diagnosis Procedures ...................................115
INPUT SIGNAL CHECK MODE .........................115
OPERATING CHECK MODE .............................115
Diagnosis Chart ....................................................116
Back Door Power Supply and Ground Circuit
Inspection ..............................................................117
Power Liftgate Switch System Inspection .............118
GLASS HATCH AJAR SWITCH CHECK ...........119
Back Door Close (Close) Switch System Inspection . 120
Back Door Close (Cancel) Switch System Inspec-
tion ........................................................................ 121
Pinch Strip System Inspection .............................. 122
Back Door Warning Chime System Inspection ..... 123
Half-Latch Switch System Inspection .................... 124
Open Switch System Inspection ........................... 125
Close Switch System Inspection ........................... 126
Back Door Handle Switch System Inspection ....... 127
Cinch Latch Motor System Inspection .................. 128
DOOR ...................................................................... 129
Fitting Adjustment ................................................. 129
FRONT DOOR ................................................... 129
REAR DOOR ..................................................... 129
STRIKER ADJUSTMENT .................................. 129
Removal and Installation ....................................... 130
FRONT DOOR ................................................... 130
REAR DOOR ..................................................... 130
BACK DOOR ..................................................... 131
FRONT DOOR LOCK .............................................. 132
Component Structure ............................................ 132
Removal and Installation ....................................... 132
REMOVAL .......................................................... 132
INSTALLATION .................................................. 134
Disassembly and Assembly .................................. 134
DOOR KEY CYLINDER ASSEMBLY ................. 134
REAR DOOR LOCK ................................................ 135
Component Structure ............................................ 135
Removal and Installation ....................................... 135
REMOVAL .......................................................... 135
INSTALLATION .................................................. 135
BACK DOOR LOCK ................................................ 136
Power Back Door Opener ..................................... 136
REMOVAL ......................................................... 136
INSTALLATION ................................................. 136
Door Lock Assembly ............................................. 137
REMOVAL ......................................................... 137
INSTALLATION ................................................. 137
IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-
NATS) ...................................................................... 138
Component Parts and Harness Connector Location . 138
System Description ............................................... 139
System Composition ............................................. 139
ECM Re-communicating Function ........................ 140
Wiring Diagram — NATS — .................................. 141
Page 791 of 3371
BL-26
POWER DOOR LOCK SYSTEM
Revision: August 20072004 QX56
CONSULT–II Function (BCM)EIS002RE
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
CONSULT–II INSPECTION PROCEDURE
CONSULT-II can display each diagnostic item using the following diagnostic test modes: data monitor, active
test, and CAN diagnostic support monitor through data reception and command transmission via the BCM
communication line.
"DOOR LOCK"
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
1. Turn ignition switch OFF.
2. Connect CONSULT-II and CONSULT-II CONVERTER to the
data link connector.
3. Turn ignition switch ON.
4. Touch “START (NISSAN BASED VHCL)”.
BCM
diagnostic test itemDiagnostic mode Description
Inspection by partWORK SUPPORTSupports inspections and adjustments. Commands are transmitted to the
BCM for setting the status suitable for required operation, input/output sig-
nals are received from the BCM and received date is displayed.
DATA MONITOR Displays BCM input/output data in real time.
ACTIVE TESTOperation of electrical loads can be checked by sending drive signal to
them.
SELF-DIAG RESULTS Displays BCM self-diagnosis results.
CAN DIAG SUPPORT MNTRThe result of transmit/receive diagnosis of CAN communication can be
read.
ECU PART NUMBER BCM part number can be read.
CONFIGURATION Performs BCM configuration read/write functions.
BBIA0369E
BCIA0029E
Page 811 of 3371
BL-46
REMOTE KEYLESS ENTRY SYSTEM
Revision: August 20072004 QX56
keyless power window down (open)
auto door lock operation
OPERATING PROCEDURE
When the keyfob is operated, the signal from the keyfob is sent and the remote keyless entry receiver
receives the signal and sends it to the BCM. The BCM only locks/unlocks the doors if the ID number
matches (remote control entry functions).
Using the keyfob, the transmitter sends radio waves to the remote keyless entry receiver, which then
sends the received waves to the BCM. Only if the ID number matches does the BCM lock/unlock the
doors (remote control door function).
Unless the key is inserted into the ignition key cylinder or one of the doors is opened within 1 minute after
the UNLOCK switch on the keyfob is pressed, all the doors are automatically locked (auto lock function).
When a door is locked or unlocked, the vehicle turn signal lamps flash and the horn sounds to verify oper-
ation (active check function).
When the key is in the ignition key cylinder (when the key switch is ON) and one of the doors is open, the
door lock function does not work even when the door lock is operated with the keyfob.
Keyfob ID set up is available.
If a keyfob is lost, a new keyfob can be set up. A maximum of 5 IDs can be set up simultaneously.
Remote Control Entry Functions
Operation Description
When a button on the keyfob is operated, the signal is sent from the keyfob and received by the remote
keyless entry receiver.
The received signal is sent to the BCM and compared with the registered ID number.
If the ID number matches, the BCM sends the lock/unlock signal to each door lock actuator.
When the door lock actuators receive this signal, each operates to lock/unlock its door.
BCM locks all doors with input of LOCK signal from keyfob.
When an UNLOCK signal is sent from keyfob once, driver's door will be unlocked.
Then, if an UNLOCK signal is sent from keyfob again within 5 seconds, all other doors will be unlocked.
Remote control entry operation conditions
Auto Lock Function
Operation Description
Unless the key is inserted into the ignition key cylinder, one of the doors is opened, or the keyfob is oper-
ated within 1 minute after a door lock is unlocked by keyfob operation, all the doors are automatically
locked.
The 1 minute timer count is executed by the BCM and after 1 minute, the BCM sends the lock signal to all
doors.
Lock operations are the same as for the remote control entry function.
Remote Control Automatic Back Door Function
Switching from all closed to all open
When a button on the keyfob is operated, the signal is sent from the keyfob and received by the remote
keyless entry receiver.
The received signal is sent to the BCM and compared with the registered ID number.
If the ID number matches, the BCM uses power window serial link communication to send the back door
open signal to the back door control unit.
When the back door control unit receives the back door open signal for 0.5 seconds, if the remote control
automatic back door operation enable conditions are met, the warning chime is sounded and the back
door unlock signal is sent to the back door latch using communication.
Keyfob operation Operation condition
Door lock operation (locking)
With key removed (key switch: OFF)
Closing all doors (door switch: OFF)
Door lock operation (unlocking) With key removed (key switch: OFF)
Page 812 of 3371
REMOTE KEYLESS ENTRY SYSTEM
BL-47
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: August 20072004 QX56
When the back door latch receives the back door unlock signal, it operates the release actuator and
releases to back door latch.
The back door control unit operates the back door motor to open the back door. (At this time, speed con-
trol, input reverse, and overload reverse control are executed.)
When the back door is opened to the fully open position, the full-open position is detected with the rotation
sensor, the back door motor is stopped.
The door held by the back door stays at the full open position.
Full open → full closed operation
When a button of the keyfob is operated, the signal is sent from the keyfob and received by the remote
keyless entry receiver.
The received signal is sent to the BCM and compared with the registered ID number.
If the ID number matches, the BCM uses power window serial link communication to send the back door
close request signal to the back door control unit.
When the back door control unit receives the back door close request signal for 0.5 seconds, if the remote
control automatic back door operation enable conditions are met, the warning chime is sounded and the
back door motor begins closing the back door.
The back door control unit operates the magnetic clutch and the back door motor to close the back door.
(At this time, the back door control unit executes speed control, input reverse, and overload reverse con-
trol.)
When the back door comes to the half-latch state, the back door latch detects the half-latch state through
half-latch switch operation. The back door latch latches the back door.
For the automatic back door system operation enable conditions, refer to BL-101, "
AUTOMATIC BACK DOOR
SYSTEM" .
Active Check Function
Operation Description
When a door is locked or unlocked by keyfob operation, the vehicle turn signals flash and the horn sounds to
verify operation.
When a button on the keyfob is operated, the signal is sent from the remote controller and received by the
keyless remote entry receiver.
The received signal is sent to the BCM and compared with the registered ID number.
If the ID number matches, the BCM sends the turn signal flashing and horn signal to the IPDM E/R.
The IPDM E/R flashes the turn signal lamps and sounds the horn for each keyfob operation.
Operating function of hazard and horn reminder
Hazard and Horn Reminder
BCM output to IPDM E/R for horn reminder signal as DATA LINE (CAN-H and CAN-L).
The hazard and horn reminder has C mode (horn chirp mode) and S mode (non-horn chirp mode).
How to change hazard and horn reminder mode
With CONSULT-II
Hazard and horn reminder can be changed using “WORK SUPPORT” mode in “MULTI ANSWER BACK SET".
Without CONSULT-II
Refer to Owner's Manual for instructions.
Interior Lamp Operation
When the following input signals are both supplied:
all door switches are in the OFF position (when all the doors are closed);
interior lamp switch is in DOOR position.
C mode S mode
Keyfob operation Lock Unlock Lock Unlock
Hazard warning lamp
flashTwic e O nc e Twic e —
Horn sound Once — — —
Page 813 of 3371
BL-48
REMOTE KEYLESS ENTRY SYSTEM
Revision: August 20072004 QX56
Remote keyless entry system turns on interior lamp and ignition keyhole illumination (for 30 seconds) with
input of UNLOCK signal from keyfob.
For detailed description, refer to LT- 1 3 1 , "
ROOM LAMP TIMER OPERATION" .
Panic Alarm Operation
When key switch is OFF (ignition key is not inserted in key cylinder), remote keyless entry system turns on and
off horn and headlamp intermittently with input of PANIC ALARM signal from keyfob.
The alarm automatically turns off after 25 seconds or when BCM receives any signal from keyfob.
Keyless Power Window Down (Open) Operation
When keyfob unlock switch is turned ON with ignition switch OFF, and the switch is detected to be on continu-
ously for 3 seconds, the driver's door and passenger's door power windows are simultaneously opened.
Power window is operated to open and the operation continues as long as the keyfob unlock switch is
pressed.
CAN Communication System DescriptionEIS002RQ
Refer to LAN-5, "CAN COMMUNICATION" .
