VACUUM PUMP
The oil contained inside the vacuum pump is not compatible with the
specified oil for HFC-134a (R-134a) A/C systems. The vent side of
the vacuum pump is exposed to atmospheric pressure so the vac-
uum pump oil may migrate out of the pump into the service hose.
This is possible when the pump is switched off after evacuation (vac-
uuming) and hose is connected to it.
To prevent this migration, use a manual valve situated near the
hose-to-pump connection, as follows.

Usually vacuum pumps have a manual isolator valve as part of
the pump. Close this valve to isolate the service hose from the
pump.

For pumps without an isolator, use a hose equipped with a man-
ual shut-off valve near the pump end. Close the valve to isolate
the hose from the pump.

If the hose has an automatic shut off valve, disconnect the hose
from the pump: as long as the hose is connected, the valve is
open and lubricating oil may migrate.
Some one-way valves open when vacuum is applied and close
under a no vacuum condition. Such valves may restrict the pump's
ability to pull a deep vacuum and are not recommended.
MANIFOLD GAUGE SET
Be certain that the gauge face indicates HFC-134a (R-134a or
134a). Make sure the gauge set has 1/2 ″-16 ACME threaded con-
nections for service hoses. Confirm the set has been used only with
refrigerant HFC-134a (R-134a) along with specified oil.
SERVICE HOSES
Be certain that the service hoses display the markings described
(colored hose with black stripe). All hoses must include positive shut-
off devices (either manual or automatic) near the end of the hoses
opposite the manifold gauge.
RHA270D
SHA533D
RHA272D

OIL
ATC-23
C
D E
F
G H
I
K L
M A
B
AT C
Revision: November 2009 2006 QX56
Oil Adjustment Procedure for Compressor Replacement
1. Before connecting recovery/recycling equipment to vehicle, check recovery/recycling equipment gauges.
No refrigerant pressure should be displayed. If NG, recover refrigerant from equipment lines.
2. Connect recovery/recycling equipment to vehicle. Confirm refrigerant purity in supply tank using recovery/ recycling equipment and refrigerant identifier. If NG, refer to AT C - 5 , "
Contaminated Refrigerant" .
3. Confirm refrigerant purity in vehicle A/C system using recovery/recycling equipment and refrigerant identi- fier. If NG, refer to AT C - 5 , "
Contaminated Refrigerant" .
4. Discharge refrigerant into the refrigerant recovery/recycling equipment. Measure oil discharged into the recovery/recycling equipment.
5. Drain the oil from the “old” (removed) compressor into a graduated container and recover the amount of
oil drained.
6. Drain the oil from the “new ” compressor into a separate, clean container.
7. Measure an amount of new oil installed equal to amount drained from “old” compressor. Add this oil to
“new ” compressor through the suction port opening.
8. Measure an amount of new oil equal to the amount recovered during discharging. Add this oil to “new”
compressor through the suction port opening.
9. If the liquid tank also needs to be replaced, add an additional 5 m (0.2 US fl oz, 0.2 Imp fl oz) of oil at this time.
1. New compressor 2. Old compressor3. Recovery/recycling equipment
4. Measuring cup X 5. Measuring cup Y6. New oil
A. Drain oil from the new compressor into clean container B. Record amount of oil recovered C.
Add an additional 5 m (0.2 US fl oz,
0.2 Imp fl oz) of new oil when replac-
ing liquid tank
D. Install new oil equal to recorded amounts in measuring cups X plus Y
WJIA1716E

ATC-28
AIR CONDITIONER CONTROL
Revision: November 20092006 QX56
DISPLAY SCREEN
Displays the operational status of the system.
AUTO SWITCH

The compressor, intake door, air mix doors, outlet doors and blower speed are automatically controlled so
that the in-vehicle temperature will reach, and be maintained at the set temperature selected by the oper-
ator.

When pressing AUTO switch, air inlet, air outlet, blower speed, and discharge air temperature are auto-
matically controlled.
TEMPERATURE CONTROL DIAL (TEMPERATURE CONTROL) (DRIVER SIDE)
Increases or decreases the set temperature.
TEMPERATURE CONTROL DIAL (TEMPERATURE CONTROL) (PASSENGER SIDE)
Increases or decreases the set temperature.
TEMPERATURE CONTROL DIAL (TEMPERATURE AND MODE CONTROL) (REAR)
Increases or decreases the set temperature. The mode also changes from foot at full hot setting, to foot/vent
mid-range (warm) setting, and then to panel on full cold setting.
RECIRCULATION () SWITCH

When REC switch is ON, REC switch indicator turns ON, and air inlet is set to REC.

When REC switch is turned OFF, or when compressor is turned from ON to OFF, REC switch is automati-
cally turned OFF. REC mode can be re-entered by pressing REC switch again.

REC switch is not operated when DEF switch is turned ON, at the D/F position or in floor position.
DEFROSTER () SWITCH
Positions the air outlet doors to the defrost position. Also positions the intake doors to the outside air position.
REAR WINDOW DEFOGGER SWITCH
When switch is ON, rear window and door mirrors are defogged.
OFF SWITCH
The compressor and blower are OFF, the intake doors are set to the outside air position, and the air outlet
doors are set to the foot (75% foot and 25% defrost) position.
A/C SWITCH
The compressor is ON or OFF.
(Pressing the A/C switch when the AUTO switch is ON will turn off the A/C switch and compressor.)
MODE SWITCH (FRONT)
Controls the air discharge outlets.
FRONT BLOWER CONTROL DIAL
Manually control the blower speed. Seven speeds are available for manual control (as shown on the display
screen).

ATC-34
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
TROUBLE DIAGNOSISPFP:00004
CONSULT-II Function (HVAC)EJS003XD
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
CONSULT-II BASIC OPERATION
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
1. With the ignition switch OFF, connect CONSULT-II and “CON-
SULT-II CONVERTER ” to the data link connector, and turn the
ignition switch ON.
2. Touch “START (NISSAN BASED VHCL) ”.
3. Touch “HVAC” on “SELECT SYSTEM ” screen. If “HVAC” is not
indicated, go to GI-40, "
CONSULT-II Data Link Connector (DLC)
Circuit" .
Diagnostic mode Description
SELF-DIAG RESULTS Displays front air control self-diagnosis results. DATA MONITOR Displays front air control input/output data in real time.
CAN DIAG SUPPORT MNTR The result of transmit/receive diagnosis of CAN communication can be read. ECU PART NUMBER Front air control part number can be read.
BBIA0369E
BCIA0029E
BCIA0030E

TROUBLE DIAGNOSISATC-35
C
DE
F
G H
I
K L
M A
B
AT C
Revision: November 2009 2006 QX56
SELF-DIAGNOSIS
Operation Procedure
1. Touch “SELF-DIAG RESULTS ” on “SELECT DIAG MODE”
screen to view all set DTC's.
Display Item List
DATA MONITOR
Operation Procedure
1. Touch “DATA MONITOR ” on “SELECT DIAG MODE ” screen.
2. Touch either “MAIN SIGNALS” or “SELECTION FROM MENU ” on “DATA MONITOR” screen.
3. When “SELECTION FROM MENU ” is selected, touch items to be monitored. When “MAIN SIGNALS” is
selected, all the items will be monitored.
4. Touch “START”.
5. Touch “RECORD” while monitoring, then the status of the monitored item can be recorded. To stop
recording, touch “STOP”.
BCIA0031E
DTC Description
Reference page
B2573 Battery voltage out of range SC-4, "
BATTERY"
B2578 In-vehicle sensor circuit out of range (low)
ATC-137, "In-vehicle Sensor Circuit"B2579 In-vehicle sensor circuit out of range (high)
B257B Ambient sensor circuit short ATC-134, "
Ambient Sensor Circuit"B257C Ambient sensor circuit open
B257F Optical sensor (Driver) circuit open or short ATC-140, "
Optical Sensor Circuit"B2580 Optical sensor (Passenger) circuit open or short
B2581 Intake sensor circuit shortATC-142, "
Intake Sensor Circuit"B2582 Intake sensor circuit open
U1000 CAN bus fault LAN-26, "
CAN COMMUNICATION"
B2587 Stuck buttonATC-144, "FRONT AIR CONTROL"
BCIA0031E
MAIN SIGNALSMonitors all the items.
SELECTION FROM MENU Selects and monitors the individual item selected.

ATC-36
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
Display Item List
*: DENT is displayed when MODE switch is between selections.
Monitor itemValue Contents
BATT VIA CAN "V" Displays battery voltage signal.
IGN VIA CAN "ON/OFF" Displays ignition switch signal.
DVR SUNLD SEN "w/m2" Displays optical sensor (driver) signal.
PAS SUNLD SEN "w/m2" Displays optical sensor (passenger) signal.
AMB TEMP SEN "° C/ °F" Displays ambient sensor 1 signal.
EVAP TEMP SEN "° C/ °F" Displays intake sensor signal.
INCAR TMP SEN "° C/ °F" Displays in-vehicle sensor signal.
RR TEMPSET FR "V" Displays air mix door (front) set point signal.
RR TEMPSET RR "V" Displays air mix door (rear) set point signal.
MODE FDBCK "V" Displays mode door motor feedback signal.
DVR MIX FDBCK "V" Displays air mix door motor (driver) feedback signal.
PAS MIX FDBCK "V" Displays air mix door motor (passenger) feedback signal.
RR FDBCK "V" Displays air mix door motor (rear) feedback signal.
DEF FDBCK "V" Displays defroster door motor feedback signal.
RECIRC "ON/OFF" Displays recirculation switch signal.
DEFROST "ON/OFF" Displays defroster switch signal.
AUTO "ON/OFF" Displays AUTO switch signal.
A/C "ON/OFF" Displays A/C switch signal.
MODE "ON/OFF" Displays MODE switch signal.
L TEMP UP "ON/OFF" Displays driver side temperature control dial (temp increase) signal.
L TEMP DOWN "ON/OFF" Displays driver side temperature control dial (temp decrease) signal.
R TEMP UP "ON/OFF" Displays rear temperature control dial [front (temp increase)] signal.
R TEMP DOWN "ON/OFF" Displays Rear temperature control dial [front (temp decrease)] signal.
RR DEFOG "ON/OFF" Displays rear defroster request signal.
FANUP "ON/OFF" Displays front blower motor (blower speed increase) signal.
FANDOWN "ON/OFF" Displays front blower motor (blower speed decrease) signal.
MODE SELECT " [ PNL ]"
" [ MIX ]"
" [ FLR ]"
" [ DEFR ]" " [ MAX ]"
" [ DENT ]" Displays mode door motor position.

TROUBLE DIAGNOSISATC-37
C
DE
F
G H
I
K L
M A
B
AT C
Revision: November 2009 2006 QX56
CONSULT-II Function (BCM)EJS003XE
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
CONSULT-II BASIC OPERATION
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
1. With the ignition switch OFF, connect CONSULT-II and “CON-
SULT-II CONVERTER ” to the data link connector, and turn the
ignition switch ON.
2. Touch “START (NISSAN BASED VHCL) ”.
3. Touch “BCM” on “SELECT SYSTEM ” screen. If “BCM” is not
indicated, go to GI-40, "
CONSULT-II Data Link Connector (DLC)
Circuit" .
BCM diagnostic
test item Diagnostic mode
Description
Inspection by part WORK SUPPORT
Supports inspections and adjustments. Commands are transmitted to the BCM
for setting the status suitable for required operation, input/output signals are
received from the BCM and received data is displayed.
DATA MONITOR Displays BCM input/output data in real time. ACTIVE TEST Operation of electrical loads can be checked by sending drive signal to them.
SELF-DIAG RESULTS Displays BCM self-diagnosis results.
CAN DIAG SUPPORT MNTR The result of transmit/receive diagnosis of CAN communication can be read. ECU PART NUMBER BCM part number can be read.CONFIGURATION Performs BCM configuration read/write functions.
BBIA0369E
BCIA0029E
BCIA0030E

ATC-38
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
DATA MONITOR
Operation Procedure
1. Touch “AIR CONDITIONER” on “SELECT TEST ITEM” screen.
2. Touch “DATA MONITOR ” on “SELECT DIAG MODE ” screen.
3. Touch either “ALL SIGNALS ” or “SELECTION FROM MENU” on
“DATA MONITOR ” screen.
4. When “SELECTION FROM MENU” is selected, touch items to
be monitored. When "ALL SIGNALS ” is selected, all the items
will be monitored.
5. Touch “START”.
6. Touch “RECORD” while monitoring, then the status of the moni-
tored item can be recorded. To stop recording, touch “STOP”.
Display Item List
WJIA0468E
BCIA0031E
ALL SIGNALS Monitors all the items.
SELECTION FROM MENU Selects and monitors the individual item selected.
WJIA0469E
Monitor item name “ operation or
unit ” Contents
IGN ON SW “ON/OFF ”Displays “IGN Position (ON)/OFF, ACC Position (OFF) ” status as judged from ignition switch signal.
COMP ON SIG “ON/OFF ”Displays “COMP (ON)/COMP (OFF) ” status as judged from air conditioner switch signal.
FAN ON SIG “ON/OFF ”Displays “FAN (ON)/FAN (OFF) ” status as judged from blower motor switch signal.

TROUBLE DIAGNOSISATC-39
C
DE
F
G H
I
K L
M A
B
AT C
Revision: November 2009 2006 QX56
How to Perform Trouble Diagnosis for Quick and Accurate RepairEJS003XF
WORK FLOW
SYMPTOM TABLE
*1AT C - 5 8 , "Operational Check (Front)"
or ATC-60, "
Operational Check
(Rear)" .
SHA900E
Symptom Reference Page
A/C system does not come on. Go to Trouble Diagnosis Procedure for A/C System. AT C - 6 1
A/C system display is malfunctioning. Go to Navigation System. AV- 8 4
A/C system cannot be controlled.Go to Self-diagnosis Function. AT C - 5 6
Air outlet does not change.
Go to Trouble Diagnosis Procedure for Mode Door Motor. AT C - 6 4
Mode door motor is malfunctioning.
Discharge air temperature does not change.
Go to Trouble Diagnosis Procedure for Air Mix Door Motor. AT C - 7 0
Air mix door motor is malfunctioning.
Intake door does not change.
Go to Trouble Diagnosis Procedure for Intake Door Motor. AT C - 8 3
Intake door motor is malfunctioning.
Defroster door motor is malfunctioning. Go to Trouble Diagnosis Procedure for Defroster Door Motor. AT C - 8 7
Front blower motor operation is malfunction-
ing.Go to Trouble Diagnosis Procedure for Front Blower Motor.
AT C - 9 3
Rear blower motor operation is malfunction-
ing.Go to Trouble Diagnosis Procedure for Rear Blower Motor.
AT C - 1 0 1
Rear discharge air temperature and/or air
outlet does not change.Go to Trouble Diagnosis Procedure for Rear Air Control circuit.
AT C - 11 2
Magnet clutch does not engage.Go to Trouble Diagnosis Procedure for Magnet Clutch. AT C - 11 5
Insufficient coolingGo to Trouble Diagnosis Procedure for Insufficient Cooling. AT C - 1 2 1
Insufficient heatingGo to Trouble Diagnosis Procedure for Insufficient Heating. AT C - 1 2 8
NoiseGo to Trouble Diagnosis Procedure for Noise. AT C - 1 2 9
Self-diagnosis cannot be performed. Go to Trouble Diagnosis Procedure for Self-diagnosis. AT C - 1 3 0
Memory function does not operate.Go to Trouble Diagnosis Procedure for Memory Function. AT C - 1 3 1

ATC-56
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
A/C System Self-diagnosis FunctionEJS003XK
DESCRIPTION
The self-diagnostic system diagnoses sensors, door motors, blower motor, etc. Refer to applicable sections
(items) for details. Fault codes (if any are present) will be displayed in the ambient temperature display area.
Refer to AT C - 5 7 , "
SELF-DIAGNOSIS CODE CHART" .
WJIA1913E
