TROUBLE DIAGNOSISAT-61
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
Symptom ChartECS00CEN

The diagnostics item numbers show the sequence for inspection. Inspect in order from item 1.

Overhaul and inspect inside the A/T only if A/T fluid condition is NG. Refer to AT- 5 1 , "A/T FLUID
CHECK" .
No. Items Symptom Condition Diagnostic ItemReference
page
1
Shift
Shock Large shock. (
“N ” → “
D ” position)
Refer to AT-182,
"Large Shock (“N” to
“D” Position)" . ON vehicle 1. Engine idle speed
EC-76
2. Engine speed signalAT- 11 6
3. Accelerator pedal position sensorAT-124
4. Control cable adjustmentAT-227
5. ATF temperature sensorAT-127
6. ATF pressure switch 1 and front brake solenoid valveAT-159,
AT-143
7. CAN communication line AT- 9 6
8. Fluid level and stateAT- 5 1
9. Line pressure testAT- 5 2
10. Control valve with TCMAT-230
OFF vehicle11. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT- 1 7 , AT- 1 8
.) AT-264
2Shock is too large
when changing D1 →

D
2 . ON vehicle1. Accelerator pedal position sensor
AT-124
2. Control cable adjustmentAT-227
3. ATF pressure switch 5 and direct clutch solenoid valveAT-163,
AT-147
4. CAN communication line AT- 9 6
5. Engine speed signalAT- 11 6
6. Turbine revolution sensorAT-109
7. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT-132
8. Fluid level and state AT- 5 1
9. Control valve with TCMAT-230
OFF vehicle 10. Direct clutch AT-298
3Shock is too large
when changing D2 →

D
3 . ON vehicle1. Accelerator pedal position sensor
AT-124
2. Control cable adjustmentAT-227
3. ATF pressure switch 6, high and low reverse clutch sole-
noid valveAT-165,
AT-151
4. CAN communication line AT- 9 6
5. Engine speed signalAT- 11 6
6. Turbine revolution sensorAT-109
7. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT-132
8. Fluid level and state AT- 5 1
9. Control valve with TCMAT-230
OFF vehicle 10. High and low reverse clutch AT-296

AT-62
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
4
Shift
Shock Shock is too large
when changing D3
→
D
4 . ON vehicle1. Accelerator pedal position sensor
AT- 1 2 4
2. Control cable adjustmentAT- 2 2 7
3. ATF pressure switch 3 and input clutch solenoid valveAT- 1 6 1,
AT- 1 3 9
4. CAN communication line AT- 9 6
5. Engine speed signalAT- 11 6
6. Turbine revolution sensorAT- 1 0 9
7. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT- 1 3 2
8. Fluid level and state AT- 5 1
9. Control valve with TCMAT- 2 3 0
OFF vehicle 10. Input clutch AT- 2 8 6
5Shock is too large
when changing D4
→
D
5 . ON vehicle1. Accelerator pedal position sensor
AT- 1 2 4
2. Control cable adjustmentAT- 2 2 7
3. ATF pressure switch 1 and front brake solenoid valveAT- 1 5 9,
AT- 1 4 3

4. CAN communication line AT- 9 6
5. Engine speed signalAT- 11 6
6. Turbine revolution sensorAT- 1 0 9
7. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT- 1 3 2
8. Fluid level and state AT- 5 1
9. Control valve with TCMAT- 2 3 0
OFF vehicle10. Front brake (brake band)
AT- 2 5 011. Input clutchAT- 2 8 6
6Shock is too large for
downshift when accel-
erator pedal is
pressed. ON vehicle1. Accelerator pedal position sensor
AT- 1 2 4
2. Control cable adjustmentAT- 2 2 7
3. CAN communication line AT- 9 6
4. Engine speed signalAT- 11 6
5. Turbine revolution sensorAT- 1 0 9
6. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT- 1 3 2
7. Fluid level and state AT- 5 1
8. Control valve with TCMAT- 2 3 0
OFF vehicle9. Front brake (brake band)
AT- 2 5 0
10. Input clutchAT- 2 8 6
11. High and low reverse clutchAT- 2 9 6AT-
296
12. Direct clutch
AT- 2 9 8
No. ItemsSymptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSISAT-63
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
7
Shift
Shock Shock is too large for
upshift when acceler-
ator pedal is released.
ON vehicle1. Accelerator pedal position sensor
AT-124
2. Control cable adjustmentAT-227
3. Engine speed signal AT- 11 6
4. CAN communication line AT- 9 6
5. Turbine revolution sensorAT-109
6. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT-132
7. Fluid level and state AT- 5 1
8. Control valve with TCMAT-230
OFF vehicle9. Front brake (brake band)
AT-25010. Input clutchAT-286
11. High and low reverse clutchAT-296
12. Direct clutchAT-298
8Shock is too large for
lock-up. ON vehicle1. Accelerator pedal position sensor
AT-124
2. Control cable adjustmentAT-227
3. Engine speed signal AT- 11 6
4. CAN communication line AT- 9 6
5. Turbine revolution sensorAT-109
6. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT-132
7. Torque converter clutch solenoid valve AT- 11 8
8. Fluid level and state AT- 5 1
9. Control valve with TCMAT-230
OFF vehicle 10. Torque converter AT-264
9Shock is too large
during engine brake. ON vehicle
1. Accelerator pedal position sensor
AT-124
2. Control cable adjustmentAT-227
3. CAN communication line AT- 9 6
4. Fluid level and stateAT- 5 1
5. Control valve with TCMAT-230
OFF vehicle6. Front brake (brake band)
AT-2507. Input clutchAT-286
8. High and low reverse clutchAT-296
9. Direct clutchAT-298
No. ItemsSymptom Condition Diagnostic ItemReference
page

AT-64
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
10
No Up
Shift Gear does not change
from D
1
→ D2 .
Refer to AT-194, "
A/T
Does Not Shift: D1 →
D2" . ON vehicle1. Fluid level and state
AT- 5 1
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT- 1 3 2
3. ATF pressure switch 5 and direct clutch solenoid valve AT- 1 6 3,
AT- 1 4 7
4. Line pressure test AT- 5 2
5. CAN communication lineAT- 9 6
6. Control valve with TCMAT- 2 3 0
OFF vehicle 7. Direct clutch AT- 2 9 8
11Gear does not change
from D2
→ D3 .
Refer to AT-196, "
A/T
Does Not Shift: D2 →
D3" . ON vehicle1. Fluid level and state
AT- 5 1
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT- 1 3 2
3. ATF pressure switch 6, high and low reverse clutch sole-
noid valve AT- 1 6 5,
AT- 1 5 1
4. Line pressure test AT- 5 2
5. CAN communication lineAT- 9 6
6. Control valve with TCMAT- 2 3 0
OFF vehicle 7. High and low reverse clutch AT- 2 9 6
12Gear does not change
from D
3
→ D4 .
Refer to AT-198, "
A/T
Does Not Shift: D3 →
D4" . ON vehicle1. Fluid level and state
AT- 5 1
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT- 1 3 2
3. ATF pressure switch 3 and input clutch solenoid valve AT- 1 6 1,
AT- 1 3 9
4. ATF pressure switch 1 and front brake solenoid valve AT- 1 5 9,
AT- 1 4 3
5. Line pressure test AT- 5 2
6. CAN communication lineAT- 9 6
7. Control valve with TCMAT- 2 3 0
OFF vehicle 8. Input clutch AT- 2 8 6
13Gear does not change
from D
4
→ D5 .
Refer to AT-201, "
A/T
Does Not Shift: D4 →
D5" . ON vehicle1. Fluid level and state
AT- 5 1
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT- 1 3 2
3. ATF pressure switch 1 and front brake solenoid valve AT- 1 5 9,
AT- 1 4 3
4. ATF pressure switch 5 and direct clutch solenoid valve AT- 1 6 3,
AT- 1 4 7
5. Turbine revolution sensor AT- 1 0 9
6. Line pressure test AT- 5 2
7. CAN communication lineAT- 9 6
8. Control valve with TCMAT- 2 3 0
OFF vehicle9. Front brake (brake band)
AT- 2 6 410. Input clutchAT- 2 8 6
No. ItemsSymptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSISAT-65
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
14
No Down
Shift In “
D” or "4" range,
does not downshift to
4th gear.
Refer to AT-209, "A/T
Does Not Shift: 5th
gear → 4th gear" .ON vehicle 1. Fluid level and state
AT- 5 1
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT-132

3. ATF pressure switch 1 and front brake solenoid valve AT-159
,
AT-143
4. ATF pressure switch 5 and direct clutch solenoid valve AT-163,
AT-147
5. CAN communication line AT- 9 6
6. Line pressure testAT- 5 2
7. Control valve with TCMAT-230
OFF vehicle8. Front brake (brake band)
AT-2649. Input clutchAT-286
15In “
D” or "3" range,
does not downshift to
3rd gear.
Refer to AT-212, "A/T
Does Not Shift: 4th
gear → 3rd gear" . ON vehicle 1. Fluid level and state
AT- 5 1
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT-132
3. ATF pressure switch 3 and input clutch solenoid valve AT-161,
AT-139
4. ATF pressure switch 1 and front brake solenoid valve AT-159,
AT-143
5. CAN communication line AT- 9 6
6. Line pressure testAT- 5 2
7. Control valve with TCMAT-230
OFF vehicle 8. Input clutch AT-286
16In “
D” or "2" range,
does not downshift to
2nd gear.
Refer to AT-213, "A/T
Does Not Shift: 3rd
gear → 2nd gear" .ON vehicle 1. Fluid level and state
AT- 5 1
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT-132

3. ATF pressure switch 6, high and low reverse clutch sole-
noid valve AT-165
,
AT-151
4. CAN communication line AT- 9 6
5. Line pressure testAT- 5 2
6. Control valve with TCMAT-230
OFF vehicle 7. High and low reverse clutch AT-296
17In “
D” or "1" range,
does not downshift to
1st gear.
Refer to AT-215, "A/T
Does Not Shift: 2nd
gear → 1st gear" . ON vehicle 1. Fluid level and state
AT- 5 1
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT-132
3. ATF pressure switch 5 and direct clutch solenoid valve AT-163,
AT-147
4. CAN communication line AT- 9 6
5. Line pressure testAT- 5 2
6. Control valve with TCMAT-230
OFF vehicle 7. Direct clutch AT-298
No. ItemsSymptom Condition Diagnostic ItemReference
page

AT-66
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
18
Slips/Will
Not
engage When
“D ” position,
remains in 1st gear. ON vehicle
1. Fluid level and state
AT- 5 1
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT- 1 3 2
3. Direct clutch solenoid valve AT- 1 4 7
4. Line pressure test AT- 5 2
5. CAN communication lineAT- 9 6
6. Control valve with TCMAT- 2 3 0
OFF vehicle7.
AT- 2 8 4
3rd one-way clutch AT- 2 8 4
8. 1st one-way clutch AT- 2 9 1
9. Gear systemAT- 2 5 0
10. Reverse brakeAT- 2 6 4
11. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT- 1 7
, AT- 1 8 .) AT- 2 6 4
12. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to
AT- 1 7
, AT- 1 8
.) AT- 2 6 4
19
When
“D ” position,
remains in 2nd gear. ON vehicle
1. Fluid level and state
AT- 5 1
2. Vehicle speed sensor A/T and vehicle speed sensor MTR
AT- 111 ,
AT-132
3. Low coast brake solenoid valve AT- 1 5 5
4. Line pressure test AT- 5 2
5. CAN communication lineAT- 9 6
6. Control valve with TCMAT- 2 3 0
OFF vehicle7. 3rd one-way clutch
AT- 2 8 4
8. Gear systemAT- 2 5 0
9. Direct clutchAT- 2 9 8
10. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT- 1 7
, AT- 1 8
.) AT- 2 6 4
No. Items
Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSISAT-67
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
20
Slips/Will
Not
engage When
“D ” position,
remains in 3rd gear. ON vehicle
1. Fluid level and state
AT- 5 1
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT-132
3. Line pressure test AT- 5 2
4. CAN communication lineAT- 9 6
5. Control valve with TCMAT-230
OFF vehicle6. 3rd one-way clutch
AT-284
7. Gear systemAT-250
8. High and low reverse clutchAT-296
9. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT- 1 7
, AT- 1 8 .) AT-264
10. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT- 1 7
, AT- 1 8
.) AT-264
21
When
“D ” position,
remains in 4th gear. ON vehicle1. Fluid level and state
AT- 5 1
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT-132
3. ATF pressure switch 3 and input clutch solenoid valve AT-161,
AT-139
4. ATF pressure switch 5 and direct clutch solenoid valve AT-163,
AT-
147
5. ATF pressure switch 6, high and low reverse clutch sole-
noid valve AT-165
,
AT-151
6. Low coast brake solenoid valve AT-155
7. Front brake solenoid valveAT-143
8. Line pressure test AT- 5 2
9. CAN communication lineAT- 9 6
10. Control valve with TCMAT-230
OFF vehicle11. Input clutch
AT-28612. Gear systemAT-250
13. High and low reverse clutchAT-296
14. Direct clutchAT-298
No. ItemsSymptom Condition Diagnostic ItemReference
page

AT-68
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
22
Slips/Will
Not
Engage When
“D ” position,
remains in 5th gear. ON vehicle1. Fluid level and state
AT- 5 1
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT- 1 3 2

3. ATF pressure switch 1 and front brake solenoid valve AT- 1 5 9
,
AT- 1 4 3
4. Line pressure test AT- 5 2
5. CAN communication lineAT- 9 6
6. Control valve with TCMAT- 2 3 0
OFF vehicle7. Front brake (brake band)
AT- 2 6 48. Input clutchAT- 2 8 6
9. Gear systemAT- 2 5 0
10. High and low reverse clutchAT- 2 9 6
23Vehicle cannot be
started from D
1 .
Refer to AT-191, "
Vehi-
cle Cannot Be Started
From D1" . ON vehicle
1. Fluid level and state
AT- 5 1
2. Accelerator pedal position sensorAT- 1 2 4
3. Line pressure test AT- 5 2
4. CAN communication lineAT- 9 6
5. Control valve with TCMAT- 2 3 0
OFF vehicle6. Torque converter
AT- 2 6 4
7. Oil pump assemblyAT- 2 8 2
8. 3rd one-way clutchAT- 2 8 4
9. 1st one-way clutchAT- 2 9 1
10. Gear systemAT- 2 5 0
11. Reverse brakeAT- 2 6 4
12. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT- 1 7
, AT- 1 8 .) AT- 2 6 4
13. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to
AT- 1 7
, AT- 1 8
.) AT- 2 6 4
24Does not lock-up.
Refer to
AT-203, "A/T
Does Not Perform
Lock-up" . ON vehicle1. Fluid level and state
AT- 5 1
2. Line pressure testAT- 5 2
3. Engine speed signalAT- 11 6
4. Turbine revolution sensorAT- 1 0 9
5. Torque converter clutch solenoid valve AT- 11 8
6. CAN communication line AT- 9 6
7. Control valve with TCMAT- 2 3 0
OFF vehicle8. Torque converter
AT- 2 6 49. Oil pump assemblyAT- 2 8 2
No. ItemsSymptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSISAT-69
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX5625
Slips/Will
Not
engage Does not hold lock-up
condition.
Refer to
AT-205, "A/T
Does Not Hold Lock-
up Condition" . ON vehicle 1. Fluid level and state
AT- 5 1
2. Line pressure testAT- 5 2
3. Engine speed signalAT- 11 6
4. Turbine revolution sensorAT-109
5. Torque converter clutch solenoid valve AT- 11 8
6. CAN communication line AT- 9 6
7. Control valve with TCMAT-230
OFF vehicle8. Torque converter
AT-2649. Oil pump assemblyAT-282
26Lock-up is not
released.
Refer to
AT-207,
"Lock-up Is Not
Released" . ON vehicle1. Fluid level and state
AT- 5 1
2. Line pressure testAT- 5 2
3. Engine speed signalAT- 11 6
4. Turbine revolution sensorAT-109
5. Torque converter clutch solenoid valve AT- 11 8
6. CAN communication line AT- 9 6
7. Control valve with TCMAT-230
OFF vehicle8. Torque converter
AT-2649. Oil pump assemblyAT-282
27No shock at all or the
clutch slips when
vehicle changes
speed D
1 →
D2 . ON vehicle
1. Fluid level and state
AT- 5 1
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT-132
3. ATF pressure switch 5 and direct clutch solenoid valve AT-163,
AT-147
4. CAN communication line AT- 9 6
5. Line pressure testAT- 5 2
6. Control valve with TCMAT-230
OFF vehicle7. Torque converter
AT-264
8. Oil pump assemblyAT-282
9. 3rd one-way clutchAT-284
10. Gear systemAT-250
11. Direct clutchAT-298
12. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT- 1 7
, AT- 1 8
.) AT-264
No. Items
Symptom Condition Diagnostic ItemReference
page

AT-70
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
28
Slips/Will
Not
engage No shock at all or the
clutch slips when
vehicle changes
speed D
2
→ D3 . ON vehicle
1. Fluid level and state
AT- 5 1
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT- 1 3 2
3. ATF pressure switch 6, high and low reverse clutch sole-
noid valve AT- 1 6 5,
AT- 1 5 1
4. CAN communication line AT- 9 6
5. Line pressure testAT- 5 2
6. Control valve with TCMAT- 2 3 0
OFF vehicle7. Torque converter
AT- 2 6 4
8. Oil pump assemblyAT- 2 8 2
9. 3rd one-way clutchAT- 2 8 4
10. Gear systemAT- 2 5 0
11. High and low reverse clutchAT- 2 9 6
12. Forward one- way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT- 1 7
, AT- 1 8 .) AT- 2 6 4
13. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to
AT- 1 7
, AT- 1 8
.) AT- 2 6 4
29No shock at all or the
clutch slips when
vehicle changes
speed D
3
→ D4 . ON vehicle 1. Fluid level and state
AT- 5 1
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT- 1 3 2
3. ATF pressure switch 3 and input clutch solenoid valve AT- 1 6 1,
AT- 1 3 9

4. ATF pressure switch 1 and front brake solenoid valve AT- 1 5 9
,
AT- 1 4 3
5. CAN communication line AT- 9 6
6. Line pressure testAT- 5 2
7. Control valve with TCMAT- 2 3 0
OFF vehicle8. Torque converter
AT- 2 6 4
9. Oil pump assemblyAT- 2 8 2
10. Input clutchAT- 2 8 6
11. Gear systemAT- 2 5 0
12. High and low reverse clutchAT- 2 9 6
13. Direct clutchAT- 2 9 8
No. ItemsSymptom Condition Diagnostic ItemReference
page
