AT-82
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
65 OthersEngine speed does
not return to idle.
Refer to
AT-208,
"Engine Speed Does
Not Return to Idle" .ON vehicle 1. Fluid level and state
AT- 5 1
2. ATF pressure switch 5 and direct clutch solenoid valveAT- 1 6 3,
AT- 1 4 7
3. ATF pressure switch 1 and front brake solenoid valve AT- 1 5 9,
AT- 1 4 3
4. Accelerator pedal position sensor AT- 1 2 4
5. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT- 1 3 2
6. CAN communication line AT- 9 6
7. Control valve with TCMAT- 2 3 0
OFF vehicle8. Front brake (brake band)
AT- 2 6 49. Direct clutchAT- 2 9 8
No. ItemsSymptom Condition Diagnostic ItemReference
page

AT-90
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
DATA MONITOR MODE
Operation Procedure
1. Perform “CONSULT-II SETTING PROCEDURE ”. Refer to AT- 8 6 , "CONSULT-II SETTING PROCEDURE"
.
2. Touch “DATA MONITOR ”.
NOTE:
When malfunction is detected, CONSULT-II performs
“REAL-TIME DIAGNOSIS”. Also, any malfunction detected
while in this mode will be displayed at real time.
Display Items List
X: Standard, —: Not applicable
BCIA0031E
Monitored item (Unit) Monitor Item Selection
Remarks
ECU
INPUT
SIGNALS MAIN SIG-
NALS SELEC-
TION
FROM
MENU
VHCL/S SE ·A/T (km/h) XXX Revolution sensor
VHCL/S SE ·MTR (km/h) X— X
ACCELE POSI (0.0/8) X— X Accelerator pedal position signal
THROTTLE POSI (0.0/8) XXXDegree of opening for accelerator recognized by
the TCM
For fail-safe operation, the specific value used
for control is displayed.
CLSD THL POS (ON-OFF display) X— X
Signal input with CAN communications
W/O THL POS (ON-OFF display) X— X
BRAKE SW (ON-OFF display) X— X Stop lamp switch
GEAR —XX Gear position recognized by the TCM updated
after gear-shifting
ENGINE SPEED (rpm) XXX
TURBINE REV (rpm) XXX
OUTPUT REV (rpm) XXX
GEAR RATIO —XX
TC SLIP SPEED (rpm) —XX Difference between engine speed and torque
converter input shaft speed
F SUN GR REV (rpm) ——X
F CARR GR REV (rpm) ——X
ATF TEMP SE 1 (V) X— X
ATF TEMP SE 2 (V) X— X
ATF TEMP 1 ( °C) —XX
ATF TEMP 2 ( °C) —XX
BATTERY VOLT (V) X— X
ATF PRES SW 1 (ON-OFF display) XXX (for FR/B solenoid)
ATF PRES SW 2 (ON-OFF display) XXX (for LC/B solenoid)
ATF PRES SW 3 (ON-OFF display) XXX (for I/C solenoid)
ATF PRES SW 5 (ON-OFF display) XXX (for D/C solenoid)

AT-134
DTC P1730 A/T INTERLOCK
Revision: November 20092006 QX56
DTC P1730 A/T INTERLOCKPFP:00000
DescriptionECS00CH5

Fail-safe function to detect interlock conditions.
On Board Diagnosis LogicECS00CH6

This is an OBD-II self-diagnostic item.

Diagnostic trouble code “P1730 A/T INTERLOCK ” with CONSULT-II is detected when TCM does not
receive the proper voltage signal from the sensor and switch.

TCM monitors and compares gear position and conditions of each ATF pressure switch when gear is
steady.
Possible CauseECS00CH7

Harness or connectors
(The solenoid and switch circuit is open or shorted.)

Low coast brake solenoid valve

ATF pressure switch 2
DTC Confirmation ProcedureECS00CH8
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch “ ON”. (Do not start engine.)
2. Select “DATA MONITOR ” mode for “A/T” with CONSULT-II.
3. Start engine.
4. Drive vehicle and maintain the following conditions for at least 2 consecutive seconds.
Selector lever: “D” position
5. If DTC is detected, go to AT- 1 3 5 , "
Diagnostic Procedure" .
WITH GST
Follow the procedure “With CONSULT-II”.
BCIA0030E

DTC P1731 A/T 1ST ENGINE BRAKINGAT-137
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
DTC P1731 A/T 1ST ENGINE BRAKINGPFP:00000
DescriptionECS00CHB
Fail-safe function to prevent sudden decrease in speed by engine brake other than at "1" position.
CONSULT-II Reference ValueECS00CHC
On Board Diagnosis LogicECS00CHD

This is not an OBD-II self-diagnostic item.

Diagnostic trouble code “P1731 A/T 1ST E/BRAKING ” with CONSULT-II is detected under the following
conditions.
–When TCM does not receive the proper voltage signal from the sensor.
–When TCM monitors each ATF pressure switch and solenoid monitor value, and detects as irregular when
engine brake of 1st gear acts other than at 1 position.
Possible CauseECS00CHE

Harness or connectors
(The sensor circuit is open or shorted.)

Low coast brake solenoid valve

ATF pressure switch 2
DTC Confirmation ProcedureECS00CHF
NOTE:
If “DTC Confirmation Procedure” has been previously preformed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch “ON”. (Do not start engine.)
2. Select “DATA MONITOR ” mode for “A/T” with CONSULT-II.
3. Start engine.
4. Drive vehicle and maintain the following conditions for at least 2 consecutive seconds.
ENGINE SPEED: 1,200 rpm
Selector lever: “1” position
Gear position: 1st gear
5. If DTC is detected, go to AT- 1 3 8 , "
Diagnostic Procedure" .
Item name Condition Display value
ON OFF SOL Low coast brake engaged. Refer to
AT- 2 0
.O N
Low coast brake disengaged. Refer to AT- 2 0
.O FF
ATF PRES SW 2 Low coast brake engaged. Refer to
AT- 2 0
.O N
Low coast brake disengaged. Refer to AT- 2 0
.O FF
BCIA0030E

AT-138
DTC P1731 A/T 1ST ENGINE BRAKING
Revision: November 20092006 QX56
Diagnostic ProcedureECS00CHG
1. CHECK INPUT SIGNALS
With CONSULT-II
1. Start the engine.
2. Select “SELECTION FROM MENU” in “DATA MONITOR” for
"A/T" with CONSULT-II"
3. Drive vehicle in the “1 ” position (1st gear), and confirm the ON/
OFF actuation of “ATF PRES SW 2 ” and "ON OFF SOL".
OK or NG
OK >> GO TO 4.
NG >> GO TO 2.
2. CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer to AT- 1 6 7 , "
MAIN POWER SUPPLY AND GROUND CIR-
CUIT" .
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3. DETECT MALFUNCTIONING ITEM
Check the following items:

The A/T assembly harness connector pin terminals for damage or loose connection with harness connec-
tor.
OK or NG
OK >> Replace the control valve with TCM. Refer to AT- 2 3 0 , "Control Valve With TCM and A/T Fluid
Temperature Sensor 2" .
NG >> Repair or replace damaged parts.
4. CHECK DTC
Perform “DTC Confirmation Procedure ”.

Refer to AT- 1 3 7 , "DTC Confirmation Procedure" .
OK or NG
OK >> INSPECTION END
NG >> GO TO 2.
Item name Condition Display value
ON OFF
SOL Low coast brake engaged. Refer to
AT- 2 0
.ON
Low coast brake disengaged. Refer to AT- 2 0
.OFF
ATF PRES
SW 2 Low coast brake engaged. Refer to
AT- 2 0
.ON
Low coast brake disengaged. Refer to AT- 2 0
.OFF
PCIA0067E

DTC P1757 FRONT BRAKE SOLENOID VALVEAT-143
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
DTC P1757 FRONT BRAKE SOLENOID VALVEPFP:31940
DescriptionECS00CHT
Front brake solenoid valve is controlled by the TCM in response to signals sent from the PNP switch, vehicle
speed sensor and accelerator pedal position sensor (throttle position sensor). Gears will then be shifted to the
optimum position.
CONSULT-II Reference ValueECS00CHU
On Board Diagnosis LogicECS00CHV

This is an OBD-II self-diagnostic item.

Diagnostic trouble code “P1757 FR/B SOLENOID/CIRC ” with CONSULT-II is detected under the following
conditions.
–When TCM detects an improper voltage drop when it tries to operate the solenoid valve.
–When TCM detects as irregular by comparing target value with monitor value.
Possible CauseECS00CHW

Harness or connectors
(The solenoid circuit is open or shorted.)

Front brake solenoid valve
DTC Confirmation ProcedureECS00CHX
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch “ON”. (Do not start engine.)
2. Select “DATA MONITOR ” mode for “A/T” with CONSULT-II.
3. Start engine.
4. Drive vehicle and maintain the following conditions for at least 5 consecutive seconds.
ACCELE POS: 1.5/8 - 2.0/8
Selector lever: “D” position
Gear position: 3rd
4th Gear (FR/B ON/OFF)
Driving location: Driving the vehicle uphill (increased
engine load) will help maintain the driving conditions
required for this test.
5. If DTC is detected go to AT- 1 4 4 , "
Diagnostic Procedure" .
WITH GST
Follow the procedure “With CONSULT-II”.
Item name Condition Display value (Approx.)
FR/B SOLENOID Front brake engaged. Refer to
AT- 2 0
.0.6 - 0.8 A
Front brake disengaged. Refer to AT- 2 0
.0 - 0.05 A
BCIA0030E

AT-144
DTC P1757 FRONT BRAKE SOLENOID VALVE
Revision: November 20092006 QX56
Diagnostic ProcedureECS00CHY
1. CHECK INPUT SIGNAL
With CONSULT-II
1. Turn ignition switch “ ON”.
2. Select “MAIN SIGNALS” in “DATA MONITOR” mode for “A/T”
with CONSULT-II.
3. Start engine.
4. Read out the value of “FR/B SOLENOID” while driving.
OK or NG
OK >> GO TO 4.
NG >> GO TO 2.
2. CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer to AT- 1 6 7 , "
MAIN POWER SUPPLY AND GROUND CIR-
CUIT" .
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3. DETECT MALFUNCTIONING ITEM
Check the following items:

The A/T assembly harness connector pin terminals for damage or loose connection with harness connec-
tor.
OK or NG
OK >> Replace the control valve with TCM. Refer to AT- 2 3 0 , "Control Valve With TCM and A/T Fluid
Temperature Sensor 2" .
NG >> Repair or replace damaged parts.
4. CHECK DTC
Perform “DTC Confirmation Procedure ”.

Refer to AT- 1 4 3 , "DTC Confirmation Procedure" .
OK or NG
OK >> INSPECTION END
NG >> GO TO 2.
Item name Condition Display value
(Approx.)
FR/B SOLE-
NOID Front brake engaged. Refer to AT- 2 0
. 0.6 - 0.8 A
Front brake disengaged. Refer to AT- 2 0
.0 - 0.05 ASCIA4793E

DTC P1759 FRONT BRAKE SOLENOID VALVE FUNCTIONAT-145
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
DTC P1759 FRONT BRAKE SOLENOID VALVE FUNCTIONPFP:31940
DescriptionECS00CHZ

Front brake solenoid valve is controlled by the TCM in response to signals sent from the PNP switch, vehi-
cle speed sensor and accelerator pedal position sensor (throttle position sensor). Gears will then be
shifted to the optimum position.

This is not only caused by electrical malfunction (circuits open or shorted) but also by mechanical mal-
function such as control valve sticking, improper solenoid valve operation.
CONSULT-II Reference ValueECS00CI0
On Board Diagnosis LogicECS00CI1

This is an OBD-II self-diagnostic item.

Diagnostic trouble code “P1759 FR/B SOLENOID FNCT ” with CONSULT-II is detected under the follow-
ing conditions.
–When TCM detects that actual gear ratio is irregular, and relation between gear position and condition of
ATF pressure switch 1 is irregular during depressing accelerator pedal. (Other than during shift change)
–When TCM detects that relation between gear position and condition of ATF pressure switch 1 is irregular
during releasing accelerator pedal. (Other than during shift change)
Possible CauseECS00CI2

Harness or connectors
(The solenoid and switch circuits are open or shorted.)

Front brake solenoid valve

ATF pressure switch 1
DTC Confirmation ProcedureECS00CI3
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Start engine.
2. Accelerate vehicle to maintain the following conditions.
ACCELE POS: 1.5/8 - 2.0/8
Selector lever: “D” position
Gear position: 3rd
4th Gear (FR/B ON/OFF)
Driving location: Driving the vehicle uphill (increased
engine load) will help maintain the driving conditions
required for this test.
3. Perform step “2” again.
4. Turn ignition switch “OFF”, then perform step “1” to “3 ” again.
5. Check “SELF-DIAG RESULTS ” mode for “A/T” with CONSULT-
II. If DTC (P1759) is detected, refer to AT- 1 4 6 , "
Diagnostic Procedure" .
If DTC (P1757) is detected, go to AT- 1 4 4 , "
Diagnostic Procedure" .
If DTC (P1841) is detected, go to AT- 1 6 0 , "
Diagnostic Procedure" .
Item nameCondition Display value (Approx.)
FR/B SOLENOID Front brake engaged. Refer to
AT- 2 0
.0.6 - 0.8 A
Front brake disengaged. Refer to AT- 2 0
.0 - 0.05 A
ATF PRES SW 1 Front brake engaged. Refer to
AT- 2 0
.ON
Front brake disengaged. Refer to AT- 2 0
.OFF
BCIA0030E

AT-146
DTC P1759 FRONT BRAKE SOLENOID VALVE FUNCTION
Revision: November 20092006 QX56
Diagnostic ProcedureECS00CI4
1. CHECK INPUT SIGNALS
With CONSULT-II
1. Start engine.
2. Select “SELECTION FROM MENU ” in “DATA MONITOR” mode
for “A/T ” with CONSULT-II.
3. Drive vehicle in the “D ” position (3rd
4th gear), and confirm
the ON/OFF actuation of the “ATF PRES SW 1 ” and electrical
current value of “FR/B SOLENOID ”.
OK or NG
OK >> GO TO 4.
NG >> GO TO 2.
2. CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer to AT- 1 6 7 , "
MAIN POWER SUPPLY AND GROUND CIR-
CUIT" .
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3. DETECT MALFUNCTIONING ITEM
Check the following items:

The A/T assembly harness connector pin terminals for damage or loose connection with harness connec-
tor.
OK or NG
OK >> Replace the control valve with TCM. Refer to AT- 2 3 0 , "Control Valve With TCM and A/T Fluid
Temperature Sensor 2" .
NG >> Repair or replace damaged parts.
4. CHECK DTC
Perform “DTC Confirmation Procedure ”.

Refer to AT- 1 4 5 , "DTC Confirmation Procedure" .
OK or NG
OK >> INSPECTION END
NG >> GO TO 2.
Item name Condition Display value
(Approx.)
FR/B SOLE-
NOID Front brake engaged. Refer to
AT- 2 0
. 0.6 - 0.8 A
Front brake disengaged. Refer to AT- 2 0
. 0 - 0.05 A
ATF PRES
SW 1 Front brake engaged. Refer to
AT- 2 0
.ON
Front brake disengaged. Refer to AT- 2 0
.OFF
SCIA4796E

DTC P1772 LOW COAST BRAKE SOLENOID VALVEAT-155
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
DTC P1772 LOW COAST BRAKE SOLENOID VALVEPFP:31940
DescriptionECS00CIT
Low coast brake solenoid valve is turned “ON” or “OFF ” by the TCM in response to signals sent from the PNP
switch, vehicle speed sensor and accelerator pedal position sensor (throttle position sensor). Gears will then
be shifted to the optimum position.
CONSULT-II Reference ValueECS00CIU
On Board Diagnosis LogicECS00CIV

This is an OBD-II self-diagnostic item.

Diagnostic trouble code “P1772 LC/B SOLENOID/CIRC ” with CONSULT-II is detected when TCM detects
an improper voltage drop when it tries to operate the solenoid valve.
Possible CauseECS00CIW

Harness or connectors
(The solenoid circuit is open or shorted.)

Low coast brake solenoid valve
DTC Confirmation ProcedureECS00CIX
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch “ON”. (Do not start engine.)
2. Select “DATA MONITOR” mode for “ENGINE ” with CONSULT-II.
3. Start engine.
4. Drive vehicle and maintain the following conditions for at least 5 consecutive seconds.
Selector lever: “1” or “2”
Gear position: “1st” or “2nd” gear (LC/B ON/OFF)
5. If DTC is detected, go to AT- 1 5 6 , "
Diagnostic Procedure" .
WITH GST
Follow the procedure “With CONSULT-II”.
Item name Condition Display value
ON OFF SOL Low coast brake engaged. Refer to
AT- 2 0
.ON
Low coast brake disengaged. Refer to AT- 2 0
.OFF
BCIA0030E
