DATA MONITOR
SELECTIOM FROM MENU
Monitor item [OPERATION or UNIT]Contents
SLIDE SW-FR “ON/OFF ”ON/OFF status judged from the sliding switch (FR) signal is displayed.
SLIDE SW-RR “ON/OFF ”ON/OFF status judged from the sliding switch (RR) signal is displayed.
RECLN SW-FR “ON/OFF ”ON/OFF status judged from the reclining switch (FR) signal is displayed.
RECLN SW-RR “ON/OFF ”ON/OFF status judged from the reclining switch (RR) signal is displayed.
LIFT FR SW-UP “ON/OFF ”ON/OFF status judged from the FR lifter switch (UP) signal is displayed.
LIFT FR SW-DN “ON/OFF ”ON/OFF status judged from the FR lifter switch (DOWN) signal is displayed.
LIFT RR SW-UP “ON/OFF ”ON/OFF status judged from the RR lifter switch (UP) signal is displayed.
LIFT RR SW-DN “ON/OFF ”ON/OFF status judged from the RR lifter switch (DOWN) signal is displayed.
MIR CON SW-UP “ON/OFF ”ON/OFF status judged from the door mirror remote control switch (UP) signal is
displayed.
MIR CON SW-DN “ON/OFF ”ON/OFF status judged from the door mirror remote control switch (DOWN) signal
is displayed.
MIR CON SW-RH “ON/OFF ”ON/OFF status judged from the door mirror remote control switch (RIGHT) signal
is displayed.
MIR CON SW-LH “ON/OFF ”ON/OFF status judged from the door mirror remote control switch (LEFT) signal is
displayed.
MIR CHNG SW-R “ON/OFF ”ON/OFF status judged from the door mirror remote control switch (switching to
RIGHT) signal is displayed.
MIR CHNG SW-L “ON/OFF ”ON/OFF status judged from the door mirror remote control switch (switching to
LEFT) signal is displayed.
SET SW “ON/OFF ”ON/OFF status judged from the setting switch signal is displayed.
TILT SW-UP “ON/OFF ”ON/OFF status judged from the tilt adjusting switch (UP) signal is displayed.
PEDAL SW-FR “ON/OFF ”ON/OFF status judged from the pedal adjusting switch (FR) signal is displayed.
PEDAL SW-RR “ON/OFF ”ON/OFF status judged from the pedal adjusting switch (RR) signal is displayed.
MEMORY SW1 “ON/OFF ”ON/OFF status judged from the seat memory switch 1 signal is displayed.
MEMORY SW2 “ON/OFF ”ON/OFF status judged from the seat memory switch 2 signal is displayed.
DETENT SW “ON/OFF ”The A/T selector lever position
“OFF (P position) / ON (other than P position) ”
judged from the park position switch signal is displayed.
STARTER SW “ON/OFF ”Ignition key switch ON (START, ON) /OFF (ignition switch IGN, ACC, or OFF)
status judged from the ignition switch signal is displayed.
SLIDE PULSE —Value (32768) when battery connects is as standard. If it moves BACKWARD, the
value increases. If it moves FORWARD, the value decreases.
RECLN PULSE —Value (32768) when battery connects is as standard. If it moves BACKWARD, the
value increases. If it moves FORWARD, the value decreases.
LIFT FR PULSE —Value (32768) when battery connects is as standard. If it moves DOWN, the value
increases. If it moves UP, the value decreases.
LIFT RR PULSE —Value (32768) when battery connects is as standard. If it moves DOWN, the value
increases. If it moves UP, the value decreases.
MIR/SEN RH R-L “V ” Voltage output from RH door mirror sensor (LH/RH) is displayed.
MIR/SEN RH U-D “V ” Voltage output from RH door mirror sensor (UP/DOWN) is displayed.
MIR/SEN LH R-L “V ” Voltage output from LH door mirror sensor (LH/RH) is displayed.
MIR/SEN LH U-D “V ” Voltage output from LH door mirror sensor (UP/DOWN) is displayed.
PEDAL SEN “V ” The pedal position (voltage) judged from the pedal adjust sensor signal is dis-
played.
