key INFINITI QX56 2008 Factory Service Manual

INSIDE KEY ANTENNA 2 (LUGGAGE COMPARTMENT)DLK-59
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness between Intelligent Key unit and inside key antenna 2 (luggage com- partment).
3.CHECK INSIDE KEY ANTENNA POWER SUPPLY SINGAL
1. Replace inside key antenna. (New antenna or other antenna)
2. Connect Intelligent Key unit connector.
3. Check signal between Intelligent Key unit connector and ground with oscilloscope.
Is the inspection result normal?
YES >> Replace inside key antenna 2 (luggage compartment).
NO >> Replace Intelligent Key unit. Refer to SEC-116, "
Removal and Installation".
Item ConnectorTerminalsContinuity
Intelligent Key unit A: M70 35
Ground No
36
Connector Item Te r m i n a l s
Condition Signal (V)
(Reference value)
(+) (–)
M70 Intelligent
Key unit 35 Ground Ignition
switch is
pushed.
ALKIA0587ZZ
PIIB7441E
Revision: March 2010
2008 QX56

DLK-60
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INSIDE KEY ANTENNA 3 (FRONT OF CENTER CONSOLE)
INSIDE KEY ANTENNA 3 (FRO
NT OF CENTER CONSOLE)
DescriptionINFOID:0000000001538952
Detects whether Intelligent Key is inside the vehicle.
Component Function CheckINFOID:0000000001538953
1.CHECK INSIDE KEY ANTENNA INPUT SIGNAL
With CONSULT-III
1. Check “ANTENNA” in “Active Test” mode with CONSULT-III.
2. Touch “INSIDE KEY ANTENNA 3”.
3. When Intelligent Key is inside key antenna (front of center console) detection area, hazard lamps flash.
Is the inspection result normal?
YES >> Inside key antenna 3 (front of center console) is OK.
NO >> Refer to DLK-60, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001538954
1.CHECK INSIDE KEY ANTENNA POWER SUPPLY SIGNAL
1. Turn ignition switch OFF.
2. Check signal between Intelligent Key unit connector and ground with an oscilloscope.
Is the inspection result normal?
YES >> Inside key antenna 3 (front of center console) is OK.
NO >> GO TO 2
2.CHECK INSIDE KEY ANTENNA
1. Disconnect Intelligent Key unit connector and inside key antenna 3 (front of center console) connectors.
2. Check continuity between Intelligent Key unit harness connector (A) M70 terminals 13, 14 and inside key antenna 3 (front of center console) har ness connector (B) M210 terminals 1, 2.
3. Check continuity between Inte lligent Key unit harness connector
(A) M70 terminals 13, 14 and ground.
Test Item Condition Possible cause
INSIDE KEY ANTENNA 3 An excessive high or low voltage from inside
antenna is sent to the Intelligent Key Unit • Inside key antenna 3 (front of center console)
• Between Intelligent Key unit and inside key antenna 3
(front of center console)
Connector Item Te r m i n a l s
Condition Signal (V)
(Reference value)
(+) (–)
M70 Intelligent
Key unit 13 Ground Ignition
switch is
pushed.
ALKIA0583ZZPIIB7441E
Intelligent Key
unit connector
Te r m i n a l sInside key antenna
3 (front of center
console) connector Terminals Continuity
A: M70 13
B: M210 1
Ye s
14 2
ALKIA0584ZZ
Revision: March 2010 2008 QX56

INSIDE KEY ANTENNA 3 (FRONT OF CENTER CONSOLE)
DLK-61
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness between Intelligent Key unit and inside key antenna 3 (front of center console).
3.CHECK INSIDE KEY ANTENNA POWER SUPPLY SINGAL
1. Replace inside key antenna. (New antenna or other antenna)
2. Connect Intelligent Key unit connector.
3. Check signal between Intelligent Key unit connector and ground with oscilloscope.
Is the inspection result normal?
YES >> Replace inside key antenna 3 (front of center console).
NO >> Replace Intelligent Key unit. Refer to SEC-116, "
Removal and Installation".
Item ConnectorTerminalsContinuity
Intelligent Key unit A: M70 13
Ground No
14
Connector Item Te r m i n a l s
Condition Signal (V)
(Reference value)
(+) (–)
M70 Intelligent
Key unit 13 Ground Ignition
switch is
pushed.
ALKIA0583ZZ
PIIB7441E
Revision: March 2010
2008 QX56

DLK-62
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INSIDE KEY ANTENNA 4
(OVERHEAD CONSOLE AREA)
INSIDE KEY ANTENNA 4 (OVERHEAD CONSOLE AREA)
DescriptionINFOID:0000000001538955
Detects whether Intelligent Key is inside the vehicle.
Component Function CheckINFOID:0000000001538956
1.CHECK INSIDE KEY ANTENNA INPUT SIGNAL
With CONSULT-III
1. Check “ANTENNA” in “Active Test” mode with CONSULT-III.
2. Touch “INSIDE KEY ANTENNA 4”.
3. When Intelligent Key is inside key antenna (over head console area) detection area, hazard lamps flash.
Is the inspection result normal?
YES >> Inside key antenna 4 (overhead console area) is OK.
NO >> Refer to DLK-62, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001538957
1.CHECK INSIDE KEY ANTENNA POWER SUPPLY SIGNAL
1. Turn ignition switch OFF.
2. Check signal between Intelligent Key unit connector and ground with an oscilloscope.
Is the inspection result normal?
YES >> Inside key antenna 4 (overhead console area) is OK.
NO >> GO TO 2
2.CHECK INSIDE KEY ANTENNA
1. Disconnect Intelligent Key unit connector and inside key antenna 4 (overhead console area) connectors.
2. Check continuity between Intelligent Key unit harness connector (A) M70 terminals 33, 34 and inside key antenna 4 (overhead console area) harness connector (B) R210 terminals 1, 2.
3. Check continuity between Inte lligent Key unit harness connector
(A) M70 terminals 33, 34 and ground.
Test Item Condition Possible cause
INSIDE KEY ANTENNA 4 An excessive high or low voltage from inside
antenna is sent to the Intelligent Key Unit • Inside key antenna 4 (overhead console area)
• Between Intelligent Key unit and inside key antenna 4
(overhead console area)
Connector Item Te r m i n a l s
Condition Signal (V)
(Reference value)
(+) (–)
M70 Intelligent
Key unit 33 Ground Ignition
switch is
pushed.
ALKIA0589ZZPIIB7441E
Intelligent Key
unit connector
Te r m i n a l sInside key antenna
4 (overhead console
area) connector Terminals Continuity
A: M70 33
B: R210 1
Ye s
34 2
ALKIA0590ZZ
Revision: March 2010 2008 QX56

INSIDE KEY ANTENNA 4 (OVERHEAD CONSOLE AREA)DLK-63
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness between Intelligent Key unit and inside key antenna 4 (overhead con- sole area).
3.CHECK INSIDE KEY ANTENNA POWER SUPPLY SINGAL
1. Replace inside key antenna. (New antenna or other antenna)
2. Connect Intelligent Key unit connector.
3. Check signal between Intelligent Key unit connector and ground with oscilloscope.
Is the inspection result normal?
YES >> Replace inside key antenna 4 (overhead console area).
NO >> Replace Intelligent Key unit. Refer to SEC-116, "
Removal and Installation".
Item ConnectorTerminalsContinuity
Intelligent Key unit A: M70 33
Ground No
34
Connector Item Te r m i n a l s
Condition Signal (V)
(Reference value)
(+) (–)
M70 Intelligent
Key unit 33 Ground Ignition
switch is
pushed.
ALKIA0589ZZ
PIIB7441E
Revision: March 2010
2008 QX56

DLK-64
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
INTELLIGENT KEY UNIT
INTELLIGENT KEY UNIT
: Diagnosis ProcedureINFOID:0000000001538958
1.CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect Intelligent Key unit connector.
3. Check voltage between Intelligent Key unit harness connector M70 terminals 6, 11 and ground.
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair or replace Intelligent Key unit power supply circuit.
2.CHECK GROUND CIRCUIT
Check continuity between Intelligent Key unit harness connector
M70 terminal 12 and ground.
Is the inspection result normal?
YES >> Power supply and ground circuits are OK.
NO >> Repair or replace the Intelligent Key unit ground circuit.
BCM (BODY CONTROL MODULE)
BCM (BODY CONTROL MODULE) : Diagnosis ProcedureINFOID:0000000004884061
1. CHECK FUSES AND FUSIBLE LINK
Check that the following fuses and fusible link are not blown.
Is the fuse blown?
YES >> Replace the blown fuse or fusible link after repairing the affected circuit.
NO >> GO TO 2
2. CHECK POWER SUPPLY CIRCUIT
Connector Terminals Ignition switch position
M70 (+) (–) OFF
ON
6 Ground 0V Battery voltage
11 Battery voltage Battery voltage
WIIA1171E
12 - Ground : Continuity should exist.
WIIA1172E
Terminal No. Signal nameFuses and fusible link No.
57 Battery power supply 22 (15A)
70 F (50A)
11 Ignition ACC or ON 4 (10A)
38 Ignition ON or START 59 (10A)
Revision: March 2010 2008 QX56

POWER SUPPLY AND GROUND CIRCUITDLK-65
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
1. Turn ignition switch OFF.
2. Disconnect BCM.
3. Check voltage between BCM harness connector and ground.
Is the measurement value normal?
YES >> GO TO 3
NO >> Repair or replace harness.
3. CHECK GROUND CIRCUIT
Check continuity between BCM harness connector and ground.
Does continuity exist?
YES >> INSPECTION END
NO >> Repair or replace harness.
BACK DOOR
BACK DOOR : Diagnosis ProcedureINFOID:0000000001538960
1.BACK DOOR POWER SUPPLY CIRCUIT INSPECTION
1. Turn ignition switch OFF.
2. Disconnect back door control unit connector.
3. Check voltage between back door control unit connector B55 terminals 3, 7, 10 and ground.
Connector Te r m i n a l s
Power
source Condition Voltage (V) (Ap-
prox.)
(+) (-)
M18 11 Ground
ACC
power
supply Ignition
switch
ACC or
ON Battery voltage
38 Ground Ignition
power
supply Ignition
switch ON or START Battery voltage
M20 57 Ground
Battery
power
supply Ignition
switch OFF Battery voltage
70 Ground Battery
power
supply Ignition
switch
OFF Battery voltage
LIIA2415E
BCM
GroundContinuity
Connector Terminal
M20 67 Yes
LIIA0915E
ConnectorTe r m i n a l s
Power
source Condition
Voltage (V) (Ap-
prox.)
(+) (-)
B55 3Ground
Battery
power
supply Ignition
switch OFF Battery voltage
7Ground Ignition
power
supply Ignition
switch ON
or START Battery voltage
10 Ground Battery
power
supply Ignition
switch OFF Battery voltage
ALKIA1604ZZ
Revision: March 2010
2008 QX56

DLK-66
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
POWER SUPPLY AND GROUND CIRCUIT
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair the back door control unit power supply circuit.
2.BACK DOOR GROUND CIRCUIT INSPECTION
Check continuity between back door control unit connector B55 ter-
minal 1, 2 and ground.
Is the inspection result normal?
YES >> Circuit is OK.
NO >> Repair the harness between the back door control unit and ground.
BCM
GroundContinuity
Connector Terminal
B55 1Y
es
2Y es
LIIA0801E
Revision: March 2010 2008 QX56

DOOR SWITCHDLK-67
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR SWITCH
DescriptionINFOID:0000000001538961
Detects door open/close condition.
Component Function CheckINFOID:0000000001538962
1.CHECK FUNCTIONWith CONSULT-III
Check door switches in data monitor mode with CONSULT-III.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Refer to DLK-67, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001538963
1.CHECK DOOR SWITCHES INPUT SIGNAL
With CONSULT-III
Check door switches ("DOOR SW-DR", "DOOR SW-AS", "DOOR SW-RL", "DOOR SW-RR", "BACK DOOR
SW") in DATA MONITOR mode with CONSULT–III.
• When doors are open:
• When doors are closed:
Without CONSULT-III
Check voltage between BCM connector M18 or M19 terminals 12, 13, 43, 47, 48 and ground.
Monitor item Condition
DOOR SW-DR
CLOSE → OPEN: OFF → ON
DOOR SW-AS
DOOR SW-RL
DOOR SW-RR
BACK DOOR SW
DOOR SW-DR :ON
DOOR SW-AS :ON
DOOR SW-RL :ON
DOOR SW-RR :ON
BACK DOOR SW :ON
DOOR SW-DR :OFF
DOOR SW-AS :OFF
DOOR SW-RL :OFF
DOOR SW-RR :OFF
BACK DOOR SW :OFF
Revision: March 2010 2008 QX56

DLK-68
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR SWITCH
Is the inspection result normal?
YES >> Door switch circuit is OK.
NO >> GO TO 2
2.CHECK DOOR SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect door switch and BCM.
3. Check continuity between BCM connector (A) M18, M19 terminals 12, 13, 43, 47, 48 and door switch con-
nector (B) B8 (Front LH), B108 (Front RH), B18 (Rear LH), B116 (Rear RH) terminal 2 or back door latch
connector (C) D503 terminal 7.
4. Check continuity between door switch connector (B) B8 (Front
LH), B108 (Front RH), B18 (Rear LH), B116 (Rear RH) terminal
2 or back door latch connector (C) D503 terminal 7 and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness.
3.CHECK DOOR SWITCHES
• Disconnect door switch harness.
• Check continuity between door switch connector terminals.
Connec- tor Item Te r m i n a l s
ConditionVoltage (V)
(Approx.)
( + ) ( – )
M19 Back door
switch/latch 43
Ground Open
↓
Closed 0
↓
Battery voltage
Front door
switch LH 47
Rear door switch LH 48
M18 Front door
switch RH 12
Rear door
switch RH 13
LIIA1041E
2 - 47
:Continuity should exist
2 - 12 :Continuity should exist
2 - 48 :Continuity should exist
2 - 13 :Continuity should exist
7 - 43 :Continuity should exist
2 - Ground :Continuity should not exist
7 - Ground :Continuity should not exist
ALKIA0689ZZ
Revision: March 2010 2008 QX56
