DLK-4
BACK DOOR CLOSE SWITCH SYSTEM .......133
Diagnosis Procedure ........................................... ..133
BACK DOOR SWITCH ....................................134
Diagnosis Procedure ........................................... ..134
CINCH LATCH MOTOR SYSTEM ...................135
Diagnosis Procedure ........................................... ..135
INTELLIGENT KEY UNIT POWER BACK
DOOR INPUT SIGNAL ....................................
136
Description ........................................................... ..136
Diagnosis Procedure .............................................136
INTELLIGENT KEY UNIT POWER BACK
DOOR OUTPUT SIGNAL ................................
137
Description ........................................................... ..137
Diagnosis Procedure .............................................137
HOMELINK UNIVERSAL TRANSCEIVER ......138
Wiring Diagram .................................................... ..138
Description .............................................................139
Component Function Check ................................140
Diagnosis Procedure .............................................140
ECU DIAGNOSIS ..................................... ..142
BCM (BODY CONTROL MODULE) ............... .142
Reference Value .................................................. ..142
Terminal Layout .....................................................144
Physical Values .....................................................144
Wiring Diagram — POWER DOOR LOCK SYS-
TEM — ..................................................................
150
Fail Safe ................................................................162
DTC Inspection Priority Chart .............................163
DTC Index ........................................................... ..163
INTELLIGENT KEY UNIT ................................165
Reference Value - Intelligent Key Unit ................. ..165
Reference Value - Steering Lock Solenoid ............168
Wiring Diagram — INTELLIGENT KEY SYSTEM
— ......................................................................... ..
169
Fail Safe ................................................................186
BACK DOOR CONTROL UNIT .......................187
Reference Value .................................................. ..187
Wiring Diagram—AUTOMATIC BACK DOOR
SYSTEM— ............................................................
189
Fail Safe .............................................................. ..199
SYMPTOM DIAGNOSIS ............................200
INTELLIGENT KEY SYSTEM SYMPTOMS ... .200
Symptom Table ................................................... ..200
DOOR LOCK FUNCTION SYMPTOMS ..........201
DOOR LOCK AND UNLOCK SWITCH ................. ..201
DOOR LOCK AND UNLOCK SWITCH : Symptom
Table ......................................................................
201
INTELLIGENT KEY ................................................ ..202
INTELLIGENT KEY : Symptom Table ..................202
BACK DOOR OPENER FUNCTION ................204
BACK DOOR OPENER SWITCH .......................... .204
BACK DOOR OPENER SWITCH : Symptom Ta-
ble ........................................................................ .
204
BACK DOOR SWITCH ........................................... .204
BACK DOOR SWITCH : Symptom Table .............205
INTELLIGENT KEY ................................................ .205
INTELLIGENT KEY : Symptom Table ..................205
WARNING FUNCTION SYMPTOMS ...............206
Symptom Table .................................................... .206
KEY REMINDER FUNCTION SYMPTOMS .....209
Symptom Table .................................................... .209
HAZARD FUNCTION ..................................... ..210
Symptom Table .................................................... .210
HORN FUNCTION ............................................211
Symptom Table .................................................... .211
HOMELINK UNIVERSAL TRANSCEIVER ......212
Symptom Table .................................................... .212
SQUEAK AND RATTLE TROUBLE DIAG-
NOSES ..............................................................
213
Work Flow ............................................................ .213
Inspection Procedure ............................................215
Diagnostic Worksheet ...........................................217
PRECAUTION ...........................................219
PRECAUTIONS .............................................. ..219
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" .............................................................. .
219
Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect ................................
219
Precaution for work ...............................................220
PREPARATION .........................................221
PREPARATION .............................................. ..221
Special Service Tool ............................................ .221
Commercial Service Tool ......................................222
ON-VEHICLE REPAIR ..............................223
HOOD ............................................................. ..223
Fitting Adjustment ................................................ .223
Removal and Installation of Hood Assembly ........224
Removal and Installation of Hood Lock Control ....225
Hood Lock Control Inspection ...............................226
DOOR ............................................................. ..228
Fitting Adjustment ................................................ .228
Removal and Installation .......................................229
Revision: March 2010 2008 QX56
Page 805 of 4083
![INFINITI QX56 2008 Factory User Guide DLK-12
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK FUNCTION
DOOR REQUEST SWITCH
DOOR REQUEST SWITCH : System DiagramINFOID:0000000001538910
DOOR REQUEST SWITCH : System DescriptionIN](/img/42/57030/w960_57030-804.png "INFINITI QX56 2008 Factory User Guide DLK-12
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK FUNCTION
DOOR REQUEST SWITCH
DOOR REQUEST SWITCH : System DiagramINFOID:0000000001538910
DOOR REQUEST SWITCH : System DescriptionIN")
DLK-12
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK FUNCTION
DOOR REQUEST SWITCH
DOOR REQUEST SWITCH : System DiagramINFOID:0000000001538910
DOOR REQUEST SWITCH : System DescriptionINFOID:0000000001538911
Only when pressing the request switch, it is possible
to lock and unlock the door by carrying the Intelligent
Key.
• The Intelligent Key system is a system that makes it possible to lock and unlock the door locks (door lock/
unlock function) by carrying the Intelligent Key, which operates based on the results of electronic ID verifica-
tion using two-way communications between the Intelligent Key and the vehicle (BCM).
CAUTION:
The driver should always carry the Intelligent Key
• If an action that does not meet the operating conditions of the Intelligent Key system is taken, the buzzer
goes off to inform the driver (Warning chime function).
• When a door lock is locked or unlocked with request switch or remote controller button operation, the hazard
lamps flash and the Intelligent Key warning buzzer or horn sounds (Hazard and buzzer/horn reminder func-
tion).
• The settings for each function can be changed with the CONSULT-III.
• If an Intelligent Key is lost, a new Intelligent Key can be registered. A maximum of 4 Intelligent Keys can be
registered.
• It is possible to perform a diagnosis on the system and register an Intelligent Key with the CONSULT-III.
OPERATION DESCRIPTION/DOOR LOCK/UNLOCK
• When the BCM detects that each door request switch is pressed, it starts the outside key antenna and inside
key antenna corresponding to the pressed door request swit ch and transmits the request signal to the Intelli-
gent Key. And then, check that t he Intelligent Key is near the door.
• If the Intelligent Key is within the outside key ant enna detection area, it receives the request signal and
transmits the key ID signal to the BCM via remote keyless entry receiver.
• BCM receives the key ID signal and compares it with the registered key ID.
• BCM sends the door lock/unlock signal and sounds Intelli gent Key buzzer warning (lock: 2 times, unlock: 1
time) at the same time as a reminder.
OPERATION CONDITION
If the following conditions are not satisfied, door lock/unlock operation is not performed even if the request
switch is operated.
Door switch Transmits door open/close condition to BCM.
Passenger select unlock relay Enables or disables the unlocking of rear doors when this Intelligent Key option is selected. Item
Function
ALKIA0704GB
Revision: March 2010 2008 QX56
Page 809 of 4083
![INFINITI QX56 2008 Factory User Guide DLK-16
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK FUNCTION
ALKIA0579ZZ
1. Horn E3
(view with hood open) 2. IPDM E/R E122, E124
(view with cover removed) 3. Horn relay H-1
4. Remote](/img/42/57030/w960_57030-808.png "INFINITI QX56 2008 Factory User Guide DLK-16
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK FUNCTION
ALKIA0579ZZ
1. Horn E3
(view with hood open) 2. IPDM E/R E122, E124
(view with cover removed) 3. Horn relay H-1
4. Remote")
DLK-16
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK FUNCTION
ALKIA0579ZZ
1. Horn E3
(view with hood open) 2. IPDM E/R E122, E124
(view with cover removed) 3. Horn relay H-1
4. Remote keyless entry receiver M25 (view with instrume nt panel RH removed) 5. Intelligent key warning buzzer E25 6. Combination meter M23, M24
7. Intelligent Key unit M70 (view with instrument panel LH removed) 8. BCM M18, M19, M20
(view with instrument panel LH removed) 9. Steering lock solenoid M15
(view with steering column removed)
10. Key switch and ignition knob switch M12 11. A/T shift selector (park position switch) M203
(view with center console removed)12. Inside key antenna 3 (front of center
console) M210
(view with center console removed)
13. Inside key antenna 1 (rear of center con- sole) M209 14. Inside key antenna 4 (overhead console
area) R210
(view with overhead console removed) 15. Inside key antenna 2 (luggage com-
partment) B76
(view with rear carpet removed)
16. Rear bumper antenna C7 (view with rear bumper removed) 17. Back door latch D503
18. Front outside antenna LH D15
Front outside antenna RH D115
19. Front door request switch LH D16 Front door request switch RH D116 20. Front door lock assembly LH (door un-
lock sensor) D14 21. Front door switch LH B8
RH B108
22. Rear door switch LH B18 RH B116
Revision: March 2010 2008 QX56
Page 810 of 4083
![INFINITI QX56 2008 Factory User Guide DOOR LOCK FUNCTIONDLK-17
< FUNCTION DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR REQUEST SWITCH : Component DescriptionINFOID:0000000001538913
INTELLIGENT KEY
INTEL](/img/42/57030/w960_57030-809.png "INFINITI QX56 2008 Factory User Guide DOOR LOCK FUNCTIONDLK-17
< FUNCTION DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR REQUEST SWITCH : Component DescriptionINFOID:0000000001538913
INTELLIGENT KEY
INTEL")
DOOR LOCK FUNCTIONDLK-17
< FUNCTION DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR REQUEST SWITCH : Component DescriptionINFOID:0000000001538913
INTELLIGENT KEY
INTELLIGENT KEY : System DiagramINFOID:0000000001538914
INTELLIGENT KEY : System DescriptionINFOID:0000000001538915
The Intelligent Key has the same functions as the remote control entry system. In addition to other safety fea-
tures, it can be used to lock and unlock all doors as well as open the back door.
OPERATION DESCRIPTION/DOOR LOCK/UNLOCK FUNCTION
• When door lock/unlock button of the Intelligent Key is pressed, lock signal or unlock signal is transmitted from Intelligent Key to BCM via remote keyless entry receiver and Intelligent Key unit.
• When BCM receives the door lock/unlock signal, it oper ates door lock actuator, flashes the hazard lamp
(lock: 2 times, unlock: 1 time) and horn chirp signal to IPDM E/R at the same time as a reminder.
• IPDM E/R honks horn (lock: 2 times) as a reminder
OPERATION CONDITION
OPERATION AREA
• Operating Range
Item Function
Intelligent Key unit Receives lock/unlock signal from re mote keyless entry receiver, and then transmits to BCM.
BCM Controls the door lock function and room lamp function.
Door lock and unlock switch Transmits lock or unlock signal to BCM.
Door lock actuator Receives lock/unlock signal from BCM and locks/unlocks each door.
Door switch Transmits door open/close condition to BCM.
Remote keyless entry receiver Receives lock/unlock signal from the Intelligent Key, and then transmits to Intelligent Key unit.
Request switch Transmits lock/unlock operation to Intelligent Key unit.
Intelligent Key Transmits button operation to remote keyless entry receiver.
Outside key antenna Detects if Intelligent Key is outside the vehicle.
Inside key antenna Detects if Intelligent Key is inside the vehicle.
Intelligent Key warning buzzer Warns the user of the lock/unlock condition and inappropriate operations with the buzzer sound.
ALKIA0704GB
Remote controller operation Operation conditionOperation
Lock • All doors closed All doors lock
Unlock • Intelligent Key is out of the ignition key cylinder All doors unlock
Revision: March 2010 2008 QX56
Page 811 of 4083
![INFINITI QX56 2008 Factory User Guide DLK-18
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK FUNCTION
• To ensure the Intelligent Key works effectively, us
e within 80 cm range of each doors, however the operable
range may](/img/42/57030/w960_57030-810.png "INFINITI QX56 2008 Factory User Guide DLK-18
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK FUNCTION
• To ensure the Intelligent Key works effectively, us
e within 80 cm range of each doors, however the operable
range may")
DLK-18
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK FUNCTION
• To ensure the Intelligent Key works effectively, us
e within 80 cm range of each doors, however the operable
range may differ according to surroundings.
SELECTIVE UNLOCK FUNCTION
When a LOCK signal is transmitted from Intelligent Key, all doors will be locked.
When an UNLOCK signal is transmitted from Inte lligent Key once, driver's door will be unlocked.
Then, if an UNLOCK signal is transmitted from Intell igent Key again within 5 seconds, all other doors will be
unlocked.
When a liftgate signal is transmitted from Intelligent Key for more than 0.5 second, the back door operates to
the full open position. After opening, another signal will cause the back door to close.
HAZARD AND HORN REMINDER FUNCTION
When doors are locked or unlocked by Intelligent Key, BCM flashes hazard warning lamps as a reminder and
sends horn chirp signal to IPDM E/R. IPDM E/R sounds horn as a reminder.
The hazard and horn reminder has a horn chirp mode (C mode) and a non-horn chirp mode (S mode).
Operating function of hazard and horn reminder
Hazard and horn reminders do not operate if any door switch is ON (any door is OPEN).
How to change hazard and horn reminder mode
With CONSULT-III
Refer to DLK-51, "
INTELLIGENT KEY : CONSULT-III Function (BCM - INTELLIGENT KEY)".
Without CONSULT-III
Refer to Owner's Manual for instructions.
AUTO DOOR LOCK FUNCTION
Auto Door Lock Function
When all doors are locked, ignition switch is OFF (ignition switch is not pressed) and key switch is OFF, doors
are unlocked with Intelligent Key button. When BCM does not receive the following signals within 30 seconds,
all doors are locked.
• Door switch is ON (door is opened)
• Door is locked
• Ignition switch is ON
• Key switch is ON (mechanical key is inserted in ignition key cylinder)
Auto door lock mode can be changed by DOOR LOCK -UNLOCK SET mode in “WORK SUPPORT”. Refer to
DLK-48, "
DOOR LOCK : CONSULT-III Function (BCM - DOOR LOCK)".
PANIC ALARM FUNCTION
When ignition switch is OFF (ignition switch is not pr essed) and key switch is OFF, BCM receives PANIC
ALARM signal from Intelligent Key through the remote keyless entry receiver and the Intelligent Key unit.
BCM turns on and off headlamp intermittently and transmits theft warning horn signal to IPDM E/R. Then,
IPDM E/R turns on and off horn intermittently.
The headlamp flashes and the horn sounds intermittently.
The alarm automatically turns off:
• After 25 seconds
• When BCM receives any signal from Intelligent Key
Panic alarm function mode can be changed by PANIC ALARM SET mode in “WORK SUPPORT”. Refer to
DLK-51, "
INTELLIGENT KEY : CONSULT-III Function (BCM - INTELLIGENT KEY)".
KEYLESS POWER WINDOW DOWN (OPEN) FUNCTION
Front power windows (with left and right front power window anti-pinch system) open when the unlock button
on Intelligent Key is activated and kept pressed for more than 3 seconds with the ignition switch OFF. The win-
dows keep opening if the unlock button is continuously pressed.
The power window opening stops when the following operations are performed:
• When the unlock button is kept pressed more than 15 seconds.
• When the ignition switch is turned ON while the power window opening is operated.
• When the unlock button is released.
C mode S mode
Intelligent Key operation Lock UnlockBack door
open Lock Unlock Back door
open
Hazard warning lamp flashTwice Once —Twice ——
Horns sound Once—————
