WARNING CHIME FUNCTION
DescriptionINFOID:0000000003775788
Performs operation method guide and warning with buzzer.
Component Function CheckINFOID:0000000003775789
1.CHECK FUNCTION
With CONSULT-III
1. Check the operation with "INSIDE BUZZER" in the Active Test.
2. Touch “TAKE OUT”, “KNOB”or “KEY” on screen.
Is the inspection result normal?
Yes >> Warning buzzer into combination meter is OK.
No >> Refer to D L K - 111 , "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003775790
1.CHECK METER BUZZER CIRCUIT
The inoperative warning chime is contained inside the combination meter. Replace combination meter. Refer
to MWI-102, "
Removal and Installation".
>> Inspection End.
Revision: December 20092009 QX56

DLK-112
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
HAZARD FUNCTION
HAZARD FUNCTION
DescriptionINFOID:0000000003775791
Perform answer-back for each operation with number of blinks.
Component Function CheckINFOID:0000000003775792
1.CHECK FUNCTION
Check hazard warning lamp "FLASHER" in ACTIVE TEST.
Is the inspection result normal?
YES >> Hazard warning lamp circuit is OK.
NO >> Refer to DLK-112, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003775793
1.CHECK HAZARD SWITCH CIRCUIT
Operate the hazard lights by turni ng ON the hazard warning switch.
Do the lights operate normally?
YES >> Replace the BCM. Refer to BCS fo r replacement and configuration procedure.
NO >> Repair or replace hazard warning switch circuit. Refer to EXL-78, "
Wiring Diagram".
Revision: December 20092009 QX56

AUTOMATIC BACK DOOR SELF-DIAGNOSIS PROCEDUREDLK-123
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
AUTOMATIC BACK DOOR SELF-DIAGNOSIS PROCEDURE
Self-Diagnosis ProcedureINFOID:0000000003775801
INPUT SIGNAL CHECK MODE
Input signal check mode allows testing of swit ch input signal to the back door control unit.
To activate input signal check mode on the automatic sliding door, perform the following steps:
1. Turn ignition switch OFF.
2. Turn back door close switch to CANCEL (system cancelled).
3. Place A/T shift selector in P position.
4. Using the inside emergency release lever, open the back door.
5. Have an assistant press and hold the back door handle switch.
6. While the assistant continues to hold the back door handle switch, turn ignition switch ON (DO NOT start
engine).
7. After approximately 5 seconds, the back door warning chime will sound for 0.5 seconds.
8. Release the back door handle switch.
9. Within 8 seconds of the back door warning chime sounding, press and hold the power liftgate switch.
10. After approximately 5 seconds, the back door warning chime will sound for 1 second.
11. Release the power liftgate switch.
12. The input signal check mode is now initialized.
The input signal check mode can test the following inputs. The back door warning chime will sound for approx-
imately 0.5 second each time a switch signal input oc curs. Use this test when one of these inputs is not
responding during normal automatic back door operation.
*Back door warning chime should sound as soon as vehicle moves.
Turn ignition switch OFF to end input signal check mode.
OPERATING CHECK MODE
Operating check mode allows self-diagnos is of the automatic back door system.
To activate operating check mode on the automatic back door, perform the following steps:
1. Turn ignition switch OFF.
2. Turn back door close switch to CANCEL (system cancelled).
3. Place A/T shift selector in P position.
4. Using the inside emergency release lever, open the back door.
5. Have an assistant press and hold the back door handle switch.
6. While the assistant continues to hold the back door handle switch, turn ignition switch ON (DO NOT start engine).
7. After approximately 5 seconds, the back door warning chime will sound for 0.5 second.
8. Release the back door handle switch.
Switch signal OperationRefer to
Power liftgate switch OFF → ONDLK-129
Back door close switch (CLOSE) OFF → ON DLK-131
Back door close switch (CANCEL) OFF → ON DLK-132
Back door handle switch OFF → ON DLK-138
A/T shift selector (park position switch) P position → other than P position DLK-101
Vehicle speed* Vehicle speedTM-49
Remote keyless entry signal Keyfob switch OFF → ON DLK-103
Door lock/unlock signal LOCK → UNLOCK DLK-74
Pinch strip LH signal OFF → ON DLK-133
Pinch strip RH signal OFF → ON DLK-133
Revision: December 20092009 QX56

DLK-124
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
AUTOMATIC BACK DOOR SELF-DIAGNOSIS PROCEDURE
9. Within 8 seconds of the back door warning chime
sounding, press the power liftgate switch 5 times in
rapid succession.
10. After approximately 5 seconds, the back door warning chime will sound for 1 second.
11. Release the power liftgate switch.
12. Immediately close the back door manually.
13. Press and release the power liftgate swit ch to activate the operating check mode.
Self-diagnosis results are indicated by the back door warning chime.
Turn ignition switch OFF to end input signal check mode.
Back door warning chime order Back door warning chime length
Start self-diagnosis 1.5 seconds
OK NG
1. Operating conditions diagnosis 0.5 second0.2 second
2. Back door encoder diagnosis 0.5 second0.2 second
3. Back door clutch diagnosis 0.5 second0.2 second
4. Back door motor diagnosis 0.5 second0.2 second
5. Cinch latch motor diagnosis 0.5 second0.2 second
Restart self-diagnosis 1.5 seconds
ItemNG ResultRefer to
1. Operating conditions diagnosis result One of the following operating conditions no
longer met: ignition switch ON, back door close
switch (CANCEL) ON, A/T shift selector in P
position—
2. Back door encoder diagnosis result Sensor diagnosis/short, pulse signal, pulse
signal directionDLK-243
3. Back door clutch diagnosis result
Back door clutch does not operateDLK-243
4. Back door motor diagnosis result Back door motor does not operate (no operat-
ing current)
DLK-243
5. Cinch latch motor diagnosis result Cinch latch motor does not operate (no operat-
ing current)DLK-243
Revision: December 20092009 QX56

DLK-134
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
BACK DOOR WARNING CHIME SYSTEM
BACK DOOR WARN
ING CHIME SYSTEM
Diagnosis ProcedureINFOID:0000000003775807
1.BACK DOOR WARNING CHI ME CIRCUIT INSPECTION
1. Disconnect back door control unit and back door warning chime.
2. Check continuity between back door control unit connector (A) B55 terminal 6 and back door warning chime connector (B)
D514 terminal 1.
3. Check continuity between back door control unit connector (A) B55 terminal 6 and ground.
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair or replace the harness between t he warning chime and the back door control unit.
2.WARNING CHIME CIRCUIT INSPECTION
1. Check continuity between back door control unit connector (A) B55 terminal 9 and back door warning chime connector (B)
D514 terminal 2.
2. Check continuity between back door control unit connector (A) B55 terminal 9 and ground.
Is the inspection result normal?
YES >> Replace warning chime.
NO >> Repair or replace the harness between t he warning chime and the back door control unit.
6 - 1 : Continuity should exist.
6 - Ground : Continuity should not exist.
ALKIA0673ZZ
9 - 2
: Continuity should exist.
9 - Ground : Continuity should not exist.
ALKIA0674ZZ
Revision: December 20092009 QX56
