A/T SHIFT SELECTOR (PARK POSITION SWITCH)
Diagnosis ProcedureINFOID:0000000003775773
1.CHECK A/T SHIFT SELECTOR (PARK POSITION SWITCH) INPUT SIGNAL
1. Turn ignition switch OFF.
2. While pressing the ignition knob switch, check voltage between Intelligent Key unit harness connector M70 terminal 39 and ground.
Is the inspection result normal?
YES >> Replace Intelligent Key unit. Refer to S E C - 111 ,
"Removal and Installation".
NO >> GO TO 2
2.CHECK A/T SHIFT SELECTOR (PARK POSI TION SWITCH) POWER SUPPLY CIRCUIT
1. Disconnect A/T shift selector (park position switch) connector.
2. While pressing the ignition knob switch, check voltage between A/T shift selector (park position switch) harness connector M203
terminal 5 and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness or ignition knob switch.
3.CHECK A/T SHIFT SELECTOR (PARK POSITION SWITCH)
Check continuity between A/T shift selector (park position switch) terminals 5 and 6.
Is the inspection result normal?
YES >> GO TO 4
NO >> Replace A/T shift selector (park position switch).
4.CHECK A/T SHIFT SELECTOR (PARK POSITION SWITCH) CIRCUIT
1. Disconnect Intelligent Key unit connector.
Connector Te r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (-)
M70 39 Ground A/T shift selector is in "P" posi-
tion
Battery voltage
Other than above 0
WIIA1211E
5 – Ground : Battery voltage.
ALKIA0663ZZ
Component Terminals ConditionContinuity
A/T shift se- lector (park position
switch) 56A/T shift selector is in "P" posi-
tion
Ye s
Other than above No
ALKIA0664ZZ
Revision: December 20092009 QX56

DLK-106
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY BATTERY AND FUNCTION
INTELLIGENT KEY BATTERY AND FUNCTION
DescriptionINFOID:0000000003775777
The following functions are available when having and carrying electronic ID.
• Door lock/unlock
• Back door open
Remote control entry function and panic alarm functi
on are available when operating the remote buttons.
Component Function CheckINFOID:0000000003775778
1.CHECK FUNCTION
With CONSULT-III
Check remote keyless entry receiver "RKE OPE COUN1" in DATA MONITOR mode with CONSULT-III.
Is the inspection result normal?
YES >> Intelligent Key is OK.
NO >> Refer to DLK-106, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003775779
1.CHECK INTELLIGENT KEY FUNCTION
Check keyfob function using Remote Keyless Entry Tester J-43241.
Does the test pass?
YES >> Intelligent Key is OK.
NO >> GO TO 2
2. CHECK INTELLIGENT KEY COMPONENTS
1. Release the lock knob at the back of the Intelligent Key and remove the mechanical key.
2. Insert a flat-blade screwdriver (A) wrapped with a cloth into the slit of the corner and twist it to separate the upper part from the
lower part.
CAUTION:
• Do not touch the circuit board or battery terminal.
• The keyfob is water-resistant. However, if it does get wet,
immediately wipe it dry.
3. Remove the Intelligent Key battery.
CAUTION:
• Keep dirt, grease, and other fo reign materials off the elec-
trode contact area.
4. Visually inspect keyfob internal components.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace malfunctioning parts.
3.CHECK INTELLIGENT KEY BATTERY
Monitor item Condition
RKE OPE COUN1 Check that the numerical value is changing while operating the Intelligent Key.
LEL946A
PIIB6221E
Revision: December 20092009 QX56

KEY SWITCH (INTELLIGENT KEY UNIT INPUT)
DLK-113
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
KEY SWITCH (INTELLIGENT KEY UNIT INPUT)
Diagnosis ProcedureINFOID:0000000003775794
1.CHECK KEY SWITCH
With CONSULT-III
Check key switch (“KEY SW”) in “DATA MONITOR” mode with CONSULT-III.
Without CONSULT-III
1. Turn ignition switch OFF.
2. Disconnect Intelligent Key unit harness connector.
3. Check voltage between Intelligent Key unit harness connector M70 terminal 7 and ground.
Is the inspection result normal?
YES >> Key switch is OK.
NO >> GO TO 2
2.CHECK KEY SWITCH POWER SUPPLY CIRCUIT
1. Remove mechanical key from ignition switch.
2. Disconnect key switch and i gnition knob switch connector.
3. Check voltage between key switch and ignition knob switch harness connector M12 terminal 3 and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace key switch and ignition knob switch power supply circuit.
3.CHECK KEY SWITCH OPERATION
Monitor item Condition
KEY SW Insert mechanical key into ignition switch: ON
Remove mechanical key from ignition switch: OFF
ConnectorTe r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (–)
M70 7 Ground Insert mechanical key
into ignition switch
Battery voltage
Remove mechanical
key from ignition switch 0
WIIA1173E
3 - Ground
: Battery voltage
PIIB4254E
Revision: December 20092009 QX56

DLK-114
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
KEY SWITCH (INTELLIGENT KEY UNIT INPUT)
Check continuity between key switch and ignition knob switch termi-
nals 3 and 4.
Is the inspection result normal?
YES >> GO TO 4
NO >> Replace key cylinder assembly (built-in key switch).
4.CHECK KEY SWITCH CIRCUIT
1. Check continuity between Intelligent Key unit harness connector (A) M70 terminal 7 and key switch and ignition knob switch harness connector (B) M12 terminal 4.
2. Check continuity between Inte lligent Key unit harness connector
(A) M70 terminal 7 and ground.
Is the inspection result normal?
YES >> Check the condition of harness and harness connector.
NO >> Repair or replace harness between Intelligent Key unit and key switch and ignition knob switch.
Component Terminals ConditionContinuity
Key switch 3 4 Insert mechanical key
into ignition switch.
Ye s
Remove mechanical key
from ignition switch. No
PIIA6140E
7 - 4
: Continuity should exist.
7 - Ground : Continuity should not exist.
WIIA1174E
Revision: December 20092009 QX56

KEY SWITCH (BCM INPUT)DLK-115
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
KEY SWITCH (BCM INPUT)
Diagnosis ProcedureINFOID:0000000003775795
1.CHECK KEY SWITCH POWER SUPPLY CIRCUIT
1. Remove mechanical key from ignition switch.
2. Disconnect key switch and i gnition knob switch connector.
3. Check voltage between key switch and ignition knob switch har- ness connector M12 terminal 3 and ground.
Is the inspection result normal?
YES >> GO TO 2
NO >> Check harness between key switch and ignition knob switch and fuse.
2.CHECK KEY SWITCH
Check continuity between key switch and ignition knob switch termi-
nals 3 and 4.
Is the inspection result normal?
YES >> GO TO 3
NO >> Replace key cylinder assembly (built-in key switch).
3.CHECK KEY SWITCH SIGNAL CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between BCM harness connector M18 terminal 37 and key switch and ignition knob switch harness connector
M12 terminal 4.
3. Check continuity between BCM harness connector M18 terminal 37 and ground.
Is the inspection result normal?
YES >> Key switch (BCM input) circuit is OK.
NO >> Repair or replace harness between key switch and ignition knob switch and BCM. 3 – Ground
: Battery voltage.
PIIB4254E
Component Terminals ConditionContinuity
Ignition switch 34 Insert mechanical key
into ignition switch.
Ye s
Remove mechanical key
from ignition switch. No
PIIA6140E
37 – 4
: Continuity should exist.
37 – Ground : Continuity should not exist.
PIIB4256E
Revision: December 20092009 QX56

DLK-116
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
IGNITION KNOB SWITCH
IGNITION KNOB SWITCH
Ignition Knob
Switch CheckINFOID:0000000003775796
1.CHECK IGNITION KNOB SWITCH
With CONSULT-III
Display “PUSH SW” on DATA MONITOR screen, and check if ON/OFF display is linked to ignition switch oper-
ation.
Without CONSULT-III
1. Turn ignition switch OFF.
2. Disconnect Intelligent Key unit connector.
3. Check voltage between Intelligent Key unit harness connector M70 terminal 27 and ground.
Is the inspection result normal?
YES >> Ignition knob switch is OK.
NO >> GO TO 2
2.CHECK IGNITION KNOB SWITCH POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect key switch and ignition knob switch connector.
3. Check voltage between key switch and ignition knob switch harness connector M12 terminal 1 and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace key switch and ignition knob switch power supply circuit.
3.CHECK IGNITION KNOB SWITCH OPERATION
Check continuity between key switch and ignition knob switch terminals 1 and 2.
Monitor item Condition
PUSH SW Ignition switch is pushed: ON
Ignition switch is released: OFF
ConnectorTe r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (–)
M70 27 Ground Ignition switch is
pushed
Battery voltage
Ignition switch is re-
leased 0
WIIA1175E
1 - Ground
: Battery voltage
PIIB4257E
Revision: December 20092009 QX56

IGNITION KNOB SWITCHDLK-117
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> GO TO 4
NO >> Replace key switch and ignition knob switch.
4.CHECK IGNITION KN OB SWITCH CIRCUIT
1. Check continuity between Intelligent Key unit harness connector (A) M70 terminal 27 and key switch and ignition knob switch harness c onnector (B) M12 terminal 2.
2. Check continuity between Intelligent Key unit harness connector M70 terminal 27 and ground.
Is the inspection result normal?
YES >> Check the condition of harness and harness connector.
NO >> Repair or replace harness between Intelligent Key unit and key switch and ignition knob switch.
Component Terminals ConditionContinuity
Ignition
knob switch 12 Ignition switch is pushed Yes
Ignition switch is released No
PIIA9929E
27 - 2
: Continuity should exist.
27 - Ground : Continuity should not exist.
WIIA1176E
Revision: December 20092009 QX56

POWER LIFTGATE SWITCH FUNCTIONDLK-125
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
POWER LIFTGATE SWITCH FUNCTION
Diagnosis ProcedureINFOID:0000000003775802
1.POWER LIFTGATE SWITCH FUNCTION INSPECTION
Check power liftgate switch using switch operation.
Did the back door respond correctly?
YES >> Power liftgate switch is OK.
NO >> GO TO 2
2.POWER LIFTGATE SWITCH SIGNAL INSPECTION
1. Turn ignition switch OFF.
2. While operating the power liftgate switch, check voltage between back door control unit connector B55 terminal 23 and
ground.
Is the inspection result normal?
YES >> Switch is OK.
NO >> GO TO 3
3.POWER LIFTGATE SWITCH CIRCUIT INSPECTION
1. Disconnect back door control unit and power liftgate switch connectors.
2. Check continuity between back door control unit connector (A) B55 terminal 23 and power liftgate switch connector (B) M92 ter-
minal 1.
3. Check continuity between back door control unit connector (A) B55 terminal 23 and ground.
Is the inspection result normal?
YES >> GO TO 4
NO >> Repair the harness between the power liftgate switch and the back door control unit.
4.POWER LIFTGATE SWITCH GROUND INSPECTION
Check continuity between power liftgate switch connector terminal 2
and ground.
Is the inspection result normal?
YES >> GO TO 5
NO >> Repair the harness between the power liftgate switch and ground.
5.POWER LIFTGATE SWITCH POWER SUPPLY CIRCUIT INSPECTION
1. Reconnect back door control unit.
2. Ensure liftgate is closed.
Te r m i n a l Measuring condition Voltage (V)
(Approx.)
(+) (-)
23 GroundPower liftgate
switch ON
0
OFF Battery voltage
LIIA0802E
23 - 1 : Continuity should exist.
23 - Ground : Continuity should not exist.
ALKIA0670ZZ
2 - Ground : Continuity should exist.
LIIA1065E
Revision: December 20092009 QX56

GLASS HATCH SWITCHDLK-127
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
GLASS HATCH SWITCH
Diagnosis ProcedureINFOID:0000000004190670
NOTE:
Repair any front door lock actuator RH malf unction before proceeding with this diagnosis.
1.CHECK GLASS HATCH SWITCH
1. Turn ignition switch OFF.
2. Insure front door lock actuator RH is in the unlock position.
3. Check continuity between glass hatch switch terminal 2 and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK HARNESS CONTINUITY
1. Disconnect glass hatch switch.
2. Disconnect BCM.
3. Check continuity between BCM connector M18 (A) terminal 30 and glass hatch switch connector D706 (B) terminal 2.
4. Check continuity between BCM connector M18 (A) terminal 30 and ground.
Is the inspection result normal?
YES >> Glass hatch switch circuit is OK.
NO >> Repair or replace harness.
3.CHECK GLASS HATCH SWITCH
1. Disconnect glass hatch switch.
2. Check continuity between glass hatch switch harness connector D706 terminal 1 and ground.
Is the inspection result normal?
YES >> Replace glass hatch switch.
NO >> GO TO 4.
4.CHECK HARNESS CONTINUITY
1. Disconnect front door lock actuator RH.
Connec- tor Te r m i n a l s
ConditionContinuity
(+) (–)
D706 2 Ground With the glass hatch switch
pressed
Ye s
With the glass hatch switch
released No
LIIA2399E
30 - 2
: Continuity should exist.
30 - Ground : Continuity should not exist.
LIIA2400E
1 - Ground: Continuity should exist.
LIIA2401E
Revision: December 20092009 QX56

GLASS HATCH AJAR SWITCHDLK-129
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
GLASS HATCH AJAR SWITCH
Diagnosis ProcedureINFOID:0000000003775803
1.CHECK GLASS HATCH AJAR SWITCH INPUT SIGNALWith CONSULT-III
Check glass hatch ajar switch ("TRNK OPN MNTR") in DATA MONITOR mode with CONSULT–III.
• When glass hatch is open:
• When glass hatch is closed:
Without CONSULT-III
Check voltage between BCM connector M19 terminal 42 and ground.
Is the inspection result normal?
YES >> System is OK.
NO >> GO TO 2
2.CHECK GLASS HATCH AJAR SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect glass hatch ajar switch, BCM and back door control unit.
3. Check continuity between BCM connector (A) M19 te rminal 42 and glass hatch ajar switch connector (C)
D707 terminal 1.
4. Check continuity between back door control unit connector B55
(B) terminal 17 and glass hatch ajar switch connector (C) D707
terminal 1.
5. Check continuity between glass hatch ajar switch connector (C) D707 terminal 1 and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness.
3.CHECK GLASS HATCH AJAR SWITCH
1. Disconnect glass hatch ajar switch connector.
2. Check continuity between glass hatch ajar switch connector terminal 1 and ground. TRNK OPN MNTR : ON
TRNK OPN MNTR : OFF
Connector Item
Te r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (–)
M19 BCM 42 Ground Open
↓
Closed 0
↓
Battery voltage
LIIA1149E
42 - 1 : Continuity should exist.
17 - 1 : Continuity should exist.
1 - Ground : Continuity should not exist.
ALKIA0667ZZ
Revision: December 20092009 QX56
