DTC 98 GEAR POSITION
DTC 98 GEAR POSITION
DTC 98 GEAR POSITIONINFOID:0000000003776950
1.DIAGNOSTIC CHECK
Perform ICC self diagnosis.
Does "DTC 43 VDC/TCS/ABS CIRC" or "DTC 41 VHCL SP EED SE CIRC" indicated in self-diagnosis display
item?
YES >> Repair or replace as necessary. Erase DTC and perform self-diagnosis of ICC system again.
NO >> GO TO 2
2.CHECK VEHICLE SPEED SIGNAL
With data monitor, check that “VHCL SPEED SE” is normal.
Does the "VHCL SPEED SE" monitor item display normally?
YES >> GO TO 3
NO >> Replace ICC unit. Refer to CCS-70, "
ICC Unit". Erase DTC and perform self-diagnosis of ICC sys-
tem again.
3.CHECK GEAR SHIFT POSITION
Check that gear positions are correct in A/T.
Does the transmission operate normally?
YES >> GO TO 5
NO >> GO TO 4
4.CHECK TCM GEAR POSITION SIGNAL
With TCM data monitor, check that gear positions are correct.
Does the data monitor indicate proper gear positions?
YES >> Replace ICC unit. Refer to CCS-70, "ICC Unit".
NO >> • Perform TCM diagnosis.
• Erase DTC and perform self-d iagnosis of ICC system again.
5.CHECK TCM TURBINE ROTATION
With TCM diagnosis, check that turbine rpm is normal. Refer to TM-47, "
Description".
Does the TCM check OK?
YES >> Replace ICC unit. Refer to CCS-70, "ICC Unit".
NO >> • Perform TCM diagnosis.
• Erase DTC and perform self-d iagnosis of ICC system again. CCS-17, "
Diagnosis Description"
Revision: December 20092009 QX56

CCS
DTC 102 LASER STAINCCS-41
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
K L
M B
N P A
DTC 102 LASER STAIN
DTC 102 LASER STAININFOID:0000000003776951
1.VISUAL INSPECTION (1)
Check that there is no cont amination and foreign material on ICC sensor body window.
Is the ICC sensor clean?
YES >> GO TO 2
NO >> • Clean ICC sensor. • Erase DTC and perform ICC system running test. Refer to CCS-8, "
ACTION TEST : ICC Sys-
tem Running Test".
2.VISUAL INSPECTION (2)
Check ICC sensor body window for cracks.
Is the ICC sensor window undamaged?
YES >> GO TO 3
NO >> • Replace ICC sensor and adjust laser beam. Refer to CCS-71, "
ICC Sensor".
• Erase DTC and perform ICC system running test. Refer to CCS-8, "
ACTION TEST : ICC Sys-
tem Running Test".
3.ASK CUSTOMER FOR DRIVING CONDITIONS
1. Is there any trace of contamination or foreign material on ICC sensor?
2. Is there any possibility that vehicle was driven in snow or ICC sensor was frosted?
3. Is there any possibility that ICC sensor was fogged temporarily? (Front window glass may have also been fogged.)
Was the ICC sensor obstructed by normal conditions?
YES >> Explain system operation and parameters to customer. System may be operating normally.
NO >> • Replace ICC sensor and adjust laser beam aiming. Refer to CCS-71, "
ICC Sensor".
• Erase DTC and perform ICC system running test. Refer to CCS-8, "
ACTION TEST : ICC Sys-
tem Running Test".
Revision: December 20092009 QX56

CCS-42
< COMPONENT DIAGNOSIS >
DTC 103 LASER SENSOR FAIL
DTC 103 LASER SENSOR FAIL
DTC 103 LASER SENSOR FAILINFOID:0000000003776952
1.DIAGNOSTIC CHECK
Perform self-diagonsis.
Are "DTC 11 CONTROL UNIT" or DTC 20 CAN COMM CIRCUIT" indicated in self diagnosis?
YES >> GO TO applicable item inspection. Refer to CCS-22, "DTC 11 CONTROL UNIT", and CCS-24,
"DTC 20 CAN COMM CIRCUIT".
NO >> • Replace ICC sensor and adjus t laser beam aiming. Refer to CCS-71, "
ICC Sensor".
• Erase DTC and perform ICC system running test. Refer to CCS-8, "
ACTION TEST : ICC Sys-
tem Running Test".
Revision: December 20092009 QX56

CCS
DTC 104 LASER AIMING INCMPCCS-43
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
K L
M B
N P A
DTC 104 LASER AIMING INCMP
DTC 104 LASER AIMING INCMPINFOID:0000000003776953
1.DIAGNOSTIC CHECK
1. Adjust laser beam aiming. Refer to CCS-5, "
LASER BEAM AIMING ADJUST MENT : Outline of Laser
Beam Aiming Adjustment Procedure". Erase DTC and perform ICC system running test. Refer to CCS-8,
"ACTION TEST : ICC System Running Test".
2. Perform self-diagnosis of ICC system.
Is "DTC 104 LASER AIMING INCMP" indicated?
YES >> • Replace ICC sensor and adjust laser beam aiming. Refer to CCS-71, "ICC Sensor".
• Erase DTC and perform ICC system running test. Refer to CCS-8, "
ACTION TEST : ICC Sys-
tem Running Test".
NO >> Inspection end.
Revision: December 20092009 QX56

CCS-44
< COMPONENT DIAGNOSIS >
DTC 107 LASER COMM FAIL
DTC 107 LASER COMM FAIL
DTC 107 LASER COMM FAILINFOID:0000000003776954
1.DIAGNOSTIC CHECK
Perform self-diagnosis?
Is "DTC 11 CONTROL UNIT" or "DTC 20 CAN COMM CIRCUIT" indicated?
YES >> GO TO applicable item inspection. Refer to CCS-22, "DTC 11 CONTROL UNIT", or CCS-24,
"DTC 20 CAN COMM CIRCUIT".
NO >> • Replace ICC sensor and adjus t laser beam aiming. Refer to CCS-71, "
ICC Sensor".
• Erase DTC and perform ICC system running test. Refer to CCS-8, "
ACTION TEST : ICC Sys-
tem Running Test".
Revision: December 20092009 QX56

CCS
DTC109 LASER HIGH TEMPCCS-45
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
K L
M B
N P A
DTC109 LASER HIGH TEMP
DTC 109 LASER HIGH TEMPINFOID:0000000003776955
1.CHECK SYMPTOM
Inspect engine cooling system.
Did the engine overheat?
YES >> • Repair cooling system. • Erase DTC and perform ICC system running test. Refer to CCS-8, "
ACTION TEST : ICC Sys-
tem Running Test". Then perform self-diagnosis of ICC system again.
NO >> • Replace ICC sensor and adjust laser beam aiming. Refer to CCS-71, "
ICC Sensor".
• Erase DTC, then perform ICC system running test. Refer to CCS-8, "
ACTION TEST : ICC Sys-
tem Running Test". Then perform self-diagnosis of ICC system again.
Revision: December 20092009 QX56

CCS-46
< ECU DIAGNOSIS >
ICC UNIT
ECU DIAGNOSIS
ICC UNIT
Terminal and Reference Value for ICC UnitINFOID:0000000003776956
Te r m i n a lWire col-
or Item Condition
Voltage (V)
(Approx.)
Ignition
switch Operation
1W/L Battery power supply OFF— Battery voltage
2W/L
5 P CAN-L —— —
7 B/R N-P RANGE ON A/T selector lever in "P" or "N"Battery voltage
10 V/R Brake booster signal ON—
14 L CAN-H —— —
19 B Ground
ON——
20 B
29 BR/W ICC brake switch
(normally closed) Selector le-
ver: Not in “N” or “P” position Depress the brake
pedal
0
Release the brake
pedal Battery voltage
30 L TX —— —
33 R/B Ignition switch power supply ON —
Battery voltage
38 R/G St op la mp sw i tc h
(normally open) OFFDepress the brake pedal
Release the brake pedal
0
39 V/W RX —— —
40 G Parking brake signal
ONParking brake is ON
0
Parking brake is OFF Battery voltage
42 R/B Ignition switch power supply —Battery voltage
46 B Ground ——
47 BR Stop lamp drive output signal Brake operating with ICC system
Battery voltage
Brake not operating with ICC sys-
tem 0
SKIA1243E
Revision: December 20092009 QX56

CCS
ICC UNITCCS-47
< ECU DIAGNOSIS >
C
DE
F
G H
I
J
K L
M B
N P A
Wiring DiagramINFOID:0000000003776957
ABOWA0005GB
Revision: December 20092009 QX56

CCS-48
< ECU DIAGNOSIS >
ICC UNIT
ABOWA0004GB
Revision: December 20092009 QX56

CCS
ICC UNITCCS-49
< ECU DIAGNOSIS >
C
DE
F
G H
I
J
K L
M B
N P A
ABOIA0011GB
