Page 388 of 4171
![INFINITI QX56 2009 Factory Service Manual
BCS-14
< FUNCTION DIAGNOSIS >[BCM]
POWER CONSUMPTION CONTROL SYSTEM
Sleep condition
Wake-up operation
BCM transmits sleep wake up signal (wake up) to eac
h unit when any condition listed below is e](/img/42/57031/w960_57031-387.png "INFINITI QX56 2009 Factory Service Manual
BCS-14
< FUNCTION DIAGNOSIS >[BCM]
POWER CONSUMPTION CONTROL SYSTEM
Sleep condition
Wake-up operation
BCM transmits sleep wake up signal (wake up) to eac
h unit when any condition listed below is e")
BCS-14
< FUNCTION DIAGNOSIS >[BCM]
POWER CONSUMPTION CONTROL SYSTEM
Sleep condition
Wake-up operation
BCM transmits sleep wake up signal (wake up) to eac
h unit when any condition listed below is established,
and then goes into normal mode from low power consumption mode.
Each unit starts transmissions with CAN communication by receiving sleep wake up signals. Each unit trans-
mits wake up signals to BCM with CAN communication to convey the start of CAN communication.
Wake-up condition
CAN sleep condition B CM sleep condition
Receiving the sleep-ready signal (ready) from all units
Ignition switch: OFF
Vehicle security system alarm: No operation
Warning lamp: No operation
Warning chime: No operation
Stop lamp switch: OFF
Key switch status: No change for 2 seconds
Hazard warning lamp: No operation
Exterior lamp: OFF
Door lock status: No change for 2 seconds
CONSULT-III communication status: No communication
Door switch status: No change for 2 seconds The controls only BCM are completed.
(Interior room lamp battery saver: Time out etc.)
BCM wake-up condition
Ignition switch: OFF → ACC or ON
Stop lamp switch: ON (Depress brake pedal)
Any door switch: OFF → ON
Lighting switch: OFF → 1ST or PASS
Hazard switch: OFF → ON
Back door opener switch OFF → ON
Remote keyless entry receiver: Receiving
Intelligent Key unit: Receiving
Revision: December 20092009 QX56
Page 390 of 4171
![INFINITI QX56 2009 Factory Service Manual
BCS-16
< FUNCTION DIAGNOSIS >[BCM]
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT-III Fu
nction (BCM - COMMON ITEM)INFOID:0000000003776387
APPLICATION ITEM
CONSULT-II](/img/42/57031/w960_57031-389.png "INFINITI QX56 2009 Factory Service Manual
BCS-16
< FUNCTION DIAGNOSIS >[BCM]
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT-III Fu
nction (BCM - COMMON ITEM)INFOID:0000000003776387
APPLICATION ITEM
CONSULT-II")
BCS-16
< FUNCTION DIAGNOSIS >[BCM]
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT-III Fu
nction (BCM - COMMON ITEM)INFOID:0000000003776387
APPLICATION ITEM
CONSULT-III performs the following functions via CAN communication with BCM.
SYSTEM APPLICATION
BCM can perform the following functions for each system.
NOTE:
It can perform the diagnosis modes except the following for all sub system selection items.
BCM
BCM : CONSULT-III Function (BCM - BCM)INFOID:0000000003776388
WORK SUPPORT
Diagnosis mode Function Description
WORK SUPPORT Changes the setting for each system function.
SELF-DIAG RESULTS Displays the diagnosis results judged by BCM. Refer to BCS-51, "DTC Index"
.
CAN DIAG SUPPORT MNTR Monitors the reception status of CAN communication viewed from BCM.
DATA MONITOR The BCM input/output signals are displayed.
ACTIVE TEST The signals used to activate each device are forcibly supplied from BCM.
ECU IDENTIFICATION The BCM part number is displayed.
CONFIGURATION Enables to read and save the vehicle specification.
Enables to write the vehicle specification when replacing BCM.
System Sub system selection item Diagnosis mode
WORK SUPPORT DATA MONITOR ACTIVE TEST
BCM BCM ×
Door lock DOOR LOCK ×××
Rear window defo gger REAR DEFOGGER ×
Warning chime BUZZER ××
Interior room lamp timer INT LAMP ×××
Remote keyless entry system MULTI REMOTE ENT ××
Exterior lamp HEAD LAMP ×××
Wiper and washer WIPER ×××
Turn signal and hazard warning lamps FLASHER ××
Air conditioner AIR CONDITONER ×
Intelligent Key system INTELLIGENT KEY ×
Combination switch COMB SW ×
Immobilizer IMMU ××
Interior room lamp battery saver BATTERY SAVER ×××
Back door open TRUNK ××
RAP (retained accessory power) RETAINED PWR ×××
Signal buffer system SIGNAL BUFFER ××
TPMS (tire pressure monitoring sys-
tem) AIR PRESSURE MONITOR
×××
Vehicle security system PANIC ALARM ×
Revision: December 20092009 QX56
Page 394 of 4171
![INFINITI QX56 2009 Factory Service Manual
BCS-20
< FUNCTION DIAGNOSIS >[BCM]
DIAGNOSIS SYSTEM (BCM)
MULTIREMOTE ENT : CONSULT-III Function (BCM - MULTIREMOTE ENT)
INFOID:0000000004176237
WORK SUPPORT
Hazard and horn reminder mode
Auto lockin](/img/42/57031/w960_57031-393.png "INFINITI QX56 2009 Factory Service Manual
BCS-20
< FUNCTION DIAGNOSIS >[BCM]
DIAGNOSIS SYSTEM (BCM)
MULTIREMOTE ENT : CONSULT-III Function (BCM - MULTIREMOTE ENT)
INFOID:0000000004176237
WORK SUPPORT
Hazard and horn reminder mode
Auto lockin")
BCS-20
< FUNCTION DIAGNOSIS >[BCM]
DIAGNOSIS SYSTEM (BCM)
MULTIREMOTE ENT : CONSULT-III Function (BCM - MULTIREMOTE ENT)
INFOID:0000000004176237
WORK SUPPORT
Hazard and horn reminder mode
Auto locking function mode
Panic alarm operation mode
Back door open operation mode
Keyless power window down operation mode
DATA MONITOR
Te s t I t e m D e s c r i p t i o n
REMO CONT ID REGIST Keyfob ID code can be registered.
REMO CONT ID ERASUR Keyfob ID code can be erased.
REMO CONT ID CONFIR It can be checked whether keyfob ID code is registered or not in this mode.
HORN CHIRP SET Horn chirp function mode can be changed in this mode. The function mode will be changed when "CHANG SETT" on CONSULT-III screen is touched.
HAZARD LAMP SET Hazard lamp function mode can be changed in this mode. The function mode will be changed when "CHANG SETT" on CONSULT-III screen is touched.
MULTI ANSWER BACK SET Hazard and horn reminder mode can be changed in this mode. The reminder mode will be changed
when “CHANG SETT” on CONSULT-III screen is touched.
AUTO LOCK SET Auto locking function mode can be changed in this mode. The function mode will be changed when
"CHANG SETT" on CONSULT-
III screen is touched.
PANIC ALRM SET Panic alarm operation mode can be changed in this mode. The operation mode will be changed when
"CHANG SETT" on CONSULT-
III screen is touched.
PW DOWN SET Keyless power window down (open) operation mode can be changed in this mode. The operation
mode will be changed when "CHANG SETT" on CONSULT-III screen is touched.
MODE 1
(C mode) MODE 2
(S mode) MODE 3MODE 4MODE 5MODE 6
Keyfob
operation Lock Unlock Lock Unlock Lock Unlock Lock Unlock Lock Unlock Lock Unlock
Hazard warning
lamp flash TwiceOnceTwice — — — TwiceOnceTwice — — Once
Horn sound Once———————Once—Once—
MODE 1 MODE 2 MODE 3
Auto locking function 5 minutes Nothing 1 minute
MODE 1 MODE 2 MODE 3
Keyfob operation 0.5 seconds Nothing 1.5 seconds
MODE 1 MODE 2 MODE 3
Keyfob operation 0.5 seconds Nothing 0.5 seconds
MODE 1MODE 2MODE 3
Keyfob operation 3 seconds Nothing 5 seconds
Monitored Item Description
DOOR SW-AS Indicates [ON/OFF] condition of front door switch RH.
DOOR SW-RR Indicates [ON/OFF] condition of rear door switch RH.
DOOR SW-RL Indicates [ON/OFF] condition of rear door switch LH.
DOOR SW-DR Indicates [ON/OFF] condition of front door switch LH.
KEY ON SW Indicates [ON/OFF] condition of key switch.
ACC ON SW Indicates [ON/OFF] condition of ignition switch in ACC position.
Revision: December 20092009 QX56
Page 395 of 4171
![INFINITI QX56 2009 Factory Service Manual
BCS
DIAGNOSIS SYSTEM (BCM)BCS-21
< FUNCTION DIAGNOSIS > [BCM]
C
D
E
F
G H
I
J
K L
B A
O P
N
ACTIVE TEST
HEADLAMP
HEADLAMP : CONSULT-III Func
tion (BCM - HEAD LAMP)INFOID:0000000003776393
WORK SUPPORT](/img/42/57031/w960_57031-394.png "INFINITI QX56 2009 Factory Service Manual
BCS
DIAGNOSIS SYSTEM (BCM)BCS-21
< FUNCTION DIAGNOSIS > [BCM]
C
D
E
F
G H
I
J
K L
B A
O P
N
ACTIVE TEST
HEADLAMP
HEADLAMP : CONSULT-III Func
tion (BCM - HEAD LAMP)INFOID:0000000003776393
WORK SUPPORT")
BCS
DIAGNOSIS SYSTEM (BCM)BCS-21
< FUNCTION DIAGNOSIS > [BCM]
C
D
E
F
G H
I
J
K L
B A
O P
N
ACTIVE TEST
HEADLAMP
HEADLAMP : CONSULT-III Func
tion (BCM - HEAD LAMP)INFOID:0000000003776393
WORK SUPPORT
*: Initial settingIGN ON SW Indicates [ON/OFF] condition of ignition switch in ON position.
KEYLESS PANIC Indicates [ON/
OFF] condition of panic signal from keyfob.
KEYLESS UNLOCK Indicates [ON/O FF] condition of unlock signal from keyfob.
KEYLESS LOCK Indicates [ON/OFF] conditio n of lock signal from keyfob.
KEY CYL LK-SW Indicates [ON/OFF] condition of lock signal from door key cylinder switch.
KEY CYL UN-SW Indicates [ON/OFF] condition of un lock signal from door key cylinder switch.
CDL UNLOCK SW Indicates [ON/OFF] condition of unlock signal from lock/unlock switch.
CDL LOCK SW Indicates [ON/OFF] condition of lock signal from lock/unlock switch.
DOOR SW-RL Indicates [ON/OFF] condition of rear door switch LH.
DOOR SW-RR Indicates [ON/OFF] condition of rear door switch RH.
RKE LCK-UNLCK Indicates [ON/OFF] condition of lock/unlock signal at the same time from keyfob.
RKE KEEP UNLK Indicates [ON/OFF] condition of unlock signal from keyfob. Monitored Item Description
Test Item Description
FLASHER This test is able to check right and left hazard reminder operation. The right hazard lamp turns on when “RH” on CONSULT-III screen is touched and th e left hazard lamp turns on when "LH" on CON-
SULT-III screen is touched.
POWER WINDOW DOWN This test is able to check power window down operation. The windows are lowered when “ON” on CONSULT-III screen is touched.
HORN This test is able to check panic alarm and horn reminder operations. The alarm activate for 0.5 sec- onds after “ON” on CONSULT-III screen is touched.
DOOR LOCK This test is able to check door lock operatio n. The doors lock and unlock based on the item on CON-
SULT-III screen touched.
Work Item Setting item Setting
BATTERY SAVER SET ON* With the exterior lamp battery saver function
OFF Without the exterior lamp battery saver function
CUSTOM A/LIGHT SET-
TING MODE1* Normal
MODE2 More sensitive setting than normal setting (Turns ON earlier than normal operation.)
MODE3 More sensitive setting than MODE 2 (Turns ON earlier than MODE 2.)
MODE4 Less sensitive setting than normal setting (Turns ON later than normal operation.)
ILL DELAY SET MODE1* 45 sec.
Sets delay timer function timer operation time
(All doors closed)
MODE2
Without the func-
tion
MODE3 30 sec.
MODE4 60 sec.
MODE5 90 sec.
MODE6 120 sec.
MODE7 150 sec.
MODE8 180 sec.
Revision: December 20092009 QX56
Page 403 of 4171
![INFINITI QX56 2009 Factory Service Manual
BCS
DIAGNOSIS SYSTEM (BCM)BCS-29
< FUNCTION DIAGNOSIS > [BCM]
C
D
E
F
G H
I
J
K L
B A
O P
N
ID Read
The registered ID number is displayed.
ID Regist
Refer to
WT-6, "ID Registration Procedure".
SELF-](/img/42/57031/w960_57031-402.png "INFINITI QX56 2009 Factory Service Manual
BCS
DIAGNOSIS SYSTEM (BCM)BCS-29
< FUNCTION DIAGNOSIS > [BCM]
C
D
E
F
G H
I
J
K L
B A
O P
N
ID Read
The registered ID number is displayed.
ID Regist
Refer to
WT-6, \"ID Registration Procedure\".
SELF-")
BCS
DIAGNOSIS SYSTEM (BCM)BCS-29
< FUNCTION DIAGNOSIS > [BCM]
C
D
E
F
G H
I
J
K L
B A
O P
N
ID Read
The registered ID number is displayed.
ID Regist
Refer to
WT-6, "ID Registration Procedure".
SELF-DIAG RESULTS MODE
Operation Procedure
Refer to WT-12, "Self-Diagnosis (With CONSULT-III)".
DATA MONITOR MODE
Screen of data monitor mode is displayed. Refer to WT-11, "CONSULT-III Function (BCM)".
NOTE:
When malfunction is detected, CONSUL T-III perform REAL-TIME DIAGNOSIS.
Also, any malfunction detected while in this mode will be displayed at real time.
ACTIVE TEST MODE
NOTE:
Before performing the self-diagnosis, be sure to register the ID, or else the actual malfunction may be different
from that displayed on CONSULT-III.
TEST ITEM LIST
THEFT ALM
THEFT ALM : CONSULT-III Function (BCM - THEFT ALM)INFOID:0000000003776406
WORK SUPPORT
Test item Content
WARNING LAMP This test is able to check to make sure that the warning lamp turns on.
ID REGIST WARNING This test is able to check to make sure that the buzzer sounds or the warning lamp turns on.
FLASHER This test is able to check to make sure that each turn signal lamp turns on.
HORN This test is able to check to make sure that the horn sounds.
Work Item Description
SECURITY ALARM SET Vehicle security function mode can be changed in this mode.
ON: Vehicle security function is ON.
OFF: Vehicle security function is OFF.
Revision: December 20092009 QX56
Page 774 of 4171
DEF-6
< FUNCTION DIAGNOSIS >
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT-III Function (BCM - COMMON ITEM)INFOID:0000000004223690
APPLICATION ITEM
CONSULT-III performs the following functions via CAN communication with BCM.
SYSTEM APPLICATION
BCM can perform the following functions for each system.
NOTE:
It can perform the diagnosis modes except the following for all sub system selection items.
REAR WINDOW DEFOGGER
Diagnosis mode Function Description
WORK SUPPORT Changes the setting for each system function.
SELF-DIAG RESULTS Displays the diagnosis results judged by BCM. Refer to BCS-51, "
DTCIndex".
CAN DIAG SUPPORT MNTR Monitors the reception status of CAN communication viewed from BCM.
DATA MONITOR The BCM input/output signals are displayed.
ACTIVE TEST The signals used to activate each device are forcibly supplied from BCM.
ECU IDENTIFICATION The BCM part number is displayed.
CONFIGURATION • Enables to read and save the vehicle specification.
• Enables to write the vehicle specification when replacing BCM.
System
Sub system selection item Diagnosis mode
WORK SUPPORT DATA MONITOR ACTIVE TEST
BCM BCM ×
Door lock DOOR LOCK ×××
Rear window defogger REAR DEFOGGER ×
Warning chime BUZZER ××
Interior room lamp timer INT LAMP ×××
Remote keyless entry system MULTI REMOTE ENT ××
Exterior lamp HEAD LAMP ×××
Wiper and washer WIPER ×××
Turn signal and hazard warning lamps FLASHER ××
Air conditioner AIR CONDITONER ×
Intelligent Key system INTELLIGENT KEY ×
Combination switch COMB SW ×
Immobilizer IMMU ××
Interior room lamp battery saver BATTERY SAVER ×××
Back door open TRUNK ××
RAP (retained accessory power) RETAINED PWR ×××
Signal buffer system SIGNAL BUFFER ××
TPMS (tire pressure monitoring sys-
tem) AIR PRESSURE MONITOR
×××
Vehicle security system PANIC ALARM ×
Revision: December 20092009 QX56
Page 834 of 4171
![INFINITI QX56 2009 Factory Service Manual DLK-22
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK FUNCTION
• To ensure the Intelligent Key works effectively, us
e within 80 cm range of each doors, however the operable
range may](/img/42/57031/w960_57031-833.png "INFINITI QX56 2009 Factory Service Manual DLK-22
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK FUNCTION
• To ensure the Intelligent Key works effectively, us
e within 80 cm range of each doors, however the operable
range may")
DLK-22
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK FUNCTION
• To ensure the Intelligent Key works effectively, us
e within 80 cm range of each doors, however the operable
range may differ according to surroundings.
SELECTIVE UNLOCK FUNCTION
When a LOCK signal is transmitted from Intelligent Key, all doors will be locked.
When an UNLOCK signal is transmitted from Inte lligent Key once, driver's door will be unlocked.
Then, if an UNLOCK signal is transmitted from Intell igent Key again within 5 seconds, all other doors will be
unlocked.
When a liftgate signal is transmitted from Intelligent Key for more than 0.5 second, the back door operates to
the full open position. After opening, another signal will cause the back door to close.
HAZARD AND HORN REMINDER FUNCTION
When doors are locked or unlocked by Intelligent Key, BCM flashes hazard warning lamps as a reminder and
sends horn chirp signal to IPDM E/R. IPDM E/R sounds horn as a reminder.
The hazard and horn reminder has a horn chirp mode (C mode) and a non-horn chirp mode (S mode).
Operating function of hazard and horn reminder
Hazard and horn reminders do not operate if any door switch is ON (any door is OPEN).
How to change hazard and horn reminder mode
With CONSULT-III
Refer to DLK-56, "
CONSULT-III Function (INTELLIGENT KEY)".
Without CONSULT-III
Refer to Owner's Manual for instructions.
AUTO DOOR LOCK FUNCTION
Auto Door Lock Function
When all doors are locked, ignition switch is OFF (ignition switch is not pressed) and key switch is OFF, doors
are unlocked with Intelligent Key button. When BCM does not receive the following signals within 30 seconds,
all doors are locked.
• Door switch is ON (door is opened)
• Door is locked
• Ignition switch is ON
• Key switch is ON (mechanical key is inserted in ignition key cylinder)
Auto door lock mode can be changed by DOOR LOCK -UNLOCK SET mode in “WORK SUPPORT”. Refer to
DLK-52, "
DOOR LOCK : CONSULT-III Function (BCM - DOOR LOCK)".
PANIC ALARM FUNCTION
When ignition switch is OFF (ignition switch is not pr essed) and key switch is OFF, BCM receives PANIC
ALARM signal from Intelligent Key through the remote keyless entry receiver and the Intelligent Key unit.
BCM turns on and off headlamp intermittently and transmits theft warning horn signal to IPDM E/R. Then,
IPDM E/R turns on and off horn intermittently.
The headlamp flashes and the horn sounds intermittently.
The alarm automatically turns off:
• After 25 seconds
• When BCM receives any signal from Intelligent Key
Panic alarm function mode can be changed by PANIC ALARM SET mode in “WORK SUPPORT”. Refer to
DLK-56, "
CONSULT-III Function (INTELLIGENT KEY)".
KEYLESS POWER WINDOW DOWN (OPEN) FUNCTION
Front power windows (with left and right front power window anti-pinch system) open when the unlock button
on Intelligent Key is activated and kept pressed for more than 3 seconds with the ignition switch OFF. The win-
dows keep opening if the unlock button is continuously pressed.
The power window opening stops when the following operations are performed:
• When the unlock button is kept pressed more than 15 seconds.
• When the ignition switch is turned ON while the power window opening is operated.
• When the unlock button is released.
C mode S mode
Intelligent Key operation Lock UnlockBack door
open Lock Unlock Back door
open
Hazard warning lamp flashTwice Once —Twice ——
Horns sound Once—————
Revision: December 20092009 QX56
Page 835 of 4171
![INFINITI QX56 2009 Factory Service Manual DOOR LOCK FUNCTIONDLK-23
< FUNCTION DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
While retained power operation activate, Keyless power window down (open) function canno](/img/42/57031/w960_57031-834.png "INFINITI QX56 2009 Factory Service Manual DOOR LOCK FUNCTIONDLK-23
< FUNCTION DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
While retained power operation activate, Keyless power window down (open) function canno")
DOOR LOCK FUNCTIONDLK-23
< FUNCTION DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
While retained power operation activate, Keyless power window down (open) function cannot be operated.
Keyless power window down operation mode can be changed by PW DOWN SET mode in “WORK SUP-
PORT”. Refer to DLK-56, "
CONSULT-III Function (INTELLIGENT KEY)".
ROOM LAMP ILLUMINATION OPERATION
When the following conditions are met:
• Condition of interior lamp switch is in DOOR position
• Door switch OFF (all the doors are closed)
Intelligent Key system turns on interior lamp (for 30 seconds) by receiving UNLOCK signal from Intelligent
Key. For detailed description, refer to DLK-21, "
INTELLIGENT KEY : System Description".
LIST OF OPERATION RELATED PARTS
Parts marked with × are the parts related to operation.
Remote keyless entry functions
Intelligent Key
Intelligent Key unit
Key switch and ignition knob switch
Door request switch (Driver, Passenger)
Door switch
Door lock actuator
Intelligent Key warning buzzer
CAN communication system
BCM
Combination meter
Hazard warning lamps
Horn
IPDM E/R
Head lamp
Door lock/unlock function by remote control button ××× ×× ××
Hazard and horn reminder function ×××××××××
Selective unlock function ×× ×× ××
Keyless power window down (open) function ×××××
Auto door lock function ××× × ××
Panic alarm function ×× ××× ×××
Revision: December 20092009 QX56
Page 851 of 4171
![INFINITI QX56 2009 Factory Service Manual WARNING FUNCTIONDLK-39
< FUNCTION DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
WARNING METHOD
The following table shows the alarm or warning methods with chime.
Combinat](/img/42/57031/w960_57031-850.png "INFINITI QX56 2009 Factory Service Manual WARNING FUNCTIONDLK-39
< FUNCTION DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
WARNING METHOD
The following table shows the alarm or warning methods with chime.
Combinat")
WARNING FUNCTIONDLK-39
< FUNCTION DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
WARNING METHOD
The following table shows the alarm or warning methods with chime.
Combination meter shows information display when the warning conditions are met.
Engine start information Ignition switch is ON posi-
tion
• Ignition switch: ON position.
• Shift position: P position
• Engine is stopped
Ignition switch is except
ON position • Ignition switch: Except ON position.
• Shift position: P position
• Intelligent Key can be detected inside the vehicle.
Steering lock information When steering lock can not be released after ignition switch is turned ON.
Intelligent Key low battery warning When Intelligent Key has low battery, it is detected by BCM after ignition switch
is turned ON.
Key ID warning When registered intelligent Key cannot be detected inside the vehicle after ig-
nition switch is turned ON.
Warning/Information functions
Operation procedure
Warning/Information functions Combination meter display Warning chime
Combination
meter buzzer Intelligent
Key warning buzzer
Intelligent Key system malfunction ———
OFF position warn-
ing For internal
—Activate —
For external —— Activate
P position warning Activate —
Ta k e a w a y w a r n i n g Door is open to
close
Activate Activate
Door is open ——
Ta k e a w a y
through window Activate —
Door lock operation
warning Request switch
operation
——
Activ a te
Intelligent Key
operation ——
Activ a te
Key ID warning ——
JMKIA0037GB
JMKIA0036GB
JMKIA0036GB
Revision: December 20092009 QX56
Page 864 of 4171
![INFINITI QX56 2009 Factory Service Manual DLK-52
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT-III Fu
nction (BCM - COMMON ITEM)INFOID:0000000004190661
APPL](/img/42/57031/w960_57031-863.png "INFINITI QX56 2009 Factory Service Manual DLK-52
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT-III Fu
nction (BCM - COMMON ITEM)INFOID:0000000004190661
APPL")
DLK-52
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT-III Fu
nction (BCM - COMMON ITEM)INFOID:0000000004190661
APPLICATION ITEM
CONSULT-III performs the following functions via CAN communication with BCM.
SYSTEM APPLICATION
BCM can perform the following functions for each system.
NOTE:
It can perform the diagnosis modes except the following for all sub system selection items.
DOOR LOCK
DOOR LOCK : CONSULT-III Function (BCM - DOOR LOCK)INFOID:0000000004190662
WORK SUPPORT
Diagnosis mode Function Description
WORK SUPPORT Changes the setting for each system function.
SELF-DIAG RESULTS Displays the diagnosis results judged by BCM. Refer to BCS-51, "
DTCIndex".
CAN DIAG SUPPORT MNTR Monitors the reception status of CAN communication viewed from BCM.
DATA MONITOR The BCM input/output signals are displayed.
ACTIVE TEST The signals used to activate each device are forcibly supplied from BCM.
ECU IDENTIFICATION The BCM part number is displayed.
CONFIGURATION • Enables to read and save the vehicle specification.
• Enables to write the vehicle specification when replacing BCM.
System
Sub system selection item Diagnosis mode
WORK SUPPORT DATA MONITOR ACTIVE TEST
BCM BCM ×
Door lock DOOR LOCK ×××
Rear window defogger REAR DEFOGGER ×
Warning chime BUZZER ××
Interior room lamp timer INT LAMP ×××
Remote keyless entry system MULTI REMOTE ENT ××
Exterior lamp HEAD LAMP ×××
Wiper and washer WIPER ×××
Turn signal and hazard warning lamps FLASHER ××
Air conditioner AIR CONDITONER ×
Intelligent Key system INTELLIGENT KEY ×
Combination switch COMB SW ×
Immobilizer IMMU ××
Interior room lamp battery saver BATTERY SAVER ×××
Back door open TRUNK ××
RAP (retained accessory power) RETAINED PWR ×××
Signal buffer system SIGNAL BUFFER ××
TPMS (tire pressure monitoring sys-
tem) AIR PRESSURE MONITOR
×××
Vehicle security system PANIC ALARM ×
Revision: December 20092009 QX56
