DIAGNOSIS SYSTEM (ICC SENSOR INTEGRATED UNIT)
CCS-19
< FUNCTION DIAGNOSIS >
C
D E
F
G H
I
J
K L
M B
N P A
• Last five cancel (system cancel) causes are displayed.
• “CAUSE OF AUTO-CANCEL” displays times of ignition switch ON/OFF up to 254 maximum. 254 is kept though the number exceeds 254. The num ber returns to 0 when detecting the same cancellation causes.
SELF DIAGNOSTIC RESULT
For details, refer to CCS-56, "Diagnostic Trouble Code (DTC) Chart".
NOTE:
“DTC RESULTS” and “TIME” are indicated on “Self Diagnostic Result”. “TIME” is used as a reference data of
diagnosis. It shows when malfunction is detected.
“TIME” shows the following.
• 0: malfunction is detected at present (from malfunction detection to ignition switch OFF).
CAN communication ([U1000], [U1010])
• 1 ~ 39: Displays when it is normal at present and finds malfunction in the past. It increases like
0→ 1→ 2...38→ 39 after returning to the normal condition whenever IGN OFF→ ON. If it is over 39, it is fixed to
39 until the self-diagnostic results are erased. It retu rns to 0 when malfunction is detected again in the pro-
cess.
Other than CAN communication (other than [U1000], [U1010])
• 1 ~ 49: Displays when it is normal at present and finds malfunction in the past. It increases like 0→ 1→ 2...48→ 49 after returning to the normal condition whenever IGN OFF→ ON. If it is over 49, it is fixed to
49 until the self-diagnostic results are erased. It retu rns to 0 when malfunction is detected again in the pro-
cess.
DATA MONITOR
× : Applicable
VDC/TCS OFF SW ×VDC OFF switch was pressed.
WHEEL SPD UNMATCH ××Wheel speed became different from A/T vehicle speed.
TIRE SLIP ××Wheel slipped.
IGN LOW VOLT ××Power supply voltage became low.
NO RECORD ××—
Monitored Item [unit]MAIN
SIGNALS SELECTION
FROM
MENU Description
VHCL SPEED SE
[km/h] or [mph] ××Indicates vehicle speed calculated from ICC sensor integrated unit through
CAN communication [ABS actuator and electric unit (control unit) transmits
vehicle speed signal (wheel speed) through CAN communication].
SET VHCL SPD
[km/h] or [mph] ××
Indicates set vehicle speed memorized in ICC sensor integrated unit.
THRTL OPENING
[%] ××Indicates throttle position read from ICC sensor integrated unit through CAN
communication (ECM transmits accelerator pedal position signal through
CAN communication).
SET DISTANCE
[SHOR/MID/LONG] ××
Indicates set distance memorized in ICC sensor integrated unit.
MAIN SW
[On/Off] ××Indicates [On/Off] status as judged from ICC steering switch signal (ECM
transmits ICC steering switch signal through CAN communication).
SET/COAST SW
[On/Off] ××
Indicates [On/Off] status as judged from ICC steering switch signal (ECM
transmits ICC steering switch signal through CAN communication).
CANCEL SW
[On/Off] ××Indicates [On/Off] status as judged from ICC steering switch signal (ECM
transmits ICC steering switch signal through CAN communication).
RESUME/ACC SW
[On/Off] ××Indicates [On/Off] status as judged from ICC steering switch signal (ECM
transmits ICC steering switch signal through CAN communication).
DISTANCE SW
[On/Off] ×
Indicates [On/Off] status as judged from ICC steering switch signal (ECM
transmits ICC steering switch signal through CAN communication).
CRUISE OPE
[On/Off] ××
Indicates whether controlling or not (ON means “controlling”).
BRAKE SW
[On/Off] ××Indicates [On/Off] status as judged from ICC brake switch signal (ECM trans-
mits ICC brake switch signal through CAN communication).
Revision: April 20092010 QX56

CCS-20
< FUNCTION DIAGNOSIS >
DIAGNOSIS SYSTEM (ICC SENSOR INTEGRATED UNIT)
ACTIVE TEST
STOP LAMP SW
[On/Off] ××
Indicates [On/Off] status as judged from stop lamp switch signal (ECM trans-
mits stop lamp switch signal through CAN communication).
CRUISE LAMP
[On/Off] ××
Indicates [On/Off] status of MAIN switch indicator lamp output.
NP SW SIG
[On/Off] ××Indicates [On/Off] status as judged from transmission range switch signal
(ECM transmits transmission range switch signal through CAN communica-
tion).
STP LMP DRIVE
[On/Off] ××
Indicates [On/Off] status of ICC brake hold relay drive output.
PWR SUP MONI
[V] ××
Indicates IGN voltage input by ICC sensor integrated unit.
IDLE SW
[On/Off] ×Indicates [On/Off] status of idle switch read from ICC sensor integrated unit
through CAN communication (ECM transmits On/Off status through CAN
communication).
OWN VHCL
[On/Off] ×
Indicates [On/Off] status of own vehicle indicator output.
VHCL AHEAD
[On/Off] ×
Indicates [On/Off] status of vehicle ahead detection indicator output.
ICC WARNING
[On/Off] ×
Indicates [On/Off] status of ICC system warning lamp output.
BUZZER O/P
[On/Off] ×
Indicates [On/Off] status of ICC warning chime output.
ENGINE RPM
[rpm] ×
Indicates engine speed read from ICC sensor integrated unit through CAN
communication (ECM transmits engine speed through CAN communication).
WIPER SW
[OFF/LOW/HIGH] ×Indicates wiper [OFF/LOW/HIGH] status (BCM transmits front wiper request
signal through CAN communication).
D RANGE SW
[On/Off] ×Indicates [On/Off] status of “D” or “DS” or “M” positions read from ICC sensor
integrated unit through CAN communication; ON when position “D” or “DS” or
“M” (TCM transmits shift position indicator lamp signal through CAN commu-
nication).
NP RANGE SW
[On/Off] ×Indicates shift position indicator lamp signal read from ICC sensor integrated
unit through CAN communication (TCM transmits shift position indicator lamp
signal through CAN communication).
VHCL SPD AT
[km/h] or [mph] ×Indicates vehicle speed calculated from A/T vehicle speed sensor read from
ICC sensor integrated unit through CAN communication (TCM transmits A/T
vehicle speed sensor signal through CAN communication).
GEAR
[1, 2, 3, 4, 5] ×Indicates A/T gear position read from ICC sensor integrated unit through CAN
communication (TCM transmits current gear position signal through CAN
communication).
MODE SIG
[OFF, ICC, ASCD] ×Indicates the active mode from ICC or ASCD [conventional (fixed speed)
cruise control mode].
SET DISP IND
[On/Off] ×
Indicates [On/Off] status of SET switch indicator output.
DISTANCE
[m] ×
Indicates the distance from the vehicle ahead.
RELATIVE SPD
[m/s] ×
Indicates the relative speed of the vehicle ahead.
Monitored Item [unit]
MAIN
SIGNALS SELECTION
FROM
MENU Description
Revision: April 20092010 QX56

CCS-56
< ECU DIAGNOSIS >
ICC UNIT
Diagnostic Trouble Code (DTC) Chart
INFOID:0000000005146007
× :Applicable
DTC
No. CONSULT-III screen terms ICC sys-
tem
warning lamp Fail-safe
Malfunctions detected where... Refer-
ence
page
Vehicle-
to-vehi-cle dis-
tance
control mode Conven-
tional
(fixed
speed) cruise
control mode Brake as-
sist (with
preview
function)
11 CONTROL UNIT ×××× • ICC unit internal malfunctionCCS-22
12 VDC CONTROL UNIT ×××× • VDC malfunction
• Brake booster signal harness is
open or shorted CCS-23
20 CAN COMM CIRCUIT
×××× • ICC unit detected
CAN communi-
cation malfunction CCS-24
31 POWER SUPPLY CIR1
×××× • ICC unit power supply voltage is
excessively low (less than 8V) CCS-25
34 POWER SUPPLY CIR2
×××× • ICC unit power supply voltage is
excessively high. CCS-25
41 VHCL SPEED SE CIRC
×××× • Wheel sensor malfunction
• ABS actuator and electric unit
(control unit) malfunction
• A/T vehicle speed sensor mal-
function
•TCM malfunction CCS-26
43 VDC/TCS/ABS CIRC
×××× • VDC/TCS/ABS system malfunc-
tion CCS-27
45 BRAKE SW/ STOP L SW
×××× • ICC brake switch or stop lamp
switch harness is open or shorted
• ICC brake switch or stop lamp switch is stuck to OFF
• ICC brake switch or stop lamp switch is stuck to ON CCS-28
46 OPERATION SW CIRC
××× • ICC steering switch harness or
spiral cable is open or shorted
• ICC steering switch malfunction CCS-30
74 LASER BEAM OFF CNTR
××ו Laser beam of ICC sensor is off
the aiming point CCS-32
90 STOP LAMP RLY FIX
××ו Normally open terminal of stop
lamp relay is stuck CCS-33
92 ECM CIRCUIT
×××× •ECM malfunction
• Accelerator pedal position sensor
malfunction
• ICC unit malfunction CCS-38
96 NP RANGE
××× • Transmission range switch har-
ness is open or shorted
• Transmission range switch mal- function
•TCM malfunction CCS-39
97 AT CIRCUIT
××× •TCM malfunctionCCS-40
98 GEAR POSITION ××× •TCM malfunction
• A/T input speed sensor malfunc-
tion
• A/T vehicle speed sensor mal- function CCS-41
Revision: April 20092010 QX56

CCS
ICC UNITCCS-57
< ECU DIAGNOSIS >
C
DE
F
G H
I
J
K L
M B
N P A
NOTE: DTC 55 will display when no malfunction is detected. 102 LASER STAIN
××ו ICC sensor body window has
contamination CCS-42
103 LASER SENSOR FAIL
×× × • ICC sensor internal malfunctionCCS-43
104 LASER AIMING INCMP ×× × • Laser beam aiming of ICC sensor
is not adjusted CCS-44
107 LASER COMM FAIL
×× × • CAN data received by ICC sensor
is strange (from ICC unit, combi-
nation meter or ECM) CCS-45
109 LASER HIGH TEMP
×× × • Temperature around ICC sensor
is excessively high CCS-46
DTC
No. CONSULT-III screen terms ICC sys-
tem
warning lamp Fail-safe
Malfunctions detected where... Refer-
ence
page
Veh ic le-
to-vehi-cle dis-
tance
control mode Conven-
tional
(fixed
speed) cruise
control mode Brake as-
sist (with
preview
function)
Revision: April 20092010 QX56

CCS-58
< SYMPTOM DIAGNOSIS >
INTELLIGENT CRUISE CONTROL SYSTEM SYMPTOMS
SYMPTOM DIAGNOSIS
INTELLIGENT CRUISE CONTROL SYSTEM SYMPTOMS
Symptom ChartINFOID:0000000005146008
Symptoms Reference page
Operation ON/OFF switch does not switch ON.
CCS-59
ON/OFF switch does not switch OFF.CCS-59
Cruise does not function for setting (powering functions).CCS-60
CANCEL switch does not function.CCS-61
RESUME does not function.CCS-61
The set speed does not increase.CCS-61
The set distance to the vehicle ahead cannot be changed.CCS-61
The ICC is not cancelled when the gear is in "N".CCS-62
Display/ChimeThe ICC system display does not appear.
Check combination meter. Refer to
MWI-22, "Diagnosis Description"
Chime does not function. CCS-63
ControlDriving force is hunting. CCS-64
Function to detect the vehicle aheadThe system frequently cannot detect the vehicle ahead.
CCS-65
The distance to detect the vehicle ahead is short.CCS-65
The system misidentifies a vehicle even though there is
no vehicle ahead.• Refer to CCS-5, "
LASER BEAM
AIMING ADJUSTMENT : Out-
line of Laser Beam Aiming Ad-
justment Procedure"
• Refer to
CCS-8, "ACTION TEST
: ICC System Running Test"
The system misidentifies a vehicle in the next lane. • Refer to CCS-5, "
LASER BEAM
AIMING ADJUSTMENT : Out-
line of Laser Beam Aiming Ad-
justment Procedure"
• Refer to
CCS-8, "ACTION TEST
: ICC System Running Test"
The system does not detect a vehicle at all. CCS-66
Revision: April 20092010 QX56

CCS
NORMAL OPERATING CONDITIONCCS-67
< SYMPTOM DIAGNOSIS >
C
DE
F
G H
I
J
K L
M B
N P A
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000005146017
PRECAUTIONS FOR VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE
• Intelligent Cruise Control is functionally limited. This never support careless driving and low visibility (rain,
fog, etc.). Drive the vehicle safely. Keep a safe distance between vehicles by decreasing the vehicle speed
according to the driving condition etc.
• Intelligent Cruise Control never stop the vehicle automatically. Intelligent Cruise Control is automatically released, and the buzzer sounds if any vehicle ahead is not detected when the vehicle speed is approxi-
mately 35 km (21.5 MPH) or less.
• Use this system when the vehicle speed does not ex tremely change. This system may not properly function
when any vehicle cuts in, or when the vehicle ahead suddenly applies the brake. Then, the warning (buzzer
and indication) activates.
• Never use Intelligent Cruise Control in the following conditions.
- A well-trafficed road, and a tight turn. It may cause any accident because the driving does not fit to the road condition.
- A slippery road (e.g., freezing, or snowy road) The vehicle may lose the control by wheelspin.
- The vehicle drives in bad whether (rain, fog, snow etc.). The distance from the vehicle ahead is not detected pr ecisely if the whether condition is bad. Intelligent
Cruise Control is released automatically if the wiper activates in low or high speed.
- The vehicle receives bright light (sunshine etc.). The distance from the vehicle ahead is not detected pr ecisely if bright light enters in the vehicle.
- Raindrop or snow is on the sensor.
The distance from the vehicle ahead is not detected precisely if raindrop or snow attaches on the sensor.
- A steep downhill The setting vehicle speed may exceed if Intelligent Cr uise Control does not detect the vehicle ahead. The
brake may heat up in the vehicle-to-vehicle distance control mode.
- A repeated uphill and downhill Intelligent Cruise Control may not detect the vehicle ahead precisely. An accident may occur by tailgating.
- Maintaining proper vehicle distance is diff icult due to frequent acceleration/deceleration.
It may cause any accident because the driving does not fit to the road condition if keeping a proper vehicle-
to-vehicle distance is difficult.
- When entering in the highway interchange (swerving off the main line),
Unexpected accident may cause if the vehicle ahead drives slower
than the preset vehicle speed. The vehicle-to-vehicle distance con-
trol mode accelerates automatically because the vehicle ahead is
not detected on the lane if the own vehicle or the vehicle ahead
changes the lane.
• Intelligent Cruise Control does not activate to the parking vehicles, and vehicles driving extremely slower than the own vehicle. Never
hit the vehicle stopping at a tollgate, or the tail end of traffic jam.
• Intelligent Cruise Control does not activate to the vehicle edging way, and non-vehicle objects (passengers etc.).
• This function detects the reflector of the vehicle ahead. Intelligent Cruise Control may not detect the vehicle
ahead, and keep a proper vehicle-to-vehicle distance in the following conditions. Drive the vehicle according
to the driving condition.
- The vehicle ahead installs the reflector higher (trailer etc.).
- The rear of the vehicle ahead is extremely dirt.
- The vehicle ahead or vehicle on other lanes splashes water or snow on the road.
- The vehicle ahead provides dark exhaust gas. Smoke blocks the visibility.
- The vehicle ahead attaches film on the reflector. The vehicle ahead does not install the reflector. The reflec- tor is broken.
- Extremely heavy load is on the rear seat or in the cargo area.
- The vehicle drives on a repeated uphill and downhill
EL-2980D
Revision: April 20092010 QX56

CCS-68
< SYMPTOM DIAGNOSIS >
NORMAL OPERATING CONDITION
• The sensor detection distance is limited if the vehicle-to-vehicledistance is close. The vehicle distance may not maintain properly
because the motorcycle (A) driving on the lane edge is not
detected or detecting the vehicle ahead (cutting in the own vehicle)
delays.
• The sensor dirt is detected automatically. But it is not perfect. Dirt
is not judged despite the sensor is dirt. Dirt is not detected if snow
or ice is on the sensor.
Keeping the vehicle-to-vehicle distance is difficult. Drive the vehi-
cle safely. Always clean the sensor.
Intelligent Cruise Control is released automatically if dirt is
detected.
• The vehicle ahead may not be detected temporarily, the vehicle or object on the neighboring lane may be
detected or the warning buzzer may sound according to the road shape (curve and nar\
row road) and the
own vehicle condition (steering, driving lane position, accident, malfunction etc.).
The vehicle ahead is not detected temporarily. The vehicle approaches too close.
PRECAUTIONS FOR CONVENTIONAL (FIXED SPEED) CRUISE CONTROL MODE
• Conventional cruise control mode does neither control the brake nor activate the warning.
Drive the vehicle safely. Keep a safe distance between vehicles by decreasing the vehicle speed according
to the driving condition etc.
• Never use the conventional cruise c ontrol mode in the following conditions.
- A well-trafficed road, and a tight turn.
It may cause any accident because the dr iving does not fit to the road condition.
- A slippery road (e.g., freezing, or snowy road) The vehicle may lose the control by wheelspin.
- A steep downhill The engine brake does not activate effectively on a steep downhill. The preset vehicle speed may exceed.
JSOIA0050ZZ
Revision: April 20092010 QX56

P1827 CLUTCH PRESSURE SWITCHDLN-73
< COMPONENT DIAGNOSIS > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
YES >> GO TO 6.
NO >> Replace transfer control unit. Refer to DLN-130, "
Removal and Installation".
6.CRUISE TEST
Perform cruise test. Refer to DLN-7, "
Preliminary Check".
Are inspection results normal?
YES >> Inspection End.
NO >> Perform the applicable trouble diagnosis.
Component InspectionINFOID:0000000005148836
1. Turn ignition switch OFF. (Stay for at least 5 seconds.)
2. Remove clutch pressure switch. Refer to DLN-16, "
Component Parts Location".
3. Push and release clutch pressure switch and check continuity between terminal 7 and ground.
4. If the inspection results are abnormal replace the clutch pres- sure switch.
Terminal Condition Continuity
7 - Ground Push clutch pressure switch
Yes
Release clutch pressure switch No
WDIA0171E
Revision: April 20092010 QX56

DLN-76
< COMPONENT DIAGNOSIS >[ATX14B]
P1828 LINE PRESSURE SWITCH
5.CHECK DTC
Perform the self-diagnosis, after driving a vehicle for a while.
Are inspection results normal?
YES >> GO TO 6.
NO >> Replace transfer control unit. Refer to DLN-130, "
Removal and Installation".
6.CRUISE TEST
Perform cruise test. Refer to DLN-7, "
Preliminary Check".
Are inspection results normal?
YES >> Inspection End.
NO >> Perform the applicable trouble diagnosis.
Component InspectionINFOID:0000000005148840
1. Turn ignition switch OFF. (Stay for at least 5 seconds.)
2. Remove line pressure switch. Refer to DLN-16, "
Component Parts Location".
3. Push and release line pressure switch and check continuity between terminal 1 and ground.
4. If the inspection results are abnormal, replace the line pressure switch.
Terminal Condition Continuity
1 - Ground Push line pressure switch
Yes
Release line pressure switch No
WDIA0172E
Revision: April 20092010 QX56

AUTOMATIC SPEED CONTROL DEVICE (ASCD)EC-33
< FUNCTION DIAGNOSIS > [VK56DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
AUTOMATIC SPEED CONTROL DEVICE (ASCD)
System DescriptionINFOID:0000000005149068
INPUT/OUTPUT SIGNAL CHART
*: This signal is sent to the ECM through CAN communication line
BASIC ASCD SYSTEM
Refer to Owner's Manual for ASCD operating instructions.
Automatic Speed Control Device (ASCD) allows a driver to keep vehicle at predetermined constant speed
without depressing accelerator pedal. Driver can set
vehicle speed in advance between approximately 40 km/
h (25 MPH) and 144 km/h (89 MPH).
ECM controls throttle angle of electric thro ttle control actuator to regulate engine speed.
Operation status of ASCD is indicated by CRUISE i ndicator and SET indicator in combination meter. If any
malfunction occurs in ASCD system, it automatically deactivates control.
NOTE:
Always drive vehicle in safe manner according to traffic conditions and obey all traffic laws.
SET OPERATION
Press MAIN switch. (The CRUISE indicato r in combination meter illuminates.)
When vehicle speed reaches a desired speed between approximately 40 km/h (25 MPH) and 144 km/h (89
MPH), press SET/COAST switch. (Then SET indicator in combination meter illuminates.)
ACCELERATE OPERATION
If the RESUME/ACCELERATE switch is pressed during cr uise control driving, increase the vehicle speed until
the switch is released or vehicle speed reac hes maximum speed controlled by the system.
And then ASCD will keep the new set speed.
CANCEL OPERATION
When any of following conditions exis t, cruise operation will be canceled.
• CANCEL switch is pressed
• More than 2 switches at ASCD steer ing switch are pressed at the same time (Set speed will be cleared)
• Brake pedal is depressed
• Selector lever is changed to N, P, R position
• Vehicle speed decreased to 13 km/h (8 MPH) lower than the set speed
• VDC system is operated
When the ECM detects any of the following conditions, the ECM will cancel the cruise operation and inform
the driver by blinking indicator lamp.
• Engine coolant temperature is slightly higher than the normal operating temperature, CRUISE indicator may
blink slowly.
When the engine coolant temperature decreases to the normal operating temperature, CRUISE indicator will
stop blinking and the cruise operation will be able to work by pressing SET/COAST switch or RESUME/
ACCELERATE switch.
• Malfunction for some self-diagnoses regarding ASCD control: SET indicator will blink quickly.
If MAIN switch is turned to OFF during ASCD is activated, all of ASCD operations will be canceled and vehicle
speed memory will be erased.
COAST OPERATION
When the SET/COAST switch is pressed during cruise control driving, decrease vehicle set speed until the
switch is released. And then ASCD will keep the new set speed.
RESUME OPERATION
Sensor Input signal to ECM ECM functionActuator
ASCD brake switch Brake pedal operation
ASCD vehicle speed controlElectric throttle control
actuator
Stop lamp switch
Brake pedal operation
ASCD steering switch ASCD steering switch operation
Wheel sensor Vehicle speed*
TCM Gear position
Powertrain revolution*
Revision: April 20092010 QX56
