INFINITI QX56 2010 Factory Service Manual

PG
HARNESSPG-51
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
K L
B A
O P
N
BODY HARNESS
C3 C6 B/2 : Evap canister vent control valve B4 C103 B/3 : Rear sonar sensor LH inner
B4 C7 GR/2 : Rear bumper antenna
B4 C104 B/3 : Rear sonar sensor RH inner
C4 C8 B/3 : Height sensor C5 C105 B/3 : Rear sonar sensor RH outer
B4 C9 B/4 : Suspension air compressor
ABMIA0158GB
Revision: April 20092010 QX56

PG-52
< COMPONENT DIAGNOSIS >
HARNESS
G3 B3 W/16 : Suspension control unitC5 B69 SMJ : To M40
E4 B6 W/18 : To D201 G2 B70 GR/3 : Rear combination lamp LH
C5 B7 — : Body ground D5 B72 BR/6 : Subwoofer
D4 B8 W/3 : Front door switch LH F3 B73 W/16 : Rear view camera control unit
C4 B9 Y/12 : Air bag diagnosis sensor unit C4 B74 Y/4 : Seat belt buckle pre-tensioner assembly LH
E5 B10 Y/2 : Front LH side air bag module F2 B75 W/10 : To B400
F3 B13 W/24 : ICC unit F2 B76 GR/2 : Luggage area antenna
E5 B14 Y/2 : Front LH seat belt pre-tensioner C3 B78 W/3 : Rear seat heater RH
E5 B15 Y/2 : LH side air bag (satellite) sensor E3 B79 W/3 : Rear seat heater LH
G3 B17 GR/24 : ICC unit Front seat LH harness
E3 B18 W/3 : Rear door switch LH D3 B200 W/16 : To B37
G1 B19 — : Body ground D5 B202 W/32 : Driver seat control unit
G2 B24 W/16 : Sonar control unit D5 B203 W/16 : Driver seat control unit
B4 B32 W/6 : To B124 C5 B204 GR/5 : Sliding motor LH
G2 B35 B/3 : Rear combination lamp LH D3 B205 W/4 : Reclining motor LH
D3 B37 W/16 : To B200 C4 B206 GR/5 : Lifting motor (front)
C5 B38 Y/2 : LH side front curtain air bag module D4 B207 GR/5 : Lifting motor (rear)
C5 B40 W/24 : To E34 D4 B208 W/10 : Power seat switch LH
C5 B41 W/12 : To E35 D4 B209 W/3 : Front seat heater LH
C5 B42 W/2 : To E36 D5 B210 W/4 : Lumbar support switch
B4 B43 W/16 : To B111 E5 B211 B/2 : Lumbar support motor
F1 B48 W/18 : To D401 Third row power folding seat sub-harness
F1 B49 W/2 : To D402 F2 B400 W/10 : To B75
F2 B52 W/2 : Rear power vent window motor LH E3 B401 GR/12 : Third row power folding seat control unit
F2 B54 Y/2 : LH side rear curtain air bag module E3 B402 W/10 : Third row power folding seat control unit
G3 B55 W/26 : Back door control unit F3 B403 GR/4 : Third row power folding seat motor LH
F2 B56 GR/16 : Sonar control unit (with front and rear
sonar system) E2 B404 W/4 : To B425
G2 B57 GR/10 : Sonar control unit (with front and rear
sonar system) E3 B425 W/4 : To B404
G1 B63 W/6 : Back door close switch E2 B426 GR/4 : Third row power folding seat motor RH
Revision: April 20092010 QX56

PG
HARNESSPG-53
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
K L
B A
O P
N
BODY NO. 2 HARNESS
ABMIA0159GB
F4 B101 W/16 : To M84
A1 B140 W/6 : To D601
A3 B105 B/3 : Rear combination lamp RHD1 B145 W/16 : To R200
D4 B106 W/18 : To D301 E2 B146 BR/24 : To R201
F4 B107 W/8 : To E139 F4 B149 SMJ : To M36
D4 B108 W/3 : Front door switch RH B2 B150 W/2 : Rear power vent window motor RH
Revision: April 20092010 QX56

PG-54
< COMPONENT DIAGNOSIS >
HARNESS
ROOM LAMP HARNESS
F4 B111 W/16 : To B43B2 B153 W/2 : Cargo lamp
E3 B113 Y/12 : Air bag diagnosis sensor unit E5 B154 W/2 : To B303
D5 B114 Y/2 : RH side air bag (satellite) sensor B3 B155 B/6 : Air mix door motor (rear)
C3 B116 W/3 : Rear door switch RH B3 B156 B/6 : Mode door motor (rear)
F5 B117 — : Body ground E5 B157 Y/4 : Seat belt buckle pre-tensioner assembly RH
E5 B118 W/3 : Front seat heater RH C3 B162 BR/6: Third row power folding seat switch
passenger side (front)
A2 B119 W/2 : Condenser-3 A3 B163 W/6: Third row power folding seat switch
passenger side (rear)
A2 B120 W/2 : Condenser-4 C3 B164 W/6: Third row power folding seat switch
driver side (front)
F4 B124 W/6 : To B32 A3 B165 BR/6: Third row power folding seat switch
driver side (rear)
E4 B126 Y/2 : Front RH side air bag module B2 B166 B/2 : Rear sonar buzzer
D4 B127 Y/2 : Front RH seat belt pre-tensioner Front seat RH harness
C3 B128 Y/2 : RH side rear curtain air bag module E5 B303 W/2 : To B154
F3 B129 Y/2 : RH side front curtain air bag module E4 B308 W/10 : Power seat switch RH
A3 B130 GR/3 : Rear combination lamp RH E4 B309 GR/2 : Sliding motor RH
A3 B132 — : Body ground E5 B310 GR/2 : Lifting motor RH (rear)
A3 B133 W/4 : Variable blower control (re ar)E4 B311 GR/2 : Lifting motor RH (front)
B3 B134 W/2 : Rear blower motor E4 B350 W/8 : To B136
E3 B136 W/8 : To B350 E4 B351 B/18 : Occupant classification system control unit
D5 B137 W/3 : Belt tension sensor E4 B352 B/3 : Occupant classification system sensor
B2 B138 B/3 : Rear cargo power sock etE4 B372 W/2 : Reclining motor RH
A1 B139 W/16 : To D602
Revision: April 20092010 QX56

PG
HARNESSPG-55
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
K L
B A
O P
N
FRONT DOOR LH HARNESS
A4 R1 W/16 : To M1
C3 R107 W/8 : To R9
A4 R2 W/12 : To M2 C2 R108 B/6 : Rear air control (front)
D3 R3 W/2 : Vanity lamp LH D2 R109 W/4 : Microphone
C3 R4 W/10 : Sunroof motor assembly Room lamp sub-harness B
C2 R6 W/16 : To R101 D1 R200 W/16 : To B145
C3 R7 GR/10 : Auto anti-dazzling inside mirror D1 R201 BR/24 : To B146
B3 R8 W/2 : Vanity lamp RH C2 R202 W/12 : Video monitor
D3 R9 W/8 : To R107 D1 R203 W/3 : Personal lamp 2ND row
Room lamp sub-harness A D2 R204 W/16 : Rear audio remote control unit
C2 R101 W/16 : To R6 E1 R205 W/3 : Personal lamp 3RD row
C3 R102 GR/8 : Front room/map lamp assembly D2 R209 B/6 : Rear air control (rear)
D3 R104 GR/6 : Sunroof switch E1 R210 W/2 : Over head console area antenna
ALMIA0215GB
D1 BR/24 : To M9 D9 GR/6 : Front power window motor LH
D2 W/16 : To M8 D10 BR/16 : Door mirror remote control switch
D3 W10 : To M158 D11 W/2 : Front step lamp LH
D4 W/16 : Door mirror LH D12 W/2 : Front door speaker LH
D5 W/8 : Seat memory switch D14 B/6 : Front door lock assembly LH
D7 W/16 : Main power window and door lock/unlock switch D15 GR/2 : Front outside antenna LH
D8 W/3 : Main power window and door lock/unlock switch D16 GR/2 : Front door request switch LH
Revision: April 20092010 QX56

PG-56
< COMPONENT DIAGNOSIS >
HARNESS
FRONT DOOR RH HARNESS
ALMIA0218GB
D101 W/10 : To M75 D109 W/2 : Front step lamp RH
D102 BR/20 : To M74 D112 W/2 : Front door speaker RH
D104 GR/6 : Front power window motor RH D114 B/6 : Front door lock assembly RH
D105 W/16 : Power window and door lock/unlock switch RH D115 GR/2 : Front outside antenna RH
D107 W/16 : Door mirror RH D116 GR/2 : Front door request switch RH
Revision: April 20092010 QX56

PG
HARNESSPG-57
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
K L
B A
O P
N
REAR DOOR LH HARNESS
AWMIA0109GB
D201 W/18 : To B6
D206 W/2 : Rear step lamp LH
D203 W/8 : Rear power window switch LHD207 BR/2 : Rear door speaker LH
D204 GR/6 : Rear power window motor LH D208 BR/2 : Rear door tweeter LH
D205 B/6 : Rear door lock actuator LH D209 W/18 : Rear power window control unit LH
Revision: April 20092010 QX56

PG-58
< COMPONENT DIAGNOSIS >
HARNESS
REAR DOOR RH HARNESS
AWMIA0110GB
D301 W/18 : To B106 D306 W/2 : Rear step lamp RH
D303 W/8 : Rear power window switch RHD307 BR/2 : Rear door speaker RH
D304 GR/6 : Rear power window motor RH D308 BR/2 : Rear door tweeter RH
D305 B/6 : Rear door lock actuator RH D309 W/18 : Rear power window control unit RH
Revision: April 20092010 QX56

PG
HARNESSPG-59
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
K L
B A
O P
N
BACK DOOR HARNESS
ABMIA1204GB
Back door No. 2 LH harness
Back door RH harness
E2 D401 W/18 : To B48 B3 D701 W/16 : To D606
E2 D402 W/2 : To B49 A4 D702 W/6 : To D605
D2 D403 GR/2 : High mounted stop lamp E3 D703 W/2 : License plate lamps
G3 D405 W/18 : To D501 D3 D704 W/6 : Rear wiper motor
Revision: April 20092010 QX56

PG-60
< COMPONENT DIAGNOSIS >
HARNESS
F2 D406 B/1 : Rear window defoggerD2 D705 GR/2 : Back-up lamp LH
Back door LH harness C4 D706 W/4 : Back door and glass hatch switch assembly
G3 D501 W/18 : To D405 D2 D707 B/1 : Glass hatch ajar switch
E4 D503 W/8 : Back door latch B4 D709 GR/2 : Back-up lamp RH
E4 D504 W/4 : Rear view camera B4 D711 W/4 : Glass hatch lock actuator
F4 D514 BR/2 : Back door warning chime B4 D715 BR/2 : Pinch strip RH
F4 D517 BR/2 : Pinch strip LH B4 D716 BR/2 : Back door speaker RH
F4 D518 BR/2 : Back door speaker LH
Back door No. 2 RH harness
C2 D601 W/6 : To B140
C2 D602 W/16 : To B139
D2 D603 — : Body ground
B2 D604 B/1 : Rear window defogger
A3 D605 W/6 : To D702
B3 D606 W/16 : To D701
Revision: April 20092010 QX56
