INFINITI QX56 2010 Factory Service Manual

CCS-42
< COMPONENT DIAGNOSIS >
DTC 102 LASER STAIN
DTC 102 LASER STAIN
DTC 102 LASER STAININFOID:0000000005145999
1.VISUAL INSPECTION (1)
Check that there is no contamination and foreign material on ICC sensor body window.
Is the ICC sensor clean?
YES >> GO TO 2
NO >> • Clean ICC sensor. • Erase DTC and perform ICC system running test. Refer to CCS-8, "
ACTION TEST : ICC Sys-
tem Running Test".
2.VISUAL INSPECTION (2)
Check ICC sensor body window for cracks.
Is the ICC sensor window undamaged?
YES >> GO TO 3
NO >> • Replace ICC sensor and adjust laser beam. Refer to CCS-72, "
ICC Sensor".
• Erase DTC and perform ICC system running test. Refer to CCS-8, "
ACTION TEST : ICC Sys-
tem Running Test".
3.ASK CUSTOMER FOR DRIVING CONDITIONS
1. Is there any trace of contaminati on or foreign material on ICC sensor?
2. Is there any possibility that vehicle was driven in snow or ICC sensor was frosted?
3. Is there any possibility that ICC sensor was f ogged temporarily? (Front window glass may have also been
fogged.)
Was the ICC sensor obstructed by normal conditions?
YES >> Explain system operation and parameters to customer. System may be operating normally.
NO >> • Replace ICC sensor and adjus t laser beam aiming. Refer to CCS-72, "
ICC Sensor".
• Erase DTC and perform ICC system running test. Refer to CCS-8, "
ACTION TEST : ICC Sys-
tem Running Test".
Revision: April 20092010 QX56

CCS
DTC 103 LASER SENSOR FAILCCS-43
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
K L
M B
N P A
DTC 103 LASER SENSOR FAIL
DTC 103 LASER SENSOR FAILINFOID:0000000005146000
1.DIAGNOSTIC CHECK
Perform self-diagonsis.
Are "DTC 11 CONTROL UNIT" or DTC 20 CAN COMM CIRCUIT" indicated in self diagnosis?
YES >> GO TO applicable item inspection. Refer to CCS-22, "DTC 11 CONTROL UNIT", and CCS-24,
"DTC 20 CAN COMM CIRCUIT".
NO >> • Replace ICC sensor and adjust laser beam aiming. Refer to CCS-72, "
ICC Sensor".
• Erase DTC and perform ICC system running test. Refer to CCS-8, "
ACTION TEST : ICC Sys-
tem Running Test".
Revision: April 20092010 QX56

CCS-44
< COMPONENT DIAGNOSIS >
DTC 104 LASER AIMING INCMP
DTC 104 LASER AIMING INCMP
DTC 104 LASER AIMING INCMPINFOID:0000000005146001
1.DIAGNOSTIC CHECK
1. Adjust laser beam aiming. Refer to CCS-5, "
LASER BEAM AIMING ADJUSTMENT : Outline of Laser
Beam Aiming Adjustment Procedure". Erase DTC and perform ICC system running test. Refer to CCS-8,
"ACTION TEST : ICC System Running Test".
2. Perform self-diagnosis of ICC system.
Is "DTC 104 LASER AIMING INCMP" indicated?
YES >> • Replace ICC sensor and adjus t laser beam aiming. Refer to CCS-72, "ICC Sensor".
• Erase DTC and perform ICC system running test. Refer to CCS-8, "
ACTION TEST : ICC Sys-
tem Running Test".
NO >> Inspection end.
Revision: April 20092010 QX56

CCS
DTC 107 LASER COMM FAILCCS-45
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
K L
M B
N P A
DTC 107 LASER COMM FAIL
DTC 107 LASER COMM FAILINFOID:0000000005146002
1.DIAGNOSTIC CHECK
Perform self-diagnosis?
Is "DTC 11 CONTROL UNIT" or "DTC 20 CAN COMM CIRCUIT" indicated?
YES >> GO TO applicable item inspection. Refer to CCS-22, "DTC 11 CONTROL UNIT", or CCS-24,
"DTC 20 CAN COMM CIRCUIT".
NO >> • Replace ICC sensor and adjust laser beam aiming. Refer to CCS-72, "
ICC Sensor".
• Erase DTC and perform ICC system running test. Refer to CCS-8, "
ACTION TEST : ICC Sys-
tem Running Test".
Revision: April 20092010 QX56

CCS-46
< COMPONENT DIAGNOSIS >
DTC109 LASER HIGH TEMP
DTC109 LASER HIGH TEMP
DTC 109 LASER HIGH TEMPINFOID:0000000005146003
1.CHECK SYMPTOM
Inspect engine cooling system.
Did the engine overheat?
YES >> • Repair cooling system. • Erase DTC and perform ICC system running test. Refer to CCS-8, "
ACTION TEST : ICC Sys-
tem Running Test". Then perform self-diagnosis of ICC system again.
NO >> • Replace ICC sensor and adjus t laser beam aiming. Refer to CCS-72, "
ICC Sensor".
• Erase DTC, then perform ICC system running test. Refer to CCS-8, "
ACTION TEST : ICC Sys-
tem Running Test". Then perform self-diagnosis of ICC system again.
Revision: April 20092010 QX56

CCS
ICC UNITCCS-47
< ECU DIAGNOSIS >
C
DE
F
G H
I
J
K L
M B
N P A
ECU DIAGNOSIS
ICC UNIT
Terminal and Reference Value for ICC UnitINFOID:0000000005146004
Te r m i n a l Wire col-
or Item Condition
Voltage (V)
(Approx.)
Ignition
switch Operation
1W/L Battery power supply OFF— Battery voltage
2W/L
5 P CAN-L —— —
7 B/R N-P RANGE ON A/T selector lever in "P" or "N"Battery voltage
10 V/R Brake booster signal ON—
14 L CAN-H —— —
19 B Ground
ON——
20 B
29 BR/W ICC brake switch
(normally closed) Selector le-
ver: Not in “N” or “P” position Depress the brake
pedal
0
Release the brake
pedal Battery voltage
30 L TX —— —
33 R/B Ignition switch power supply ON —
Battery voltage
38 R/G Stop lamp switch
(normally open) OFFDepress the brake pedal
Release the brake pedal
0
39 V/W RX —— —
40 G Parking brake signal
ONParking brake is ON
0
Parking brake is OFF Battery voltage
42 R/B Ignition switch power supply —Battery voltage
46 B Ground ——
47 BR Stop lamp drive output signal Brake operating with ICC system
Battery voltage
Brake not operating with ICC sys-
tem 0
SKIA1243E
Revision: April 20092010 QX56

CCS-48
< ECU DIAGNOSIS >
ICC UNIT
Wiring Diagram
INFOID:0000000005146005
ABOWA0005GB
Revision: April 20092010 QX56

CCS
ICC UNITCCS-49
< ECU DIAGNOSIS >
C
DE
F
G H
I
J
K L
M B
N P A
ABOWA0004GB
Revision: April 20092010 QX56

CCS-50
< ECU DIAGNOSIS >
ICC UNIT
ABOIA0011GB
Revision: April 20092010 QX56

CCS
ICC UNITCCS-51
< ECU DIAGNOSIS >
C
DE
F
G H
I
J
K L
M B
N P A
ABOIA0012GB
Revision: April 20092010 QX56
