homelink INFINITI QX56 2010 Factory Service Manual

DLK-2
System Diagram .....................................................47
System Description .................................................47
Component Parts Location ...................................48
Component Description .........................................50
HOMELINK UNIVERSAL TRANSCEIVER ........51
Component Description ....................................... ...51
DIAGNOSIS SYSTEM (BCM) ............................52
COMMON ITEM ..................................................... ...52
COMMON ITEM : CONSULT-III Function (BCM -
COMMON ITEM) ................................................. ...
52
DOOR LOCK .......................................................... ...52
DOOR LOCK : CONSULT-III Function (BCM -
DOOR LOCK) .........................................................
53
MULTIREMOTE ENT ............................................. ...53
MULTIREMOTE ENT : CONSULT-III Function
(BCM - MULTIREMOTE ENT) ................................
53
INTELLIGENT KEY ................................................ ...55
INTELLIGENT KEY : CONSULT-III Function
(BCM - INTELLIGENT KEY) ...................................
55
DIAGNOSIS SYSTEM (INTELLIGENT KEY
UNIT) ............................................................... ...
56
CONSULT-III Function (INTELLIGENT KEY) ...... ...56
COMPONENT DIAGNOSIS ........................58
U1000 CAN COMM CIRCUIT ......................... ...58
Description ........................................................... ...58
DTC Logic ...............................................................58
Diagnosis Procedure ..............................................58
U1010 CONTROL UNIT (CAN) .........................59
DTC Logic ............................................................ ...59
Diagnosis Procedure ..............................................59
Special Repair Requirement ...................................59
CENTER CONSOLE AREA ANTENNA
(REAR) ............................................................ ...
60
Description ........................................................... ...60
Component Function Check .................................60
Diagnosis Procedure ..............................................60
LUGGAGE AREA ANTENNA ...........................62
Description ..............................................................62
Component Function Check .................................62
Diagnosis Procedure ..............................................62
CENTER CONSOLE AREA ANTENNA
(FRONT) .............................................................
64
Description ........................................................... ...64
Component Function Check .................................64
Diagnosis Procedure ..............................................64
OVERHEAD CONSOLE AREA ANTENNA ......66
Description ........................................................... ...66
Component Function Check .................................66
Diagnosis Procedure ............................................ ...66
POWER SUPPLY AND GROUND CIRCUIT .....68
INTELLIGENT KEY UNIT ....................................... ...68
INTELLIGENT KEY UNIT : Diagnosis Procedure ...68
BCM (BODY CONTROL MODULE) ..........................68
BCM (BODY CONTROL MODULE) : Diagnosis
Procedure ...............................................................
68
BACK DOOR CONTROL UNIT .............................. ...69
BACK DOOR CONTROL UNIT : Diagnosis Proce-
dure ...................................................................... ...
69
DOOR SWITCH .................................................71
Description ........................................................... ...71
Component Function Check ..................................71
Diagnosis Procedure ...............................................71
DOOR LOCK AND UNLOCK SWITCH .............74
DRIVER SIDE ......................................................... ...74
DRIVER SIDE : Description ....................................74
DRIVER SIDE : Component Function Check ........74
DRIVER SIDE : Diagnosis Procedure .....................74
PASSENGER SIDE ...................................................76
PASSENGER SIDE : Descripti on ...........................76
PASSENGER SIDE :
Component Function Check ............................... ...
76
PASSENGER SIDE : Diagnosis Procedure ............76
KEY CYLINDER SWITCH .................................79
Description ........................................................... ...79
Component Function Check ...................................79
Diagnosis Procedure ...............................................79
FRONT DOOR LOCK ACTUATOR LH (DOOR
UNLOCK SENSOR) ..........................................
81
Description ........................................................... ...81
Component Function Check ..................................81
Diagnosis Procedure ...............................................81
Component Inspection ............................................82
DOOR REQUEST SWITCH ...............................83
Description ..............................................................83
Component Function Check ..................................83
Diagnosis Procedure ...............................................83
Component Inspection ............................................85
DOOR LOCK ACTUATOR ................................86
DRIVER SIDE ......................................................... ...86
DRIVER SIDE : Description ....................................86
DRIVER SIDE : Component Function Check ........86
DRIVER SIDE : Diagnosis Procedure .....................86
PASSENGER SIDE ...................................................87
PASSENGER SIDE : Descripti on ...........................87
PASSENGER SIDE :
Component Function Check ............................... ...
87
PASSENGER SIDE : Diagnosis Procedure ............87
Revision: April 20092010 QX56

DLK-4
Diagnosis Procedure .............................................138
BACK DOOR CLOSE SWITCH SYSTEM .......139
Diagnosis Procedure ........................................... ..139
BACK DOOR SWITCH ....................................140
Diagnosis Procedure ........................................... ..140
CINCH LATCH MOTOR SYSTEM ...................141
Diagnosis Procedure ........................................... ..141
INTELLIGENT KEY UNIT POWER BACK
DOOR INPUT SIGNAL ....................................
142
Description ........................................................... ..142
Diagnosis Procedure .............................................142
INTELLIGENT KEY UNIT POWER BACK
DOOR OUTPUT SIGNAL ................................
143
Description ........................................................... ..143
Diagnosis Procedure .............................................143
HOMELINK UNIVERSAL TRANSCEIVER ......144
Wiring Diagram .................................................... ..144
Description .............................................................145
Component Function Check ................................146
Diagnosis Procedure .............................................146
ECU DIAGNOSIS ..................................... ..148
BCM (BODY CONTROL MODULE) ............... .148
Reference Value .................................................. ..148
Terminal Layout .....................................................151
Physical Values .....................................................151
Wiring Diagram — POWER DOOR LOCK SYS-
TEM — ..................................................................
157
Fail Safe ................................................................170
DTC Inspection Priority Chart .............................171
DTC Index ........................................................... ..171
INTELLIGENT KEY UNIT ................................173
Reference Value .................................................. ..173
Terminal Layout - Intelligent Key Unit ....................174
Physical Values - Intelligent Key Unit ....................174
Terminal Layout - Steering Lock Solenoid ........... ..177
Physical Values - Steering Lock Solenoid .............177
Wiring Diagram — INTELLIGENT KEY SYSTEM
— ...........................................................................
178
Fail Safe ................................................................195
DTC Inspection Priority Chart .............................196
DTC Index ........................................................... ..196
BACK DOOR CONTROL UNIT .......................197
Reference Value .................................................. ..197
Wiring Diagram—AUTOMATIC BACK DOOR
SYSTEM— ............................................................
199
Fail Safe .............................................................. ..209
SYMPTOM DIAGNOSIS ............................210
INTELLIGENT KEY SYSTEM SYMPTOMS ... .210
Symptom Table ................................................... ..210
DOOR LOCK FUNCTION SYMPTOMS ...........211
DOOR LOCK AND UNLOCK SWITCH .................. .211
DOOR LOCK AND UNLOCK SWITCH : Symptom
Table .....................................................................
211
INTELLIGENT KEY ................................................ .212
INTELLIGENT KEY : Symptom Table ..................212
BACK DOOR OPENER FUNCTION ................214
BACK DOOR OPENER SWITCH .......................... .214
BACK DOOR OPENER SWITCH : Symptom Ta-
ble ........................................................................ .
214
BACK DOOR HANDLE .......................................... .214
BACK DOOR HANDLE : Symptom Table .............215
INTELLIGENT KEY ................................................ .215
INTELLIGENT KEY : Symptom Table ..................215
WARNING FUNCTION SYMPTOMS ...............216
Symptom Table .................................................... .216
KEY REMINDER FUNCTION SYMPTOMS .....219
Symptom Table .................................................... .219
HAZARD FUNCTION ..................................... ..220
Symptom Table .................................................... .220
HORN FUNCTION ............................................221
Symptom Table .................................................... .221
HOMELINK UNIVERSAL TRANSCEIVER ......222
Symptom Table .................................................... .222
SQUEAK AND RATTLE TROUBLE DIAG-
NOSES ..............................................................
223
Work Flow ............................................................ .223
Inspection Procedure ............................................225
Diagnostic Worksheet ...........................................227
PRECAUTION ...........................................229
PRECAUTIONS .............................................. ..229
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" .............................................................. .
229
Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect ................................
229
Precaution for work ...............................................230
PREPARATION .........................................231
PREPARATION .............................................. ..231
Special Service Tool ............................................ .231
Commercial Service Tool ......................................232
ON-VEHICLE REPAIR ..............................233
HOOD ............................................................. ..233
Fitting Adjustment ................................................ .233
Removal and Installation of Hood Assembly ........234
Revision: April 20092010 QX56

HOMELINK UNIVERSAL TRANSCEIVERDLK-51
< FUNCTION DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
HOMELINK UNIVERSAL TRANSCEIVER
Component DescriptionINFOID:0000000005146899
Item FunctionReference page
Homelink universal transceiver A maximum of 3 radio signals can be stored and transmitted to operate
the garage door, etc. Refer to Owner's
Manual
Revision: April 20092010 QX56

DLK-144
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
HOMELINK UNIVERSAL TRANSCEIVER
HOMELINK UNIVERSAL TRANSCEIVER
Wiring DiagramINFOID:0000000005147014
ABKWA0018GB
Revision: April 20092010 QX56

HOMELINK UNIVERSAL TRANSCEIVERDLK-145
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DescriptionINFOID:0000000005147015
Homelink universal transceiver can store and transmit a maximum of 3 radio signals.
Allows operation of garage doors, gates, home and office lighting, entry door locks and security system, etc.
Homelink universal transceiver power supply uses vehicle battery, which enables it to maintain every program
in case battery is discharged or removed.
ABKIA0056GB
Revision: April 20092010 QX56

DLK-146
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
HOMELINK UNIVERSAL TRANSCEIVER
Component Function Check
INFOID:0000000005147016
1.CHECK FUNCTION
Check that system receiver (garage door opener, et c.) operates with original hand-held transmitter.
Is the inspection result normal?
YES >> GO TO 2
NO >> Receiver or hand-held transmitter is malfunctioning.
2.CHECK ILLUMINATION
1. Turn ignition switch “OFF”.
2. Press each of the transmitter buttons and watch for the red light
to illuminate with each button.
Is the inspection result normal?
YES >> GO TO 3
NO >> Refer to DLK-146, "
Diagnosis Procedure".
3.CHECK TRANSMITTER
Check transmitter with Tool*.
*:For details, refer to Technical Service Bulletin.
Is the inspection result normal?
YES >> Receiver or hand-held transmitter malfunction, not vehicle related.
NO >> Replace auto anti-dazzling inside mirror (homelink universal transceiver).
Diagnosis ProcedureINFOID:0000000005147017
Regarding Wiring Diagram information, refer to DLK-144, "Wiring Diagram".
1.CHECK POWER SUPPLY
1. Disconnect auto anti-dazzling inside mirror (homelink universal transceiver) connector.
2. Check voltage between auto anti-dazzling inside mirror (homelink universal transceiver) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2
PIIA4815E
ALKIA0659ZZ
Auto anti-dazzling inside mirror
(Homelink universal transceiver)
connector Terminal Condition
Voltage (V)
(Approx.)
R7 10 Ground Ignition switch position: LOCK Battery voltage
Revision: April 20092010 QX56

HOMELINK UNIVERSAL TRANSCEIVERDLK-147
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
NO >> Check the following. • 10A fuse [No. 19 located in the fuse block (J/B)]
• Harness for open or short between fuse and auto anti-dazzling inside mirror (homelink universaltransceiver).
2.CHECK GROUND CIRCUIT
Check continuity between auto anti-dazzling inside mirror (homelink
universal transceiver) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair harness.
3.CHECK INTERMITTENT INCIDENT
Refer to GI-38, "
Intermittent Incident".
>> INSPECTION END.
ALKIA0660ZZ
Auto anti-dazzling inside mirror
(Homelink universal transceiver) connector Te r m i n a l
Ground Continuity
R7 8 Yes
Revision: April 20092010 QX56

DLK-222
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
HOMELINK UNIVERSAL TRANSCEIVER
HOMELINK UNIVERSAL TRANSCEIVER
Symptom TableINFOID:0000000005147042
HOMELINK UNIVERSAL TRANSCEIVER MALFUNCTION
Symptom
Diagnosis/service procedureReference page
Homelink universal transceiver does not operate properly. 1. Check homelink universal transceiver function.
DLK-146
2. Check Intermittent Incident. GI-38
Revision: April 20092010 QX56
