P0037, P0038, P0057, P0058 HO2S2 HEATER
EC-185
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.DETECT MALFUNCTIONING PART
Check the following.
 20 A fuse (No. 43)
 Harness for open or short between heated oxygen sensor 2 and fuse
 Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
3.CHECK HO2S2 OUTPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between HO2S2 harness connector and ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
4.CHECK HO2S2 HEATER
Refer to EC-186, "
Component Inspection (HO2 Sensor 2 Heater)".
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 5.
5.REPLACE HEATED OXYGEN SENSOR 2
Replace malfunctioning heated oxygen sensor 2. Refer to EX-5, "
Removal and Installation".
CAUTION:
 Discard any heated oxygen sensor which has been dr opped from a height of more than 0.5 m (19.7
in) onto a hard surface such as a concrete floor; use a new one.
 Before installing new oxygen sensor, clean exh aust system threads using Oxygen Sensor Thread
Cleaner [commercial service tool (J-43897-18 or J-43897-12)] and approved anti-seize lubricant
(commercial service tool).
>> INSPECTION END
6.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
DTC HO2S2
Ground Voltage
Bank Connector Terminal
P0037, P0038 1 F87 2 Ground Battery voltage
P0057, P0058 2 F88 2
DTC HO2S2 ECM
Continuity
Bank Connector Terminal Connector Terminal
P0037, P0038 1 F87 3 F 11147
Existed
P0057, P0058 2 F88 3 52
Revision: 2010 May2011 QX56

EC-186
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0037, P0038, P0057,
P0058 HO2S2 HEATER
Component Inspection (HO2 Sensor 2 Heater)
INFOID:0000000006217780
1.CHECK HEATED OXYGEN SENSOR 2 HEATER
1. Turn ignition switch OFF.
2. Disconnect heated oxygen sensor 2 (HO2S2) harness connector.
3. Check resistance between HO2S2 terminals as follows.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.REPLACE HEATED OXYGEN SENSOR 2
Replace malfunctioning heated oxygen sensor 2. Refer to EX-5, "
Removal and Installation".
CAUTION:
 Discard any heated oxygen sensor which has been dropped from a height of more than 0.5 m (19.7
in) onto a hard surface such as a concrete floor; use a new one.
 Before installing new oxygen sensor, clean exh aust system threads using Oxygen Sensor Thread
Cleaner [commercial service tool (J-43897-18 or J-43897-12)] and approved anti-seize lubricant
(commercial service tool).
>> INSPECTION END
Terminal Resistance2 and 3 3.4 - 4.4 Ω [at 25 °C (77 °F)]
1 and 2, 3, 4 ∞ Ω
(Continuity should not exist)
4 and 1, 2, 3
Revision: 2010 May2011 QX56

EC-238
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0133, P0153 A/F SENSOR 1
P0133, P0153 A/F SENSOR 1
DTC LogicINFOID:0000000006217811
DTC DETECTION LOGIC
To judge the malfunction of A/F sensor
1, this diagnosis measures response time of the A/F signal computed
by ECM from the A/F sensor 1 signal. The time is compensated by engine operating (speed and load), fuel
feedback control constant, and the A/F sensor 1 temper ature index. Judgment is based on whether the com-
pensated time (the A/F signal cycling time index) is inordinately long or not.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
Will CONSULT-III be used?
YES >> GO TO 2.
NO >> GO TO 5.
2.PERFORM DTC CONFIRMATION PROCEDURE-I
WITH CONSULT-III
1. Start engine and warm it up to normal operating temperature.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Restart engine and keep the engine speed between 3,500 and 4,000 rpm for at least 1 minute under no load.
6. Let engine idle for 1 minute.
7. Select “A/F SEN1(B1) P1278/P1279” (for DTC P 0133) or “A/F SEN1(B2) P1288/P1289” (for DTC P0153)
of “A/F SEN1” in “DTC WORK SUPPORT” mode with CONSULT-III.
8. Touch “START”.
Is
“COMPLETED” displayed on CONSULT-III screen?
YES >> GO TO 3
NO >> GO TO 4.
3.PERFORM DTC CONFIRMATION PROCEDURE-II
Touch “SELF-DIAG RESULT”.
Which is displayed on CONSULT-III screen?
OK >> INSPECTION END
NG >> Go to EC-239, "
Diagnosis Procedure".
4.PERFORM DTC CONFIRMATION PROCEDURE-II
DTC No.Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible Cause
P0133 A/F SENSOR1 (B1)
[Air fuel ratio (A/F) sensor 1
(bank 1) circuit slow response]
 The response of the A/F signal computed by ECM from A/F sensor 1 signal takes
more than the specified time.  Harness or connectors
(The A/F sensor 1 circuit is open or
shorted.)
 A/F sensor 1
 A/F sensor 1 heater
 Fuel pressure
 Fuel injector
 Intake air leaks
 Exhaust gas leaks
PCV
 Mass air flow sensor
P0153
A/F SENSOR1 (B2)
[Air fuel ratio (A/F) sensor 1
(bank 2) circuit slow response]
Revision: 2010 May2011 QX56

P0133, P0153 A/F SENSOR 1EC-241
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
5. Also check harness for short to power.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
7.CHECK A/F SENSOR 1 GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between A/F sensor 1 harness connector and ECM harness connector.
4. Also check harness for short to power.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
8.CHECK A/F SENSOR 1 HEATER
Refer to EC-182, "
Component Inspection (A/F Sensor 1 Heater)".
Is the inspection result normal?
YES >> GO TO 9.
NO >> GO TO 12.
9.CHECK MASS AIR FLOW SENSOR
Check mass air flow sensor.
Refer to EC-190, "
Component Inspection (MAF Sensor)".
Is the inspection result normal?
YES >> GO TO 10.
NO >> Replace malfunctioning mass air flow sensor. Refer to EM-30, "
Removal and Installation".
10.CHECK PCV VALVE
Refer to EC-534, "
Inspection".
Is the inspection result normal?
YES >> GO TO 11.
NO >> Repair or replace PCV valve.
11 .CHECK INTERMITTENT INCIDENT
Perform GI-40, "
Intermittent Incident".
Is the inspection result normal?
YES >> GO TO 12.
NO >> Repair or replace malfunctioning part.
12.REPLACE A/F SENSOR 1
Replace malfunctioning A/F sensor 1. Refer to EM-40, "
Exploded View".
CAUTION:
 Discard any A/F sensor which has been dropped from a height of more than 0.5 m (19.7 in) onto a
hard surface such as a concrete floor; use a new one.
DTC A/F sensor 1 ECM
Ground Continuity
Bank Connector Terminal Connector Terminal
P0133 1 F67 3 F11088
Ground Not existed
P0153 2 F68 3 78
DTC A/F sensor 1 ECM
Continuity
Bank Connector Terminal Connector Terminal
P0133 1 F67 6 F 11194
Existed
P0153 2 F68 6 74
Revision: 2010 May2011 QX56

EC-296
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0300, P0301, P0302, P
0303, P0304, P0305, P0306, P0307, P0308 MISFIRE
4. Also check harness for short to power.
Is the inspection result normal?
YES >> GO TO 16.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
16.CHECK A/F SENSOR 1 HEATER
Refer to EC-182, "
Component Inspection (A/F Sensor 1 Heater)".
Is the inspection result normal?
YES >> GO TO 17.
NO >> Replace malfunctioning A/F sensor 1. Refer to EX-5, "
Exploded View".
17.CHECK MASS AIR FLOW SENSOR
WITH CONSULT-III
Check mass air flow sensor signal in “DATA MONITOR” mode with CONSULT-III.
For specification, refer to EC-538, "
Mass Air Flow Sensor".
WITH GST
Check mass air flow sensor signal in Service $01 with GST.
For specification, refer to EC-538, "
Mass Air Flow Sensor".
Is the measurement value within the specification?
YES >> GO TO 18.
NO >> Check connectors for rusted terminals or loose connections in the mass air flow sensor circuit or
ground. Refer to EC-201, "
Diagnosis Procedure".
18.CHECK SYMPTOM MATRIX CHART
Check items on the rough idle symptom in EC-524, "
Symptom Table".
Is the inspection result normal?
YES >> GO TO 19.
NO >> Repair or replace malfunctioning part.
19.ERASE THE 1ST TRIP DTC
Some tests may cause a 1st trip DTC to be set.
Erase the 1st trip DTC from the ECM memo ry after performing the tests. Refer to EC-63, "
CONSULT-III
Function" or EC-60, "On Board Diagnosis Function".
>> GO TO 20.
20.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
DTC A/F sensor 1 ECM
Continuity
Bank Connector Terminal Connector Terminal
P0130 1 F67 6 F11094
Existed
P0150 2 F68 6 74
Revision: 2010 May2011 QX56

EC-396
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P1148, P1168 CLOSED LOOP CONTROL
P1148, P1168 CLOSED LOOP CONTROL
DTC LogicINFOID:0000000006288347
DTC DETECTION LOGIC
NOTE:
DTC P1148 or P1168 is displayed with DTC for A/F sensor 1.
When the DTC is detected, perform the trouble di
agnosis of DTC corresponding to A/F sensor 1.
Diagnosis ProcedureINFOID:0000000006288348
DTC P1148 or P1168 is displayed with DTC for A/F sensor 1.
When the DTC is detected, perform the trouble diagnosis of DTC corresponding to A/F sensor 1.Refer to EC-
98, "DTC Index".
DTC No.Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P1148 CLOSED LOOP-B1
[Closed loop control function
(bank 1)] The closed loop control function for bank 1
does not operate even when vehicle is being
driven in the specified condition.
 Harness or connectors
(The A/F sensor 1 circuit is open or
shorted.)
 A/F sensor 1
 A/F sensor 1 heater
P1168 CLOSED LOOP-B2
[Closed loop control function
(bank 2)] The closed loop control function for bank 2
does not operate even when vehicle is being
driven in the specified condition.
Revision: 2010 May2011 QX56

P2A00, P2A03 A/F SENSOR 1EC-487
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P2A00, P2A03 A/F SENSOR 1
DTC LogicINFOID:0000000006217987
DTC DETECTION LOGIC
To judge the malfunction, the A/F signal computed by ECM fr
om the A/F sensor 1 signal is monitored so it will
not shift to LEAN side or RICH side.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Clear the mixture ratio self-learning value. Refer to EC-152, "
Work Procedure".
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Start engine and keep the engine speed between 3,500 and 4,000 rpm for 1 minute under no load.
6. Let engine idle for 1 minute.
7. Keep engine speed between 2,500 and 3,000 rpm for 20 minutes.
8. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-487, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217988
1.RETIGHTEN A/F SENSOR 1
Loosen and retighten the A/F sensor 1. Refer to EX-5, "
Exploded View".
>> GO TO 2.
2.CHECK A/F SENSOR 1 CONNECTOR
1. Disconnect A/F sensor 1 harness connector.
2. Check that water is not inside connectors.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness connector.
3.CHECK FOR INTAKE AIR LEAKAGE
1. Reconnect A/F sensor 1 harness connector.
2. Start engine and run it at idle.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P2A00 A/F SENSOR1 (B1)
(Air fuel ratio (A/F) sensor 1 (bank 1)
circuit range/performance)  The output voltage computed by ECM from
the A/F sensor 1 signal shifts to the lean side
for a specified period.
 The A/F signal computed by ECM from the
A/F sensor 1 signal shifts to the rich side for
a specified period.  A/F sensor 1
 A/F sensor 1 heater
 Fuel pressure
 Fuel injector
 Intake air leaks
P2A03 A/F SENSOR1 (B2)
(Air fuel ratio (A/F) sensor 1 (bank 2)
circuit range/performance)
Revision: 2010 May2011 QX56

P2A00, P2A03 A/F SENSOR 1EC-489
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
4. Also check harness for short to power.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
8.CHECK A/F SENSOR 1 HEATER
Refer to EC-182, "
Component Inspection (A/F Sensor 1 Heater)".
Is the inspection result normal?
YES >> GO TO 9.
NO >> GO TO 10.
9.CHECK INTERMITTENT INCIDENT
Perform GI-40, "
Intermittent Incident".
Is the inspection result normal?
YES >> GO TO 10.
NO >> Repair or replace malfunctioning part.
10.REPLACE AIR FUEL RATIO (A/F) SENSOR 1
Replace air fuel ratio (A/F) sensor 1. Refer to EX-5, "
Exploded View".
CAUTION:
 Discard any A/F sensor which has been dropped from a height of more than 0.5 m (19.7 in) onto a
hard surface such as a concrete floor; use a new one.
 Before installing new A/F senso r, clean exhaust system threads using Oxygen Sensor Thread
Cleaner [commercial service tool (J-43897-18 or J-43897-12)] and approved anti-seize lubricant
(commercial service tool).
Will CONSULT-III be used?
YES >> GO TO 11.
NO >> GO TO 12.
11 .CONFIRM A/F ADJUSTMENT DATA
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “A/F ADJ-B1” and “A/F ADJ-B2” in “DATA MONITOR” mode with CONSULT-III.
3. Check that “0.000” is di splayed on CONSULT-III screen.
Is
“0.000” displayed?
YES >> INSPECTION END
NO >> GO TO 12.
12.CLEAR THE MIXTURE RATIO SELF-LEARNING VALUE
Clear the mixture ratio self-learning value. Refer to EC-152, "
Work Procedure".
Will CONSULT-III be used?
YES >> GO TO 13.
NO >> INSPECTION END
13.CONFIRM A/F ADJUSTMENT DATA
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “A/F ADJ-B1” and “A/F ADJ-B2” in “DATA MONITOR” mode with CONSULT-III.
3. Check that “0.000” is di splayed on CONSULT-III screen.
>> INSPECTION END
DTC A/F sensor 1 ECM
Continuity
Bank Connector Terminal Connector Terminal
P2A00 1 F67 6 F11094
Existed
P2A03 2 F68 6 74
Revision: 2010 May2011 QX56

ELECTRICAL LOAD SIGNALEC-493
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ELECTRICAL LOAD SIGNAL
DescriptionINFOID:0000000006217994
The electrical load signal (Rear window defogger switch
signal, headlamp switch signal, heater fan switch sig-
nal, etc.) is transferred via the CAN communication line.
Component Function CheckINFOID:0000000006217995
1.CHECK REAR WINDOW DEF OGGER SWITCH FUNCTION
1. Turn ignition switch ON.
2. Select “DATA MONITOR” mode with CONSULT-III.
3. Select “LOAD SIGNAL” and check indication under the following conditions.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Go to EC-493, "
Diagnosis Procedure".
2.CHECK LIGHTING SWITCH FUNCTION
Check “LOAD SIGNAL” indication under the following conditions.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Go to EC-493, "
Diagnosis Procedure".
3.CHECK HEATER FAN CONTROL SWITCH FUNCTION
Select “HEATER FAN SW” and check indication under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-493, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006217996
1.INSPECTION START
Confirm the malfunctioning circuit (rear window defogger, headlamp or heater fan). Refer to EC-493, "
Compo-
nent Function Check".
Which circuit is related to the incident?
Rear window defogger>>GO TO 2.
Headlamp>>GO TO 3.
Heater fan>>GO TO 4.
2.CHECK REAR WINDOW DEFOGGER SYSTEM
Refer to DEF-24, "
Work Flow".
Monitor item Condition Indication
LOAD SIGNAL Rear window defogger switch ON ON
OFF OFF
Monitor item Condition Indication
LOAD SIGNAL Lighting switch ON at 2nd position ON
OFF OFF
Monitor item Condition Indication
HEATER FAN SW Heater fan control switch ON ON
OFF OFF
Revision: 2010 May2011 QX56

EC-494
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
ELECTRICAL LOAD SIGNAL
>> INSPECTION END
3.CHECK HEADLAMP SYSTEM
Refer to EXL-59, "
Work Flow".
>> INSPECTION END
4.CHECK HEATER FAN CONTROL SYSTEM
Refer to HAC-60, "
Work Flow".
>> INSPECTION END
Revision: 2010 May2011 QX56
