INFINITI QX60 2017 Owner's Manual

9Random mode indicator
Touch to change the random mode.
Mode Screen display
Random Off
OFF
All Random
All
1 Folder Random
1 Folder
Depending on the audio device that is connected
to the vehicle, track information may not be dis-
played.
Bluetooth® streaming audio operation
The ability to pause, change tracks, fast-forward,
rewind, randomize and repeat music may be dif-
ferent between devices. Some or all of these
functions may not be supported on each device.
● Depending on the Bluetooth® streaming
audio device that is connected, it may not be
possible to perform audio operations.
● Depending on the Bluetooth® streaming
audio device that is connected, a time lag
may occur before music is played back.
● Depending on the application except for the
native audio application that is played on the
Bluetooth® streaming audio device, incor-
rect behavior (information lacking, timer
skipping, etc.) may occur. Activation and playing
Bluetooth® streaming audio device can be se-
lected from the audio sources list by touching the
“Source” key or by pushing the MEDIA button.
For additional information, refer to “Selecting au-
dio source” and “Main audio buttons” in this
section.
To play the Bluetooth® streaming audio device,
touch the “Play” key and to pause the Bluetooth®
streaming audio device, touch the “Pause” key in
the Bluetooth® streaming audio menu.
Selecting folder/track
Touch the “Folder/Track” key to select a
folder/track.
Changing play mode
Touch the “Repeat” key or “Random” key in the
Bluetooth® streaming audio menu to change the
play mode.
Fast-forwarding/rewinding
Push and hold the SEEK•CAT•TRACK button to
fast-forward the song. Release the SEEK•CAT-
•TRACK button to play the song at normal speed.
Skipping songs/folders
Push the SEEK•CAT•TRACK button to skip to
the next or previous song.
To skip to the next or previous folder, turn the
TUNE/FOLDER AUDIO button.
Bluetooth® streaming audio controls
Touch the “Control” key on the Bluetooth® Audio
operation screen to display the control screen.
“Select Audio Device” key Touch to select a different
Bluetooth® streaming
audio device from a list of
registered Bluetooth®
devices. For additional
information, refer to
“Bluetooth® settings” in
this section.
“Connect Device” key Touch to connect a new Bluetooth® device.
4-88Monitor, climate, audio, phone and voice recognition systems

DIGITAL VERSATILE DISC (DVD)
PLAYER (if so equipped)
Touch screen display
1Title/chapter number:
This indicates the DVD title/chapter number
currently selected.
2Play time:
The play time of the track is displayed.
3DVD operation menu:
DVD menu items are displayed. Touch a key
to operate the DVD.
● “Play/Pause” key ●
“Stop” key
● “Skip <<” key
● “Skip >>” key
● “
” key
● “CM <<” key
● “CM >>” key
● “Top Menu” key
● “Title List” key
● “Title Menu” key
● “10 Key Search” key
● “Select No.” key
● “Previous Title” key
● “Next Title” key
● “Default Position” key
● “Display Settings” key
● “Play Mode” key
4Play mode indicator
This indicates the current play mode.
Mode Screen display
1 Disc Repeat
Disc
1 Chapter Repeat
1 Chapter
● The DVD menu list will appear when the
screen is touched while a movie is play-
ing.
● The availability of the DVD menu items
depend on the type of DVD.
5“Select Rear Source” key
The select rear source screen is displayed.
For additional information, refer to “Control-
ling the rear system on the front display” in
this section.
DVD player operation
Precautions
● Use DVDs with the region code “ALL” or the
code applicable to the DVD player. (The
region code is displayed as a small symbol
printed on the top of the DVD) . This vehicle-
installed DVD player can only play DVDs
with the applicable region code.
● Images cannot be displayed when the igni-
tion switch is in the ON position.
● Some VIDEO-CD functions may not be sup-
ported with this system.
● Displaying items may vary depending on the
type of disc.JVH1506M
Monitor, climate, audio, phone and voice recognition systems4-89

Loading
Insert the DVD into the slot with the label side
facing up. The DVD will be guided automatically
into the slot and start playback.
When a DVD is loaded, the DVD operation
screen is displayed on the display.
Activation and playing
Inserting the DVD into the slot will activate the
DVD mode. The DVD mode can also be selected
from the source list by pushing the DISC button
with a DVD loaded. For additional information,
refer to “Selecting audio source” and “Main audio
buttons” in this section.
Touch the “Play” key in the DVD menu to start
playing. Touch the “Pause” key to pause and
touch the “Stop” key to stop playing the DVD.
Skipping
Touch the “Skip >>” key or “Skip <<” key in the
DVD menu to skip to the next or previous
track/chapter.
Displaying keys
Touch the “Key” key in the DVD menu to display
operation keys such as the “Enter” key or “Re-
turn” key, etc.on the display.
Skipping commercial messages
Touch the “CM >>” key or “CM <<” key in the
DVD menu to skip commercials.Displaying top menu
Touch the “Top Menu” key in the DVD menu to
display the top menu specific to each disc. For
additional information, refer to the disc instruc-
tions.
Displaying title list
Touch the “Title List” key in the DVD menu to
display the title list.
Displaying title menu
Touch the “Title Menu” key in the DVD menu to
display the title menu specific to each disc. For
additional information, refer to the disc instruc-
tions.
Selecting track/chapter
Touch the “10 Key Search” key in the DVD menu
to display the keyboard screen. Enter the
track/chapter you wish to play.
Selecting track/chapter/menu number
Touch the “10 Key Search” key or “Select No.”
key in the DVD menu to display the keyboard
screen. Enter the track/chapter or menu number
you wish to play.
Viewing from default list
Touch the “Default Position” key in the DVD menu
to view from the default list.
Adjusting the display
Touch the “Display Settings” key in the DVD
menu to adjust the display settings of the display.
“Brightness” key
Adjusts the display bright-
ness
“Contrast” key Adjusts the display con-
trast
“Black Level” key Adjusts the display black
level
“Tint” key Adjusts the tint level
“Color” key Adjusts the color
“Reset Settings” key Resets all the display set- tings to default
AUXILIARY (AUX) DEVICES
Connecting auxiliary devices
The auxiliary input jacks are located in the center
console box.
The auxiliary audio input jack accepts any stan-
dard analog audio input such as from a portable
cassette player, CD player or MP3 player.
A video player can be connected to the auxiliary
video input jack to play movies.
4-90Monitor, climate, audio, phone and voice recognition systems

INFO:
Insert a 1/8 in (3.5 mm) stereo mini plug in the
audio input jack. If a cable with a mono plug is
used, the audio output may not function normally.
AUX operation
Activation and playing:
Turn on an AUX device.
Connecting an AUX device into the jack will
activate the AUX mode.
AUX can be selected from the other audio
sources by touching the “Source” key (if so
equipped) or by pushing the MEDIA button.
Display Settings:
Touch the “Display Settings” key to adjust the
display settings on the display.
AUDIO SETTINGS
Audio settings can be adjusted or audio related
functions can be turned on/off using the following
procedure.
Some of the setting items may not be displayed
when the audio system is turned off. 1. Push the SETTING button.
2. Touch the “Audio” key. The following setting items are available:
*: Availability of the item depends on the
model and specifications.
●“Sound Settings” key
JVH1454M
Monitor, climate, audio, phone and voice recognition systems4-91

Setting ItemsAction
“Bass” key Adjust the speaker tone quality and sound balance by touching the “+”/”-” keys, “L”/“R”
keys or “R”/“F” keys.
“Treble” key
“Balance” key
“Fader” key
“Bose®Centerpoint” key* When this item is turned on, surround sound playback is generated from a traditional ste-
reo recording. Turn on this item to activate Bose®Centerpoint and to change its effect
level with the “Surround Vol” key.
“Surround Vol” key* Touch the “+”/”-” keys to adjust the “Surround Vol” key level if Bose®Centerpoint is
turned on.
“Speed Sensitive Vol” key* This automatically adjusts the volume depending on the vehicle speed. Touch the “+”/”-”
keys to change the sensitivity level.
“Driver’s Audio Stage” key* When this item is turned on, a better sound quality will be provided to the driver’s
position. The driver can enjoy a more crisp and clear sound that is specialized for the driv-
er’s seat position. The prominence of the effect of this feature depends on the type of mu-
sic that is played. For some music, it may be difficult to recognize the effect of this feature.
● “Display Album Cover Art” key
Turn this item on to display image files from the media device. If the media device does not contain images, no image will be displayed.
● “Radio Settings” key
Setting Items Action
“HD Mode AM” key When this item is turned on, the analog and digital reception switches automatically.
When this item is turned off, the reception is fixed in the analog mode.
“HD Mode FM” key
4-92Monitor, climate, audio, phone and voice recognition systems

●“DVD Settings” key*
Setting Items Action
“Angle” key Images and movies can be viewed in different angles if the DVD contains this data.
Switch the angle number by touching the “+”/“-” keys.
“CM Skip” key Select commercial skip length from 15, 30, and 60 seconds.
“DRC” key Select the DRC (Dynamic Range Compression) setting from OFF, 1 and 2. DRC allows
tuning of the dynamic range of sound recorded in the Dolby Digital format.
“Angle Mark” key Turn the angle mark display on/off. When this item is turned on, “Multi Angle” will be dis-
played on the DVD screen.
“Menu Skip” key DVD menus are automatically configured and the contents will be played directly when
this item is turned on. Note that some discs may not be played directly even if this item is
turned on.
“DOWN MIX” key When this item is turned on, a multi-channel recording will be converted to a traditional
two channel (stereo) recording.
“DVD Language” key Enter the language code of the preferred language.
“Language” key Changeable items will vary depending on the type of DVD.
For DVD-V:
Audible language can be changed by touching the “+” or “-” keys.
For Video CD:
Select the sound setting from Main audio, Sub audio and Main/Sub audio.
For DVD VR:
Select the sound setting from Main audio 1, Sub audio 1, Main/Sub audio 1, Main audio
2, Sub audio 2, and Main/Sub audio 2.
“Subtitle” key The subtitle language can be changed by touching the “+” or “-” keys.
“DVD Screen Settings” key Touch to adjust the DVD aspect ratio.
“PG/PL Mode” key Touch to switch the PG/PL mode setting.
INFO:
The available setting items differ depending on the DVD.
Monitor, climate, audio, phone and voice recognition systems4-93

●“AUX settings” key
Setting Items Action
“AUX Image Display” key The image display size setting can be selected from the “Normal”, “Wide” and “Cinema”
keys.
“Volume Setting” key The volume setting can be selected from the “Low”, “Medium” and “High” keys.
INFO:
Image display can be turned on/off by touching the “Image ON”/“Image OFF” keys on the upper right corner on the screen.
4-94Monitor, climate, audio, phone and voice recognition systems

DISC/USB MEMORY DEVICE CARE
AND CLEANING
Discs
●Handle a disc by its edges. Never touch the
surface of the disc. Do not bend the disc.
● Always place discs in their storage cases
when they are not being used.
● To clean a disc, wipe the surface from the
center to the outer edge using a clean, soft
cloth. Do not wipe the disc using a circular
motion. Do not use a conventional record cleaner or
alcohol intended for industrial use.
● The inner and outer edges of a new disc may
be rough. Remove the rough edges by rub-
bing the inner and outer edges with the side
of a pen or pencil as illustrated.
USB memory device
●Never touch the terminal portion of the USB
memory device.
● Do not place heavy objects on the USB
memory device.
● Do not store the USB memory device in very
humid locations.
● Do not expose the USB memory device to
direct sunlight.
● Do not spill any liquids on the USB memory
device.
Refer to the owner’s manual for the USB memory
device for details. If your vehicle is equipped with the Mobile Enter-
tainment System (MES) , you can enjoy playing
audio and movie files on the rear displays with
images and sound.
A DVD and an AUX device inserted/connected to
the audio system for the front seat audio unit as
well as the devices connected to the rear media
interface (USB and HDMI ports for the rear dis-
plays) can be played on the rear displays.
The front and left/right rear displays can show
different sources individually.
CD/DVD slot is on the instrument panel. For
additional information, refer to “Names and func-
tions of audio control buttons” in this section.
AUX jacks are located inside the center console
box.
The rear media interface (USB and HDMI con-
nection ports) is located behind the center con-
sole box. For additional information, refer to
“Connecting rear media interface” in this section.
WARNING
The driver must not attempt to operate the
MES while driving so full attention may be
given to vehicle operation.
SAA0451
MOBILE ENTERTAINMENT SYSTEM
(MES) (if so equipped)
Monitor, climate, audio, phone and voice recognition systems4-95

CAUTION
●Do not attempt to use the system in
extremely high or low temperature con-
ditions [below -4°F (-20°C) or above
158°F (70°C)].
● To avoid draining the vehicle battery
(12V battery) , do not operate the system
for more that 15 minutes without start-
ing the engine.
The front display is designed not to show
images during driving, as the driver’s at-
tention must be given to vehicle operation
for safety. Sounds are still audible. To
show images on the front display, stop the
vehicle in a safe location, move the shift
lever to the “P” (Park) position and apply
the parking brake.
PRECAUTIONS
Start the engine when using the MES.
WARNING
The driver must not attempt to operate the
MES or wear the headphones while the
vehicle is in motion so that full attention
may be given to vehicle operation. Park the vehicle in a safe location and
apply the parking break to view the im-
ages on the front center display screen
using the DVD player.
CAUTION
●
Only operate the MES while the engine
is running. Operating the MES for ex-
tended periods of time with the engine
turned off can discharge the vehicle
battery (12V battery) .
● Do not allow the system to get wet.
Excessive moisture such as spilled liq-
uids may cause the system to
malfunction.
●
While playing VIDEO-CD media, this DVD
player does not guarantee complete
functionality of all VIDEO-CD formats.
TECHNICAL INFORMATION
USB media support
Supported USB media
USB 1.1 Low Speed (1.5 Mbps) , Full
Speed (12 Mbps)
USB 2.0 Low Speed (1.5 Mbs) , Full
Speed (12 Mbps) , High
Speed (480 Mps)
Mass Storage Support
The Mobile Entertainment System recognizes the
connected USB media as a mass storage device.
Supported file systems and partition
The first partition of the following file systems are
supported.
● NTFS
● FAT32
● FAT16
● HFS+
Supported folder structure
Folders 1,000 folders maximum
Files 10, 000 files maximum
Pass length 3072 characters
Full name length 232 characters
Folder levels 11 levels maximum (when
route is regarded as level 0)
4-96Monitor, climate, audio, phone and voice recognition systems

Supported format and decode
Video codec
CodecProfile Maximum Resolution/Frame Rate Notes
DivX DivX 3.11/4/5/6 SD (720 x 576)/30Only single-instance playback is supported
for DivX 3.11.
Flash - 1080 p/30-
H.263 - 1080 p/30-
H.264 BP/MP/HP 1080 p/30Extended file not supported.
MPEG-1 - 1080 p/30-
MPEG-2 MP@ML 1080 p/30-
MPEG-4 SP/ASP 1080 p/30-
Real Video RV8/9/10 1080 p/30-
XviD - SD (720 x 576)/30-
WMV7/8 - D1/30HD version not provided.
Only single instance playback is supported
for WMV7/8
WMV9/VC-1 SP/MP/AP 1080 p/30Complex Profile not supported.
Monitor, climate, audio, phone and voice recognition systems4-97
