•Fan speed control
Press theFan speed control buttons
to manually control the fan speed.
Rear Heating
1. Press the AUTO button. The AUTO indi- cator button will illuminate on the front
display.
2. Turn the temperature control dial to set the desired temperature.
Turning the system off
1. Press the REAR ON-OFF button on the front display to turn the rear climate sys-
tem off. The indicator light will turn off.
2. Press the ON-OFF button. The rear cli- mate will turn off and the control will
switch to front climate.
Locking the REAR controls
1. Press the REAR LOCK button on the front climate control panel. LOCK will be dis-
played on the rear climate display screen.
2. The rear climate controls will be locked and can only be adjusted using the front
controls. Rear control buttons
1.
Fan speed (increase) button
2. Display screen
3.
Temperature (increase) button
4.
Temperature (decrease) button
5.
Heated 2nd row seat switches (if so
equipped)
6. ON-OFF button
7. Air flow control buttons
8. AUTO button 9.
Fan speed (decrease) button
The rear seat passengers can adjust the rear
automatic air conditioning system using the
control switches at the rear of the center
console.
The rear control buttons do not function
when the REAR LOCK button is on.
• ON-OFF button Turns rear automatic air
conditioning system on and off.
• Fan speed control buttons
adjust the
rear fan speed up or down.
LHA5486
Rear Controls
Monitor, climate, audio, phone and voice recognition systems4-35

•Heated 2nd row seat switches (if so
equipped) For additional information, see
“Heated 2nd row seat switches” (P. 2-86).
• Air flow control buttons controls air flow
and selects the air outlet.
• AUTO button Turns rear automatic air
conditioning system on, AUTO mode on.
• Temperature
increase andde-
crease buttons Adjusts the rear tempera-
ture up or down. The air conditioner system in your INFINITI
vehicle is charged with a refrigerant designed
with the environment in mind.
This refrigerant does not harm the earth's
ozone layer.
Special charging equipment and lubricant is
required when servicing your INFINITI air
conditioner. Using improper refrigerants or
lubricants will cause severe damage to your
air conditioner system. For additional infor-
mation, see “Air conditioner system refriger-
ant and oil recommendations” (P. 10-7).
It is recommended that you visit an INFINITI
retailer to service your “environmentally
friendly” air conditioner system.
WARNING
The air conditioner system contains refrig-
erant under high pressure. To avoid per-
sonal injury, any air conditioner service
should be done only by an experienced
technician with proper equipment. The vehicle is equipped with a shark fin an-
tenna and an antenna pattern is printed in-
side the rear window.
CAUTION
• Do not place metalized film near the rear
window glass or attach any metal parts
to it. This may cause poor reception or
noise.
• When cleaning the inside of the rear win-
dow, be careful not to scratch or damage
the rear window antenna. Lightly wipe
along the antenna with a dampened soft
cloth.
SERVICING AIR CONDITIONER ANTENNA
4-36Monitor, climate, audio, phone and voice recognition systems

3. Replace the battery with a new one.Recommended battery: CR2032 or
equivalent.
• Do not touch the internal circuit and electric terminals as doing so could
cause a malfunction.
• Hold the battery by the edges. Holding the battery across the contact points
will seriously deplete the storage
capacity.
• Make sure that the + side faces the bot- tom of the lower part.
4. Close the lid securely as illustrated with
OCandOD.
5. Operate the buttons to check the operation.
If you need assistance with replacement, it is
recommended that you visit an INFINITI re-
tailer for this service.
FCC Notice:
For USA:
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) This device may not
cause harmful interference, and (2) this de-
vice must accept any interference received,
including interference that may cause unde-
sired operation.
NOTE:
Changes or modifications not expressly ap-
proved by the party responsible for compli-
ance could void the user’s authority to oper-
ate the equipment.
For Canada:
This device contains licence-exempt
transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Develop-
ment Canada’s licence-exempt RSS(s). Op-
eration is subject to the following two con-
ditions: (1) This device may not cause
interference. (2) This device must accept any
interference, including interference that
may cause undesired operation of the
device.
LDI3309
