Locking doors
1. Push the P (Park) button, place the igni-tion switch in the LOCK position and make
sure you carry the Intelligent Key with you.
2. Close all doors
3. Push any door handle lock sensor while carrying the Intelligent Key with you.
4. All doors and the rear liftgate will lock.
5. The hazard warning lights flash twice and the outside chime sounds once.
NOTE:
•Lock sensors for all doors and liftgate can be
deactivated when the Ext. Door Switch fea-
ture is switched to OFF using the “Vehicle
Settings” menu on the vehicle information
display. For additional information, see
“Vehicle information display 7 inch (18 cm)
Type A” (P. 2-22) or “Vehicle information
display 12.3 inch (21 cm) Type B” (P. 2-44).
• Doors do not lock with the door handlelock sensor while the ignition switch is not
in the LOCK position.
• Doors do not lock by pushing the door handle lock sensor while the driver’s door
is open. • Doors do not lock with the door handle
lock sensor with the Intelligent Key inside
the vehicle and a beep sounds to warn you.
However, when an Intelligent Key is inside
the vehicle, doors can be locked with an-
other Intelligent Key.
• The lock sensor may not react immediately when the door handle is wet from rain, etc.
Keep touching the lock senor until the
doors lock, or touch the lock sensor after
grasping the door handle.
• Touching the door lock sensor while wear- ing gloves may delay or prevent lock op-
eration. Remove the gloves and touch the
lock sensor again.
• If the door handle becomes wet while the electronic key is within the effective
range, the door may lock and unlock re-
peatedly. In this case, follow the following
correction procedures to wash the vehicle:
– Place the electronic key in a location 6 ft. (2 m) or more away from the ve-
hicle. (Take care to ensure that the key is
not stolen.)
– If the electronic key is inside the vehicle and a door handle becomes wet during a
car wash, a buzzer will sound outside
the vehicle. To turn off the alarm, re-
move the key from the inside vehicle.
LPD3222LPD3255
3-10Pre-driving checks and adjustments

1. Carry the Intelligent Key.
2. Wrap your hand around the door handleto activate the capacitive unlock sensor
OA.
• When unlocking from the driver’s door handle, the driver’s door will unlock. Un-
wrap your hand from the driver’s door
handle and touch the lock sensor
OBwithin 60 seconds to unlock all doors.
• When unlocking from the passenger door, rear doors or liftgate, all vehicle
doors will unlock. • To allow driver and passenger doors to
unlock at the same time from driver’s
door handle, turn off the Selective Un-
lock feature in the vehicle settings menu.
For additional information, see “Vehicle
information display 7 inch (18 cm) Type
A” (P. 2-22) or “Vehicle information dis-
play 12.3 inch (21 cm) Type B” (P. 2-44).
3. The warning indicator lights flash once and the outside buzzer sounds once.
NOTE:
• Lock sensors for all doors and liftgate canbe deactivated when the Ext. Door Switch
feature is switched to OFF using the “Ve-
hicle Settings” menu on the vehicle infor-
mation display. For additional informa-
tion, see “Vehicle information display 7
inch (18 cm) Type A” (P. 2-22) or “Vehicle
information display 12.3 inch (21 cm) Type
B” (P. 2-44).
• Doors do not lock with the door handle lock sensor while the ignition switch is not
in the LOCK position.
LPD3334LPD3256
3-12Pre-driving checks and adjustments

• The lock sensor may not react immediatelywhen the door handle is wet from rain, etc.
Keep touching the lock sensor until the
doors unlock, or touch the lock sensor af-
ter grasping the door handle.
If a door handle is pulled while unlocking the
doors, that door may not be unlocked. Re-
turning the door handle to its original position
will unlock the door. If the door does not
unlock after returning the door handle, touch
the door handle lock sensor to unlock the
door.
All doors will be locked automatically unless
one of the following operations is performed
within 1 minute after touching the lock
sensor:
• Opening any door.
• Pushing the ignition switch.
Using the interior lights
The interior lights timer illuminates for a pe-
riod of time when a door is unlocked and the
DOOR/OFF switch is pressed. The interior
lights can be turned off without waiting by
performing one of the following operations:
• Placing the ignition switch in the ON position.
• Locking the doors with the Intelligent Key. • Switching the DOOR/OFF switch to the
OFF position.
• Switching the Auto Room Lamp feature to the OFF position using the “Vehicle Set-
tings” menu on the vehicle information
display. For additional information, see
“Vehicle information display 7 inch (18 cm)
Type A” (P. 2-22) or “Vehicle information
display 12.3 inch (21 cm) Type B” (P. 2-44).
For additional information, see “Interior
lights” (P. 2-114).
Outside mirror welcome lights
When you unlock the doors using the Intelli-
gent Key, capacitive unlock sensor, the out-
side mirror welcome lights
OAwill illuminate
for a period of time. The welcome lights will
also illuminate when you open an unlocked
door without carrying the Intelligent Key with
you. When you lock the doors using the Intel-
ligent Key or lock sensor, the outside mirror
welcome lights fade out.
LPD3279
Driver’s and passenger’s side
Pre-driving checks and adjustments3-13

3. Press thebutton on the Intelligent
Key.
4. The hazard indicator lights flash twice and the horn beeps once.
5. All doors will be locked.
WARNING
After locking the doors using the Intelli-
gent Key, be sure that the doors have been
securely locked by operating the door
handles within two seconds of locking.
Failure to follow these instructions may re-
sult in inadvertently unlocking the doors,
which may decrease the safety and secu-
rity of your vehicle.
Unlocking doors
1. Press thebutton on the Intelligent
Key to unlock the driver’s door.
2. The hazard indicator lights flash once and the driver’s door unlocks.
3. Press the
button again within 60
seconds to unlock all doors.
NOTE:
The unlocking operation can be changed in
Selective Unlock in “Vehicle Settings” of the
vehicle information display. For additional
information, see “Vehicle information dis-
play 7 inch (18 cm) Type A” (P. 2-22) or “Ve-
hicle information display 12.3 inch (21 cm)
Type B” (P. 2-44).
All doors will be locked automatically unless
one of the following operations is performed
within 1 minute after pressing the
button:
• Opening any doors.
• Pushing the ignition switch.
Using the interior lights
The interior lights timer illuminates for a pe-
riod of time when a door is unlocked and the
DOOR/OFF switch is pressed. The interior
lights can be turned off without waiting by
performing one of the following operations:
• Placing the ignition switch in the ON position.
• Locking the doors with the Intelligent Key.
• Switching the DOOR/OFF switch to the OFF position. • Switching the Auto Room Lamp feature to
the OFF position using the “Vehicle Set-
tings” menu on the vehicle information dis-
play. For additional information, see “Ve-
hicle information display 7 inch (18 cm)
Type A” (P. 2-22) or “Vehicle information
display 12.3 inch (21 cm) Type B” (P. 2-44).
For additional information, see “Interior
lights” (P. 2-114).
Opening windows
The Intelligent Key allows you to simultane-
ously open windows equipped with auto-
matic operation.
To open the windows, press the
button
on the Intelligent Key for longer than 3 sec-
onds after all doors are unlocked
The door windows will open while pressing
the
button on the Intelligent Key.
The door windows cannot be closed by using
the Intelligent Key.
Releasing the rear liftgate
The rear liftgate can be opened and closed by
performing the following:
• Press the
button for longer than 1
second to open the rear liftgate.
• Press the
button again for longer than
1 second to close the rear liftgate.
Pre-driving checks and adjustments3-15

When thebutton is pressed during the
open or close process, the liftgate motors will
stop. When the
button is pressed again
for longer than 1 second the liftgate will re-
verse direction.
Using the panic alarm
If you are near your vehicle and feel threat-
ened, you may activate the panic alarm to call
attention by pressing and holding the
button on the Intelligent Key for longer than
0.5 seconds.
The panic alarm and headlights will stay on
for a period of time.
The panic alarm stops when:
• It has run for a period of time, or
• Any button is pressed on the Intelligent Key.
• The lock sensor is touched and the Intelli- gent Key is in range of the door handle.
Answer back horn feature
If desired, the answer back horn feature can
be deactivated using the Intelligent Key.
When it is deactivated and the
button
is pressed, the hazard indicator lights flash twice. When the
button is pressed, nei-
ther the hazard indicator lights nor the horn
operates.
NOTE:
If you change the answer back horn fea-
ture with the Intelligent Key, the vehicle
information display screen will show the
current mode after the ignition switch
has been cycled from the OFF to the ON
position. The vehicle information display
screen can also be used to change the an-
swer back horn mode.
For additional information, see “Vehicle
information display 7 inch (18 cm) Type A”
(P. 2-22) or “Vehicle information display
12.3 inch (21 cm) Type B” (P. 2-44).
To deactivate:
Press and hold theandbuttons
for at least 5 seconds. The hazard indicator
lights will flash three times to confirm that the
answer back horn feature has been
deactivated.
To activate:
Press and hold the
andbuttons
for at least 5 seconds once more. The hazard
indicator lights will flash once and the horn
will sound once to confirm that the horn beep
feature has been reactivated. Deactivating the horn beep feature does not
silence the horn if the alarm is triggered.
WARNING SIGNALS
To help prevent the vehicle from moving un-
expectedly by erroneous operation of the In-
telligent Key or to help prevent the vehicle
from being stolen, a chime or buzzer sounds
from inside and outside the vehicle and a
warning is displayed in the instrument panel.
When a chime or beep sounds or a warning is
displayed, be sure to check the vehicle and
the Intelligent Key.
For additional information, see “Trouble-
shooting guide” (P. 3-16), “Vehicle informa-
tion display 7 inch (18 cm) Type A” (P. 2-22) or
“Vehicle information display 12.3 inch (21 cm)
Type B” (P. 2-44).
TROUBLESHOOTING GUIDE
Verify the location of all Intelligent Keys that
are programmed for the vehicle. If another
Intelligent Key is in range or inside the vehicle,
the vehicle system may respond differently
than expected.
3-16Pre-driving checks and adjustments

SymptomPossible CauseRemedy
When shifting the shift position to the P
(Park) position The “Push Ignition to OFF” warning ap-
pears in the display. The ignition switch is in the ACC or ON
position.Place the ignition switch in the OFF
position.
When opening the driver's door to get
out of the vehicle The “Door Open” warning appears on the
display. The ignition switch is in the ACC or ON
position.Place the ignition switch in the OFF
position.
When closing the door after getting out
of the vehicle The “No Key Detected” warning appears
on the display, the outside chime sounds
three times and the inside warning chime
sounds for approximately 3 seconds. The ignition switch is in the ACC or ON
position.
Place the ignition switch in the OFF
position.
The “Rear Door Alert” (if so equipped)
warning message appears on the display,
the horn sounds three times twice, or a
“Check Back Seat For All Articles” (if so
equipped) warning appears on the dis-
play. The Rear Door Alert is activated. Check the back seat for all articles, press
the ENTER button to clear the “Rear
Door Alert” warning message.
When closing the door with the inside
lock knob turned to LOCK The outside chime sounds for approxi-
mately 3 seconds and all the doors un-
lock. The Intelligent Key is inside the vehicle. Carry the Intelligent Key with you.
When touching the door handle lock
sensor or the
button on the Intel-
ligent Key to lock the door The outside chime sounds for approxi-
mately 2 seconds.
The Intelligent Key is inside the vehicle. Carry the Intelligent Key with you.
When pushing the ignition switch to
start the engine The key low battery indicator appears on
the display. The battery charge is low.
Replace the battery with a new one. For
additional information, see “Battery re-
placement” (P. 8-24).
When pushing the ignition switch The “I-Key System Error: See Owner’s Manual” warning message in the vehicle
information display appears. It warns of a malfunction with the Intelli-
gent Key system.
It is recommended that you visit an
INFINITI retailer.
Pre-driving checks and adjustments3-17

• The alarm sounds due to illegal entry intothe vehicle.
• Pushing the ignition switch without the In- telligent Key in the vehicle.
• Not pressing the brake pedal while pressing the ignition switch with the Intelligent Key
in the vehicle.
CONDITIONS THE REMOTE
ENGINE START WILL NOT WORK
The Remote Engine Start will not operate if
any of the following conditions are present:
• The ignition switch is placed in the ONposition.
• The hood is not securely closed.
• The hazard indicator lights are on.
• The engine is still running. The engine must be completely stopped. Wait at least 6 sec-
onds if the engine goes from running to off.
This is not applicable when extending en-
gine run time.
• The
button is not pressed and held for
at least 2 seconds.
• The
button is not pressed and held
within 5 seconds of pressing the lock
button.
• The brake is pressed.
• The doors are not closed and locked. • The liftgate is open.
• The I–Key System Error warning message
appears in the vehicle information display.
• The alarm sounds due to illegal entry into the vehicle.
• Two Remote Engine Starts, or a single Re- mote Engine Start with an extension, have
already been used.
• The vehicle is not in P (Park).
• There is a detected registered key already inside of the vehicle.
The Remote Engine Start may display a
warning or indicator in the vehicle informa-
tion display. For additional information, see
“Vehicle information display 7 inch (18 cm)
Type A” (P. 2-22) or “Vehicle information dis-
play 12.3 inch (21 cm) Type B” (P. 2-44).
3-20Pre-driving checks and adjustments

•Do not gaze into the Smart Rear View
Mirror display during driving. It may
cause a distraction and it could lose con-
trol of your vehicle and cause an accident
or serious injury.
• Do not put a cigarette or flames to the
Smart Rear View Mirror, the camera unit
or wirings. It may cause a fire.
• Be sure to adjust the Smart Rear View
Mirror before driving. Switch the system
to the conventional rearview mirror
mode and be properly seated on the driv-
er’s seat. Then adjust the mirror so as to
see the rear window properly. Driving
without adjusting the mirror may cause
difficulty in watching the display at
Smart Rear View Mirror (camera view
mode) due to the reflection from the sur-
face of the mirror.
• If the Smart Rear View Mirror malfunc-
tions, immediately switch the system to
the conventional rearview mirror mode. •
When strong light (for example, sunlight
or high beams from following vehicles)
enters the camera, a light beam or a glar-
ing light may appear on the monitor
screen of the Smart Rear View Mirror. In
that case, switch the system to the con-
ventional rearview mirror mode
appropriately.
• If dirt, rain or snow accumulates on the
exterior glass surface covering the cam-
era, the Smart Rear View Mirror may not
display object clearly. Use of the rear
window wiper/washer may improve vis-
ibility, but if not, switch the Smart Rear
View Mirror to the conventional rear-
view mirror mode until a time the glass
covering the camera can be cleaned.
Components:
Smart Rear View Mirror provides a clear rear-
view from a camera located on the rear of the
vehicle. Smart Rear View Mirror has two
modes: conventional rearview mirror mode
and Smart Rear View Mirror mode (camera
view mode). You can switch these two modes
by the mode select lever
O4.
LPD3204
1. MENU button
2. Left button
3. Right button
4. Mode select lever
Pre-driving checks and adjustments3-35

For additional information on HomeLink®
Universal Transceiver (if so equipped) opera-
tion, see “HomeLink® Universal Transceiver”
(P. 2-116).How to change the mode:
The mode can be switched when the ignition
switch is in the ON position.
• Pull the mode select lever
OAto switch to
the Smart Rear View Mirror mode (camera
view mode).
• Push the mode select lever
OBto switch to
the conventional rearview mirror mode. How to make settings of Smart Rear View
Mirror:
You can choose display settings of the Smart
Rear View Mirror such as brightness, camera
angle, textual indication ON or OFF and lan-
guage. When the Smart Rear View Mirror
mode is on, setting menu can be selected by
pushing the MENU buttonO1. Each time the
MENU button
O1is pushed, the setting menu
will change as follows:
MENU (initial screen) →BRIGHTNESS →
DOWN/UP →LEFT/RIGHT →ROTATION
→ INDICATION →DIMMING MIRROR →
LANGUAGE →MENU (initial screen)
LPD3205LPD3206
3-36Pre-driving checks and adjustments

NOTE:
To switch the image quality adjustment
items with MENU button
O1, push the but-
ton within 5 seconds after completing the
adjustment of the previous item. If 5 seconds
or more pass, the monitor will return to
MENU (initial screen).
BRIGHTNESS
The brightness of the display screen can be
adjusted.
O3
• Push the left buttonO2to dim the screen.
• Push the right button
O3to brighten the
screen. DOWN/UP
The vertical camera angle of the display
screen can be adjusted.
• Push the left button
O2to pan the camera
angle down.
• Push the right button
O3to pan the camera
angle up.
LPD3207LPD3209
Pre-driving checks and adjustments3-37
