ISUZU TF SERIES 2004 Workshop Manual

RESTRAINT CONTROL 9A1-61

DTC B1000 (Flash Code 72) SDM Internal Fault (SDM=SRS control unit)


RTW49JLF000101
Circuit Description
DTC B1000 is an indication of a potential internal SRS
control unit malfunction and will set if any of the
following conditions are detected:
1) Microprocessor energy reverse time failure.
2) EEPROM read / write failure.
3) ROM check sum.
4) Calibration check sum fault.
5) Inflators reserve voltage low.
6) Inflators electronic sensor active signal not detected
during commanded deployment.
7) QSDD (High-side/Low-side) FET failure.
8) Frontal accelerometer failure.
9) Phase lock loop lost lock.
10) QSDD communication fault.
DTC Will Set When
Any of the above indicated malfunctions are detected by
the SRS control unit. The malfunctions described
above are tested mainly during “Continuous Monitoring”
and some ones run each ignition cycle.

Action Taken
SRS control unit turns “ON” the “AIR BAG” warning
lamp and sets a diagnostic trouble code.

DTC Will Clear When
SRS control unit is replaced.

9A1-62 RESTRAINT CONTROL SYSTEM

DTC B1000 (Flash Code 72) SDM Internal Fault (SDM=SRS control unit)
WARNING: DURING SERVICE PROCEDURES. BE VERY CAREFUL WHEN HANDLING A SRS CONTROL
UNIT. NEVER STRIKE OR JAR THE SRS CONTROL UNIT. NEVER POWER UP THE SRS WHEN THE SRS
CONTROL UNIT IS NOT RIGIDLY ATTACHED TO THE VEHICLE. ALL SRS CONTROL UNIT AND MOUNTING
BRACKET FASTENERS MUST BE CAREFULLY TORQUED AND THE ARROW MUST BE POINTING TOWARD
THE FRONT OF THE VEHICLE TO ENSURE PROPER OPERATION OF THE SRS. THE SRS CONTROL UNIT
COULD BE ACTIVATED WHEN POWERED WHILE NOT RIGIDLY ATTACHED TO THE VEHICLE WHICH
COULD CAUSE DEPLOYMENT AND RESULT IN PERSONAL INJURY.
CAUTION: If DTC B1000 can not clear by Tech2, it is necessary to replace the SRS control unit.

Step Action Yes No
1 Was the “SRS Diagnostic System Check” performed? Ignition switch
“OFF.”
Replace SRS
control unit.
Repeat the “SRS
Diagnostic System
Check” Go to the “SRS
Diagnostic System
Check”

No. TFRET-WE-0431

WORKSHOP MANUAL
TF SERIES
AXLE

SECTION 4

PROPELLER SHAFT 4A-1
SECTION 4A
PROPELLER SHAFT
TABLE OF CONTENTS
PAGE
Main Data and Specifications ........................................................................................... 4A- 3
Rear Propeller Shaft...................................................................................................... 4A- 3
Torque Specifications ....................................................................................................... 4A- 5
Front Propeller Shaft ................................................................................................... 4A- 6
Torque Specifications ....................................................................................................... 4A- 7
Rear Propeller Shaft .......................................................................................................... 4A- 8
General Description ...................................................................................................... 4A- 8
Removal and Installation .............................................................................................. 4A-11
Universal Joint Disassembly........................................................................................ 4A-12
Inspection and Repair .................................................................................................. 4A-14
Universal Joint Reassembly ........................................................................................ 4A-16
Rear Propeller Shaft Assembly ........................................................................................ 4A-17
Disassembly and Reassembly .................................................................................... 4A-18
Front Propeller Shaft ........................................................................................................ 4A-19
Removal and Installation .............................................................................................. 4A-19
Disassembly ................................................................................................................. 4A-21
Universal Joint Disassembly and Reassembly ......................................................... 4A-23
Reassembly .................................................................................................................. 4A-27

4A-2 PROPELLER SHAFT
Service Precaution
WARNING: THIS VEHICLE HAS A
SUPPLEMENTAL RESTRAINT SYSTEM (SRS).
REFER TO THE SRS COMPONENT AND WIRING
LOCATION VIEW IN ORDER TO DETERMINE
WHETHER YOU ARE PERFORMING SERVICE ON
OR NEAR THE SRS COMPONENTS OR THE SRS
WIRING. WHEN YOU ARE PEREFORMING
SERVICE ON OR NEAR THE SRS COMPONENTS
OR THE SRS WIRING, REFER TO THE SRS
SERVICE INFORMATION. FAILURE TO FOLLOW
WARNING COULD RESULT IN POSSIBLE AI
R
BAG DEPLOYMENT, PERSONAL INJURY, OR
OTHERWISE UNNEEDED SRS SYSTEM
REPAIRS. CAUTION : Always use the correct fastener in the
proper location. When you replace a fastener,
use ONLY the exact part number for that
application. ISUZU will call out those fasteners
that require a replacement after removal. ISUZU
will also call out the fasteners that require thread
lockers or thread sealant. UNLESS OTHERWISE
SPECIFIED, do not use supplemental coatings
(Paints, greases, or other corrosion inhibitors)
on threaded fasteners or fastener joint
interfaces. Generally, such coatings adversely
affect the fastener torque and the joint clamping
force, and may damage the fastener. When you
install fasteners, use the correct tightening
sequence and specifications. Following these
instructions can help you avoid damage to parts
and systems.

PROPELLER SHAFT 4A-3
MAIN DATA AND SPECIFICATIONS
REAR PROPELLER SHAFT

mm(in)
4

2 Model
Engine Model 4JA1-T(L) 4JA1-TC 4JH1-TC
Transmission Type 5 M/T (MUA) 5M/T (MUA) 4A/T
Wheel Base Long Long Extra Long Long
Front Suspension
High Ride
SuspensionExcept High
Ride
Suspension


Rear Axle
220mm



Type
OBS



Outside Diameter mm 75 68.9 68.9 68.9 63.5
(in) (2.95) (2.71) (2.71) (2.71) (2.50)
Inside Diameter mm 71.8 64.9 64.9 64.9 60.3
(in) (2.89) (2.63) (2.63) (2.63) (2.44)
Length 1st(L1) mm 799.5 798.5 801.5 946.5 720.5
(in) (31.48) (31.44) (31.56) (37.26) (28.37)
2nd(L2) mm 796 801 796 801 801
(in) (31.34) (31.54) (31.34) (31.54) (31.54)
Spline Major mm 29.89 29.89 29.89 29.89 29.89
Diameter (in) (1.18) (1.18) (1.18) (1.18) (1.18)
Fix Bolt Size M10 M10 M10 M10 M10
* OBS - Outboard Slip (Spline Engagement To T/M)



mm(in)
4

2 Model
Engine Model C24SE
6VE1
Transmission Type 5M/T (MUA)
5M/T (MUA) 4A/T
Wheel Base Long Extra Long Long Extra Long Long Extra Long
Front Suspension High Ride
Suspension Except High
Ride
Suspension










Rear Axle


220mm



Type


OBS



Outside Diameter mm 75 75 75 68.9 68.9 75 75
(in) (2.95) (2.95) (2.95) (2.71) (2.71) (2.95) (2.95)
Inside Diameter mm 71.8 71.8 71.8 64.9 64.9 71.8 71.8
(in) (2.89) (2.89) (2.89) (2.63) (2.63) (2.89) (2.89)
Length 1st(L1) mm 823.5 820.5 970.5 823.5 971.5 778.5 928.5
(in) (32.42) (32.30) (38.21) (32.42) (38.25) (30.65) (36.56)
2nd(L2) mm 801 796 796 801 801 801 801
(in) (31.54) (31.34) (31.34) (31.54) (31.54) (31.54) (31.54)
Spline Major mm 29.89 29.89 29.89 29.89 29.89 30.48 30.48
Diameter (in) (1.18) (1.18) (1.18) (1.18) (1.18) (1.20) (1.20)
Fix Bolt Size M10 M10 M10 M10 M10 M10 M10
* OBS - Outboard Slip (Spline Engagement To T/M)

4A-4 PROPELLER SHAFT

mm(in)
4

4 Model
Engine Model 4JA1-T(L) 4JA1-TC 4JH1-TC
Transmission Type 5M/T (MUA) 5M/T (MUA) 4A/T
Wheel Base Long Long Extra Long Long
Front Suspension








Rear Axle 220mm 220mm


Type OBS OBS


Outside Diameter mm 75 68.9 68.9 63.5
(in) (2.95) (2.71) (2.71) (2.50)
Inside Diameter mm 71.8 64.9 64.9 60.3
(in) (2.89) (2.63) (2.63) (2.44)
Length 1st(L1) mm 469.5 468.5 616.5 402.5
(in) (18.48) (18.44) (24.27) (15.85)
2nd(L2) mm 801 801 801 801
(in) (31.54) (31.54) (31.54) (31.65)
Spline Major mm 29.89 29.89 29.89 29.89
Diameter (in) (1.18) (1.18) (1.18) (1.18)
Fix Bolt Size M10 M10 M10 M10
* OBS - Outboard Slip (Spline Engagement To T/M)


mm(in)
4

4 Model
Engine Model C24SE 6VE1
Transmission Type 5M/T
(MUA) 5M/T (MUA) 4A/T
Wheel Base Long Long Extra Long Long
Front Suspension




Rear Axle
Type
Outside Diameter mm 63.5 68.9 68.9 75
(in) (2.50) (2.71) (2.71) (2.95)
Inside Diameter mm 60.3 64.9 64.9 71.8
(in) (2.44) (2.63) (2.63) (2.89)
Length 1st(L1) mm 495.5 492.5 641.5 484.5
(in) (19.51) (19.39) (25.26) (19.07)
2nd(L2) mm 801 801 801 801
(in) (31.54) (31.54) (31.54) (31.54)
Spline Major mm 29.89 29.89 29.89 29.89
Diameter (in) (1.18) (1.18) (1.18) (1.18)
Fix Bolt Size M10 M10 M10 M10
* OBS - Outboard Slip (Spline Engagement To T/M)
