DIAGNOSIS (JR405E) 7A2-5
PAGE
NO. Z3: MODE LAMP (POWER DRIVE OR 3RD START) LIGHTS UP WHEN
THE POWER MODE OR 3RD START MODE IS TURNED OFF .................................. 7A2-137
NO. Z4: OIL TEMPERATURE WARNING LAMP LIGHTS UP ...................................... 7A2-137
NO. Z5: SELECT LEVER FEELING IS FAULTY. .......................................................... 7A2-137
NO. Z6: POOR FUEL CONSUMPTION ......................................................................... 7A2-138
NO. Z7: PATTERN SELECT SWITCH IS FAULTY........................................................ 7A2-138
NO. Z8: OIL IS SPLASHED DURING THE RUNNING .................................................. 7A2-138
NO. Z9: ABNORMAL SMELL ........................................................................................ 7A2-138
NO. Z10: ATF QUANTITY IS LOW OR HIGH ................................................................ 7A2-138
NO. Z11: ABNORMAL OIL PRESSURE........................................................................ 7A2-139
NO. Z12: REVERSE BUZZER DOES NOT RING .......................................................... 7A2-139
STALL TEST .................................................................................................................. 7A2-140
LINE PRESSURE TEST................................................................................................. 7A2-141
TIME LAG TEST............................................................................................................. 7A2-143
TEST DRIVE................................................................................................................... 7A2-144
SHIFT POINT CHART .................................................................................................... 7A2-147
SHIFT POINT DIAGRAM................................................................................................ 7A2-149
TCM VOLTAGE CHECK ................................................................................................ 7A2-154

7A2-12 DIAGNOSIS (JR405E)
F0: Diagnostic Trouble Code
F0: Read DTC Infor As Stored By ECU
F1: Clear DTC Information
F1: Data Display
F2: Snapshot
F3: Miscellaneous Test
F0: Lamp
F0: Power Lamp Test
F1: 3rd Start Lamp Test
F2: AT Oil Temperature Lamp Test
F3: Transmission Check Light Test
F1: Solenoids
F0: Low & Reverse Brake Solenoid
F1: 2-4 Brake Solenoid
F2: High Clutch Solenoid
F3: Low Clutch Solenoid
F4: Line Pressure Solenoid
F5: Lock Up Duty Solenoid
F4: Programming
F0: Program VIN
F1: Lock ECU

F0: Diagnostic Trouble Code
The purpose of the "Diagnostic Trouble Codes" mode is to
display stored trouble code in the TCM.
When "Clear DTC Information" is selected, a "Clear DTC
Information", warning screen appears. This screen informs you
that by cleaning DTC's "all stored DTC information in the TCM
will be erased".
After clearing codes, confirm system operation by test driving
the vehicle.

F1: Data Display
The purpose of the "Data Display" mode is to continuously
monitor data parameters.
The current actual values of all important sensors and signals
in the system are display through F1mode.
See the "Typical Scan Data" section.

F2: Snapshot
"Snapshot" allows you to focus on making the condition occur,
rather than trying to view all of the data in anticipation of the
fault. The snapshot will collect parameter information around a
trigger point that you select.

F3: Miscellaneous Test:
The purpose of "Miscellaneous Test" mode is to check for
correct operation of electronic system actuators.

F4: Programming (Factory Use Only):
The purpose of "Programming" is to program VIN in the ECM
and lock the programmed data.

7A2-14 DIAGNOSIS (JR405E)
MISCELLANEOUS TEST
The state of each circuit can be tested by using miscellaneous test menus. Especially when DTC cannot be
detected, a faulty circuit can be diagnosed by testing each circuit by means of these menus.
Even DTC has been detected, the circuit tests using these menus could help discriminate between a mechanical
trouble and an electrical trouble.

Connect Tech 2 and select "Powertrain", "JR 405E" & "Miscellaneous Test".
F0: Lamps
The circuit is normal if the warning light in the meter panel comes on and goes out in accordance with Tech 2
instruction.

Lamps

F0: Power Lamp Test
F1: 3rd Start Lamp Test
F2: AT Oil Tempeature Lamp Test
F3: Transmission Check Light Test


F0: Power Lamp Test


Power Lamp Test

Power Lamp Off



 Press "Active" key.
Then, "POWER DRIVE" indicator lamp is turned on in the meter panel.
 Press "Inactive" key.
Then, "POWER DRIVE" indicator lamp is turned off in the
meter panel.
 Press "Quit" Key to cancel the test.
F1: 3rd Start Lamp Test
F2: AT Oil Temperature Lamp Test
F3: Transmisstion Check Light Test
Test procedure is same as "F0: Power Lamp Test".
The circuit is normal if the warning light in the meter panel
comes on and goes out in accordance with Tech 2 instruction.

F1: Solenoids
The circuit is normal if clicking sound is generated in accordance with Tech 2 instruction.

Solenoids
F0: Low & Reverse Brake Solenoid
F1: 2-4 Brake Solenoid
F2: High Clutch Solenoid
F3: Low Clutch Solenoid
F4: Line Pressure Solenoid
F5: Lock Up Duty Solenoid

7A2-42 DIAGNOSIS (JR405E)
DTC P0710 (Flash Code 15) ATF Temperature Sensor Failure

ATF
Temp.
Sensor
TCM


B4 (+)



B14 (-)

H23 (8)



(3)
C95 (4)



(14)
BLU
Terminal
Assembly
BLU/BLKE54 (2)



(8)
BLU
BLU/BLK


Setting Condition:

The condition in which the voltage of oil temperature sensor is below 0.1V (146 C) and ATF temperature
warning lamp ON in the P or N range lasts for more than 5 minutes.
Or

The vehicle speed exceeds 20 km/h and the voltage of oil temperature sensor exceeds 2.43V (-40 C) for more
than 10 seconds.

Fail Safe:

The lock-up is inhibited, and TCM is controlled ATF temperature 80 C condition as substitute.

When the engine speed is more than 470 rpm for 10 minuets, the lock-up and gear shift to 4th (over-drive) are
allowed.

Possible Cause:

Oil temperature sensor wire open circuit or short circuit.

Oil temperature sensor malfunction.

Power supply wire open circuit, short circuit to battery or short circuit to ground between oil temperature sensor
and TCM terminal B4 (C95).

Ground wire open circuit or short circuit to battery between oil temperature sensor terminal and TCM terminal
B14 (C95).

Poor connection of each connector.

Reference:
Following output voltage and resistance can be measured by circuit tester.
Measurement terminal: B4 (C95) and B14 (C95)

ATF Temperature Output Voltage Resistance ATF Temperature Output Voltage Resistance
20
C
1.55V 2,500  80
C
0.5V 320
40
C 1.08V 1,160  100
C
0.3V 190
60
C
0.7V 590  120
C
0.2V 120

7A2-66 DIAGNOSIS (JR405E)
Step Action Yes No
1 Clear the DTC from the memory once.
Was the action complete?


Go to Step 2
Refer DTC clear
method in this
manual.
2 Turn the ignition switch off once, then restart the engine and shift to
4th gear in the D range. When about 10 seconds elapsed, does the
CHECK TRANS lamp blink?
Go to Step 3 Go to Step 7
3 Is the DTC P0753 (31) Low & Reverse Brake Duty Solenoid Failure
stored? Go to P0753 (31)
Section Go to Step 4
4 Connect the Tech 2 and select the item for low & reverse brake
pressure switch. Is the indication of low & reverse brake pressure
switch turned off when the terminal assembly connector is
disconnected?
Go to Step 5
Repair the harness
or connector.
Go to Step 12
5 Turn the key switch off and disconnect the terminal assembly
connector. Are the pins correct?
Go to Step 6
Repair the
connector or pin.
Go to Step 12
6 Remove the oil pan. Is the continuity correct between terminal
assembly terminal 12 and low & reverse brake pressure switch
connector?

12

Repair the harness
or connector.
Go to Step 12
Replace pressure
switch.
Go to Step 12
7 Start the engine and select the R range. When about 10 seconds
elapsed, does the CHECK TRANS lamp blink?
Go to Step 8
Go to P0753 (31)
Section
8 Connect the Tech 2, and with the key switch in OFF position, short
the terminals 11 and 12 on the vehicle harness side. Does the
indication of the low & reverse brake pressure switch on the Tech 2
becomes on when the key switch is turned on?
Go to Step 9
Repair the harness
or connector.
Go to Step 12

DIAGNOSIS (JR405E) 7A2-67
Step Action Yes No
9 Check if the trouble is caused by a poor connection of terminal
assembly connector.
With the key switch in OFF position, is the connection condition of
the connector and harness correct?
Go to Step 10
Repair the harness
or connector.
Go to Step 12
10 Remove the oil pan. Is the continuity correct between terminal
assembly terminal 12 and low & reverse brake pressure switch
connector?

12
Go to Step 11
Repair the harness
or connector.
Go to Step 12
11 Is the result OK when the oil pan is removed and the low & reverse
brake pressure switch is checked? Refer the ON VEHICLE
SERVICE SECTION in this manual for the procedure. Repair the control
valve.
Go to Step 12
Replace pressure
switch.
Go to Step 12
12 Clear the DTC from the memory and perform the work after repair. Is
the same DTC code outputted again in the subsequent DTC check?
Replace the TCM Go to Step 13
13 Are the other DTCs outputted? Go to Other DTC
Section Action is completed

7A2-70 DIAGNOSIS (JR405E)
Step Action Yes No
1 Clear the DTC from the memory once.
Was the action complete?
Go to Step 2
Refer DTC clear
method in this
manual.
2 Turn the ignition switch off once, then restart the engine and in D
range. When about 10 seconds elapsed, does the CHECK TRANS
lamp blink?
Go to Step 3 Go to Step 7
3 Is the DTC P0758 (32) 2-4 Brake Duty Solenoid Failure stored?
Go to P0758 (32)
Section Go to Step 4
4 Connect the Tech 2 and select the item for 2-4 brake pressure
switch. Is the indication of 2-4 brake pressure switch turned off when
the terminal assembly connector is disconnected?
Go to Step 5
Repair the harness
or connector.
Go to Step 12
5 Turn the key switch off and disconnect the terminal assembly
connector. Are the pins correct?
Go to Step 6
Repair the
connector or pin.
Go to Step 12
6 Remove the oil pan. Is the continuity correct between terminal
assembly terminal 7 and 2-4 brake pressure switch connector?

7

Repair the harness
or connector.
Go to Step 12
Replace pressure
switch.
Go to Step 12
7 Start the engine and shift to 4th gear in the D range. When about 10
seconds elapsed, does the CHECK TRANS lamp blink?
Go to Step 8
Go to P0758 (32)
Section
8 Connect the Tech 2, and with the key switch in OFF position, short
the terminals 11 and 7 on the vehicle harness side. Does the
indication of the 2-4 brake pressure switch on the Tech 2 becomes
on when the key switch is turned on?
Go to Step 9
Repair the harness
or connector.
Go to Step 12

DIAGNOSIS (JR405E) 7A2-71
Step Action Yes No
9 Check if the trouble is caused by a poor connection of terminal
assembly connector.
With the key switch in OFF position, is the connection condition of
the connector and harness correct?
Go to Step 10
Repair the harness
or connector.
Go to Step 12
10 Remove the oil pan. Is the continuity correct between terminal
assembly terminal 7 and 2-4 brake pressure switch connector?

7
Go to Step 11
Repair the harness
or connector.
Go to Step 12
11 Is the result OK when the oil pan is removed and the 2-4 brake
pressure switch is checked? Repair the control
valve.
Go to Step 12
Replace pressure
switch.
Go to Step 12
12 Clear the DTC from the memory and perform the work after repair. Is
the same DTC code outputted again in the subsequent DTC check?
Replace the TCM Go to Step 13
13 Are the other DTCs outputted?
Go to Other DTC
Section Action is completed

7A2-74 DIAGNOSIS (JR405E)
Step Action Yes No
1 Clear the DTC from the memory once.
Was the action complete?
Go to Step 2
Refer DTC clear
method in this
manual.
2 Turn the ignition switch off once, then restart the engine and in R
range. When about 10 seconds elapsed, does the CHECK TRANS
lamp blink?
Go to Step 3 Go to Step 7
3 Is the DTC P0763 (33) High Clutch Duty Solenoid Failure stored?
Go to P0763 (33)
Section Go to Step 4
4 Connect the Tech 2 and select the item for high clutch pressure
switch. Is the indication of high clutch pressure switch turned off
when the terminal assembly connector is disconnected?
Go to Step 5
Repair the harness
or connector.
Go to Step 12
5 Turn the key switch off and disconnect the terminal assembly
connector. Are the pins correct?
Go to Step 6
Repair the
connector or pin.
Go to Step 12
6 Remove the oil pan. Is the continuity correct between terminal
assembly terminal 1 and high clutch pressure switch connector?

1

Repair the harness
or connector.
Go to Step 12
Replace pressure
switch.
Go to Step 12
7 Start the engine and shift to 4th gear in the D range. When about 10
seconds elapsed, does the CHECK TRANS lamp blink?
Go to Step 8
Go to P0763 (33)
Section
8 Connect the Tech 2, and with the key switch in OFF position, short
the terminals 11 and 1 on the vehicle harness side. Does the
indication of the high clutch pressure switch on the Tech 2 turn on
when the key switch is turned on?
Go to Step 9
Repair the harness
or connector.
Go to Step 12

DIAGNOSIS (JR405E) 7A2-75
Step Action Yes No
9 Check if the trouble is caused by a poor connection of terminal
assembly connector.
With the key switch in OFF position, is the connection condition of
the connector and harness correct?
Go to Step 10
Repair the harness
or connector. Go to
Step 12
10 Remove the oil pan. Is the continuity correct between terminal
assembly terminal 1 and high clutch pressure switch connector?

1
Go to Step 11
Repair the harness
or connector.
Go to Step 12
11 Is the result OK when the oil pan is removed and the high clutch
pressure switch is checked? Repair the control
valve.
Go to Step 12
Replace pressure
switch.
Go to Step 12
12 Clear the DTC from the memory and perform the work after repair.
Is the same DTC code outputted again in the subsequent DTC
check?
Replace the TCM Go to Step 13
13 Are the other DTCs outputted?
Go to Other DTC
Section Action is completed
