Reverse Park Control
General
The function of the Reverse Park Control (RPC) is
to provide an audible warning to the driver of the
distance to obstacles near the rear bumper of the
vehicle when reversing. The system operates
through four ultrasonic sensors that send out
beams covering the area behind the vehicle.
These beams are reflected by obstructions behind
the vehicle and re-enter the sensors. The reflected
beam information is processed by the reverse
park control module (RPCM) to calculate the
J.419.027
REVERSE PARK CONTROL COMPONENT LAYOUT
RPC Switch
RPC ModuleRPC Sensor
RPC Speaker distance of the obstruction. The sounder is then
activated and gives the appropriate warning signal
starting from an intermittent beep (at
approximately 0.8 meters) up to the continuous
ÔstopÕ tone (at approximately 0.2 meters).
The sensors are fitted, equally spaced, across the
rear bumper. The system is activated when the
gear selector is moved to the reverse position
whilst the engine is running. It can be switched off
by pressing the switch in the overhead console. A

JAGUARS-TYPEElectrical/Electronic
127 red indicator light in the switch illuminates when
the system is switched off. It is reset every time
the ignition is cycled.
Should there be a failure in the system, the red
indicator light in the switch is constantly
illuminated and a fault code is logged in the
PACM.
The reversing aid comprises the following
components:
¥ Harness
¥ PACM located on the LH side of the spare
wheel well
¥ Speaker located under the trim on the rear
parcel shelf
¥ Four sensors located in the bumpers (see
page 13)
¥ Sensor holders located in the bumpers
