washer fluid JEEP CHEROKEE 2019 Owner handbook (in English)

CAUTION!
vehicle battery cables before connecting
the charger to the battery. Do not use a
“fast charger” to provide starting voltage.
DEALER SERVICE
An authorized dealer has the qualified service
personnel, special tools, and equipment to
perform all service operations in an expert
manner. Service Manuals are available which
include detailed service information for your
vehicle. Refer to these Service Manuals be-
fore attempting any procedure yourself.
NOTE:
Intentional tampering with emissions control
systems may void your warranty and could
result in civil penalties being assessed
against you.
WARNING!
You can be badly injured working on or
around a motor vehicle. Only do service
work for which you have the knowledge
WARNING!
and the proper equipment. If you have any
doubt about your ability to perform a ser-
vice job, take your vehicle to a competent
mechanic.
Windshield Wiper Blades
Clean the rubber edges of the wiper blades
and the windshield periodically with a sponge
or soft cloth and a mild nonabrasive cleaner.
This will remove accumulations of salt or road
film.
Operation of the wipers on dry glass for long
periods may cause deterioration of the wiper
blades. Always use washer fluid when using
the wipers to remove salt or dirt from a dry
windshield.
Avoid using the wiper blades to remove frost
or ice from the windshield. Keep the blade
rubber out of contact with petroleum prod-
ucts such as engine oil, gasoline, etc.NOTE:
Life expectancy of wiper blades varies de-
pending on geographical area and frequency
of use. Poor performance of blades may be
present with chattering, marks, water lines or
wet spots. If any of these conditions are
present, clean the wiper blades or replace as
necessary.
The wiper blades and wiper arms should be
inspected periodically, not just when wiper
performance problems are experienced. This
inspection should include the following
points:
• Wear or uneven edges
• Foreign material
• Hardening or cracking
• Deformation or fatigue
If a wiper blade or wiper arm is damaged,
replace the affected wiper arm or blade with a
new unit. Do not attempt to repair a wiper
arm or blade that is damaged.
235

BODYWORK
Preserving The Bodywork
Washing
• Wash your vehicle regularly. Always wash
your vehicle in the shade using a mild car
wash soap, and rinse the panels completely
with clear water.
• If insects, tar, or other similar deposits have
accumulated on your vehicle, use a specific
detergent to remove.
• Use a high quality cleaner wax to remove
road film, stains and to protect your paint
finish. Take care never to scratch the paint.
• Avoid using abrasive compounds and power
buffing that may diminish the gloss or thin
out the paint finish.
CAUTION!
• Do not use abrasive or strong cleaning
materials such as steel wool or scouring
powder that will scratch metal and
painted surfaces.
CAUTION!
• Use of power washers exceeding
1,200 psi (8,274 kPa) can result in
damage or removal of paint and decals.
Some parts of the vehicle may be painted
with a matte paintwork which requires spe-
cial care for its preservation
CAUTION!
Avoid washing with rollers and/or brushes
in washing stations. Wash the vehicle only
by hand using neutral pH detergents; dry it
with a wet chamois leather. Abrasive prod-
ucts and/or polishes should not be used for
cleaning the car. Bird droppings must be
washed off immediately and thoroughly as
the acid they contain is particularly ag-
gressive. Avoid (if at all possible) parking
the vehicle under trees; remove vegetable
resins immediately as, when dried, it may
only be possible to remove them with abra-
sive products and/or polishes, which is
highly inadvisable as they could alter the
typical opaqueness of the paint. Do not
use pure windshield washer fluid for
CAUTION!
cleaning the front windshield and rear win-
dow; dilute it min. 50% with water. Only
use pure windshield washer fluid when
strictly necessary due to outside tempera-
ture conditions.
Special Care
• If you drive on salted or dusty roads or if you
drive near the ocean, hose off the undercar-
riage at least once a month.
• It is important that the drain holes in the
lower edges of the doors, rocker panels, and
trunk be kept clear and open.
• If you detect any stone chips or scratches in
the paint, touch them up immediately. The
cost of such repairs is considered the re-
sponsibility of the owner.
• If your vehicle is damaged due to a collision
or similar cause that destroys the paint and
protective coating, have your vehicle re-
paired as soon as possible. The cost of such
repairs is considered the responsibility of
the owner.
SERVICING AND MAINTENANCE
250

Tires............138, 239, 244, 245
Aging (Life Of Tires)..........242
Air Pressure...............239
Chains...................247
Changing..............196, 239
Compact Spare.............245
General Information. . . .239, 244, 245
High Speed................241
Inflation Pressure............240
Jacking...............196, 239
Life Of Tires...............242
Pressure Monitoring
System (TPMS)...........70, 94
Radial...................241
Replacement...............243
Rotation..................248
Safety...................239
Snow Tires................244
Spare Tires............244, 245
Spinning.................242
Tread Wear Indicators.........242
Wheel Nut Torque............253
Tire Service Kit...............204
To Open Hood.................53
Towing.................181, 214
Disabled Vehicle.............214
Guide...................181Recreational...............182
Weight...................181
Towing Behind A Motorhome.......182
Traction Control................80
Trailer Sway Control (TSC)..........84
Trailer Towing................181
Trailer Towing Guide............181
Trailer Weight................181
Transaxle
Automatic
...............
.146
Operation.................146
Transmission.................148
Automatic.............148, 234
Fluid....................265
Maintenance...............234
Manual..................144
Transporting Pets..............135
Tread Wear Indicators............242
Turn Signals.............32, 36, 73
Uconnect
Uconnect Settings...........288
Uconnect 3 With 5-Inch Display.....268
Uconnect 4C/4C Nav With 8.4-Inch
Display...................278
Uconnect 4 With 7-Inch Display.....272
Uconnect Phone...............295Making A Call..............302
Pairing..................298
Uconnect Settings
Customer Programmable Features . .20,
288
Passive Entry Programming.......20
Untwisting Procedure, Seat Belt.....104
USB......................289
Vehicle Modifications/Alterations......4
Vehicle Storage................48
Ventilated Seats................28
Voice Command........301, 302, 305
Voice Recognition
System (VR).........301, 302, 305
Warning Lights (Instrument Cluster
Descriptions)................69
Warnings And Cautions............4
Warnings, Roll Over..............2
Washers, Windshield............232
Washing Vehicle...............250
Wheel And Wheel Tire Care........246
Wheel And Wheel Tire Trim........246
Wind Buffeting................50
Window Fogging................49
Windows....................49
339

Power....................49
Windshield Defroster............137
Windshield Washers.............37
Fluid....................232
Windshield Wiper Blades.........235
Windshield Wipers...........37, 232
Wipers Blade Replacement........235
Wipers, Intermittent.............37
Wipers, Rain Sensitive............38
INDEX
340
