Once a Month
•Check tire pressure and look for unusual wear or
damage.
•Inspect the battery and clean and tighten the terminals
as required.
•Check the fluid levels of coolant reservoir, brake/
clutch master cylinder, and manual transaxle and add
as needed.
•Check all lights and all other electrical items for correct
operation.
At Each Oil Change
•Change the engine oil filter.
•Inspect the exhaust system.
•Inspect the brake hoses.
•Inspect the CV joints (if equipped) and front suspen-
sion components.
•Check the manual transmission fluid level (if
equipped).
•Check the coolant level, hoses, and clamps.
CAUTION!
Do not check the automatic transaxle fluid. It must
be check by a trained service technician every 15,000
miles and if required only the recommended fluid
be added. Refer to the section “Fluids, Lubricants
And Genuine Parts” for the proper fluid.
368 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Schedule “B”
Follow schedule “B” if you usually operate your vehicle
under one or more of the following conditions.
•Day or night temperatures are below 32° F (0° C).
•Stop and go driving.
•Extensive engine idling.
•Driving in dusty conditions.
•Short trips of less than 10 miles (16 km).
•More than 50% of your driving is at sustained high
speeds during hot weather, above 90° F (32° C).
•Trailer towing.
•Taxi, police, or delivery service (commercial service).
•Off-road or desert operation.
•Heavy Loading
NOTE:IfANYof these apply to you then change your
engine oil every 3,000 miles (5 000 km) or 3 months,
whichever comes first and follow schedule “B” of the
Maintenance Schedulessection of this manual.
NOTE:IfANYof these apply to you then change your
coolant every 102,000 miles (170 000 km) or 60 months,
whichever comes first and follow schedule “B” of the
Maintenance Schedulessection of this manual.
SCHEDULE “B” 369
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 48,000 51,000 54,000 57,000 60,000
(Kilometers) (80 000) (85 000) (90 000) (95 000) (100 000)
Change engine oil and engine oil filter, or at 3 months
whichever comes first.X X XXX
Change Automatic Transaxle (CVT) Fluid and Filter X
Change Manual Transaxle Fluid. X
Change Rear Drive Assembly (RDA) fluid. X
Change Power Transfer Unit (PTU) fluid. X
Rotate tires. X X X
Check spare tire for proper pressure and correct stowage.XXX
Inspect brake linings. X
Replace engine air cleaner filter.X
Replace spark plugs.X
Inspect PCV valve, replace as necessary.**X
Inspect auto tension drive belt and replace, if required.X
Flush and replace engine coolant at 60 months, or
102,000 miles (170 000 km) whichever comes first.X
SCHEDULE “B” 373
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 93,000 96,000 99,000 102,000
(Kilometers) (155 000) (160 000) (165 000) (170 000)
Change engine oil and engine oil filter, or at 3 months
whichever comes first.XXXX
Change Manual Transaxle Fluid. X
Rotate tires. X X
Check spare tire for proper pressure and correct stowage. X X
Flush and replace engine coolant, if not done at 60
months.X
376 SCHEDULE “B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 105,000 108,000 111,000 114,000 117,000 120,000
(Kilometers) (175 000) (180 000) (185 000) (190 000) (195 000) (200 000)
Change engine oil and engine oil filter, or at 3
months whichever comes first.XXXXXX
Change Automatic Transaxle (CVT) Fluid and FilterX
Change Rear Drive Assembly (RDA) fluid. X
Change Power Transfer Unit (PTU) fluid. X
Rotate tires. X X X
Check spare tire for proper pressure and correct stowage.XXX
Inspect brake linings. X
Replace engine air cleaner filter.XX
Replace spark plugs.X
Inspect PCV valve, replace as necessary.**X
Inspect auto tension drive belt and replace, if required.XX
Flush and replace engine coolant, if not replaced at
102,000 miles (170 000 km).X
** This maintenance is recommended by the manufacturer to the owner, but not required to maintain the emissions
warranty.
SCHEDULE “B” 377
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 36,000 42,000 48,000 54000 60,000 66,000
(Kilometers) (60 000) (70 000) (80 000) (90 000) (100 000) (110 000)
[Months] [36] [42] [48] [54] [60] [66]
Change engine oil and engine oil filter. X XXXXX
Change Rear Drive Assembly (RDA) fluid. X
Change Power Transfer Unit (PTU) fluid. X
Rotate tires. X XXXXX
Check spare tire for proper pressure and correct
stowage.X X XXXX
Flush and replace engine coolant at 60 months, if
not replaced at 102,000 miles (170 000 km).X
Inspect brake linings. X X
Inspect engine air cleaner filter, replace if necessary.X
Replace engine air cleaner filter.X
Replace spark plugs.X
Inspect PCV valve, replace as necessary.**X
Inspect auto tension drive belt and replace, if required.X
SCHEDULE “A” 379
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 102,000 108,000 114,000 120,000
(Kilometers) (170 000) (180 000) (190 000) (200 000)
[Months] [102] [108] [114] [120]
Change engine oil and engine oil filter. X X X X
Change Rear Drive Assembly (RDA) fluid. X
Change Power Transfer Unit (PTU) fluid. X
Rotate tires. X X X X
Check spare tire for proper pressure and correct stowage. X X X X
Flush and replace engine coolant, if not done at 60 months. X
Flush and replace engine coolant, if not done at 102,000
miles (170 000 km)X
Inspect brake linings. X
Inspect auto tension drive belt and replace, if required. X X
Inspect engine air cleaner filter, replace if necessary.X
Replace engine air cleaner filter.X
Replace spark plugs.X
Inspect PCV valve, replace as necessary.**X
SCHEDULE “A” 381
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

ABS (Anti-Lock Brake System).............. 247
Adding Engine Coolant (Antifreeze).......... 335
Adding Fuel........................... 281
Adding Washer Fluid..................127,158
Additives, Fuel......................... 279
Air Cleaner, Engine (Engine Air Cleaner Filter) . . . 327
Air Conditioner Maintenance............... 329
Air Conditioning Controls................. 220
Air Conditioning, Operating Tips............ 226
Air Conditioning Refrigerant.............329,330
Air Conditioning System................220,329
Air Pressure, Tires....................... 260
Airbag................................ 48
Airbag Deployment....................... 60
Airbag Light....................... 62,74,167
Airbag Maintenance....................... 61
Airbag, Side............................ 58
Alarm System (Security Alarm)............ 30,170
Alignment and Balance................... 268Alterations/Modifications, Vehicle............. 7
Antenna, Satellite Radio................... 217
Antifreeze (Engine Coolant)...........334,362,363
Capacities........................... 362
Disposal............................ 336
Anti-Lock Brake System (ABS)............138,247
Anti-Theft Security Alarm (Theft Alarm)........ 30
Appearance Care........................ 345
Automatic Door Locks................... 20,21
Automatic Transaxle........... 12,232,235,300,342
Fluid Level Check...................... 342
Interlock System..................... 17,236
Overheating.......................... 300
Selection Of Lubricant................... 342
Shifting ............................. 237
Special Additives...................... 343
Autostick ............................. 239
BallJoints ............................. 331
392 INDEX

Battery............................... 327
Keyless Transmitter Replacement (RKE)....... 29
Belts,Drive ............................ 324
Body Mechanism Lubrication............... 331
B-Pillar Location........................ 255
Brake Assist System...................... 140
Brake Fluid............................ 364
Brake, Parking.......................... 244
Brake System........................246,339
Anti-Lock (ABS)....................138,247
Hoses.............................. 339
Master Cylinder....................... 340
Parking............................. 244
Warning Light........................ 169
Brakes.............................246,339
Brake/Transmission Interlock............... 236
Break-In Recommendations, New Vehicle........ 72
Bulb Replacement.....................354,355
Bulbs,Light ............................ 354Calibration, Compass..................... 184
Capacities, Antifreeze (Engine Coolant)........ 362
Capacities, Fluid........................ 362
Caps, Filler
Fuel................................ 281
Oil (Engine).......................316,323
Car Washes............................ 345
Carbon Monoxide Warning................. 280
Cargo Area Cover....................... 154
Cargo Area Features...................... 152
Cargo Compartment
Light ............................... 152
Luggage Carrier....................... 159
CargoLight ............................ 152
Cargo Load Floor........................ 155
Cargo Tie-Downs........................ 155
Carrier, Luggage........................ 159
Catalytic Converter...................... 325
Caution, Exhaust Gas...................... 73
INDEX 393
10

CD (Compact Disc) Player...............187,195
CD (Compact Disc) Player Maintenance........ 219
Cellular Phone........................ 83,220
Center High Mounted Stop Light............ 361
Chains, Tire............................ 275
Changing A Flat Tire..................... 301
Chart, Tire Sizing........................ 252
Check Engine Light
(Malfunction Indicator Light)............... 318
Child Restraint.......................... 64
Child Restraint Tether Anchors............... 68
Child Restraint with Automatic Belts........... 67
Child Safety Locks........................ 23
Child Seat.............................. 70
Clean Air Gasoline....................... 278
Cleaning
Wheels............................. 347
Climate Control......................... 220
Clock ........................186,189,197,210Clutch............................... 340
Clutch Fluid........................... 340
CoinHolder ........................... 152
Compact Disc (CD) Maintenance............. 219
Compact Spare Tire...................... 263
Compass.............................. 184
Compass Calibration..................... 184
Compass Variance....................... 183
Console.............................. 152
Contract, Service........................ 386
Coolant (Antifreeze)...................362,363
Cooling System......................... 333
Adding Coolant (Antifreeze).............. 335
Coolant Level......................334,337
Disposal of Used Coolant................ 336
Drain, Flush, and Refill.................. 334
Inspection........................... 337
Points to Remember.................336,337
Pressure Cap......................... 336
394 INDEX
