wheel bolts JEEP GLADIATOR 2023 Owners Manual

208STARTING AND OPERATING
3. After all bolts and nuts have been removed, pull the side step assembly off of the vehicle.
4. To reinstall the side steps align the studs to the body side holes and fasten all nuts on all four
brackets. Then secure all four bolts to the
underbody. Repeat the reassembly procedure
for the other side.
Bumper End Cap Removal — If Equipped
The end caps on your vehicle’s front bumper can
be removed by following the steps below:
NOTE:Bumper end caps are removable on steel bumpers
only.

1. Loosen the two bolts that retain the GAWR bracket (Bolts #1 and #2) to the end cap
using a T45 Torx bit screw driver. Do not
remove the bolts.

Bolt #1 Bolt #2

2. Remove the remaining eight bolts.
3. Gently remove the end cap from the vehicle and store it where it will not get damaged.
4. Repeat this procedure on the other side.
The Basics Of Off-Road Driving
You will encounter many types of terrain driving
off-road. You should be familiar with the terrain
and area before proceeding. There are many types
of surface conditions: hard-packed dirt, gravel,
rocks, grass, sand, mud, snow and ice. Every
surface has a different effect on your vehicle's
steering, handling and traction. Controlling your
vehicle is one of the keys to successful off-road
driving, so always keep a firm grip on the steering
wheel and maintain a good driving posture. Avoid
sudden accelerations, turns or braking. In most
cases, there are no road signs, posted speed limits or signal lights. Therefore, you will need to use your
own good judgment on what is safe and what is
not. When on a trail, you should always be looking
ahead for surface obstacles and changes in
terrain. The key is to plan your future driving route
while remembering what you are currently driving
over.
NOTE:It is recommended that the Stop/Start system be
disabled during off-road use.
When To Use 4L Range
When off-road driving, shift into 4L for additional
traction and control on slippery or difficult terrain,
ascending or descending steep hills, and to
increase low speed pulling power. This range
should be limited to extreme situations such as
deep snow, mud, steep inclines, or sand where
WARNING!
Always wear your seat belt and firmly tie down
cargo. Unsecured cargo can become projectiles
in an off-road situation.
CAUTION!
Never park your vehicle over dry grass or other
combustible materials. The heat from your
vehicle exhaust system could cause a fire.

23_JT_OM_EN_USC_t.book Page 208

IN CASE OF EMERGENCY341

Rear Jacking Location

5. Raise the vehicle by turning the jack screw clockwise. Raise the vehicle only until the tire
just clears the ground surface and enough
clearance is obtained to install the spare tire.
Minimum tire lift provides maximum stability. 6. Remove the lug nuts and wheel.
7. Mount the spare tire on the axle.
8. Install the lug nuts with the cone-shaped end
toward the wheel. Lightly tighten the lug nuts
clockwise.
9. Lower the vehicle by turning the jack screw counterclockwise, and remove the jack. 10. Finish tightening the wheel bolts. Push down
on the wrench while at the end of the handle
for increased leverage. Tighten the wheel bolts
in a star pattern until each wheel bolt has been
tightened twice Úpage 418. If in doubt about
the correct tightness, have them checked with
a torque wrench by an authorized dealer or at
a service station.
11. After 25 miles (40 km), check the lug nut torque with a torque wrench to ensure that all
lug nuts are properly seated against the wheel.
12. Remove the jack assembly and wheel blocks.
13. Secure the jack and tools in their proper locations.
CAUTION!
Before raising the wheel off the ground, make
sure that the jack will not damage surrounding
truck parts and adjust the jack position as
required.
WARNING!
Raising the vehicle higher than necessary can
make the vehicle less stable. It could slip off the
jack and hurt someone near it. Raise the vehicle
only enough to remove the tire.
WARNING!
To avoid the risk of forcing the vehicle off the
jack, do not tighten the wheel nuts fully until the
vehicle has been lowered. Failure to follow this
warning may result in serious injury.WARNING!
A loose tire or jack thrown forward in a collision
or hard stop, could endanger the occupants of
the vehicle. Always stow the jack parts and the
spare tire in the places provided.7

23_JT_OM_EN_USC_t.book Page 341

418
TECHNICAL SPECIFICATIONS
VEHICLE IDENTIFICATION NUMBER (VIN)
The VIN is found on the left front corner of the
A-pillar, visible from outside of the vehicle through
the windshield.
Vehicle Identification Number

NOTE:It is illegal to remove or alter the VIN plate.
BRAKE SYSTEM
Your vehicle is equipped with dual hydraulic brake
systems. If either of the two hydraulic systems lose
normal capability, the remaining system will still
function. However, there will be some loss of
overall braking effectiveness. You may notice
increased pedal travel during application, greater
pedal force required to slow or stop, and potential
activation of the Brake Warning Light.
In the event power assist is lost for any reason (i.e.,
repeated brake applications with the engine off)
the brakes will still function. However, the effort
required to brake the vehicle will be much greater
than that required with the power system
operating.
WHEEL AND TIRE TORQUE SPECIFICATIONS
Proper lug nut/bolt torque is very important to
ensure that the wheel is properly mounted to the
vehicle. Any time a wheel has been removed and
reinstalled on the vehicle, the lug nuts/bolts
should be torqued using a properly calibrated
torque wrench using a six-sided (hex) deep wall
socket.
TORQUE SPECIFICATIONS
**Use only authorized dealer recommended lug nuts/
bolts and clean or remove any dirt or oil before tightening.
Inspect the wheel mounting surface prior to
mounting the tire and remove any corrosion or
loose particles.
Wheel Mounting Surface

Lug Nut/Bolt Torque **Lug Nut/
Bolt Size Lug Nut/Bolt
Socket Size
130 ft-lb
(176 N·m) M14 x
1.50 mm 22 mm

23_JT_OM_EN_USC_t.book Page 418

TECHNICAL SPECIFICATIONS419
Tighten the lug nuts/bolts in a star pattern until
each nut/bolt has been tightened twice. Ensure
that the socket is fully engaged on the lug nut/bolt
(do not insert it halfway).

Torque Patterns

After 25 miles (40 km), check the lug nut/bolt
torque to be sure that all the lug nuts/bolts are
properly seated against the wheel.
FUEL REQUIREMENTS — GASOLINE ENGINE
While operating on gasoline with the required
octane number, hearing a light knocking sound
from the engine is not a cause for concern.
However, if the engine is heard making a heavy
knocking sound, see an authorized dealer
immediately. Use of gasoline with an octane
number lower than recommended can cause
engine failure and may void the New Vehicle
Limited Warranty.
Poor quality gasoline can cause problems such as
hard starting, stalling, and hesitations. If you
experience these symptoms, try another brand of
gasoline before considering service for the vehicle.
3.6L ENGINE
This engine is designed to meet all
emission regulations and provide
excellent fuel economy and performance
when using high-quality unleaded regular
gasoline having an octane rating of 87 as specified
by the (R+M)/2 method. The use of higher octane
premium gasoline will not provide any benefit over
regular gasoline in these engines.
REFORMULATED GASOLINE
Many areas of the country require the use of
cleaner-burning gasoline referred to as
“reformulated gasoline”. Reformulated gasoline contains oxygenates and are specifically blended
to reduce vehicle emissions and improve air
quality.
The use of reformulated gasoline is recommended.
Properly blended reformulated gasoline will
provide improved performance and durability of
engine and fuel system components.
MATERIALS ADDED TO FUEL
Besides using unleaded gasoline with the proper
octane rating, gasolines that contain detergents,
corrosion and stability additives are
recommended. Using gasolines that have these
additives will help improve fuel economy, reduce
emissions, and maintain vehicle performance.
Designated TOP TIER Detergent Gasoline
contains a higher level of detergents to
further aide in minimizing engine and
fuel system deposits. When available,
the usage of TOP TIER Detergent Gasoline is
recommended. Visit www.toptiergas.com for a list
of TOP TIER Detergent Gasoline retailers.
Indiscriminate use of fuel system cleaning agents
should be avoided. Many of these materials
intended for gum and varnish removal may contain
active solvents or similar ingredients. These can
harm fuel system gasket and diaphragm materials.
WARNING!
To avoid the risk of forcing the vehicle off the
jack, do not tighten the lug nuts/bolts fully until
the vehicle has been lowered. Failure to follow
this warning may result in personal injury.9

23_JT_OM_EN_USC_t.book Page 419

438
Leaks, Fluid
................................................... 330Leather Surfaces........................................... 417Life Of Tires................................................... 404Light Bulbs........................................... 330, 392Lights............................................................. 3304WD.......................................................... 1384WD Auto.................................................. 1394WD Low................................................... 1384WD Part Time.......................................... 138AdBlue UREA Injection System Failure...... 138Air Bag.................................... 132, 306, 329Automatic Headlights.................................. 58Axle Locker Fault....................................... 138Bed.............................................................. 59Brake Assist Warning................................ 283Brake Warning.......................................... 132Bulb Replacement..................................... 393Cargo......................................................... 139Center Mounted Stop................................ 395Daytime Running......................................... 57Dimmer Switch, Headlight........................... 57Electronic Throttle Control......................... 133Engine Check Malfunction Indicator..........136Engine Coolant Temperature..................... 133Exterior............................................... 56, 330Fog............................................58, 140, 394Front And Rear Axle Lock.......................... 138Hazard Warning Flasher............................ 332Headlight Switch......................................... 56Headlights.......................................... 56, 393
High Beam..........................................57, 141High Beam/Low Beam Select...................... 57Hood Open............................................... 133Instrument Cluster....................................... 56Interior......................................................... 59Lights On Reminder..................................... 58Low Diesel Exhaust Emissions Additive.... 139Low Fuel................................................... 136Neutral..................................................... 139Off Road................................................... 139Oil Pressure.............................................. 134Oil Temperature........................................ 134Passing........................................................ 58Rear Axle Lock.......................................... 138Rear Servicing.......................................... 395Rear Tail Lamps....................................... 395Seat Belt Reminder.................................. 134Security Alarm.......................................... 135Service..................................................... 393Service 4WD............................................. 136Service Forward Collision......................... 137Side Marker.............................................. 395StopStart.................................................. 140Sway Bar Fault.......................................... 137Tire Pressure Monitoring (TPMS)..... 137, 294Traction Control........................................ 283Transmission Temperature....................... 134Turn Signal............................................... 330Turn Signals........................... 140, 394, 395Two Wheel Drive High............................... 140
Load Shed Battery Saver Mode..................... 127Loading Vehicle............................................. 195Tires.......................................................... 400Locking Axle.................................................. 165, 166LocksAutomatic Door............................................27Child Protection...........................................27Power Door..................................................25Low Tire Pressure System............................. 294Lowering The Soft Top
S
........................83, 86Lubrication, Body.......................................... 374Lug Nuts/Bolts.............................................. 418Luggage Carrier............................................. 115
M
Maintenance Free Battery............................ 364Maintenance Schedule........................ 353, 357ManualPark Release............................................ 348Service...................................................... 431Manual Transmission........................... 153, 381Fluid Level Check...................................... 381Lubricant Selection.......................... 381, 426Shift Speeds............................................. 154Media Mode.................................................. 242Methanol....................................................... 420Methylcyclopentadienyl Manganese
Tricarbonyl (MMT) In Gasoline...................... 420

23_JT_OM_EN_USC_t.book Page 438
