C107 (DIESEL) - GRAY (LEFT HEADLAMP AND
DASH SIDE)
CAV CIRCUIT
A-
B A148 16LG/RD
C C1 12DG
D A149 12RD/TN
E-
F A1 12RD
G A145 10WT/RD
H A146 10OR/WT
J A147 10RD/GY
K A148 10PK/WT
L A2 12PK/BK
M-
1 X2 18DG/RD
2 V11 20BK/TN
3 K4 18BK/LB
4 V37 18RD/LG
5 V55 16TN/RD
6 V6 16DB
7 V10 20BR
8-
9 K226 18DB/WT
10 X3 20BK/RD
11 F15 18DB/WT
12 F45 18YL/RD
13 T41 18BK/WT
14 -
15 G70 20BR/TN
16 G9 18GY/BK (RHD)
17 Z231 18BK (RHD)
18 -
19 -
20 -
21 F991 20OR/DB
22 -
23 X75 18GY/LB
24 Y42 18OR/DB
25 B7 18WT
26 B6 18WT/DB
27 B4 18LG
28 B3 18LG/DB
29 B2 18YL
30 B1 18YL/DB
31 -
32 M1 18PK
8W - 80 - 28 8W-80 CONNECTOR PIN-OUTWJ

C107 (DIESEL) - GRAY (LEFT HEADLAMP AND
DASH SIDE)
CAV CIRCUIT
33 F20 18DB/PK
34 L50 18WT/TN
35 R47 18DB/LB
36 T2 18TN/BK
37 Z305 20BK/OR
38 Z306 20BK/LG
39 R49 18LB
40 K29 18WT/PK
41 C18 18DB (RHD)
42 -
43 K6 18VT/WT (RHD)
44 -
45 V16 20VT
46 V14 20RD/VT
47 L13 18BR/YL
48 D25 18VT/YL
49 D21 18PK
50 K173 18LG
51 -
52 -
53 L7 18BK/YL
54 L61 20LG
55 L1 18VT/BK
56 V20 18BK/WT
57 L39 20LB
58 F22 18WT/PK
59 L43 18VT
60 L33 18LG/BR
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 29

C107 (GAS) - GRAY/RHD BLACK/LHD (LEFT
HEADLAMP AND DASH SIDE)
CAV CIRCUIT
A-
B-
C-
D-
E A10 12RD/DG
F-
G-
H-
J-
K-
L-
M A20 12RD/DB
1 V37 18RD/LG (RHD)
2 V11 20BK/TN
3 V3 16BR/WT
4 V4 16RD/YL
5 V55 16TN/RD
6 V6 16DB
7 V10 20BR
8 F12 20DB/WT
9 K52 20PK/BK (LHD)
9 K226 18LB/YL (RHD)
10 -
11 K512 18RD/YL (4.7L RHD)
12 K4 18BK/LB (RHD)
13 -
14 T6 18OR/BK (4.0L RHD)
14 T6 18OR/WT (4.7L RHD)
15 G70 20BR/TN (RHD)
16 G9 18GY/BK (RHD)
17 Z231 18BK (RHD)
18 -
19 D32 18LG/DG (RHD)
20 -
21 -
22 -
23 X75 18GY/LG (RHD)
24 F42 18DG/LG (RHD)
25 B7 18WT
26 B6 18WT/DB
27 B4 18LG
28 B3 18LG/DB
29 B2 18YL
30 B1 18YL/DB
31 -
32 M1 20PK/RD (LHD)
32 M1 18PK (RHD)
33 F20 18DB/PK
34 L50 18WT/TN
35 R47 18DB/LB (LHD)
36 -
37 K51 18DB/YL (RHD)
38 K25 18VT/LG (RHD)
39 R49 18LB (LHD)
8W - 80 - 32 8W-80 CONNECTOR PIN-OUTWJ

C107 (GAS) - GRAY/RHD BLACK/LHD (LEFT
HEADLAMP AND DASH SIDE)
CAV CIRCUIT
39 K31 18BR (RHD)
40 K29 18WT/PK (RHD)
41 K125 18WT/DB (RHD)
42 V32 18OR/DG (RHD)
43 R47 18DB/LB (RHD)
44 V35 18LG/RD (RHD)
45 B22 18DG/YL (LHD)
45 V36 18TN/RD (RHD)
46 C13 18DB/OR (RHD)
47 L13 18BR/YL (RHD)
48 D25 18VT/YL
49 D21 18PK (RHD)
50 R49 18LB (RHD)
51 -
52 -
53 L7 20BK/YL
54 L61 20TN/LG
55 -
56 V20 18BK/WT
57 L39 20LB
58 -
59 L43 18VT
60 L33 18RD
C108 - BLACK (LEFT HEADLAMP AND DASH
SIDE)
CAV CIRCUIT
1 M1 20PK (BUILT-UP-EXPORT)
1 M1 20PK/RD (EXCEPT
BUILT-UP-EXPORT)
2 Z141 20BK
C108 - BLACK (UNDERHOOD LAMP SIDE)
CAV CIRCUIT
1 M1 20PK/RD
2 Z141 20BK
C109 - BLACK (ENGINE SIDE)
CAV CIRCUIT
1 K77 18LG/BK
2 K4 18BK/LB
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 33

C109 - BLACK (TRANSFER CASE JUMPER SIDE)
CAV CIRCUIT
1 K77 18LG/BK
2 K4 18BK/LB
C110 (DIESEL) - GRAY (LEFT HEADLAMP AND
DASH SIDE)
CAV CIRCUIT
1 K154 10GY
2 K254 10GY/YL
C110 (DIESEL) - GRAY (GLOW PLUG SIDE)
CAV CIRCUIT
1 K154 10GY
2 K254 10GY/YL
C111 - BLACK (LEFT FRONT LIGHTING MODULE
SIDE)
CAV CIRCUIT
1 L33 18RD
2 L43 18VT
3 L61 20TN/LG
4 L7 20BK/YL
5 L114 18BR/YL (BUILT-UP-EXPORT)
6 Z141 18BK
C111 - BLACK (LEFT HEADLAMP AND DASH
SIDE)
CAV CIRCUIT
1 L33 18LG/BR (DIESEL)
1 L33 18RD (GAS)
2 L43 18VT
3 L61 20LG (DIESEL)
3 L61 20TN/LG (GAS)
4 L7 18BK/YL (DIESEL)
4 L7 20BK/YL (GAS)
5 L13 18BR/YL (BUILT-UP-EXPORT)
6 Z141 18BK
8W - 80 - 34 8W-80 CONNECTOR PIN-OUTWJ

C112 - BLACK (RIGHT HEADLAMP AND DASH
SIDE)
CAV CIRCUIT
1 L34 18RD/OR
2 L44 18VT/RD
3 L60 20TN
4 L7 20BK/YL
5 L13 18BR/YL (BUILT-UP-EXPORT)
6 Z142 18BK
C112 - BLACK (RIGHT FRONT LIGHTING
MODULE SIDE)
CAV CIRCUIT
1 L34 18RD/OR
2 L44 18VT/RD
3 L60 20TN
4 L7 20BK/YL
5 L13 18BR/YL (BUILT-UP-EXPORT)
6 Z142 18BK
C113 (DIESEL) - LT. GRAY (ENGINE SIDE)
CAV CIRCUIT
1 D51 16WT
2 D52 16DG/WT
C113 (DIESEL) - LT. GRAY (TRANSMISSION
SIDE)
CAV CIRCUIT
1 D52 18LG/WT
2 D51 18DG/WT
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 35

GENERATOR (GAS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K125 18WT/DB GENERATOR SOURCE
2 K20 18DG GENERATOR FIELD DRIVER
GLOVE BOX LAMP - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 F70 20PK/BK FUSED B(+)
2 M20 20BR/OR COURTESY LAMP LOAD SHED
HEADLAMP LEVELING SWITCH (BUILT-UP-EXPORT) - WHITE 3 WAY
CAV CIRCUIT FUNCTION
1 Z234 20BK GROUND
2 L7 18BK/YL PARK LAMP RELAY OUTPUT
3 L13 20BR/YL HEADLAMP ADJUST SIGNAL
HOOD AJAR SWITCH (BUILT-UP-EXPORT) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 G70 20BR/TN HOOD AJAR SWITCH SENSE
2 Z141 20BK (DIESEL) GROUND
2 Z161 20BK (GAS) GROUND
HORN NO. 1 - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z307 18BK GROUND
2 X2 18DG/RD HORN RELAY OUTPUT
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 83

LEFT HEADLAMP LEVELING MOTOR (BUILT-UP-EXPORT) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 Z1 18BK GROUND
2 L114 18VT/DB HEADLAMP ADJUST SIGNAL
3 L7 20BK/PK PARK LAMP RELAY OUTPUT
LEFT HIGH BEAM HEADLAMP - BLACK 2 WAY
CAV CIRCUIT FUNCTION
A Z1 18BK GROUND
B L33 18RD FUSED LEFT HIGH BEAM OUTPUT
LEFT INSTRUMENT PANEL SPEAKER - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 X83 18YL/RD LEFT INSTRUMENT PANEL SPEAKER (+)
2 X81 18YL/BK LEFT INSTRUMENT PANEL SPEAKER (-)
LEFT LIFTGATE AJAR SWITCH - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z1 20BK GROUND
2 G78 20TN/BK LIFTGATE AJAR SWITCH SENSE
LEFT LOW BEAM HEADLAMP - GRAY 2 WAY
CAV CIRCUIT FUNCTION
A Z1 18BK GROUND
B L43 18VT FUSED LEFT LOW BEAM OUTPUT
8W - 80 - 94 8W-80 CONNECTOR PIN-OUTWJ

LEFT MULTI-FUNCTION SWITCH - WHITE 11 WAY
CAV CIRCUIT FUNCTION
1 L27 20WT/TN FOG LAMP SWITCH SENSE
2 Z234 20BK GROUND
3- -
4 L80 20WT/DG HEADLAMP SWITCH RETURN
5 L309 20PK/LG HIGH BEAM RELAY CONTROL
6 L40 20BR HIGH BEAM SWITCH SENSE
7 L302 20LB/YL RIGHT TURN SWITCH SENSE
8 L305 20LB/WT LEFT TURN SWITCH SENSE
9 L91 20DB/PK HAZARD SWITCH SENSE
10 E19 20RD PANEL LAMPS DIMMER SIGNAL
11 G52 20YL HEADLAMP SWITCH MUX
LEFT REAR DOOR LOCK MOTOR/AJAR SWITCH - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 G77 18TN/YL LEFT REAR DOOR AJAR SWITCH SENSE
2 Z1 18BK GROUND
3 P36 18PK/VT DOOR UNLOCK DRIVER
4 P35 18OR/VT DOOR LOCK DRIVER
LEFT REAR DOOR SPEAKER - WHITE 3 WAY
CAV CIRCUIT FUNCTION
1 X51 18WT/VT (BASE) LEFT REAR DOOR SPEAKER (+)
1 X91 18WT/VT (PREMIUM) LEFT REAR DOOR SPEAKER (+)
2- -
3 X57 18TN/DG (BASE) LEFT REAR DOOR SPEAKER (-)
3 X93 18TN/DG (PREMIUM) LEFT REAR DOOR SPEAKER (-)
LEFT REAR LAMP ASSEMBLY - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 L1 18VT/BK BACK-UP LAMP FEED
2 L95 18DG/YL (BUILT-UP-EXPORT) REAR FOG LAMP RELAY OUTPUT
3 L7 18BK/YL PARK LAMP RELAY OUTPUT
4 L63 18DG/RD LEFT TURN SIGNAL
5 Z150 18BK GROUND
6 L50 18WT/TN PRIMARY BRAKE SWITCH SIGNAL
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 95

RIGHT FRONT SIDE MARKER LAMP (EXCEPT BUILT-UP-EXPORT) - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 L7 20BK/PK PARK LAMP RELAY OUTPUT
2 L60 20TN RIGHT TURN SIGNAL
RIGHT FRONT TURN SIGNAL LAMP (BUILT-UP-EXPORT) - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 L60 20TN RIGHT TURN SIGNAL
2 Z1 18BK GROUND
RIGHT FRONT WHEEL SPEED SENSOR - GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 B7 18WT RIGHT FRONT WHEEL SPEED SENSOR 12 VOLT
SUPPLY
2 B6 18WT/DB RIGHT FRONT WHEEL SPEED SENSOR SIGNAL
RIGHT HEADLAMP LEVELING MOTOR (BUILT-UP-EXPORT) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 Z1 18BK GROUND
2 L114 18VT/DB HEADLAMP ADJUST SIGNAL
3 L7 20BK/PK PARK LAMP RELAY OUTPUT
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 115
