JEEP GRAND CHEROKEE 2004 WK / 3.G Owners Manual

5 km/h). Avoid attempting to engage or disengage 4LO
with the vehicle moving faster than 2 to 3 mph (3 to 5
km/h).
Quadra-Trac IITOperating
Instructions/Precautions Ð If Equipped
The Quadra-Trac IIttransfer case is fully automatic in the
normal driving 4 ALL TIME mode. The Quadra-Trac IIt
transfer case provides three mode positions Ð four wheel
drive high range, neutral, and four wheel drive low
range.
This transfer case is fully automatic in the 4 ALL TIME
mode. The 4 ALL TIME mode transmits torque to the rear
axle during normal driving, similar to a rear wheel drive
vehicle. When speed difference is increased between the
front and rear driveshafts the majority of engine torque
can be transmitted to the front driveshaft.
When additional traction is required, the 4LO position
can be used to lock the front and rear driveshafts togetherand force the front and rear wheels to rotate at the same
speed. The 4LO position is intended for loose, slippery
road surfaces only. Driving in the 4LO position on dry
hard surfaced roads may cause increased tire wear and
damage to driveline components.
When operating your vehicle in 4LO, the engine speed is
approximately three times that of the 4 ALL TIME
position at a given road speed. Take care not to overspeed
the engine and do not exceed 25 mph (40 km/h).
Proper operation of four wheel drive vehicles depends on
tires of equal size, type, and circumference on each
wheel. Any difference will adversely affect shifting and
cause damage to the transfer case.
Because four wheel drive provides improved traction,
there is a tendency to exceed safe turning and stopping
speeds. Do not go faster than road conditions permit.
STARTING AND OPERATING 191
5

WARNING!
You or others could be injured if you leave the
vehicle unattended with the transfer case in the N
(Neutral) position without first fully engaging the
parking brake. The transfer case N (Neutral) position
disengages both the front and rear driveshafts from
the powertrain and will allow the vehicle to move
regardless of the transmission position. The parking
brake should always be applied when the driver is
not in the vehicle.
Shift Positions
For additional information on the appropriate use of each
transfer case mode position, see the information below:
4 ALL TIME
Normal All Wheel Drive High Range Ð All roads sur-
faces such as ice, snow, gravel, sand, and dry hard
pavement.
N (Neutral)
Neutral Ð Disengages both the front and rear driveshafts
from the powertrain. To be used for flat towing behind
another vehicle. Refer to ªRecreational Towingº in Sec-
tion 5 of this manual.
4LO
Four Wheel Drive Low Range Ð Low speed 4 wheel
drive. Locks the front and rear driveshafts together.
Forces the front and rear wheels to rotate at the same
192 STARTING AND OPERATING

speed. Additional traction and maximum pulling power
for loose, slippery road surfaces only. Do not exceed 25
mph (40 km/h).
Shifting Procedure
4 ALL TIME to 4 LO or 4 LO to 4 ALL TIME
With the vehicle rolling at 2 to 3 mph (3 to 5 km/h), shift
the transmission into N (Neutral). While the vehicle iscoasting at 2 to 3 mph (3 to 5 km/h), shift the transfer
case lever firmly into the desired position. Do not pause
in transfer case N (Neutral).
NOTE:Pausing in transfer case N (Neutral) in vehicles
equipped with an automatic transmission may require
shutting the engine OFF to avoid gear clash while
completing the shift. If difficulty occurs, shift the trans-
mission into N (Neutral), hold foot on brake, and turn the
engine OFF. Make shift to desired mode.
NOTE:Shifting into or out of 4LO is possible with the
vehicle completely stopped, however difficulty may oc-
cur due to the mating clutch teeth not being properly
aligned. Several attempts may be required for clutch
teeth alignment and shift completion to occur. The pre-
ferred method is with the vehicle rolling 2 to 3 mph (3 to
5 km/h). Avoid attempting to engage or disengage 4LO
with the vehicle moving faster than 2 to 3 mph (3 to 5
km/h).
STARTING AND OPERATING 193
5

Quadra-DriveTSystem Ð If Equipped
The optional Quadra-DrivetSystem features three
torque transfer couplings. The couplings include Vari-
Lok front and rear axles and Quadra-Trac IIttransfer
case. The optional Vari-Lok axles are fully automatic and
require no driver input to operate. Under normal driving
conditions the units function as standard axles balancing
torque evenly between left and right wheels. With a
traction difference between left and right wheels the
coupling will sense a speed difference. As one wheel
begins to spin faster than the other, torque will automati-
cally transfer from the wheel that has less traction to the
wheel that has traction. While the transfer case and axle
couplings differ in design, their operation is similar.
Follow the Quadra-Trac IIttransfer case shifting infor-
mation, preceding this section, for shifting this system.
VARI-LOK FRONT AND REAR AXLES Ð IF
EQUIPPED
The optional Vari-Lok axle is fully automatic and requires
no driver input to operate. Under normal driving condi-
tions the unit functions as a standard axle balancing
torque evenly between left and right wheels. With a
traction difference between left and right wheels the
coupling will sense a speed difference. As one wheel
begins to spin faster than the other, torque will automati-
cally transfer from the wheel that has less traction to the
wheel that has traction.
PARKING BRAKE
To set the parking brake, pull the lever up as firmly as
possible. When the parking brake is applied with the
ignition ON, the ªBrake Warning Lightº in the instru-
ment cluster will light.
194 STARTING AND OPERATING

NOTE:The instrument cluster ªBrake Warning Lightº
indicates only that the parking brake is applied. It does
not indicate the degree of brake application.Before leaving the vehicle parked on a hill, you must
make sure the parking brake is fully applied and place
the gear selector in the P (Park) position. Make certain the
transfer case is in gear. Failure to do so may cause the
vehicle to roll and cause damage or injury.
When parking on a hill, it is important to set the parking
brake before placing the gear selector in P (Park), other-
wise the load on the transmission locking mechanism
may make it difficult to move the selector out of P (Park).
The parking brake should always be applied when the
driver is not in the vehicle.
STARTING AND OPERATING 195
5

WARNING!
²Leaving children unattended in a vehicle is dan-
gerous for a number of reasons. A child or others
could be injured. Children should be warned not
to touch the parking brake or the gear selector
lever. Don't leave the keys in the ignition. A child
could operate power windows, other controls, or
move the vehicle.
²Do not leave children or animals inside parked
vehicles in hot weather. Interior heat build up
may cause serious injury or death.
To release the parking brake, pull up slightly, press the
center button, then lower the lever completely.Be sure the parking brake is fully disengaged before
driving. Failure to do so can lead to brake failure.
NOTE:Parking brake adjustment and maintenance
should be performed by your authorized dealer.
196 STARTING AND OPERATING

ANTI-LOCK BRAKE SYSTEM
The Anti-Lock Brake System (ABS) is designed to aid the
driver in maintaining vehicle control under adverse
braking conditions. The system operates with a separate
computer to modulate hydraulic pressure to prevent
wheel lock-up and help avoid skidding on slippery
surfaces.
All vehicle wheels and tires must be the same size and
type and tires must be properly inflated to produce
accurate signals for the computer.
WARNING!
Significant over or under inflation of tires, or mixing
sizes of tires or wheels on the vehicle can lead to loss
of braking effectiveness.
The Anti-Lock Brake System conducts a low-speed self-
test at about 12 mph (20 km/h). If you have your foot
lightly on the brake while this test is occurring you may
feel slight pedal movement. The movement can be more
apparent on ice and snow. This is normal.
The Anti-Lock Brake System pump motor runs during
the self-test at 12 mph (20 km/h) and during an ABS stop.
The pump motor makes a low humming noise during
operation, which is normal.
WARNING!
Pumping of the Anti-Lock Brakes will diminish
their effectiveness and may lead to an accident.
Pumping makes the stopping distance longer. Just
press firmly on your brake pedal when you need to
slow down or stop.
STARTING AND OPERATING 197
5

WARNING!
²Anti-lock system (ABS) cannot prevent the natu-
ral laws of physics from acting on the vehicle, nor
can it increase braking or steering efficiency be-
yond that afforded by the condition of the vehicle
brakes and tires or the traction afforded.
²The ABS cannot prevent accidents, including
those resulting from excessive speed in turns,
following another vehicle too closely, or hydro-
planing. Only a safe, attentive, and skillful driver
can prevent accidents.
²The capabilities of an ABS equipped vehicle must
never be exploited in a reckless or dangerous
manner which could jeopardize the user's safety
or the safety of others.
CAUTION!
The Anti-Lock Brake System is subject to possible
detrimental effects of electronic interference caused
by improperly installed after-market radios or tele-
phones.
NOTE:During severe braking conditions, a pulsing
sensation may occur and a clicking noise will be heard.
This is normal, indicating that the Anti-Lock Brake
System is functioning.
WARNING!
To use your brakes and accelerator more safely,
follow these tips:
198 STARTING AND OPERATING

²Do not ªrideº the brakes by resting your foot on the
pedal. This could overheat the brakes and result in
unpredictable braking action, longer stopping dis-
tances, or brake damage.
²When descending mountains or hills, repeated brak-
ing can cause brake fade with loss of braking control.
Avoid repeated heavy braking by downshifting the
transmission or locking out overdrive whenever pos-
sible.
²Engines may idle at higher speeds during warm-up,
which could cause rear wheels to spin and result in
loss of vehicle control. Be especially careful while
driving on slippery roads, in close-quarter maneuver-
ing, parking or stopping. Remember, always engage
4-wheel drive when driving on slippery roads (Selec-
Trac only). The Quadra-Trac II transfer case engages
four-wheel drive automatically when required.
²Do not drive too fast for road conditions, especially
when roads are wet or slushy. A wedge of water can
build up between the tire tread and the road. This
hydroplaning action can cause loss of traction, braking
ability, and control. Under such conditions, engage
4-wheel drive (Selec-Trac only).
²After going through deep water or a car wash, brakes
may become wet, resulting in decreased performance
and unpredictable braking action. Dry the brakes by
gentle, intermittent pedal action while driving at very
slow speeds.
ON-ROAD DRIVING TIPS
Utility vehicles have higher ground clearance and a
narrower track to make them capable of performing in a
wide variety of off-road applications. Specific design
characteristics give them a higher center of gravity than
ordinary cars.
STARTING AND OPERATING 199
5

An advantage of the higher ground clearance is a better
view of the road, allowing you to anticipate problems.
They are not designed for cornering at the same speeds as
conventional 2-wheel drive vehicles any more than low-
slung sports cars are designed to perform satisfactorily in
off-road conditions. If at all possible, avoid sharp turns or
abrupt maneuvers. As with other vehicles of this type,
failure to operate this vehicle correctly may result in loss
of control or vehicle rollover.
OFF-ROAD DRIVING TIPS
When To Use 4 LO (Low) Range
When off-road driving, shift to 4 LO for additional
traction in moving forward or descending a hill, for
low-speed pulling power or to improve handling and
control on slippery or difficult terrain. Also use 4 LO
range on the road in rain, ice, snow, mud or sand to get
heavy loads rolling, or whenever ªHighº range four-
wheel drive traction is insufficient.
In Snow, Mud and Sand
In heavy snow, when pulling a load, or for additional
control at slower speeds, shift the transmission to a low
gear and shift the transfer case to 4 LO if necessary. Don't
shift to a lower gear than necessary to maintain headway.
Over-revving the engine can spin the wheels and traction
will be lost.
Do not downshift on icy or slippery roads, because
engine braking may cause skidding and loss of control.
Hill Climbing
Before climbing a steep hill,shift the transmission to a
lower gear and shift the transfer case to 4 LO. Use first
gear and 4 LO for very steep hills.
If you stall or begin to lose headwaywhile climbing a
steep hill, allow your vehicle to come to a stop and
immediately apply the brakes. Restart the engine and
shift to R (Reverse). Back slowly down the hill allowing
the compression braking of the engine and transmission
200 STARTING AND OPERATING
