JEEP GRAND CHEROKEE 2004 WK / 3.G Owners Manual

FLUID CAPACITIES
U.S. Metric
Fuel (Approximate)20 Gallons 76 Liters
Engine Oil with Filter
4.0 Liter Engine (SAE 10W-30, API Certified Engine Oil) 6 Qts 5.7 Liters
4.7, 4.7HO Liter Engine (SAE 5W-30, API Certified Engine Oil) 6 Qts 5.7 Liters
Cooling System *
4.0 Liter Engine (MopartAntifreeze/Coolant 5 Year/100,000
Mile Formula)15 Qts 14.1 Liters
4.7 & 4.7HO Liter Engine (MopartAntifreeze/Coolant 5 Year/
100,000 Mile Formula)14.5 Qts 13.7 Liters
* Includes heater and coolant recovery bottle filled to MAX level.
MAINTAINING YOUR VEHICLE 291
7

RECOMMENDED FLUIDS, LUBRICANTS AND GENUINE PARTS
Engine
Component Fluid, Lubricant, or Genuine Part
Engine Coolant MopartAntifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or-
ganic Additive Technology)
Engine Oil API Certified SAE 10W-30 Engine Oil is recommended for the 4.0L engine.
API Certified SAE 5W-30 Engine Oil is recommended for the 4.7L/4.7LHO
engine. Refer to oil viscosity chart for correct SAE grade meeting
DaimlerChrysler Material Standard MS-6395.
Oil Filter (All Engines) MopartOil Filter (P/N 05281090)
Spark Plugs Refer to the Vehicle Emission Control Information label in the engine com-
partment.
Fuel Selection 87 Octane (91 Octane is recommended but not required for the 4.7LHO)
292 MAINTAINING YOUR VEHICLE

Chassis
Component Fluid, Lubricant, or Genuine Part
Automatic Transmission MopartATF+4 Automatic Transmission Fluid
Transfer Case Selec-Trac Models - MopartATF+4 Automatic Transmission Fluid. Quadra-Trac
Models - MopartTransfer Case Fluid (P/N 05016796)
Axle Differential (front-rear) MopartSynthetic Gear Lubricant or equivalent of SAE 75W-140 (API-GL5) if
equipped with a Vari-Loktfront axle. MopartGear Lubricant or equivalent of
SAE 80W-90 (API-GL5) if not equipped with a Vari-Loktfront axle. Mopart
Synthetic Gear Lubricant or equivalent of SAE 75W-140 (API-GL5) if equipped
with a Dana M35 or M44 Vari-Loktrear axle. MopartGear Lubricant or
equivalent of SAE 80W-90 (API-GL5) if equipped with a Dana M44 rear axle
without Vari-Lokt. For trailer towing applications, use a SAE 75W-140 Syn-
thetic Gear Lubricant in rear axle. Vari-Loktequipped axles require a friction
modifier additive.
Brake Master Cylinder MopartDOT 3, SAE J1703 should be used. If DOT 3, SAE J1703 brake fluid is
not available, then DOT 4 is acceptable. Use only recommended brake fluids.
Power Steering Reservoir MopartPower Steering Fluid (MS-5931)
Ball Joints, Prop Shafts, U-Joints,
Yokes, & Wheel BearingsMopartMulti-Purpose Lube NLGI Grade 2 EP, GC-LB
MAINTAINING YOUR VEHICLE 293
7

MAINTENANCE SCHEDULES
CONTENTS
mEmission Control System Maintenance........296
mMaintenance Schedules...................296NSchedule ªBº........................299
NSchedule ªAº........................310
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

EMISSION CONTROL SYSTEM MAINTENANCE
The ªScheduledº maintenance services, listed inbold
typemust be done at the times or mileages specified to
assure the continued proper functioning of the emission
control system. These, and all other maintenance services
included in this manual, should be done to provide best
vehicle performance and reliability. More frequent main-
tenance may be needed for vehicles in severe operating
conditions such as dusty areas and very short trip
driving.
Inspection and service also should be done any time a
malfunction is suspected.
NOTE:Maintenance, replacement, or repair of the emis-
sion control devices and systems on your vehicle may be
performed by any automotive repair establishment or
individual using any automotive part which has been
certified pursuant to U.S. EPA or, in the State of Califor-
nia, California Air Resources Board regulations.
MAINTENANCE SCHEDULES
There are two maintenance schedules that show the
requiredservice for your vehicle.
First is Schedule(B(. It is for vehicles that are operated
under the conditions that are listed below and at the
beginning of the schedule.
²Day or night temperatures are below 32ÉF (0ÉC)
²Stop and go driving
²Excessive engine idling
²Driving in dusty conditions
²Short trips of less than 10 miles (16.2 km)
²More than 50% of your driving is at sustained high
speeds during hot weather, above 90ÉF (32ÉC)
²Trailer towing
296 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

²Taxi, police, or delivery service (commercial service)
²Off-road or desert driving
²If equipped for and operated with E-85 (ethanol)
fuel.
NOTE:Most vehicles are operated under the conditions
listed for Schedule ªB.º
NOTE:IfANYof these apply to you, change your
engine oil every 3,000 miles (5 000 km) or 3 months,
whichever comes first, and follow the maintenance rec-
ommendations in ªMaintenance Schedule B.º
Second is ScheduleªAº. It is for vehicles that are not
operated under any of the conditions listed under Sched-
ule ªB.º
Use the schedule that best describes your driving condi-
tions. Where time and mileage are listed, follow the
interval that occurs first.
CAUTION!
Failure to perform the required maintenance items
may result in damage to the vehicle.
At Each Stop for Fuel
²Check the engine oil level about 5 minutes after a fully
warmed engine is shut off. Checking the oil level while
the vehicle is on level ground will improve the accu-
racy of the oil level reading. Add oil only when the
level is at or below the ADD or MIN mark.
²Check the windshield washer solvent, add as required.
MAINTENANCE SCHEDULES 297
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Once a Month
²Check the tire pressure and look for unusual wear or
damage.
²Inspect the battery and clean and tighten the terminals
as required.
²Check the fluid levels of the coolant reservoir, brake
master cylinder, and transmission, and add as needed.
²Check all lights and all other electrical items for correct
operation.At Each Oil Change
²Change the engine oil filter.
²Inspect the exhaust system.
²Inspect brake hoses.
²Check the coolant level, hoses, and clamps.
²Rotate the tires at each oil change interval shown on
Schedule ªAº 6,000 miles (10 000 km) or every other
interval shown on Schedule ªBº 6,000 miles (10 000
km).
²After completion of off-road operation, the underside
of the vehicle should be thoroughly inspected. Exam-
ine threaded fasteners for looseness.
298 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Schedule ªBº
Follow this schedule if you usually operate your vehicle
under one or more of the following conditions.
²Day or night temperatures are below 32ÉF (0ÉC)
²Stop and go driving
²Excessive engine idling
²Driving in dusty conditions
²Short trips of less than 10 miles (16.2 km)
²More than 50% of your driving is at sustained high
speeds during hot weather, above 90ÉF (32ÉC)
²Trailer towing
²Taxi, police, or delivery service (commercial service)
²Off-road or desert driving
²If equipped for and operated with E-85 (ethanol)
fuel.
NOTE:IfANYof these apply to you, change your
engine oil every 3,000 miles (5 000 km) or 3 months,
whichever comes first, and follow the maintenance rec-
ommendations in ªMaintenance Schedule B.º
SCHEDULE ªBº 299
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 3,000 6,000 9,000 12,000 15,000
(Kilometers) (5 000) (10 000) (14 000) (19 000) (24 000)
Change the engine oil and engine oil filter. X X X X X
Inspect the engine air cleaner filter, replace if nec-
essary.X
Lubricate the upper knuckle ball stud at steering &
suspension ball joints.XX
Drain and refill the front and rear axles. X
Inspect the brake linings. X
Clean and lubricate the brake caliper pins. X
