seat memory JEEP GRAND CHEROKEE 2023 Owners Manual

2
INTRODUCTION
SYMBOLS KEY ........................................................ 11
ROLLOVER WARNING .......................................... 11
VEHICLE MODIFICATIONS/ALTERATIONS .......... 12
SYMBOL GLOSSARY.............................................. 12
GETTING TO KNOW YOUR VEHICLE
KEYS ....................................................................... 18
Key Fob .............................................................18
SENTRY KEY .......................................................... 22
IGNITION SWITCH .................................................. 22
Keyless Enter ‘n Go™ Ignition .........................22
REMOTE START — IF EQUIPPED .......................... 24
How To Use Remote Start ................................24
To Exit Remote Start Mode .............................25
Remote Start Front Defrost Activation —
If Equipped........................................................25
Remote Start Comfort Systems —
If Equipped........................................................25
Remote Start Windshield Wiper De-Icer
Activation — If Equipped ..................................26
Remote Start Abort Message ..........................26 VEHICLE SECURITY SYSTEM — IF EQUIPPED .....26
To Arm The System ..........................................26
To Disarm The System .....................................27
Rearming Of The System .................................27
Security System Manual Override ...................27
Tamper Alert .....................................................27
DOORS .....................................................................27
Manual Door Locks ..........................................27
Power Door Locks ...........................................28
Keyless Enter ‘n Go™ — Passive Entry ...........29
Automatic Unlock Doors On Exit......................31
Automatic Door Locks — If Equipped ..............31
Child-Protection Door Lock System —
Rear Doors .......................................................31
STEERING WHEEL ..................................................32
Manual Tilt/Telescoping Steering Column —
If Equipped .......................................................32
Power Tilt/Telescoping Steering Column —
If Equipped .......................................................32
Heated Steering Wheel — If Equipped ............33 UCONNECT VOICE RECOGNITION QUICK
TIPS — IF EQUIPPED .............................................. 33
Introducing Voice Recognition ........................ 33
Basic Voice Commands ................................... 33
Get Started .......................................................34
Additional Information ..................................... 34
DRIVER AND PASSENGER MEMORY SETTINGS —
IF EQUIPPED ........................................................... 34
Programming The Memory Feature ................35
Linking And Unlinking The Key
Fob To Memory.................................................35
Memory Position Recall ................................... 36
SEATS ...................................................................... 36

Manual Adjustment (Front Seats) — If Equipped .. 36

Manual Adjustment (Rear Seats).................... 37

Power Adjustment (Front Seats) — If Equipped ... 41
Power Adjustment (Rear Seats) — If Equipped ..... 43

Power Seatback Massage — If Equipped ....... 44
Heated Seats — If Equipped ........................... 45
Ventilated Seats — If Equipped .......................46
Head Restraints ............................................... 47

23_WL_OM_EN_USC_t.book Page 2

34GETTING TO KNOW YOUR VEHICLE
GET STARTED
The VR button is used to activate/deactivate
your Voice Recognition system. You can also use
the system’s “Wake Up” word to activate voice
recognition. The “Wake Up” word can be set
through the Uconnect Settings Úpage 204.
Helpful hints for using Voice Recognition:
Reduce background noise. Wind noise and
passenger conversations are examples of noise
that may impact recognition.
Speak clearly at a normal pace and volume
while facing straight ahead.
Each time you give a Voice Command, first push
the VR button or say the “Wake Up” word,
wait until after the beep, then say your Voice
Command.
You can interrupt the help message or system
prompts by pushing the VR button and saying a
Voice Command from the current category.
You can also interrupt the help message or
system prompts by speaking. This feature is
called “barge-in” and can be set through the
Uconnect Settings Ú page 204.
Uconnect Voice Command Buttons

ADDITIONAL INFORMATION
© 2022 FCA US LLC. All rights reserved. Mopar and
Uconnect are registered trademarks and Mopar
Owner Connect is a trademark of FCA US LLC.
SiriusXM® and all related marks and logos are
trademarks of SiriusXM® Radio Inc. Ú
page 408.
For Uconnect system support, call
1-877-855-8400 (24 hours a day 7 days a week)
or visit
DriveUconnect.com (US) or DriveUconnect.ca (Canada).
DRIVER AND PASSENGER MEMORY
SETTINGS — IF EQUIPPED
This feature allows the driver, and if equipped, also
the front passenger to save up to two different
memory profiles for easy recall through a memory
switch. Each memory profile saves desired position
settings for the following features:
Driver’s Side
Seat position
Easy Entry/Exit seat (if equipped)
Side mirrors
Power tilt and telescopic steering column (if
equipped)
A set of desired radio station presets
1 — For Vehicles Equipped With Navigation: Push
The Voice Recognition Button To Begin Radio,
Media, Navigation, Climate, Start Or Answer A
Phone Call, And Send Or Receive A Text
1 — For Vehicles Not Equipped With Navigation:
Push The Phone Button To Answer An Incoming
Phone Call
2 — Push To Access Tile Mode On The Instrument
Cluster
3 — Push The Hang Up Button To End A Call
Currently In Progress

23_WL_OM_EN_USC_t.book Page 34

GETTING TO KNOW YOUR VEHICLE35
Passenger’s Side (If Equipped)
Seat Position
The memory settings switches are located on the
front door panels, next to the door handle, and
consists of three buttons:
The set (S) button, which is used to activate the
memory save function.
The (1) and (2) buttons which are used to recall
either of two saved memory profiles.

Memory Setting Buttons

NOTE:
Your vehicle is equipped with two key fobs, each
can be linked to either driver’s side memory
position 1 or 2.
Front passenger memory settings cannot be
linked to a key fob.
PROGRAMMING THE MEMORY FEATURE
To create a new memory profile, perform the
following:
NOTE:Saving a new memory profile will erase the
selected profile from memory.

1. Place the vehicle’s ignition in the ON/RUN position (do not start the engine).

2. Adjust all memory profile settings to desired preferences (i.e., seat, side mirror, power tilt/
telescopic steering column [if equipped], and
radio station presets).
3. Push and release the set (S) button on the memory switch.
4. Within five seconds, push and release either of the memory buttons (1) or (2). The instrument
cluster display will indicate which memory
position has been set.
NOTE:Memory profiles can be set without the vehicle in
PARK, but the vehicle must be below 5 mph
(8 km/h) to recall a memory profile.
LINKING AND UNLINKING THE KEY FOB
T
O MEMORY
Your key fobs can be programmed to recall one of
two saved driver’s side memory profiles.
NOTE:
Before programming your key fobs you must select
the “Personal Settings Linked To Key Fob” feature
through the Uconnect Settings Ú page 204.
To program your key fobs, perform the following:

1. Place the vehicle’s ignition in the OFF position.

2. Select a desired driver’s side memory profile, 1 or 2.
3. Once the profile has been recalled, push and release the set (S) button on the memory
switch.
4. Within five seconds, push and release button (1) or (2) accordingly. “Memory Profile Set”
(1 or 2) will display in the instrument cluster.
5. Push and release the lock button on the key fob within 10 seconds.
NOTE:Your key fobs can be unlinked from your driver’s
side memory settings by pushing the set (S) button,
and within 10 seconds, pushing the unlock button
on the key fob.
2

23_WL_OM_EN_USC_t.book Page 35

36GETTING TO KNOW YOUR VEHICLE
(Continued)
MEMORY POSITION RECALL
NOTE:Memory Recall is available when not in PARK, if the
vehicle speed is below 5 mph (8 km/h).
To recall a memory settings profile using the
memory switches, push memory button (1) or
(2) on the memory switch.
To recall the driver’s side memory settings using
the key fob, push the unlock button on the key
fob linked to memory position 1 or 2.
A recall can be canceled by pushing any of the
memory buttons during a recall (S, 1, or 2), or by
pushing any of the seat adjustment switches.
When a recall is canceled, the seat and power tilt/
telescopic steering column (if equipped) will stop
moving. A delay of one second will occur before
another recall can be selected.
SEATS
Seats are a part of the Occupant Restraint system
of the vehicle.

MANUAL ADJUSTMENT (FRONT SEATS) —
I
F EQUIPPED

Manual Front Passenger Seat Forward/
Rearward Adjustment
Some models may be equipped with a manual
front passenger seat. The passenger seat can be
adjusted forward or rearward by using a bar
located by the front of the seat cushion, near the
floor.

Adjustment Bar

While sitting in the seat, lift up on the bar located
under the seat cushion and move the seat forward
or rearward. Release the bar once you have
reached the desired position. Then, using body
pressure, move forward and rearward on the seat
to be sure that the seat adjusters have latched.
WARNING!
It is dangerous to ride in a cargo area, inside
or outside of a vehicle. In a collision, people
riding in these areas are more likely to be seri -
ously injured or killed.
Do not allow people to ride in any area of your
vehicle that is not equipped with seats and
seat belts. In a collision, people riding in these
areas are more likely to be seriously injured or
killed.
Be sure everyone in your vehicle is in a seat
and using a seat belt properly.
WARNING!
Adjusting a seat while the vehicle is moving is
dangerous. The sudden movement of the seat
could cause you to lose control. The seat belt
might not be adjusted properly and you could
be injured. Adjust the seat only while the
vehicle is parked.
Do not ride with the seatback reclined so that
the shoulder belt is no longer resting against
your chest. In a collision you could slide under
the seat belt and be seriously or even fatally
injured. Use the recliner only when the vehicle
is parked.
WARNING!

23_WL_OM_EN_USC_t.book Page 36

GETTING TO KNOW YOUR VEHICLE43
Cushion Extender
The cushion can be extended forward a few inches
(centimeters) to increase thigh support. Push the
cushion extender switch forward or rearward to
extend or retract the cushion. Release the switch
when the desired position has been reached.
Power Lumbar — If Equipped
Vehicles equipped with power driver or passenger
seats may also be equipped with power lumbar.
The power lumbar switch is located on the
outboard side of the power seat. Push the switch
forward to increase the lumbar support. Push the
switch rearward to decrease the lumbar support.
Pushing upward or downward on the switch will
raise and lower the position of the support.

Power Lumbar Switch

Easy Entry/Exit Seat — If Equipped
This feature provides automatic driver seat
positioning to enhance driver mobility when
entering and exiting the vehicle.
The distance the driver seat moves depends on
where you have the driver seat positioned when
you place the vehicle’s ignition in the OFF position.
When you place the vehicle’s ignition in the OFF
position, the driver seat will move about
2.4 inches (6 cm) rearward if the driver seat
position is greater than or equal to 2.7 inches
(6.8 cm) forward of the rear stop. The seat will
return to its previously set position when you
place the vehicle’s ignition in the ON/RUN posi -
tion.
The Easy Entry/Easy Exit feature is disabled
when the driver seat position is less than 0.9 of
an inch (2.3 cm) forward of the rear stop. At this
position, there is no benefit to the driver by
moving the seat for Easy Exit or Easy Entry.
When enabled in Uconnect Settings, Easy Entry
and Easy Exit positions are stored in each memory
setting profile Ú page 34.
NOTE:The Easy Entry/Exit feature is enabled or disabled
within the Uconnect system Ú page 204.
POWER ADJUSTMENT (REAR SEATS) —
I
F EQUIPPED
WARNING!
Adjusting a seat while driving may be
dangerous. Moving a seat while driving could
result in loss of control which could cause a
collision and serious injury or death.
Seats should be adjusted before fastening the
seat belts and while the vehicle is parked.
Serious injury or death could result from a
poorly adjusted seat belt.
Do not ride with the seatback reclined so that
the shoulder belt is no longer resting against
your chest. In a collision you could slide under
the seat belt, which could result in serious
injury or death.
Do not place the seat belt webbing behind the
third row stow clip when using the seat belt to
restrain an occupant. The seat belt will not be
positioned properly on the occupant and they
could be more seriously injured in an accident
as a result.
2

23_WL_OM_EN_USC_t.book Page 43

GETTING TO KNOW YOUR VEHICLE45
(Continued)

Door Panel Massage Button

Once activated by either method, the massage
controls will display on the radio screen, and
“Massage Type” and “Intensity Level” can be
selected for the activated seat.
There are four intensity levels and five massage
types that can be selected.
Intensity Levels:
High
Med
Low
Off
Massage Types:
Waterfall
Lower Back
Extend
Low Extend
Rock Climb
The selected settings will save in the system’s
memory when turned off, and will resume the next
time the system is turned on.
NOTE:
The engine must be running for the power seat -
back massage to operate.
The massage feature will turn off after
20 minutes of use. However, if the massage
type or intensity level is changed, the timer then
resets.
HEATED SEATS — IF EQUIPPED
Front Heated Seats
The front heated seats control buttons
are located on the center stack below the
radio screen or within the Uconnect
system. You can gain access to the
control buttons through the Comfort screen.
Press the heated seat switch once to turn the HI
setting on.
Press the heated seat switch a second time to
turn the MED setting on.
Press the heated seat switch a third time to turn
the LO setting on.
Press the heated seat switch a fourth time to
turn the heating elements off.
WARNING!
Persons who are unable to feel pain to the
skin because of advanced age, chronic illness,
diabetes, spinal cord injury, medication,
alcohol use, exhaustion or other physical
condition must exercise care when using the
seat heater. It may cause burns even at low
temperatures, especially if used for long
periods of time.
Do not place anything on the seat or seatback
that insulates against heat, such as a blanket
or cushion. This may cause the seat heater to
overheat. Sitting in a seat that has been over -
heated could cause serious burns due to the
increased surface temperature of the seat.
WARNING!
2

23_WL_OM_EN_USC_t.book Page 45

STARTING AND OPERATING145
NOTE:
Keeping your foot on the accelerator pedal can
cause the vehicle to continue to accelerate
beyond the set speed. If this occurs, the
message “DRIVER OVERRIDE” will display in the
instrument cluster display.
If you continue to accelerate beyond the set
speed while ACC is enabled, the system will not
be controlling the distance between your vehicle
and the vehicle ahead. The vehicle speed will
only be determined by the position of the accel-
erator pedal.
To Cancel
The following conditions cancel the ACC or Fixed
Speed Cruise Control systems:
The brake pedal is applied
The CANC (cancel) button is pushed
The gear selector is removed from the DRIVE
position
The Electronic Stability Control/Traction Control
System (ESC/TCS) activates
The vehicle parking brake is applied
The Trailer Sway Control (TSC) activates
The braking temperature exceeds normal range
(overheated) The following conditions will only cancel the ACC
system:
Driver seat belt is unbuckled at low speeds
Driver door is opened at low speeds
To Turn Off
The system will turn off and erase the set speed in
memory if:
The Adaptive Cruise Control (ACC) on/off button
is pushed
Fixed Speed Cruise Control on/off button is
pushed
The ignition is placed in the OFF position
4WD Low is engaged
The Active Driving Assist (ADA) system (if
equipped) is enabled/engaged and the ADA
button is pressed
NOTE:If ADA is not enabled/engaged and the ADA button
is pressed, the ACC system will remain on or turn
on, depending on the state of ACC at the time of
the ADA button press.
To Resume
If there is a set speed in memory, push the RES
(resume) button and remove your foot from the
accelerator pedal. The instrument cluster display
will show the last set speed. Resume can be used at any speed above 20 mph
(32 km/h) when only Fixed Speed Cruise Control is
being used.
Resume can be used at any speed above 0 mph
(0 km/h) when ACC is active.
NOTE:
While in ACC mode, when the vehicle comes to
a complete stop longer than two seconds, the
driver will either have to push the RES (resume)
button or press the accelerator pedal to reen
-
gage the ACC system.
ACC cannot be resumed if there is a stationary
vehicle in front of your vehicle in close proximity.
WARNING!
The Resume function should only be used if
traffic and road conditions permit. Resuming a
set speed that is too high or too low for
prevailing traffic and road conditions could
cause the vehicle to accelerate or decelerate too
sharply for safe operation. Failure to follow these
warnings can result in a collision and death or
serious personal injury.
4

23_WL_OM_EN_USC_t.book Page 145

368SERVICING AND MAINTENANCE
F15A –10 Amp RedSpare
F15B Hands-Free Liftgate / Rear Window
Switches / MOD HVAC Cntrl Frt
F16 ––Spare
F17 40 Amp Green –Mod BCM Feed #3
F18 30 Amp Pink –Power Liftgate Module
F19A –10 Amp RedL2+ Driver Alert Lighting Module
F19B ––Spare
F20A –15 Amp BlueCentral ADAS Decision Module
(CADM)
F20B Spare
F21A ––Spare
F21B
F22 ––Spare
F23 –10 Amp RedMedia Hub #2 (RR) / #3 (LR)
F24 ––Spare
F25 30 Amp Pink –Mod Door MUX Passenger
F26 20 Amp Blue –Headrest Dump 3rd Row (LT & RT)*
F27 ––Spare
F28 30 Amp Pink –MOD Memory / Power Seat
(Passenger Frt)
Cavity
Cartridge Fuse Micro FuseDescription
* If Equipped

23_WL_OM_EN_USC_t.book Page 368

SERVICING AND MAINTENANCE369
F29A –10 Amp RedMOD ICS Switch Bank Rear (Frt
Console)
F29B Spare
F30 30 Amp Pink –MOD Memory / Power Seat (Driver
Frt)
F31 ––Spare
F32 ––Spare
F33 ––Spare
F34 30 Amp Pink –MOD Door MUX Driver
F35 25 Amp Clear –Trailer Tow Module #2
F36A –10 Amp RedIntelligent Event Base Lighting
Module
F36B Port Pwr USB Console (USB CH Only) /
Port UCI Dual USB Rear
F37 25 Amp Clear –Trailer Tow Module #1
F38 ––Spare
F39 ––Spare
F40 –30 Amp GreenMod Audio Amplifier #1A
F41 ––Spare
Cavity Cartridge Fuse Micro FuseDescription
* If Equipped
8

23_WL_OM_EN_USC_t.book Page 369

415
Loading Vehicle
............................................. 184Tires.......................................................... 379Locks Child Protection........................................... 31Manual........................................................ 27Power Door.................................................. 28Lubrication, Body........................................... 343Lug Nuts/Bolts.............................................. 396Luggage Carrier............................................... 93
M
Main Menu.................................................... 103Maintenance............................................ 84, 86Maintenance Free Battery............................. 338Maintenance Schedule.................................. 330Malfunction Indicator Light
(Check Engine).................................... 112, 118ManualService...................................................... 407MassageSeats........................................................... 44McIntosh........................................................ 233Memory Feature (Memory Seats).................... 34Memory Seat................................................... 34Memory Seats And Radio................................ 34Methanol....................................................... 398Methylcyclopentadienyl Manganese
Tricarbonyl (MMT) In Gasoline....................... 399
Mirrors............................................................. 49Automatic Dimming Rearview..................... 50Digital Rearview........................................... 50Exterior Folding............................................ 51Heated......................................................... 53Outside........................................................ 51Power.......................................................... 52Power Folding.............................................. 52Rearview.............................................49, 307Tilt Side Mirrors........................................... 53Vanity.......................................................... 50Modifications/AlterationsVehicle......................................................... 12Monitor, Tire Pressure System...................... 264Mopar Parts.................................................. 406Multi-Function Control Lever............................ 58
N
Navigation..................................................... 104Neutral.......................................................... 115New Vehicle Break-In Period......................... 122Night Vision Camera..................................... 177
O
Occupant Restraints..................................... 269Octane Rating, Gasoline (Fuel)..................... 397
Off Road Pages............................................. 245Accessory Gauges..................................... 246Pitch And Roll........................................... 246Selec Terrain............................................. 246Status Bar................................................. 245Suspension............................................... 247Vehicle Dynamics..................................... 246Off-Road Driving (Off-Pavement)................... 104Oil Change Indicator...................................... 100Reset........................................................ 100Oil Filter, Change........................................... 339Oil Filter, Selection........................................ 339Oil Pressure Light.......................................... 110Oil, Engine..................................................... 338Capacity.................................................... 400Checking................................................... 337Dipstick..................................................... 337Disposal.................................................... 339Filter......................................................... 339Filter Disposal........................................... 339Identification Logo.................................... 339Materials Added To................................... 339Pressure Warning Light............................. 110Recommendation............................ 338, 400Synthetic................................................... 339Viscosity.................................................... 400
11

23_WL_OM_EN_USC_t.book Page 415
