02 sensor JEEP LIBERTY 2002 KJ / 1.G Workshop Manual

8W-80 CONNECTOR PIN-OUTS
Component Page
A/C Compressor Clutch................8Wa-80-5
A/C High Pressure Switch (Diesel)...... 8Wa-80-5
A/C Low Pressure Switch............. 8Wa-80-5
A/C Pressure Transducer (Gas)......... 8Wa-80-5
A/C-Heater Control C1............... 8Wa-80-5
A/C-Heater Control C2............... 8Wa-80-6
Accelerator Pedal Position Sensor
(Diesel)......................... 8Wa-80-6
Airbag Control Module C1 (ORC C1).... 8Wa-80-6
Airbag Control Module C2 (ORC C2).... 8Wa-80-7
Ambient Temperature Sensor.......... 8Wa-80-7
Antenna (Except Built-Up-Export)...... 8Wa-80-7
Antenna Module C1 (Built-Up-Export) . . . 8Wa-80-8
Antenna Module C2 (Built-Up-Export) . . . 8Wa-80-8
Ash Receiver Lamp.................. 8Wa-80-8
Back-Up Lamp Switch (M/T)........... 8Wa-80-8
Battery Temperature Sensor........... 8Wa-80-8
Blend Door Actuator................. 8Wa-80-9
Blower Motor...................... 8Wa-80-9
Blower Motor Resistor Block........... 8Wa-80-9
Body Control Module C1.............. 8Wa-80-9
Body Control Module C2............. 8Wa-80-10
Body Control Module C3 (Premium).... 8Wa-80-10
Boost Pressure Sensor (Diesel)........ 8Wa-80-11
Brake Lamp Switch................. 8Wa-80-11
Brake Pressure Switch (ABS)......... 8Wa-80-11
C100 (RHD)....................... 8Wa-80-11
C100 (LHD)....................... 8Wa-80-13
C100 (LHD)....................... 8Wa-80-14
C100 (RHD)....................... 8Wa-80-16
C101 (2.4L)....................... 8Wa-80-17
C101 (2.4L)....................... 8Wa-80-18
C102 (RHD)....................... 8Wa-80-18
C102 (RHD)....................... 8Wa-80-18
C103 (Gas)....................... 8Wa-80-19
C103 (Gas)....................... 8Wa-80-19
C104 (Diesel)...................... 8Wa-80-19
C104 (Diesel)...................... 8Wa-80-20
C104 (Gas)....................... 8Wa-80-20
C104 (Gas)....................... 8Wa-80-20
C105 (Diesel)...................... 8Wa-80-21
C105 (Diesel)...................... 8Wa-80-21
C105 (Gas)....................... 8Wa-80-22
C105 (Gas)....................... 8Wa-80-22
C106............................ 8Wa-80-22
C106............................ 8Wa-80-23
C107............................ 8Wa-80-23
C107............................ 8Wa-80-23
C108 (Gas)....................... 8Wa-80-24
C108 (Gas)....................... 8Wa-80-24
C110 (2.4L)....................... 8Wa-80-24
C110 (2.4L)....................... 8Wa-80-25Component Page
C111 (Diesel)...................... 8Wa-80-25
C111 (Diesel)...................... 8Wa-80-25
C112 (Gas)........................ 8Wa-80-26
C112 (Gas)........................ 8Wa-80-26
C113 (Diesel)...................... 8Wa-80-26
C113 (Diesel)...................... 8Wa-80-26
C114 (Diesel)...................... 8Wa-80-27
C114 (Diesel)...................... 8Wa-80-27
C201............................ 8Wa-80-27
C201............................ 8Wa-80-28
C202............................ 8Wa-80-29
C202............................ 8Wa-80-29
C300 (LHD)....................... 8Wa-80-29
C300 (LHD)....................... 8Wa-80-30
C300 (RHD)....................... 8Wa-80-30
C300 (RHD)....................... 8Wa-80-31
C301 (LHD)....................... 8Wa-80-31
C301 (LHD)....................... 8Wa-80-32
C301 (RHD)....................... 8Wa-80-32
C301 (RHD)....................... 8Wa-80-33
C302 (LHD)....................... 8Wa-80-33
C302 (LHD)....................... 8Wa-80-34
C302 (RHD)....................... 8Wa-80-34
C302 (RHD)....................... 8Wa-80-35
C303 (LHD)....................... 8Wa-80-35
C303 (LHD)....................... 8Wa-80-36
C303 (RHD)....................... 8Wa-80-36
C303 (RHD)....................... 8Wa-80-37
C304............................ 8Wa-80-37
C304............................ 8Wa-80-37
C305............................ 8Wa-80-38
C305............................ 8Wa-80-38
C306............................ 8Wa-80-39
C306............................ 8Wa-80-40
C307............................ 8Wa-80-40
C307............................ 8Wa-80-41
C308............................ 8Wa-80-41
C308............................ 8Wa-80-41
C309............................ 8Wa-80-42
C309............................ 8Wa-80-42
C310............................ 8Wa-80-43
C310............................ 8Wa-80-43
C311 ............................ 8Wa-80-43
C311 ............................ 8Wa-80-44
C312 (Highline).................... 8Wa-80-44
C312 (Highline).................... 8Wa-80-44
C313............................ 8Wa-80-44
C313............................ 8Wa-80-45
C314 (Highline).................... 8Wa-80-45
C314 (Highline).................... 8Wa-80-45
C315 (Midline/Highline)............. 8Wa-80-46
C315 (Midline/Highline)............. 8Wa-80-46
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-1

Component Page
C316 (Built-Up-Export).............. 8Wa-80-46
C316 (Built-Up-Export).............. 8Wa-80-46
C317 (Except Built-Up-Export)........ 8Wa-80-47
C317 (Except Built-Up-Export)........ 8Wa-80-47
Cabin Heater (Diesel)............... 8Wa-80-47
Camshaft Position Sensor (2.4L)....... 8Wa-80-47
Camshaft Position Sensor (3.7L)....... 8Wa-80-47
Camshaft Position Sensor (Diesel)...... 8Wa-80-48
Capacitor......................... 8Wa-80-48
Cargo Lamp (Except Base)........... 8Wa-80-48
CD Changer...................... 8Wa-80-48
Center High Mounted Stop Lamp...... 8Wa-80-49
Cigar Lighter..................... 8Wa-80-49
Clockspring C1.................... 8Wa-80-49
Clockspring C2.................... 8Wa-80-49
Clockspring C3.................... 8Wa-80-49
Clutch Interlock Switch (M/T)......... 8Wa-80-50
Coil On Plug No. 1 (3.7L)............ 8Wa-80-50
Coil On Plug No. 2 (3.7L)............ 8Wa-80-50
Coil On Plug No. 3 (3.7L)............ 8Wa-80-50
Coil On Plug No. 4 (3.7L)............ 8Wa-80-50
Coil On Plug No. 5 (3.7L)............ 8Wa-80-51
Coil On Plug No. 6 (3.7L)............ 8Wa-80-51
Coil Rail (2.4L).................... 8Wa-80-51
Compass Mini-Trip Computer
(Premium)...................... 8Wa-80-51
Controller Antilock Brake............ 8Wa-80-52
Crankshaft Position Sensor (2.4L)...... 8Wa-80-52
Crankshaft Position Sensor (3.7L)...... 8Wa-80-52
Crankshaft Position Sensor (Diesel).... 8Wa-80-53
Data Link Connector................ 8Wa-80-53
Diagnostic Junction Port............. 8Wa-80-53
Dome Lamp (Base)................. 8Wa-80-54
Driver Airbag Squib 1............... 8Wa-80-54
Driver Airbag Squib 2............... 8Wa-80-54
Driver Seat Belt Switch............. 8Wa-80-54
Driver Seat Belt Tensioner........... 8Wa-80-54
EGR Solenoid (Diesel)............... 8Wa-80-55
Engine Control Module C1........... 8Wa-80-55
Engine Control Module C2........... 8Wa-80-56
Engine Coolant Level Sensor (Diesel) . . . 8Wa-80-57
Engine Coolant Temp Sensor (Diesel) . . . 8Wa-80-57
Engine Coolant Temperature
Sensor (Gas).................... 8Wa-80-58
Engine Oil Pressure Sensor........... 8Wa-80-58
Evap/Purge Solenoid................ 8Wa-80-58
Flip-Up Glass Release Motor.......... 8Wa-80-58
Flip-Up Glass Release Switch......... 8Wa-80-58
Front Wiper Motor................. 8Wa-80-59
Fuel Heater (Diesel)................ 8Wa-80-59
Fuel Injector No. 1 (Diesel)........... 8Wa-80-59
Fuel Injector No. 1 (Gas)............. 8Wa-80-59
Fuel Injector No. 2 (Diesel)........... 8Wa-80-59
Fuel Injector No. 2 (Gas)............. 8Wa-80-60Component Page
Fuel Injector No. 3 (Diesel)........... 8Wa-80-60
Fuel Injector No. 3 (Gas)............. 8Wa-80-60
Fuel Injector No. 4 (Diesel)........... 8Wa-80-60
Fuel Injector No. 4 (Gas)............. 8Wa-80-60
Fuel Injector No. 5 (3.7L)............ 8Wa-80-61
Fuel Injector No. 6 (3.7L)............ 8Wa-80-61
Fuel Pressure Sensor (Diesel)......... 8Wa-80-61
Fuel Pressure Solenoid (Diesel)........ 8Wa-80-61
Fuel Pump Module................. 8Wa-80-61
G202............................ 8Wa-80-61
Generator........................ 8Wa-80-62
Glow Plug Assembly (Diesel).......... 8Wa-80-62
Hazard Switch/Combination Flasher.... 8Wa-80-62
Headlamp Leveling Switch
(Built-Up-Export)................ 8Wa-80-63
Heated Seat Module (Highline)........ 8Wa-80-63
High Note Horn.................... 8Wa-80-63
Hood Ajar Switch (Except Base)....... 8Wa-80-63
Idle Air Control Motor............... 8Wa-80-64
Ignition Switch.................... 8Wa-80-64
Input Speed Sensor (3.7L)............ 8Wa-80-64
Instrument Cluster................. 8Wa-80-64
Intake Air Temperature Sensor (Gas) . . . 8Wa-80-65
Intrusion Sensor (Built-Up-Export)..... 8Wa-80-65
Junction Block Body Control Module-JB . 8Wa-80-65
Junction Block C1.................. 8Wa-80-66
Junction Block C2.................. 8Wa-80-67
Junction Block C3.................. 8Wa-80-68
Knock Sensor (3.7L)................ 8Wa-80-69
Leak Detection Pump............... 8Wa-80-69
Left Courtesy Lamp................ 8Wa-80-69
Left Curtain Airbag................. 8Wa-80-69
Left Cylinder Lock Switch (Except Base) . 8Wa-80-69
Left Door Lock Switch (Except Base) . . . 8Wa-80-70
Left Fog Lamp..................... 8Wa-80-70
Left Front Door Ajar Switch (Base)..... 8Wa-80-70
Left Front Door Lock Motor/Ajar Switch
(Except Base)................... 8Wa-80-70
Left Front Door Speaker (Base)........ 8Wa-80-70
Left Front Door Speaker (Premium).... 8Wa-80-71
Left Front Impact Sensor............ 8Wa-80-71
Left Front Park/Turn Signal Lamp..... 8Wa-80-71
Left Front Power Window Motor
(Midline/Highline)................ 8Wa-80-71
Left Front Wheel Speed Sensor (ABS) . . . 8Wa-80-72
Left Headlamp (Built-Up-Export)...... 8Wa-80-72
Left Headlamp (Except Built-Up-Export) . 8Wa-80-72
Left Heated Seat Assembly (Highline) . . . 8Wa-80-72
Left Heated Seat Switch (Highline)..... 8Wa-80-72
Left Instrument Panel Speaker........ 8Wa-80-73
Left Leveling Motor (Built-Up-Export) . . 8Wa-80-73
Left Position Lamp (Built-Up-Export) . . . 8Wa-80-73
Left Power Mirror (Except Base)....... 8Wa-80-73
8Wa - 80 - 2 8W-80 CONNECTOR PIN-OUTSKJ

Component Page
Left Power Seat Motors
(Midline/Highline)................ 8Wa-80-74
Left Power Seat Switch
(Midline/Highline)................ 8Wa-80-74
Left Rear Door Ajar Switch (Base)..... 8Wa-80-74
Left Rear Door Lock Motor/Ajar Switch
(Except Base)................... 8Wa-80-74
Left Rear Door Speaker.............. 8Wa-80-75
Left Rear Power Window Motor
(Midline/Highline)................ 8Wa-80-75
Left Remote Radio Switch (Premium) . . . 8Wa-80-75
Left Side Impact Airbag Control
Module (LSIACM)................ 8Wa-80-75
Left Side Marker Lamp (Except
Built-Up-Export)................. 8Wa-80-76
Left Side Repeater Lamp
(Built-Up-Export)................ 8Wa-80-76
Left Speed Control Switch (Except Base) . 8Wa-80-76
Left Tail/Stop Lamp................ 8Wa-80-76
Left Visor/Vanity Lamp (Except Base) . . . 8Wa-80-76
License Lamp (Built-Up-Export)....... 8Wa-80-77
License Lamp (Except Built-Up-Export) . 8Wa-80-77
Line Pressure Sensor (3.7L).......... 8Wa-80-77
Low Note Horn.................... 8Wa-80-77
Manifold ABSolute Pressure Sensor.... 8Wa-80-77
Multi-Function Switch C1............ 8Wa-80-78
Multi-Function Switch C2............ 8Wa-80-78
Output Speed Sensor (3.7L).......... 8Wa-80-78
Overhead Map/Reading Lamp
(Except Base)................... 8Wa-80-78
Oxygen Sensor 1/1 Upstream......... 8Wa-80-79
Oxygen Sensor 1/2 Downstream....... 8Wa-80-79
Oxygen Sensor 2/1 Upstream (3.7L).... 8Wa-80-79
Oxygen Sensor 2/2 Downstream (3.7L) . . 8Wa-80-79
Passenger Airbag................... 8Wa-80-79
Passenger Seat Belt Switch........... 8Wa-80-80
Power Mirror Switch (Except Base)..... 8Wa-80-80
Power Outlet...................... 8Wa-80-80
Power Steering Pressure Switch....... 8Wa-80-80
Power Window Master Switch
(Midline/Highline)................ 8Wa-80-81
Powertrain Control Module-C1 (2.4L) . . . 8Wa-80-81
Powertrain Control Module-C1 (3.7L) . . . 8Wa-80-82
Powertrain Control Module-C2 (Gas) . . . 8Wa-80-82
Powertrain Control Module-C3 (Gas) . . . 8Wa-80-83
Radiator Fan Motor................. 8Wa-80-84
Radiator Fan Relay................. 8Wa-80-84
Radio C1......................... 8Wa-80-84
Radio C2......................... 8Wa-80-85
Radio C3......................... 8Wa-80-85
Radio Choke (Premium)............. 8Wa-80-85
Rear Power Outlet.................. 8Wa-80-85
Rear Power Window Switch
(Midline/Highline)................ 8Wa-80-86
Rear Wheel Speed Sensor............ 8Wa-80-86Component Page
Rear Wiper Motor.................. 8Wa-80-86
Red Brake Warning Indicator Switch . . . 8Wa-80-86
Remote Keyless Entry Module
(Except Base)................... 8Wa-80-86
Right Courtesy Lamp............... 8Wa-80-87
Right Curtain Airbag................ 8Wa-80-87
Right Cylinder Lock Switch
(Except Base)................... 8Wa-80-87
Right Door Lock Switch (Except Base) . . 8Wa-80-87
Right Fog Lamp................... 8Wa-80-87
Right Front Door Ajar Switch (Base).... 8Wa-80-88
Right Front Door Lock Motor/Ajar Switch
(Except Base)................... 8Wa-80-88
Right Front Door Speaker (Base)...... 8Wa-80-88
Right Front Door Speaker (Premium) . . . 8Wa-80-88
Right Front Impact Sensor........... 8Wa-80-88
Right Front Park/ Turn Signal Lamp . . . 8Wa-80-89
Right Front Power Window Motor
(Midline/Highline)................ 8Wa-80-89
Right Front Wheel Speed Sensor (ABS) . 8Wa-80-89
Right Headlamp (Built-Up-Export)..... 8Wa-80-89
Right Headlamp (Except Built-Up-Export). 8Wa-80-89
Right Heated Seat Assembly (Highline) . 8Wa-80-90
Right Heated Seat Switch (Highline) . . . 8Wa-80-90
Right Instrument Panel Speaker....... 8Wa-80-90
Right Leveling Motor (Built-Up-Export) . 8Wa-80-90
Right Position Lamp (Built-Up-Export) . . 8Wa-80-91
Right Power Mirror (Except Base)...... 8Wa-80-91
Right Power Seat Motors
(Midline/Highline)................ 8Wa-80-91
Right Power Seat Switch
(Midline/Highline)................ 8Wa-80-91
Right Rear Door Ajar Switch (Base).... 8Wa-80-92
Right Rear Door Lock Motor/Ajar Switch
(Except Base)................... 8Wa-80-92
Right Rear Door Speaker............ 8Wa-80-92
Right Rear Power Window Motor
(Midline/Highline)................ 8Wa-80-92
Right Remote Radio Switch (Premium) . . 8Wa-80-92
Right Side Impact Airbag Control Module
(RSIACM)...................... 8Wa-80-93
Right Side Marker Lamp
(Except Built-Up-Export)........... 8Wa-80-93
Right Side Repeater Lamp
(Built-Up-Export)................ 8Wa-80-93
Right Speed Control Switch
(Except Base)................... 8Wa-80-93
Right Tail/Stop Lamp............... 8Wa-80-93
Right Visor/Vanity Lamp (Except Base) . 8Wa-80-94
Sentry Key Immobilizer Module
(Except Base)................... 8Wa-80-94
Shifter Assembly................... 8Wa-80-94
Siren (Built-Up-Export).............. 8Wa-80-94
Speed Control Servo................ 8Wa-80-94
Sunroof Motor..................... 8Wa-80-95
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-3

Component Page
Sunroof Switch.................... 8Wa-80-95
Tailgate Cylinder Lock Switch......... 8Wa-80-95
Tailgate Flip-Up Ajar Switch.......... 8Wa-80-95
Tailgate Lock Motor/Ajar Switch....... 8Wa-80-95
Throttle Position Sensor............. 8Wa-80-96
Trailer Tow Brake Lamp Relay........ 8Wa-80-96
Trailer Tow Circuit Breaker.......... 8Wa-80-96
Trailer Tow Connector............... 8Wa-80-96
Trailer Tow Left Turn Relay.......... 8Wa-80-97Component Page
Trailer Tow Relay.................. 8Wa-80-97
Trailer Tow Right Turn Relay......... 8Wa-80-97
Transfer Case Position Sensor......... 8Wa-80-97
Transmission Control Module (3.7L).... 8Wa-80-98
Transmission Solenoid/TRS Assembly
(3.7L).......................... 8Wa-80-99
Washer Fluid Level Switch........... 8Wa-80-99
Washer Pump.................... 8Wa-80-100
Water In Fuel Sensor (Diesel)........ 8Wa-80-100
8Wa - 80 - 4 8W-80 CONNECTOR PIN-OUTSKJ

A/C COMPRESSOR CLUTCH - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 C3 18DB/BK A/C COMPRESSOR CLUTCH RELAY OUTPUT
2 Z246 18BK/GY GROUND
A/C HIGH PRESSURE SWITCH (DIESEL) - GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 C18 20DB A/C PRESSURE SIGNAL
2 C21 18DB/OR A/C SWITCH SENSE
A/C LOW PRESSURE SWITCH - GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 C21 18DB/OR A/C SWITCH SENSE
2 Z142 18BK/WT (RHD) GROUND
2 Z212 18BK/OR (LHD) GROUND
A/C PRESSURE TRANSDUCER (GAS) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 K4 18BK/LB SENSOR GROUND
2 K6 18VT/WT 5 VOLT SUPPLY
3 C18 18DB A/C PRESSURE SIGNAL
4- -
A/C-HEATER CONTROL C1 - BLACK 7 WAY
CAV CIRCUIT FUNCTION
1 Z8 12BK/VT GROUND
2 C7 12BK/TN BLOWER MOTOR HIGH DRIVER
3 C6 12LB BLOWER MOTOR M2 DRIVER
4 C5 14LG BLOWER MOTOR M1 DRIVER
5 C4 14TN BLOWER MOTOR LOW DRIVER
6 C19 18BR A/C ON/OFF CONTROL
7 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-5

A/C-HEATER CONTROL C2 - BLACK 12 WAY
CAV CIRCUIT FUNCTION
1 C35 20DG/YL MODE DOOR DRIVER (A)
2 V23 20BR/PK FUSED IGNITION SWITCH OUTPUT (RUN)
3- -
4- -
5- -
6 C79 20VT/BK REAR WINDOW DEFOGGER CONTROL
7- -
8 Z12 20BK/TN GROUND
9- -
10 - -
11 - -
12 C16 20LB/YL FUSED REAR WINDOW DEFOGGER RELAY OUTPUT
ACCELERATOR PEDAL POSITION SENSOR (DIESEL) - BLACK 10 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3- -
4 K4 18BK/LB SENSOR GROUND
5 K151 20WT LOW IDLE POSITION SWITCH SENSE
6- -
7 K81 20VT/TN ACCELERATOR PEDAL POSITION SENSOR SIGNAL
8 K255 20WT/DG ACCELERATOR PEDAL POSITION SENSOR GROUND
9- -
10 K852 20VT/WT ACCELERATOR PEDAL POSITION SENSOR 5 VOLT
SUPPLY
AIRBAG CONTROL MODULE C1 (ORC C1) - YELLOW 23 WAY
CAV CIRCUIT FUNCTION
1 R45 18DG/LB DRIVER SQUIB 1 LINE 2
2 R43 18BK/LB DRIVER SQUIB 1 LINE 1
3- -
4- -
5 R53 18OR/YL DRIVER SEAT BELT TENSIONER LINE 2
6 R55 18OR/BK DRIVER SEAT BELT TENSIONER LINE 1
7 R61 18OR/LB DRIVER SQUIB 2 LINE 1
8 R63 18TN/LB DRIVER SQUIB 2 LINE 2
9 R62 18OR/YL PASSENGER SQUIB 2 LINE 2
10 R64 18TN/YL PASSENGER SQUIB 2 LINE 1
11 R42 18BK/YL PASSENGER SQUIB 1 LINE 1
12 R44 18DG/YL PASSENGER SQUIB 1 LINE 2
13 - -
14 F14 18LG/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
15 F23 18DB/YL FUSED IGNITION SWITCH OUTPUT (RUN)
16 Z6 18BK/PK GROUND
8Wa - 80 - 6 8W-80 CONNECTOR PIN-OUTSKJ

AIRBAG CONTROL MODULE C1 (ORC C1) - YELLOW 23 WAY
CAV CIRCUIT FUNCTION
17 - -
18 - -
19 - -
20 - -
21 D25 18YL/VT/OR PCI BUS
22 - -
23 - -
AIRBAG CONTROL MODULE C2 (ORC C2) - BLACK 12 WAY
CAV CIRCUIT FUNCTION
1- -
2 R59 20LB DRIVER SEAT BELT SWITCH GROUND
3 R57 20DG DRIVER SEAT BELT SWITCH SENSE
4- -
5 R60 20VT PASSENGER SEAT BELT SWITCH GROUND
6 R58 20GY PASSENGER SEAT BELT SWITCH SENSE
7 R48 20TN RIGHT FRONT IMPACT SENSOR SIGNAL
8 R46 20BR/LB RIGHT FRONT IMPACT SENSOR GROUND
9- -
10 - -
11 R47 20DB/LB LEFT FRONT IMPACT SENSOR GROUND
12 R49 20LB/OR LEFT FRONT IMPACT SENSOR SIGNAL
AMBIENT TEMPERATURE SENSOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 G31 18VT/LG AMBIENT TEMPERATURE SENSOR SIGNAL
2 G32 18DB/OR AMBIENT TEMPERATURE SENSOR RETURN
ANTENNA (EXCEPT BUILT-UP-EXPORT)-2WAY
CAV CIRCUIT FUNCTION
1 X30 BK RADIO ANTENNA CORE
2 X31 BK RADIO ANTENNA SHIELD
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-7

ANTENNA MODULE C1 (BUILT-UP-EXPORT)-2WAY
CAV CIRCUIT FUNCTION
1 F85 16VT/WT FUSED IGNITION SWITCH OUTPUT (RUN--ACC)
2- -
ANTENNA MODULE C2 (BUILT-UP-EXPORT)-2WAY
CAV CIRCUIT FUNCTION
1 X30 BK RADIO ANTENNA CORE
2 X31 BK RADIO ANTENNA SHIELD
ASH RECEIVER LAMP-2WAY
CAV CIRCUIT FUNCTION
1 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
2 Z158 20BK/GY GROUND
BACK-UP LAMP SWITCH (M/T) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 F15 18DB/WT FUSED IGNITION SWITCH OUTPUT (RUN)
2 L10 18BR/LG BACK-UP LAMP FEED
BATTERY TEMPERATURE SENSOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K118 18PK/YL BATTERY TEMPERATURE SENSOR SIGNAL
2 K4 18BK/LB SENSOR GROUND
8Wa - 80 - 8 8W-80 CONNECTOR PIN-OUTSKJ

BODY CONTROL MODULE C1 - GRAY 26 WAY
CAV CIRCUIT FUNCTION
16 D19 20VT/OR BODY CONTROL MODULE FLASH ENABLE
17 P101 20OR/PK FLIP-UP GLASS RELEASE SWITCH SENSE
18 - -
19 - -
20 B22 18LG/YL VEHICLE SPEED OUTPUT
21 G69 20BK/OR VTSS INDICATOR DRIVER
22 - -
23 C79 20VT/BK REAR WINDOW DEFOGGER CONTROL
24 C19 18BR A/C ON/OFF CONTROL
25 Z3 16BK/OR GROUND
26 P100 18OR/BR FLIP-UP GLASS RELEASE MOTOR DRIVER
BODY CONTROL MODULE C2 - GRAY 22 WAY
CAV CIRCUIT FUNCTION
1 Y66 20GY (EXCEPT BASE) RKE ANTENNA
2 G910 20VT/BR TAILGATE SWITCH GROUND
3- -
4 L80 20WT/DG HEADLAMP SWITCH RETURN
5 L307 20LG/OR HEADLAMP SWITCH MUX
6 G72 18DG/OR (LHD PREMIUM) RIGHT CYLINDER LOCK SWITCH MUX
6 G73 18LG/OR (RHD) RIGHT CYLINDER LOCK SWITCH MUX
7 L27 20WT/TN (EXCEPT BASE) FRONT FOG LAMP SWITCH SENSE
8 E21 20OR/RD PANEL LAMPS DIMMER SWITCH MUX
9 G72 18DG/OR (RHD) LEFT CYLINDER LOCK SWITCH MUX
9 G73 18LG/OR (LHD PREMIUM) LEFT CYLINDER LOCK SWITCH MUX
10 V52 20DG/RD FRONT WIPER SWITCH MUX
11 X10 20RD/DB (EXCEPT BASE) RADIO CONTROL MUX RETURN
12 Y66 20GY (EXCEPT BASE) RKE ANTENNA
13 - -
14 - -
15 G32 20DB/OR (EXCEPT BASE) AMBIENT TEMPERATURE SENSOR RETURN
16 - -
17 G71 18VT/YL TAILGATE CYLINDER LOCK SWITCH MUX
18 G31 20VT/LG (EXCEPT BASE) AMBIENT TEMPERATURE SENSOR SIGNAL
19 L324 20WT/LG HIGH BEAM SWITCH SENSE
20 F512 18PK/OR VEHICLE SPEED SENSOR SUPPLY
21 B12 18DG/OR VEHICLE SPEED SIGNAL
22 X20 20RD/BK (EXCEPT BASE) RADIO CONTROL MUX
BODY CONTROL MODULE C3 (PREMIUM)-6WAY
CAV CIRCUIT FUNCTION
1 Y60 RKE DATA
2 Y62 RKE SUPPLY
3 Y61 RKE PROGRAM
4 Y63 RKE GROUND
5 Y64 RKE ANTENNA (+)
6 Y65 RKE ANTENNA (-)
8Wa - 80 - 10 8W-80 CONNECTOR PIN-OUTSKJ

BOOST PRESSURE SENSOR (DIESEL)-4WAY
CAV CIRCUIT FUNCTION
1 K4 18BK/LB SENSOR GROUND
2 K21 18BK/RD INTAKE AIR TEMPERATURE SENSOR SIGNAL
3 K6 18VT/WT SENSOR REFERENCE VOLTAGE B
4 K37 20DB/YL BOOST PRESSURE SENSOR SIGNAL
BRAKE LAMP SWITCH - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 F32 18PK/DB FUSED B(+)
2 L50 18WT/TN (GAS) BRAKE LAMP SWITCH OUTPUT
2 L50 18WT/TN (DIESEL) PRIMARY BRAKE SWITCH SIGNAL
3 V30 18DB/RD SPEED CONTROL BRAKE SWITCH OUTPUT
4 V32 18YL/RD SPEED CONTROL SUPPLY
5 Z3 18BK/OR GROUND
6 K29 18WT/PK (GAS) BRAKE SWITCH SENSE
6 K29 18WT/PK (DIESEL) SECONDARY BRAKE SWITCH SIGNAL
BRAKE PRESSURE SWITCH (ABS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 F22 18DB/PK FUSED IGNITION SWITCH OUTPUT (RUN)
2 S43 18LB/YL FLUID PRESSURE SWITCH SIGNAL
C100 (RHD) - GRAY (INSTRUMENT PANEL SIDE)
CAV CIRCUIT
1 L43 18VT
2 F1 20DB
3 M1 18PK
4 B22 18LG/YL
5 L44 18VT/RD
6 V16 18VT/YL
7 V55 16TN/RD
8 G32 20DB/OR
9 D20 20LG
10 D25 18YL/VT/BR
11 V14 18RD/VT
12 L13 18BR/YL
13 G70 20BR/TN
14 G11 20WT/BK
15 K4 20BK/LB
16 L50 18WT/TN
17 L62 18BR/RD
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-11
