Index JEEP LIBERTY 2002 KJ / 1.G Owner's Manual

INDEX
DESCRIPTION FIGURE
FRONT END ASSEMBLY
INNER FRONT PANELS ( 4 )
INNER WHEELHOUSE ASSEMBLIES ( 5 )
INNER WHEEL HOUSES & LOWER REINFORCEMENTS ( 6 )
FRONT BUMPER CROSSMEMBER ASSEMBLY ( 7 )
INNER FRONT WHEELHOUSE ASSEMBLY ( 8 )
FRONT INNER RAIL ASSEMBLY ( 9 )
FRONT INNER RAILS AND BRACKET WELD POINTS ( 10 )
FRONT INNER RAILS AND BRACKET WELD POINTS ( 11 )
FRONT OUTER RAIL & TORQUE BOX ( 12 )
FRONT OUTER RAIL ASSEMBLIES ( 13 )
FRONT OUTER RAILS AND BRACKET WELD POINTS ( 14 )
INNER FRONT WHEELHOUSE ASSEMBLY - COMPLETE ( 15 )
INNER FRONT WHEELHOUSE TO RAILS ( 16 )
COWL SIDE PANEL ASSEMBLIES ( 17 )
PLENUM ASSEMBLY ( 18 )
PLENUM BAFFLE & PLENUM CLOSURE PANEL ( 19 )
PLENUM BAFFLE & STEERING COLUMN REINFORCEMENT ( 20 )
FRONT END ASSEMBLY/UNDERBODY
FLOOR PAN ASSEMBLY ( 21 )
FLOOR PAN AND DASH PANEL ( 22 )
DASH PANEL AND PLENUM ( 23 )
WHEELHOUSE, FLOOR PAN, DASH PANEL AND PLENUM ASSEMBLY ( 24 )
COWL SIDE PANEL ( 25 )
REAR FRAME RAILS
REAR FRAME RAIL ASSEMBLY ( 26 )
REAR CONTROL ARM AND SHOCK MOUNTING BRACKETS ( 27 )
REAR SPRING MOUNTING BRACKETS AND REINFORCEMENTS ( 28 )
REAR SPRING REINFORCEMENTS, SHOCK MOUNTING, FUEL PASS AND EXHAUST
HANGER BRACKET(29)
REAR WHEELHOUSE ASSEMBLIES ( 30 )
FRONT AND REAR RAIL REINFORCEMENTS ( 31 )
REAR FLOOR PAN ASSEMBLY
REAR FLOOR PAN, COMPRESSION AND ANCHOR PLATE ASSEMBLY ( 32 )
SWING GATE AND BUMPER REINFORCEMENT ( 33 )
FLOOR PAN AND REAR RAIL ASSEMBLIES ( 34 )
FLOOR PAN AND REAR RAIL ADHESIVE LOCATIONS ( 35 )
FLOOR PAN AND REAR RAIL WELD LOCATIONS ( 36 )
REAR FLOOR PAN, CROSSMEMBERS AND FUEL TANK REINFORCEMENTS ( 38 )
23 - 10 BODY STRUCTUREKJ
WELD AND STRUCTURAL ADHESIVE LOCATIONS (Continued)

SEALER LOCATIONS
SPECIFICATIONS
INDEX
DESCRIPTION FIGURE
SEALER APPLICATION METHODS ( 78 )
REAR FLOOR PAN AND FUEL TANK ACCESS DOOR ( 79 )
FLOOR PANS; BODY SIDE SILLS; DASH PANEL; COWL AND PLENUM ASSEMBLY ( 80 )
FRONT FLOOR PAN; DASH; BODY SIDE SILL AND COWL PANELS ( 81 )
FLOOR PANS AND SIDE SILLS ( 82 )
BODY SIDE, PLENUM AND DASH PANELS ASSEMBLIES ( 83 )
A-PILLAR AND DASH PANEL ( 84 )
PLENUM AND DASH PANEL ( 85 )
BODY SIDE PANEL ASSEMBLIES ( 86 )
BODY SIDE SILL; WHEELHOUSE; B-PILLAR ( 87 )
TAIL LAMP MOUNTING AND SWING GATE STRIKER REINFORCEMENT ASSEMBLIES ( 88 )
ROOF PANEL; SWING GATE OPENING ASSEMBLIES ( 89 )
ROOF PANEL; SWING GATE OPENING ( 90 )
ROOF PANEL; SWING GATE OPENING ( 91 )
BODY SIDE PANEL; SWING GATE OPENING; FLOOR PAN ASSEMBLY ( 92 )
SWING GATE OPENING ( 93 )
WHEELHOUSES ( 94 )
BODY SIDE PANEL; FLOOR PAN; SWING GATE OPENING ASSEMBLIES ( 95 )
WHEELHOUSES ( 96 )
WHEELHOUSES ( 97 )
WHEELHOUSE ( 98 )
ROOF PANEL ASSEMBLY ( 99 )
REAR ROOF HEADER AND ROOF PANEL ( 100 )
KJBODY STRUCTURE 23 - 87

OPENING DIMENSIONS
SPECIFICATIONS
INDEX
DESCRIPTION FIGURE
ENGINE COMPARTMENT ( 101 )
WINDSHIELD OPENING ( 102 )
BODY SIDE OPENINGS ( 103 )
SWING GATE OPENING ( 104 )
KJBODY STRUCTURE 23 - 111

GAP AND FLUSH
SPECIFICATIONS
GAP & FLUSH DIMENSIONS INDEX
DESCRIPTION FIGURE
FRONT QUADRANT ( 105 )
REAR QUADRANT ( 106 )
23 - 116 BODY STRUCTUREKJ

(7) Disconnect the heater hoses from the heater
core tubes. Install plugs in, or tape over the opened
heater core tubes.
(8) Unplug the HVAC system vacuum supply line
connector from the engine side harness.
(9) Remove the nuts from the HVAC housing
mounting studs.
(10) Remove the HVAC housing from inside the
vehicle taking care not to allow any remaining cool-
ant to drain on the vehicles interior.
DISASSEMBLY
(1) Remove the HVAC housing from the vehicle
and place it on the workbench. (Refer to 24 - HEAT-
ING & AIR CONDITIONING/DISTRIBUTION/HVAC
HOUSING - REMOVAL)
(2) Unplug the vacuum harness connectors from
the mode and recirculation door actuators and the
recirculation door actuator.
(3) Disengage the vacuum harness from any rout-
ing clips located on the lower half of the HVAC hous-
ing.
(4) Remove the blower motor and blower wheel
unit from the HVAC housing. (Refer to 24 - HEAT-
ING & AIR CONDITIONING/DISTRIBUTION/
BLOWER MOTOR - REMOVAL)
(5) Pop out the grommet onl the vacuum supply
line and slide hole in housing.
(6) Carefully remove the foam seals from the
heater core and evaporator coil tube mounting flange
of the HVAC housing. If the either seal is deformed
or damaged it must be replaced.
(7) Use a screwdriver to pry off the four snap clips
that help secure the upper and lower HVAC housing
halves together.
(8) Remove the screws that secure the upper and
lower HVAC housing halves together.
(9) Carefully separate the upper HVAC housing
from the lower half.
ASSEMBLY
(1) Assemble the upper HVAC housing half to the
lower half. During assembly, be certain of the follow-
ing.
(a) That each of the mode door pivot shaft ends
and the two temperature blend door shafts are
properly engaged in there pivot holes.
(b) That the blower motor venturi ring is prop-
erly indexed and installed.
(c) If the unit is equipped with air conditioning,
that the evaporator coil tube rubber seal is prop-
erly positioned in the grooves in both the upper
and lower HVAC housing halves.
(2) Install the screws and four snap clips that
secure the upper and lower HVAC housing halves toeach other. Tighten the screws to 2.2 N´m (20 in.
lbs.).
(3) Install the blower motor and wheel unit in the
HVAC housing. (Refer to 24 - HEATING & AIR CON-
DITIONING/DISTRIBUTION/BLOWER MOTOR -
INSTALLATION)
(4) Install the foam seals on the flanges around
the heater core and evaporator coil tube mounting
flange of the HVAC housing.
(5) Insert the vacuum supply line and connector
through the foam seal on the heater core and evapo-
rator coil tube mounting flange of the HVAC housing.
Check that the vacuum grommet is securely seated
into the housing hole flange.
(6) Engage the vacuum harness to the routing
clips and plug in the vacuum harness connector at
the floor door actuator and, if the unit is so equipped,
at the recirculation air door actuator.
INSTALLATION
WARNING: IF THE VEHICLE IS EQUIPPED WITH AIR
CONDITIONING, REVIEW THE WARNINGS AND
CAUTIONS IN PLUMBING BEFORE PERFORMING
THE FOLLOWING OPERATION. (Refer to 24 - HEAT-
ING & AIR CONDITIONING/PLUMBING - WARNING)
(Refer to 24 - HEATING & AIR CONDITIONING/
PLUMBING - CAUTION) (Refer to 24 - HEATING &
AIR CONDITIONING/PLUMBING - CAUTION -
REFRIGERANT HOSES/LINES/TUBES PRECAU-
TIONS)
(1) Position the HVAC housing to the dash panel.
Be certain that the evaporator condensate drain tube
and the housing mounting studs are inserted into
their correct mounting holes.
(2) Install and tighten the nuts onto the HVAC
housing mounting studs. Tighten the nuts to 6.2 N´m
(55 in.lbs.).
(3) Connect the HVAC system vacuum supply line
connector.
(4) Unplug or remove the tape from the heater
core tubes. Connect the heater hoses to the heater
core tubes and fill the engine cooling system(Refer to
7 - COOLING/ENGINE - STANDARD PROCE-
DURE).
(5) If the vehicle is not equipped with air condi-
tioning, go to Step 10.
(6) Unplug or remove the tape from the liquid line
and the evaporator inlet tube fittings. Connect the
liquid line coupler to the evaporator inlet tube. (Refer
to 24 - HEATING & AIR CONDITIONING/PLUMB-
ING - STANDARD PROCEDURE - A/C LINE COU-
PLERS)
(7) Evacuate the refrigerant system. (Refer to 24 -
HEATING & AIR CONDITIONING/PLUMBING -
24 - 34 DISTRIBUTIONKJ
HVAC HOUSING (Continued)

ABS - DESCRIPTION, BRAKES...........5-32
ABS - OPERATION, BRAKES.............5-32
ABS - SPECIFICATIONS, BRAKES.........5-33
ABS BRAKE BLEEDING - STANDARD
PROCEDURE.........................5-33
ABS INDICATOR - DESCRIPTION.........8J-11
ABS INDICATOR - OPERATION..........8J-11
A/C APPLICATION TABLE,
SPECIFICATIONS......................24-9
A/C COMPRESSOR CLUTCH -
INSPECTION........................24-14
A/C COMPRESSOR CLUTCH -
INSTALLATION.......................24-14
A/C COMPRESSOR CLUTCH - REMOVAL . . 24-13
A/C COMPRESSOR CLUTCH BREAK-IN -
STANDARD PROCEDURE...............24-12
A/C COMPRESSOR CLUTCH COIL -
DIAGNOSIS AND TESTING.............24-12
A/C COMPRESSOR CLUTCH RELAY -
DESCRIPTION.......................24-15
A/C COMPRESSOR CLUTCH RELAY -
INSTALLATION.......................24-16
A/C COMPRESSOR CLUTCH RELAY -
OPERATION.........................24-15
A/C COMPRESSOR CLUTCH RELAY -
REMOVAL..........................24-16
A/C COMPRESSOR NOISE - DIAGNOSIS
AND TESTING.......................24-42
A/C CONDENSER - DESCRIPTION........24-45
A/C CONDENSER - INSTALLATION.......24-46
A/C CONDENSER - OPERATION...........24-45
A/C CONDENSER - REMOVAL...........24-45
A/C DISCHARGE LINE - INSTALLATION . . . 24-47
A/C DISCHARGE LINE - REMOVAL.......24-46
A/C EVAPORATOR - DESCRIPTION.......24-49
A/C EVAPORATOR - INSTALLATION......24-49
A/C EVAPORATOR - OPERATION.........24-49
A/C EVAPORATOR - REMOVAL..........24-49
A/C HEATER CONTROL - DESCRIPTION . . . 24-16
A/C HEATER CONTROL - INSTALLATION . . . 24-17
A/C HEATER CONTROL - REMOVAL......24-17
A/C HIGH PRESSURE SWITCH -
DESCRIPTION.......................24-17
A/C HIGH PRESSURE SWITCH -
DIAGNOSIS AND TESTING.............24-18
A/C HIGH PRESSURE SWITCH -
INSTALLATION.......................24-18
A/C HIGH PRESSURE SWITCH -
OPERATION.........................24-18
A/C HIGH PRESSURE SWITCH -
REMOVAL..........................24-18
A/C LIQUID LINE - INSTALLATION.......24-47
A/C LIQUID LINE - REMOVAL...........24-47
A/C LOW PRESSURE SWITCH -
DESCRIPTION.......................24-18
A/C LOW PRESSURE SWITCH -
DIAGNOSIS AND TESTING.............24-19
A/C LOW PRESSURE SWITCH -
INSTALLATION.......................24-19
A/C LOW PRESSURE SWITCH -
OPERATION.........................24-18
A/C LOW PRESSURE SWITCH -
REMOVAL..........................24-19
A/C ORIFICE TUBE - DESCRIPTION.......24-50
A/C ORIFICE TUBE - INSTALLATION......24-50
A/C ORIFICE TUBE - OPERATION........24-50
A/C ORIFICE TUBE - REMOVAL..........24-50
A/C PERFORMANCE - DIAGNOSIS AND
TESTING............................24-2
A/C SUCTION LINE - INSTALLATION......24-49
A/C SUCTION LINE - REMOVAL.........24-48
ACCELERATOR PEDAL - INSTALLATION . . . 14-30
ACCELERATOR PEDAL - REMOVAL.......14-29
ACCESS PANEL - DESCRIPTION, LATCH . . 23-139
ACCESS PANEL - INSTALLATION, LATCH . 23-139
ACCESS PANEL - REMOVAL, LATCH.....23-139
ACCUMULATOR - DESCRIPTION.........24-51
ACCUMULATOR - INSTALLATION........24-51
ACCUMULATOR - OPERATION..........24-51
ACCUMULATOR - REMOVAL
............24-51
ACTUATION TEST MODE - DESCRIPTION,
CIRCUIT
.............................25-2
ACTUATOR - INSTALLATION, BLEND
DOOR
.............................24-20
ACTUATOR - INSTALLATION, FLOOR -
DEFROST DOOR
.....................24-25
ACTUATOR - INSTALLATION, PANEL
DOOR
.............................24-25ACTUATOR - INSTALLATION,
RECIRCULATION DOOR................24-26
ACTUATOR - REMOVAL, BLEND DOOR....24-20
ACTUATOR - REMOVAL, FLOOR -
DEFROST DOOR.....................24-24
ACTUATOR - REMOVAL, PANEL DOOR....24-24
ACTUATOR - REMOVAL, RECIRCULATION
DOOR.............................24-26
ADAPTER - INSTALLATION, DISC BRAKE
CALIPER............................5-18
ADAPTER - REMOVAL, DISC BRAKE
CALIPER............................5-18
ADAPTER HOUSING SEAL -
INSTALLATION......................21-124
ADAPTER HOUSING SEAL - REMOVAL . . . 21-124
ADAPTOR - REMOVAL, DEFROST
DUCT/DEMISTER.....................24-32
ADHESIVE LOCATIONS -
SPECIFICATIONS, WELD AND
STRUCTURAL........................23-9
ADJUSTER - DIAGNOSIS AND TESTING,
HYDRAULIC LASH.................9-19,9-30
ADJUSTER - INSTALLATION, SEAT BELT
TURNING LOOP.....................8O-38
ADJUSTER - REMOVAL, SEAT BELT
TURNING LOOP.....................8O-37
ADJUSTMENT - STANDARD
PROCEDURE, CAMBER AND CASTER.......2-5
ADJUSTMENT - STANDARD
PROCEDURE, CAMBER, CASTER AND
TOE .................................2-5
ADJUSTMENT - STANDARD
PROCEDURE, COMPASS VARIATION......8M-3
ADJUSTMENT - STANDARD
PROCEDURE, TOE......................2-5
ADJUSTMENT, ADJUSTMENTS . . . 23-119,23-124,
23-131
ADJUSTMENT, ADJUSTMENTS...........3-55
ADJUSTMENT, ADJUSTMENTS -
SUNROOF GLASS PANEL.............23-178
ADJUSTMENT, FRONT FOG LAMP UNIT . . . 8L-25
ADJUSTMENT, HEADLAMP UNIT.........8L-42
ADJUSTMENT, LOCK OUT...............5-30
ADJUSTMENT, REAR DRUM BRAKE.......5-12
ADJUSTMENTS - ADJUSTMENT . . 23-119,23-124,
23-131
ADJUSTMENTS - ADJUSTMENT..........3-55
ADJUSTMENTS - SUNROOF GLASS
PANEL ADJUSTMENT................23-178
ADJUSTMENTS, FRONT AXLE - 186FIA....3-25
ADJUSTMENTS, GEARSHIFT CABLE.....21-130
ADJUSTMENTS, PARK-INTERLOCK
CABLE............................21-154
ADJUSTMENTS, REAR AXLE - 8 1/4 .......3-92
AFTER A SUPPLEMENTAL RESTRAINT
DEPLOYMENT - STANDARD
PROCEDURE, SERVICE.................8O-6
AIR CHECKING TRANSMISSION CLUTCH
OPERATION - DIAGNOSIS AND
TESTING...........................21-80
AIR CONDITIONER - DESCRIPTION,
HEATER .............................24-1
AIR CONDITIONER - OPERATION,
HEATER .............................24-2
AIR CONTROL MOTOR - DESCRIPTION,
IDLE...............................14-35
AIR CONTROL MOTOR - INSTALLATION,
IDLE...............................14-36
AIR CONTROL MOTOR - OPERATION,
IDLE...............................14-35
AIR CONTROL MOTOR - REMOVAL, IDLE . . 14-36
AIR TEMPERATURE SENSOR -
DESCRIPTION, INTAKE................14-36
AIR TEMPERATURE SENSOR -
INSTALLATION, INTAKE................14-38
AIR TEMPERATURE SENSOR -
OPERATION, INTAKE..................14-36
AIR TEMPERATURE SENSOR -
REMOVAL, INTAKE...................14-37
AIRBAG - DESCRIPTION, DRIVER........8O-17
AIRBAG - DESCRIPTION, PASSENGER....8O-27
AIRBAG - DESCRIPTION, SIDE CURTAIN . . 8O-38
AIRBAG - INSTALLATION, DRIVER.......8O-20
AIRBAG - INSTALLATION, PASSENGER
. . . 8O-29
AIRBAG - INSTALLATION, SIDE CURTAIN
. . 8O-41
AIRBAG - OPERATION, DRIVER
.........8O-18
AIRBAG - OPERATION, PASSENGER
......8O-27
AIRBAG - OPERATION, SIDE CURTAIN
....8O-39AIRBAG - REMOVAL, DRIVER...........8O-19
AIRBAG - REMOVAL, PASSENGER.......8O-28
AIRBAG - REMOVAL, SIDE CURTAIN.....8O-40
AIRBAG CONTROL MODULE -
DESCRIPTION........................8O-9
AIRBAG CONTROL MODULE -
DESCRIPTION, SIDE IMPACT...........8O-43
AIRBAG CONTROL MODULE -
INSTALLATION......................8O-12
AIRBAG CONTROL MODULE -
INSTALLATION, SIDE IMPACT...........8O-45
AIRBAG CONTROL MODULE -
OPERATION.........................8O-10
AIRBAG CONTROL MODULE -
OPERATION, SIDE IMPACT.............8O-43
AIRBAG CONTROL MODULE - REMOVAL . . 8O-11
AIRBAG CONTROL MODULE - REMOVAL,
SIDE IMPACT.......................8O-44
AIRBAG DOOR - INSTALLATION,
PASSENGER........................8O-30
AIRBAG DOOR - REMOVAL, PASSENGER . . 8O-29
AIRBAG INDICATOR - DESCRIPTION......8J-12
AIRBAG INDICATOR - OPERATION.......8J-12
AIRBAG MOUNTING BRACKET -
INSTALLATION, PASSENGER...........8O-31
AIRBAG MOUNTING BRACKET -
REMOVAL, PASSENGER...............8O-31
AJAR INDICATOR - DESCRIPTION, DOOR . . 8J-17
AJAR INDICATOR - DESCRIPTION, GATE . . 8J-20
AJAR INDICATOR - DESCRIPTION,
GLASS..............................8J-21
AJAR INDICATOR - OPERATION, DOOR . . . 8J-17
AJAR INDICATOR - OPERATION, GATE....8J-20
AJAR INDICATOR - OPERATION, GLASS . . . 8J-21
AJAR SWITCH - DESCRIPTION, DOOR....8L-77
AJAR SWITCH - DESCRIPTION, FLIP-UP
GLASS.............................8L-77
AJAR SWITCH - DESCRIPTION, HOOD....8Q-11
AJAR SWITCH - DESCRIPTION,
TAILGATE...........................8L-82
AJAR SWITCH - DIAGNOSIS AND
TESTING, HOOD.....................8Q-12
AJAR SWITCH - INSTALLATION, HOOD . . . 8Q-12
AJAR SWITCH - OPERATION, DOOR......8L-77
AJAR SWITCH - OPERATION, FLIP-UP
GLASS.............................8L-77
AJAR SWITCH - OPERATION, HOOD.....8Q-12
AJAR SWITCH - OPERATION, TAILGATE . . . 8L-82
AJAR SWITCH - REMOVAL, HOOD.......8Q-12
AJAR SWITCH BRACKET -
INSTALLATION, HOOD.................8Q-13
AJAR SWITCH BRACKET - REMOVAL,
HOOD.............................8Q-13
AJAR SWITCH STRIKER -
INSTALLATION, HOOD.................8Q-14
AJAR SWITCH STRIKER - REMOVAL,
HOOD.............................8Q-13
ALIGNMENT - DESCRIPTION, WHEEL.......2-3
ALIGNMENT - OPERATION, WHEEL........2-3
ALIGNMENT, SPECIFICATIONS............2-6
ALUMINUM THREAD REPAIR -
STANDARD PROCEDURE...............21-81
AMBIENT TEMP SENSOR - DESCRIPTION . . 8M-9
AMBIENT TEMP SENSOR - OPERATION . . . 8M-9
AMBIENT TEMPERATURE SENSOR -
DIAGNOSIS AND TESTING..............8M-9
AMBIENT TEMPERATURE SENSOR
CIRCUIT - DIAGNOSIS AND TESTING.....8M-9
AMPERAGE TEST - DIAGNOSIS AND
TESTING, FUEL PUMP.................14-16
AMPLIFIER CHOKE AND RELAY -
DESCRIPTION........................8A-3
AMPLIFIER CHOKE AND RELAY -
DIAGNOSIS AND TESTING..............8A-4
AMPLIFIER CHOKE AND RELAY -
INSTALLATION.......................8A-4
AMPLIFIER CHOKE AND RELAY -
OPERATION..........................8A-3
AMPLIFIER CHOKE AND RELAY -
REMOVAL...........................8A-4
ANCHOR - DESCRIPTION, CHILD TETHER
. 8O-13
ANCHOR - OPERATION, CHILD TETHER
. . . 8O-13
ANGLE - STANDARD PROCEDURES,
PROPELLER SHAFT
.....................3-3
ANTENNA BODY & CABLE -
DESCRIPTION
........................8A-4
ANTENNA BODY & CABLE -
INSTALLATION
.......................8A-6
KJINDEX 1
Description Group-Page Description Group-Page Description Group-Page

ANTENNA BODY & CABLE - OPERATION . . . 8A-5
ANTENNA BODY & CABLE - REMOVAL.....8A-6
ANTENNA BODY AND CABLE -
DIAGNOSIS AND TESTING..............8A-5
ANTENNA CABLE - INSTALLATION,
INSTRUMENT PANEL..................8A-8
ANTENNA CABLE - REMOVAL,
INSTRUMENT PANEL..................8A-7
ANTILOCK BRAKE - INSTALLATION,
CONTROLLER.......................8E-10
ANTILOCK BRAKE - REMOVAL,
CONTROLLER.......................8E-10
ANTILOCK BRAKING SYSTEM -
DIAGNOSIS AND TESTING..............5-33
A-PILLAR SEAL - INSTALLATION.......23-185
A-PILLAR SEAL - REMOVAL...........23-185
A-PILLAR TRIM AND GRAB HANDLE -
INSTALLATION......................23-156
A-PILLAR TRIM AND GRAB HANDLE -
REMOVAL.........................23-156
A-PILLAR WEATHERSTRIP/RETAINER -
INSTALLATION, WINDSHIELD..........23-187
A-PILLAR WEATHERSTRIP/RETAINER -
REMOVAL, WINDSHIELD..............23-186
APPLICATION TABLE, SPECIFICATIONS -
A/C ................................24-9
AREA LEAKS - DIAGNOSIS AND
TESTING, REAR SEAL..................9-61
ARM - DESCRIPTION, FRONT WIPER.....8R-12
ARM - DESCRIPTION, LOWER CONTROL . . . 2-21
ARM - DESCRIPTION, REAR WIPER......8R-37
ARM - DESCRIPTION, ROCKER......9-29,9-37
ARM - INSTALLATION, FRONT WIPER....8R-13
ARM - INSTALLATION, LOWER CONTROL . . 2-10,
2-21
ARM - INSTALLATION, REAR WIPER.....8R-38
ARM - INSTALLATION, ROCKER..........9-37
ARM - INSTALLATION, UPPER CONTROL . . . 2-21
ARM - OPERATION, FRONT WIPER......8R-12
ARM - OPERATION, LOWER CONTROL.....2-21
ARM - OPERATION, REAR WIPER.......8R-38
ARM - REMOVAL, FRONT WIPER........8R-12
ARM - REMOVAL, LOWER CONTROL . . 2-10,2-21
ARM - REMOVAL, REAR WIPER.........8R-38
ARM - REMOVAL, ROCKER..............9-37
ARM - REMOVAL, UPPER CONTROL......2-20
ARM, BUSHINGS, AND BALL JOINT -
DESCRIPTION, UPPER SUSPENSION......2-20
ARM, BUSHINGS, AND BALL JOINT -
OPERATION, UPPER SUSPENSION........2-20
ARM PARK RAMP - INSTALLATION,
WIPER.............................8R-43
ARM PARK RAMP - REMOVAL, WIPER . . . 8R-43
ASD AND FUEL PUMP RELAYS -
DIAGNOSIS AND TESTING...............8I-4
ASD SENSE - PCM INPUT - OPERATION....8I-4
ASH RECEIVER LAMP BULB -
INSTALLATION.......................8L-71
ASH RECEIVER LAMP BULB - REMOVAL . . 8L-71
ASH RECEIVER LAMP UNIT -
INSTALLATION.......................8L-72
ASH RECEIVER LAMP UNIT - REMOVAL . . 8L-72
ASSEMBLY - ASSEMBLY, INPUT CLUTCH . 21-138
ASSEMBLY - DESCRIPTION, INPUT
CLUTCH...........................21-133
ASSEMBLY - DESCRIPTION,
TRANSMISSION SOLENOID/TRS........21-169
ASSEMBLY - DISASSEMBLY, INPUT
CLUTCH...........................21-135
ASSEMBLY - INSTALLATION.........8W-97-11
ASSEMBLY - INSTALLATION, GUIDE.....23-179
ASSEMBLY - INSTALLATION,
INSTRUMENT PANEL.................23-151
ASSEMBLY - INSTALLATION, MODULE . . . 23-181
ASSEMBLY - INSTALLATION,
TRANSMISSION SOLENOID/TRS........21-170
ASSEMBLY - OPERATION, INPUT
CLUTCH...........................21-135
ASSEMBLY - OPERATION,
TRANSMISSION SOLENOID/TRS........21-169
ASSEMBLY - POWER DISTRIBUTION
CENTER ASSEMBLY
...............8W-97-10
ASSEMBLY - REMOVAL, GUIDE
........23-179
ASSEMBLY - REMOVAL, INSTRUMENT
PANEL
............................23-149
ASSEMBLY - REMOVAL, MODULE
......23-181
ASSEMBLY - REMOVAL, TRANSMISSION
SOLENOID/TRS
.....................21-170ASSEMBLY, 4C RETAINER/BULKHEAD....21-123
ASSEMBLY, ASSEMBLY - POWER
DISTRIBUTION CENTER............8W-97-10
ASSEMBLY, DIAGNOSIS AND TESTING....21-90
ASSEMBLY, DIFFERENTIAL.........3-105,3-41
ASSEMBLY, DIFFERENTIAL - TRAC-LOK . . . 3-109,
3-77
ASSEMBLY, DISC BRAKE CALIPERS.......5-16
ASSEMBLY, HVAC HOUSING............24-34
ASSEMBLY, INPUT CLUTCH ASSEMBLY . . 21-138
ASSEMBLY, INSTRUMENT CLUSTER......8J-10
ASSEMBLY, LOW/REVERSE CLUTCH.....21-146
ASSEMBLY, MANUAL - NV1500.........21-13
ASSEMBLY, MANUAL - NV3550.........21-48
ASSEMBLY, OIL PUMP.................9-67
ASSEMBLY, OIL PUMP...............21-151
ASSEMBLY, PLANETARY GEARTRAIN....21-160
ASSEMBLY, SINGLE CARDAN
UNIVERSAL JOINTS....................3-9
ASSEMBLY, TRANSFER CASE - NV231 . . . 21-194
ASSEMBLY, TRANSFER CASE - NV242 . . . 21-230
ASSEMBLY, VALVE BODY.............21-176
ASSEMBLY, WHEEL CYLINDERS..........5-29
ASSEMBLY WINDOW DEFOGGER
FUNCTION - DIAGNOSIS AND TESTING,
REAR HVAC CONTROL.................8G-9
ASSIST HANDLE - INSTALLATION.......23-157
ASSIST HANDLE - REMOVAL............23-157
AUDIO - DESCRIPTION.................8A-1
AUDIO - DIAGNOSIS AND TESTING.......8A-2
AUDIO - OPERATION...................8A-1
AUTOMATIC TRANSMISSION - 45RFE -
DESCRIPTION.......................21-76
AUTOMATIC TRANSMISSION - 45RFE -
OPERATION.........................21-77
AUTOMATIC TRANSMISSION -
DIAGNOSIS AND TESTING.............21-77
AUTOMATIC TRANSMISSION FLUID -
DESCRIPTION.........................0-2
AUTOMATIC TRANSMISSION FLUID -
OPERATION...........................0-4
AXLE - 186FIA - ADJUSTMENTS, FRONT . . . 3-25
AXLE - 186FIA - DESCRIPTION, FRONT....3-19
AXLE - 186FIA - INSTALLATION, FRONT....3-24
AXLE - 186FIA - OPERATION, FRONT......3-19
AXLE - 186FIA - REMOVAL, FRONT.......3-24
AXLE - 198RBI - DESCRIPTION, REAR.....3-49
AXLE - 198RBI - INSTALLATION, REAR....3-54
AXLE - 198RBI - OPERATION, REAR.......3-49
AXLE - 198RBI - REMOVAL, REAR........3-54
AXLE - 8 1/4 - ADJUSTMENTS, REAR.....3-92
AXLE - 8 1/4 - DESCRIPTION, REAR......3-86
AXLE - 8 1/4 - INSTALLATION, REAR......3-91
AXLE - 8 1/4 - OPERATION, REAR........3-86
AXLE - 8 1/4 - REMOVAL, REAR..........3-91
AXLE - DESCRIPTION...................0-2
AXLE - DIAGNOSIS AND TESTING....3-20,3-51,
3-88
AXLE - INSTALLATION, 198 RBI..........5-28
AXLE - INSTALLATION, 8 1/4............5-28
AXLE - REMOVAL, 198 RBI..............5-27
AXLE - REMOVAL, 8 1/4................5-27
AXLE - SPECIFICATIONS, FRONT.........3-33
AXLE - SPECIFICATIONS, REAR..........3-62
AXLE BEARINGS - INSTALLATION....3-102,3-38
AXLE BEARINGS - REMOVAL.......3-102,3-38
AXLE BEARING/SEAL - INSTALLATION.....3-67
AXLE BEARING/SEAL - REMOVAL.........3-66
AXLE SHAFT SEALS - INSTALLATION . 3-102,3-38
AXLE SHAFT SEALS - REMOVAL....3-101,3-37
AXLE SHAFTS - INSTALLATION . . 3-101,3-37,3-65
AXLE SHAFTS - REMOVAL.....3-101,3-37,3-65
AXLE, SPECIAL TOOLS - 8 1/4 ...........3-98
AXLE, SPECIAL TOOLS - FRONT..........3-34
AXLE, SPECIAL TOOLS - REAR...........3-63
AXLE, SPECIFICATIONS - REAR..........3-98
BACK - FRONT - INSTALLATION, SEAT . . . 23-166
BACK - FRONT - REMOVAL, SEAT.......23-166
BACK - REAR - INSTALLATION, SEAT....23-168
BACK - REAR - REMOVAL, SEAT.......23-168
BACK COVER - FRONT - INSTALLATION,
SEAT
.............................23-167
BACK COVER - FRONT - REMOVAL, SEAT
. 23-166
BACK COVER - REAR - INSTALLATION,
SEAT
.............................23-169
BACK COVER - REAR - REMOVAL, SEAT
. 23-169
BACK CUSHION - FRONT -
INSTALLATION, SEAT
.................23-167BACK CUSHION - FRONT - REMOVAL,
SEAT .............................23-167
BACK CUSHION - REAR - INSTALLATION,
SEAT .............................23-170
BACK CUSHION - REAR - REMOVAL,
SEAT .............................23-170
BACK FRAME - REAR - INSTALLATION,
SEAT .............................23-171
BACK FRAME - REAR - REMOVAL, SEAT . 23-171
BACK LATCH / LOCK - INSTALLATION,
FOLDING REAR SEAT................23-170
BACK LATCH / LOCK - REMOVAL,
FOLDING REAR SEAT................23-170
BACK LATCH STRIKER - INSTALLATION,
REAR SEAT........................23-171
BACK LATCH STRIKER - REMOVAL,
REAR SEAT........................23-170
BACK RECLINER - FRONT -
INSTALLATION, SEAT.................23-166
BACK RECLINER - FRONT - REMOVAL,
SEAT .............................23-166
BACKUP LAMP SWITCH - DESCRIPTION . . 8L-15
BACKUP LAMP SWITCH - DIAGNOSIS
AND TESTING.......................8L-15
BACKUP LAMP SWITCH - OPERATION....8L-15
BAFFLE SEAL - INSTALLATION,
COWL/PLENUM WINDOW.............23-187
BAFFLE SEAL - REMOVAL, COWL/
PLENUM WINDOW..................23-187
BALANCE SHAFT - INSTALLATION........9-74
BALANCE SHAFT - REMOVAL............9-74
BALANCING - STANDARD PROCEDURE,
WHEEL.............................22-4
BALL JOINT - DESCRIPTION, UPPER
SUSPENSION ARM, BUSHINGS..........2-20
BALL JOINT - DIAGNOSIS AND TESTING,
LOWER.............................2-10
BALL JOINT - INSTALLATION, UPPER.....2-20
BALL JOINT - OPERATION, UPPER
SUSPENSION ARM, BUSHINGS..........2-20
BALL JOINT - REMOVAL, UPPER.........2-20
BAR - INSTALLATION, STABILIZER....2-14,2-19
BAR - REMOVAL, STABILIZER.......2-14,2-19
BAR BUSHINGS - INSTALLATION,
STABILIZER...........................2-9
BAR BUSHINGS - REMOVAL, STABILIZER . . . 2-9
BARRELS - INSTALLATION, PANEL
OUTLET............................24-29
BARRELS - REMOVAL, PANEL OUTLET . . . 24-29
BASE - DESCRIPTION, BRAKES...........5-2
BASE - WARNING, BRAKES..............5-2
BASE BRAKE SYSTEM - DIAGNOSIS AND
TESTING.............................5-3
BASE BRAKES, SPECIAL TOOLS...........5-7
BASE COAT/CLEAR COAT FINISH -
DESCRIPTION......................23-162
BATTERIES - STANDARD PROCEDURE,
RKE TRANSMITTER...................8N-8
BATTERY - DESCRIPTION...............8F-7
BATTERY - DIAGNOSIS AND TESTING.....8F-8
BATTERY CABLES - DESCRIPTION.......8F-18
BATTERY CABLES - DIAGNOSIS AND
TESTING...........................8F-19
BATTERY CABLES - OPERATION.........8F-18
BATTERY CHARGING - STANDARD
PROCEDURE.........................8F-8
BATTERY HOLDDOWN - DESCRIPTION....8F-17
BATTERY HOLDDOWN - INSTALLATION . . . 8F-17
BATTERY HOLDDOWN - OPERATION.....8F-17
BATTERY HOLDDOWN - REMOVAL.......8F-17
BATTERY SYSTEM - CLEANING...........8F-5
BATTERY SYSTEM - DESCRIPTION........8F-1
BATTERY SYSTEM - DIAGNOSIS AND
TESTING............................8F-2
BATTERY SYSTEM - INSPECTION.........8F-6
BATTERY SYSTEM - OPERATION.........8F-2
BATTERY SYSTEM - SPECIAL TOOLS......8F-7
BATTERY SYSTEM - SPECIFICATIONS......8F-6
BATTERY TEMPERATURE SENSOR -
DESCRIPTION.......................8F-24
BATTERY TEMPERATURE SENSOR -
INSTALLATION
.......................8F-24
BATTERY TEMPERATURE SENSOR -
OPERATION
.........................8F-24
BATTERY TEMPERATURE SENSOR -
REMOVAL
..........................8F-24
BATTERY TRAY - DESCRIPTION
.........8F-21
BATTERY TRAY - INSTALLATION
.........8F-21
2 INDEXKJ
Description Group-Page Description Group-Page Description Group-Page

BATTERY TRAY - OPERATION...........8F-21
BATTERY TRAY - REMOVAL............8F-21
BEAM INDICATOR - DESCRIPTION, HIGH . . 8J-22
BEAM INDICATOR - OPERATION, HIGH....8J-22
BEAM RELAY - DESCRIPTION,
HEADLAMP HIGH....................8L-33
BEAM RELAY - DESCRIPTION,
HEADLAMP LOW.....................8L-39
BEAM RELAY - DIAGNOSIS AND
TESTING, HEADLAMP HIGH............8L-34
BEAM RELAY - DIAGNOSIS AND
TESTING, HEADLAMP LOW.............8L-40
BEAM RELAY - INSTALLATION,
HEADLAMP HIGH....................8L-35
BEAM RELAY - INSTALLATION,
HEADLAMP LOW.....................8L-41
BEAM RELAY - OPERATION, HEADLAMP
HIGH..............................8L-33
BEAM RELAY - OPERATION, HEADLAMP
LOW ..............................8L-39
BEAM RELAY - REMOVAL, HEADLAMP
HIGH..............................8L-34
BEAM RELAY - REMOVAL, HEADLAMP
LOW ..............................8L-40
BEARING - FITTING - STANDARD
PROCEDURE, CONNECTING ROD.........9-40
BEARING - INSTALLATION, CLUTCH
RELEASE.............................6-6
BEARING - INSTALLATION, HUB...........2-9
BEARING - INSTALLATION, PILOT.........6-8
BEARING - REMOVAL, CLUTCH RELEASE . . . 6-6
BEARING - REMOVAL, HUB..............2-9
BEARING - REMOVAL, PILOT.............6-8
BEARING, FITTING - CONNECTING ROD....9-49
BEARING, FITTING - MAIN..............9-45
BEARINGS - INSTALLATION, AXLE . . . 3-102,3-38
BEARINGS - INSTALLATION,
DIFFERENTIAL CASE..........3-110,3-44,3-79
BEARINGS - REMOVAL, AXLE.......3-102,3-38
BEARINGS - REMOVAL, DIFFERENTIAL
CASE......................3-110,3-43,3-79
BEARING/SEAL - INSTALLATION, AXLE....3-67
BEARING/SEAL - REMOVAL, AXLE........3-66
BELT / CHAIN COVER(S) -
INSTALLATION, TIMING.................9-76
BELT / CHAIN COVER(S) - REMOVAL,
TIMING.............................9-74
BELT - DIAGNOSIS AND TESTING,
SERPENTINE DRIVE...................7-15
BELT & RETRACTOR - INSTALLATION,
FRONT SEAT........................8O-24
BELT & RETRACTOR - INSTALLATION,
REAR CENTER SEAT..................8O-33
BELT & RETRACTOR - INSTALLATION,
REAR OUTBOARD SEAT...............8O-34
BELT & RETRACTOR - REMOVAL, FRONT
SEAT ..............................8O-23
BELT & RETRACTOR - REMOVAL, REAR
CENTER SEAT.......................8O-32
BELT & RETRACTOR - REMOVAL, REAR
OUTBOARD SEAT....................8O-33
BELT BUCKLE - INSTALLATION, FRONT
SEAT ..............................8O-26
BELT BUCKLE - INSTALLATION, REAR
SEAT ..............................8O-35
BELT BUCKLE - REMOVAL, FRONT SEAT . . 8O-25
BELT BUCKLE - REMOVAL, REAR SEAT . . . 8O-34
BELT MOLDING - INSTALLATION, FRONT
DOOR OUTER......................23-186
BELT MOLDING - INSTALLATION, REAR
DOOR OUTER......................23-186
BELT MOLDING - REMOVAL, FRONT
DOOR OUTER......................23-186
BELT MOLDING - REMOVAL, REAR
DOOR OUTER......................23-186
BELT SWITCH - DESCRIPTION, SEAT.....8O-35
BELT SWITCH - OPERATION, SEAT.......8O-36
BELT TENSIONER - DESCRIPTION, SEAT . . 8O-36
BELT TENSIONER - OPERATION, SEAT....8O-36
BELT TURNING LOOP ADJUSTER -
INSTALLATION, SEAT
.................8O-38
BELT TURNING LOOP ADJUSTER -
REMOVAL, SEAT
.....................8O-37
BELTLINE WEATHERSTRIP -
INSTALLATION, SWING GATE
..........23-186
BELTLINE WEATHERSTRIP - REMOVAL,
SWING GATE
.......................23-186
BEZEL - INSTALLATION, CLUSTER
......23-147BEZEL - INSTALLATION, INSTRUMENT
PANEL CENTER.....................23-154
BEZEL - INSTALLATION, INSTRUMENT
PANEL PASSENGER SIDE.............23-154
BEZEL - INSTALLATION, SHIFT.........23-158
BEZEL - REMOVAL, CLUSTER..........23-147
BEZEL - REMOVAL, INSTRUMENT PANEL
CENTER...........................23-154
BEZEL - REMOVAL, INSTRUMENT PANEL
PASSENGER SIDE...................23-154
BEZEL - REMOVAL, SHIFT.............23-158
BEZELS - INSTALLATION, INSTRUMENT
PANEL DRIVER SIDE.................23-154
BEZELS - REMOVAL, INSTRUMENT
PANEL DRIVER SIDE.................23-153
BLADE - DESCRIPTION, FRONT WIPER . . . 8R-13
BLADE - DESCRIPTION, REAR WIPER....8R-39
BLADE - INSTALLATION, FRONT WIPER . . . 8R-14
BLADE - INSTALLATION, REAR WIPER....8R-40
BLADE - OPERATION, FRONT WIPER.....8R-14
BLADE - OPERATION, REAR WIPER......8R-39
BLADE - REMOVAL, FRONT WIPER......8R-14
BLADE - REMOVAL, REAR WIPER.......8R-40
BLEEDING - STANDARD PROCEDURE,
ABS BRAKE..........................5-33
BLEEDING - STANDARD PROCEDURE,
MANUAL.............................5-6
BLEEDING - STANDARD PROCEDURE,
MASTER CYLINDER...................5-24
BLEEDING - STANDARD PROCEDURE,
PRESSURE...........................5-5
BLEND DOOR - INSTALLATION..........24-35
BLEND DOOR - REMOVAL.............24-35
BLEND DOOR ACTUATOR -
INSTALLATION.......................24-20
BLEND DOOR ACTUATOR - REMOVAL....24-20
BLOCK - CLEANING, ENGINE............9-39
BLOCK - DESCRIPTION, ENGINE..........9-39
BLOCK - DESCRIPTION, JUNCTION....8W-97-4
BLOCK - DESCRIPTION, JUNCTION.......5-20
BLOCK - DIAGNOSIS AND TESTING,
JUNCTION........................8W-97-4
BLOCK - INSPECTION, ENGINE...........9-40
BLOCK - INSTALLATION, JUNCTION.......5-20
BLOCK - OPERATION, JUNCTION......8W-97-4
BLOCK - OPERATION, JUNCTION.........5-20
BLOCK - REMOVAL, JUNCTION...........5-20
BLOCKER - INSTALLATION, KNEE.......23-155
BLOCKER - REMOVAL, KNEE..........23-155
BLOWER MOTOR - DESCRIPTION.......24-30
BLOWER MOTOR - DIAGNOSIS AND
TESTING...........................24-30
BLOWER MOTOR - INSTALLATION.......24-31
BLOWER MOTOR - OPERATION.........24-30
BLOWER MOTOR - REMOVAL...........24-30
BLOWER MOTOR RELAY - DESCRIPTION . . 24-20
BLOWER MOTOR RELAY - DIAGNOSIS
AND TESTING.......................24-21
BLOWER MOTOR RELAY -
INSTALLATION.......................24-22
BLOWER MOTOR RELAY - OPERATION . . . 24-20
BLOWER MOTOR RELAY - REMOVAL.....24-21
BLOWER MOTOR RESISTOR -
DESCRIPTION.......................24-22
BLOWER MOTOR RESISTOR -
DIAGNOSIS AND TESTING.............24-22
BLOWER MOTOR RESISTOR -
INSTALLATION.......................24-22
BLOWER MOTOR RESISTOR -
OPERATION.........................24-22
BLOWER MOTOR RESISTOR - REMOVAL . . 24-22
BLOWER MOTOR SWITCH -
DESCRIPTION.......................24-23
BLOWER MOTOR SWITCH - DIAGNOSIS
AND TESTING.......................24-23
BLOWER MOTOR SWITCH -
INSTALLATION.......................24-23
BLOWER MOTOR SWITCH - OPERATION . . 24-23
BLOWER MOTOR SWITCH - REMOVAL . . . 24-23
BODY - ASSEMBLY, VALVE............21-176
BODY & CABLE - DESCRIPTION,
ANTENNA...........................8A-4
BODY & CABLE - INSTALLATION,
ANTENNA
...........................8A-6
BODY & CABLE - OPERATION, ANTENNA
. . . 8A-5
BODY & CABLE - REMOVAL, ANTENNA
....8A-6
BODY - CLEANING, VALVE
............21-175
BODY - DESCRIPTION, THROTTLE
.......14-43BODY - DESCRIPTION, VALVE..........21-171
BODY - DISASSEMBLY, VALVE.........21-173
BODY - INSPECTION, VALVE...........21-175
BODY - INSTALLATION, THROTTLE.......14-44
BODY - INSTALLATION, VALVE.........21-177
BODY - OPERATION, THROTTLE.........14-43
BODY - OPERATION, VALVE...........21-171
BODY - REMOVAL, THROTTLE..........14-43
BODY - REMOVAL, VALVE.............21-172
BODY AND CABLE - DIAGNOSIS AND
TESTING, ANTENNA...................8A-5
BODY CONTROL MODULE -
DESCRIPTION........................8E-2
BODY CONTROL MODULE - DIAGNOSIS
AND TESTING........................8E-7
BODY CONTROL MODULE -
INSTALLATION........................8E-7
BODY CONTROL MODULE - OPERATION . . . 8E-5
BODY CONTROL MODULE - REMOVAL.....8E-7
BODY LUBRICATION - STANDARD
PROCEDURE.........................23-3
BODY SIDE MOLDINGS - INSTALLATION . 23-140
BODY SIDE MOLDINGS - REMOVAL.....23-140
BODY, SPECIAL TOOLS.................23-5
BOOSTER - DESCRIPTION, POWER
BRAKE..............................5-21
BOOSTER - DIAGNOSIS AND TESTING,
MASTER CYLINDER/POWER.........5-21,5-24
BOOSTER - INSTALLATION, POWER
BRAKE..............................5-23
BOOSTER - OPERATION, POWER BRAKE . . . 5-21
BOOSTER - REMOVAL, POWER BRAKE....5-22
BOOT - INSTALLATION, 4WD FLOOR
SHIFT.............................23-156
BOOT - REMOVAL, 4WD FLOOR SHIFT . . . 23-156
BORE HONING - STANDARD
PROCEDURE, CYLINDER................9-39
BOX - INSTALLATION, GLOVE..........23-148
BOX - REMOVAL, GLOVE.............23-148
BOX LATCH - INSTALLATION, GLOVE....23-148
BOX LATCH - REMOVAL, GLOVE........23-148
BOX LATCH STRIKER - INSTALLATION,
GLOVE............................23-149
BOX LATCH STRIKER - REMOVAL,
GLOVE............................23-148
B-PILLAR LOWER TRIM - INSTALLATION . 23-157
B-PILLAR LOWER TRIM - REMOVAL....23-157
B-PILLAR UPPER TRIM - INSTALLATION . 23-158
B-PILLAR UPPER TRIM - REMOVAL.....23-157
BRACKET - INSTALLATION, CLEVIS.......2-13
BRACKET - INSTALLATION, HOOD AJAR
SWITCH............................8Q-13
BRACKET - INSTALLATION, PASSENGER
AIRBAG MOUNTING..................8O-31
BRACKET - INSTALLATION, REARVIEW
MIRROR SUPPORT..................23-161
BRACKET - REMOVAL, CLEVIS...........2-13
BRACKET - REMOVAL, HOOD AJAR
SWITCH............................8Q-13
BRACKET - REMOVAL, PASSENGER
AIRBAG MOUNTING..................8O-31
BRAKE - ADJUSTMENT, REAR DRUM......5-12
BRAKE - DESCRIPTION, PARKING........5-29
BRAKE - DESCRIPTION, REAR DRUM.....5-10
BRAKE - INSTALLATION, CONTROLLER
ANTILOCK..........................8E-10
BRAKE - OPERATION, PARKING..........5-29
BRAKE - OPERATION, REAR DRUM.......5-11
BRAKE - REMOVAL, CONTROLLER
ANTILOCK..........................8E-10
BRAKE BLEEDING - STANDARD
PROCEDURE, ABS.....................5-33
BRAKE BOOSTER - DESCRIPTION,
POWER.............................5-21
BRAKE BOOSTER - INSTALLATION,
POWER.............................5-23
BRAKE BOOSTER - OPERATION, POWER . . . 5-21
BRAKE BOOSTER - REMOVAL, POWER....5-22
BRAKE CALIPER ADAPTER -
INSTALLATION, DISC...................5-18
BRAKE CALIPER ADAPTER - REMOVAL,
DISC...............................5-18
BRAKE CALIPERS - ASSEMBLY, DISC......5-16
BRAKE CALIPERS - CLEANING, DISC
......5-16
BRAKE CALIPERS - DESCRIPTION, DISC
. . . 5-13
BRAKE CALIPERS - DISASSEMBLY, DISC
. . . 5-14
BRAKE CALIPERS - INSPECTION, DISC
....5-16
BRAKE CALIPERS - INSTALLATION, DISC
. . . 5-17
KJINDEX 3
Description Group-Page Description Group-Page Description Group-Page

BRAKE CALIPERS - OPERATION, DISC.....5-14
BRAKE CALIPERS - REMOVAL, DISC......5-14
BRAKE COMPONENTS, SPECIFICATIONS....5-6
BRAKE DRUM - DIAGNOSIS AND
TESTING............................5-27
BRAKE DRUM MACHINING - STANDARD
PROCEDURES........................5-27
BRAKE FLUID CONTAMINATION -
DIAGNOSIS AND TESTING..............5-26
BRAKE FLUID, SPECIFICATIONS..........5-27
BRAKE HOSE - INSTALLATION, FRONT.....5-10
BRAKE HOSE - INSTALLATION, REAR......5-10
BRAKE HOSE - REMOVAL, REAR..........5-9
BRAKE INDICATOR - DESCRIPTION,
BRAKE/PARK........................8J-13
BRAKE INDICATOR - DIAGNOSIS AND
TESTING...........................8J-14
BRAKE INDICATOR - OPERATION,
BRAKE/PARK........................8J-13
BRAKE LAMP SWITCH - DESCRIPTION . . . 8L-16
BRAKE LAMP SWITCH - DIAGNOSIS
AND TESTING.......................8L-17
BRAKE LAMP SWITCH - INSTALLATION . . . 8L-18
BRAKE LAMP SWITCH - OPERATION.....8L-16
BRAKE LAMP SWITCH - REMOVAL......8L-17
BRAKE LINE AND HOSES - DIAGNOSIS
AND TESTING.........................5-8
BRAKE LINES - DESCRIPTION............5-8
BRAKE PADS - INSTALLATION, FRONT.....5-11
BRAKE PADS - REMOVAL, FRONT........5-11
BRAKE ROTOR - DIAGNOSIS AND
TESTING, DISC.......................5-18
BRAKE ROTOR - STANDARD
PROCEDURE, DISC....................5-19
BRAKE SHOES - INSTALLATION, DRUM....5-11
BRAKE SHOES - REMOVAL, DRUM.......5-11
BRAKE SYSTEM - DIAGNOSIS AND
TESTING, BASE........................5-3
BRAKE TRANSMISSION SHIFT
INTERLOCK SYSTEM - DESCRIPTION....21-124
BRAKE TRANSMISSION SHIFT
INTERLOCK SYSTEM - DIAGNOSIS
AND TESTING......................21-125
BRAKE TRANSMISSION SHIFT
INTERLOCK SYSTEM - OPERATION.....21-125
BRAKE/PARK BRAKE INDICATOR -
DESCRIPTION.......................8J-13
BRAKE/PARK BRAKE INDICATOR -
OPERATION.........................8J-13
BRAKES - ABS - DESCRIPTION...........5-32
BRAKES - ABS - OPERATION............5-32
BRAKES - ABS - SPECIFICATIONS........5-33
BRAKES - BASE - DESCRIPTION...........5-2
BRAKES - BASE - WARNING..............5-2
BRAKES, SPECIAL TOOLS - BASE.........5-7
BRAKING SYSTEM - DIAGNOSIS AND
TESTING, ANTILOCK...................5-33
BREAK-IN - STANDARD PROCEDURE,
A/C COMPRESSOR CLUTCH............24-12
BUCKLE - INSTALLATION, FRONT SEAT
BELT ..............................8O-26
BUCKLE - INSTALLATION, REAR SEAT
BELT ..............................8O-35
BUCKLE - REMOVAL, FRONT SEAT BELT . . 8O-25
BUCKLE - REMOVAL, REAR SEAT BELT . . . 8O-34
BUILT-IN INDICATOR TEST - STANDARD
PROCEDURE........................8F-10
BULB - INSTALLATION, ASH RECEIVER
LAMP..............................8L-71
BULB - INSTALLATION, CARGO LAMP....8L-73
BULB - INSTALLATION, CENTER HIGH
MOUNTED STOP LAMP................8L-19
BULB - INSTALLATION, COMPASS
MINI-TRIP ILLUMINATION..............8L-75
BULB - INSTALLATION, COURTESY
LAMP..............................8L-76
BULB - INSTALLATION, FRONT FOG
LAMP..............................8L-22
BULB - INSTALLATION, FRONT LAMP....8L-27
BULB - INSTALLATION, FRONT POSITION
LAMP..............................8L-28
BULB - INSTALLATION, HEADLAMP
......8L-32
BULB - INSTALLATION, HEATER-A/C
CONTROL ILLUMINATION
..............8L-78
BULB - INSTALLATION, LICENSE PLATE
LAMP
..............................8L-45
BULB - INSTALLATION, READING LAMP
. . . 8L-79
BULB - INSTALLATION, REAR LAMP
.....8L-59BULB - INSTALLATION, REPEATER LAMP . . 8L-60
BULB - INSTALLATION, TRANSMISSION
RANGE INDICATOR ILLUMINATION.......8L-83
BULB - INSTALLATION, VANITY LAMP....8L-84
BULB - REMOVAL, ASH RECEIVER LAMP . . 8L-71
BULB - REMOVAL, CARGO LAMP........8L-72
BULB - REMOVAL, CENTER HIGH
MOUNTED STOP LAMP................8L-18
BULB - REMOVAL, COMPASS MINI-TRIP
ILLUMINATION......................8L-74
BULB - REMOVAL, COURTESY LAMP.....8L-75
BULB - REMOVAL, FRONT FOG LAMP....8L-21
BULB - REMOVAL, FRONT LAMP........8L-26
BULB - REMOVAL, FRONT POSITION
LAMP..............................8L-28
BULB - REMOVAL, HEADLAMP..........8L-31
BULB - REMOVAL, HEATER-A/C
CONTROL ILLUMINATION..............8L-78
BULB - REMOVAL, LICENSE PLATE
LAMP..............................8L-44
BULB - REMOVAL, READING LAMP......8L-79
BULB - REMOVAL, REAR LAMP.........8L-58
BULB - REMOVAL, REPEATER LAMP.....8L-60
BULB - REMOVAL, TRANSMISSION
RANGE INDICATOR ILLUMINATION.......8L-82
BULB - REMOVAL, VANITY LAMP........8L-83
BUMPER - INSTALLATION, JOUNCE.......2-19
BUMPER - REMOVAL, JOUNCE...........2-19
BURNT FLUID - DIAGNOSIS AND
TESTING, CAUSES OF................21-125
BUSHING - NV3550 - INSTALLATION,
EXTENSION HOUSING.................21-74
BUSHING - NV3550 - REMOVAL,
EXTENSION HOUSING.................21-73
BUSHINGS - INSTALLATION, STABILIZER
BAR.................................2-9
BUSHINGS - REMOVAL, STABILIZER BAR . . . 2-9
BUSHINGS, AND BALL JOINT -
DESCRIPTION, UPPER SUSPENSION
ARM ...............................2-20
BUSHINGS, AND BALL JOINT -
OPERATION, UPPER SUSPENSION
ARM ...............................2-20
CABLE - ADJUSTMENTS, GEARSHIFT....21-130
CABLE - ADJUSTMENTS, PARK-
INTERLOCK........................21-154
CABLE - DESCRIPTION.................8P-3
CABLE - DESCRIPTION, ANTENNA BODY . . . 8A-4
CABLE - DIAGNOSIS AND TESTING,
ANTENNA BODY......................8A-5
CABLE - DIAGNOSIS AND TESTING,
GEARSHIFT........................21-128
CABLE - INSTALLATION, ANTENNA BODY . . 8A-6
CABLE - INSTALLATION, GEARSHIFT....21-129
CABLE - INSTALLATION, INSTRUMENT
PANEL ANTENNA......................8A-8
CABLE - INSTALLATION, LATCH RELEASE . 23-120
CABLE - INSTALLATION, PARK -
INTERLOCK........................21-153
CABLE - INSTALLATION, THROTTLE
CONTROL..........................14-46
CABLE - OPERATION...................8P-3
CABLE - OPERATION, ANTENNA BODY.....8A-5
CABLE - REMOVAL, ANTENNA BODY......8A-6
CABLE - REMOVAL, GEARSHIFT........21-128
CABLE - REMOVAL, INSTRUMENT PANEL
ANTENNA...........................8A-7
CABLE - REMOVAL, LATCH RELEASE....23-120
CABLE - REMOVAL, PARK - INTERLOCK . 21-153
CABLE - REMOVAL, THROTTLE
CONTROL..........................14-45
CABLE RESISTANCE, 2.4L - SPARK PLUG . . . 8I-3
CABLES - DESCRIPTION, BATTERY.......8F-18
CABLES - DIAGNOSIS AND TESTING,
BATTERY...........................8F-19
CABLES - INSTALLATION...............5-30
CABLES - OPERATION, BATTERY........8F-18
CABLES - REMOVAL...................5-30
CALIBRATION - STANDARD PROCEDURE,
COMPASS...........................8M-2
CALIPER ADAPTER - INSTALLATION,
DISC BRAKE.........................5-18
CALIPER ADAPTER - REMOVAL, DISC
BRAKE
..............................5-18
CALIPERS - ASSEMBLY, DISC BRAKE
......5-16
CALIPERS - CLEANING, DISC BRAKE
......5-16
CALIPERS - DESCRIPTION, DISC BRAKE
. . . 5-13
CALIPERS - DISASSEMBLY, DISC BRAKE
. . . 5-14CALIPERS - INSPECTION, DISC BRAKE....5-16
CALIPERS - INSTALLATION, DISC BRAKE . . . 5-17
CALIPERS - OPERATION, DISC BRAKE.....5-14
CALIPERS - REMOVAL, DISC BRAKE......5-14
CAMBER AND CASTER ADJUSTMENT -
STANDARD PROCEDURE.................2-5
CAMBER, CASTER AND TOE
ADJUSTMENT - STANDARD
PROCEDURE..........................2-5
CAMSHAFT(S) - DESCRIPTION.......9-23,9-33
CAMSHAFT(S) - INSTALLATION......9-25,9-33
CAMSHAFT(S) - REMOVAL..........9-24,9-33
CANISTER - DESCRIPTION, VAPOR......25-33
CANISTER - INSTALLATION, VAPOR......25-33
CANISTER - OPERATION, VAPOR........25-33
CANISTER - REMOVAL, VAPOR..........25-33
CAP - CLEANING, RADIATOR PRESSURE . . . 7-25
CAP - DESCRIPTION, FUEL FILLER.......25-27
CAP - DESCRIPTION, RADIATOR
PRESSURE..........................7-25
CAP - DIAGNOSIS AND TESTING,
RADIATOR PRESSURE.................7-25
CAP - INSPECTION, RADIATOR
PRESSURE..........................7-25
CAP - INSTALLATION, INSTRUMENT
PANEL END........................23-153
CAP - OPERATION, FUEL FILLER........25-27
CAP - OPERATION, RADIATOR
PRESSURE..........................7-25
CAP - REMOVAL, INSTRUMENT PANEL
END ..............................23-153
CAPACITIES - SPECIFICATIONS, FLUID......0-4
CAPACITOR - DESCRIPTION, IGNITION
COIL...............................8I-16
CAPACITOR - INSTALLATION, IGNITION
COIL...............................8I-16
CAPACITOR - OPERATION, IGNITION
COIL...............................8I-16
CAPACITOR - REMOVAL, IGNITION COIL . . . 8I-16
CAPACITY - SPECIFICATIONS, CHARGE . . . 24-42
CAPACITY TEST - DIAGNOSIS AND
TESTING, FUEL PUMP.................14-15
CARDAN UNIVERSAL JOINTS -
ASSEMBLY, SINGLE.....................3-9
CARDAN UNIVERSAL JOINTS -
DISASSEMBLY, SINGLE..................3-8
CARGO LAMP BULB - INSTALLATION.....8L-73
CARGO LAMP BULB - REMOVAL........8L-72
CARGO LAMP SWITCH - INSTALLATION . . 8L-74
CARGO LAMP SWITCH - REMOVAL......8L-73
CARGO LAMP UNIT - INSTALLATION.....8L-74
CARGO LAMP UNIT - REMOVAL.........8L-74
CARPETS AND FLOOR MATS -
INSTALLATION......................23-158
CARPETS AND FLOOR MATS - REMOVAL . 23-158
CASE - NV231 - ASSEMBLY, TRANSFER . . 21-194
CASE - NV231 - CLEANING, TRANSFER . . 21-190
CASE - NV231 - DESCRIPTION,
TRANSFER............................0-3
CASE - NV231 - DESCRIPTION,
TRANSFER.........................21-178
CASE - NV231 - DIAGNOSIS AND
TESTING, TRANSFER.................21-180
CASE - NV231 - DISASSEMBLY,
TRANSFER.........................21-182
CASE - NV231 - INSPECTION, TRANSFER . 21-190
CASE - NV231 - INSTALLATION,
TRANSFER.........................21-205
CASE - NV231 - OPERATION, TRANSFER
. 21-179
CASE - NV231 - REMOVAL, TRANSFER
. . 21-181
CASE - NV242 - ASSEMBLY, TRANSFER
. . 21-230
CASE - NV242 - CLEANING, TRANSFER
. . 21-227
CASE - NV242 - DESCRIPTION,
TRANSFER
............................0-3
CASE - NV242 - DESCRIPTION,
TRANSFER
.........................21-215
CASE - NV242 - DIAGNOSIS AND
TESTING, TRANSFER
.................21-216
CASE - NV242 - DISASSEMBLY,
TRANSFER
.........................21-218
CASE - NV242 - INSPECTION, TRANSFER
. 21-228
CASE - NV242 - INSTALLATION,
TRANSFER
.........................21-243
CASE - NV242 - OPERATION, TRANSFER
. 21-215
CASE - NV242 - REMOVAL, TRANSFER
. . 21-217
CASE BEARINGS - INSTALLATION,
DIFFERENTIAL
...............3-110,3-44,3-79
4 INDEXKJ
Description Group-Page Description Group-Page Description Group-Page

CASE BEARINGS - REMOVAL,
DIFFERENTIAL...............3-110,3-43,3-79
CASE, NV231 - TRANSFER............21-206
CASE, NV242 - TRANSFER............21-244
CASE SKID PLATE - INSTALLATION,
TRANSFER...........................13-7
CASE SKID PLATE - REMOVAL,
TRANSFER...........................13-7
CASE, SPECIFICATIONS - NV242
TRANSFER.........................21-244
CASTER ADJUSTMENT - STANDARD
PROCEDURE, CAMBER..................2-5
CASTER AND TOE ADJUSTMENT -
STANDARD PROCEDURE, CAMBER........2-5
CATALYTIC CONVERTER - DESCRIPTION . . . 11-2
CATALYTIC CONVERTER - INSPECTION....11-3
CATALYTIC CONVERTER - INSTALLATION . . . 11-3
CATALYTIC CONVERTER - REMOVAL......11-2
CAUSES OF BURNT FLUID - DIAGNOSIS
AND TESTING......................21-125
CAUTION - SERVICE CAUTIONS.........24-39
CAUTION, HALF SHAFT.................3-10
CAUTION, REFRIGERANT HOSES/LINES/
TUBES PRECAUTIONS.................24-40
CAUTIONS, CAUTION - SERVICE.........24-39
CD CHANGER - DESCRIPTION...........8A-7
CD CHANGER - INSTALLATION...........8A-7
CD CHANGER - OPERATION.............8A-7
CD CHANGER - REMOVAL..............8A-7
CENTER - DESCRIPTION, POWER
DISTRIBUTION....................8W-97-6
CENTER - OPERATION, POWER
DISTRIBUTION....................8W-97-7
CENTER - REMOVAL, POWER
DISTRIBUTION....................8W-97-7
CENTER ASSEMBLY, ASSEMBLY -
POWER DISTRIBUTION.............8W-97-10
CENTER BEZEL - INSTALLATION,
INSTRUMENT PANEL.................23-154
CENTER BEZEL - REMOVAL,
INSTRUMENT PANEL.................23-154
CENTER DISASSEMBLY, DISASSEMBLY -
POWER DISTRIBUTION..............8W-97-7
CENTER HIGH MOUNTED STOP LAMP
BULB - INSTALLATION................8L-19
CENTER HIGH MOUNTED STOP LAMP
BULB - REMOVAL....................8L-18
CENTER HIGH MOUNTED STOP LAMP
UNIT - INSTALLATION.................8L-19
CENTER HIGH MOUNTED STOP LAMP
UNIT - REMOVAL....................8L-19
CENTER SEAT BELT & RETRACTOR -
INSTALLATION, REAR.................8O-33
CENTER SEAT BELT & RETRACTOR -
REMOVAL, REAR....................8O-32
CENTERING - STANDARD PROCEDURE,
CLOCKSPRING......................8O-14
CERTIFICATION LABEL - DESCRIPTION,
VEHICLE SAFETY...................Intro.-9
CHAIN COVER(S) - INSTALLATION,
TIMING BELT.........................9-76
CHAIN COVER(S) - REMOVAL, TIMING
BELT ...............................9-74
CHAIN WEAR, STANDARD PROCEDURE -
MEASURING TIMING...................9-71
CHANGER - DESCRIPTION, CD...........8A-7
CHANGER - INSTALLATION, CD..........8A-7
CHANGER - OPERATION, CD.............8A-7
CHANGER - REMOVAL, CD..............8A-7
CHANNEL - INSTALLATION, GLASS RUN . 23-123,
23-130
CHANNEL - REMOVAL, GLASS RUN....23-123,
23-130
CHARGE - STANDARD PROCEDURE,
REFRIGERANT SYSTEM...............24-41
CHARGE CAPACITY - SPECIFICATIONS....24-42
CHARGING - STANDARD PROCEDURE,
BATTERY............................8F-8
CHARGING INDICATOR - DESCRIPTION . . . 8J-15
CHARGING INDICATOR - OPERATION.....8J-15
CHARGING SYSTEM - DESCRIPTION
.....8F-22
CHARGING SYSTEM - DIAGNOSIS AND
TESTING
...........................8F-22
CHARGING SYSTEM - OPERATION
.......8F-22
CHART - DIAGNOSIS AND TESTING,
COOLING SYSTEM DIAGNOSIS
............7-6
CHART, SPECIFICATIONS - TORQUE
.....19-15,
19-19,19-8CHART, SPECIFICATIONS - TORQUE....2-17,2-8
CHECK - STANDARD PROCEDURE, FLUID
LEVEL............................21-126
CHECK - STANDARD PROCEDURE, OIL
PUMP VOLUME.....................21-148
CHECK STRAP - INSTALLATION . . 23-121,23-128,
23-135
CHECK STRAP - REMOVAL.....23-121,23-128,
23-135
CHECK VALVE - DESCRIPTION, FRONT....8R-8
CHECK VALVE - DESCRIPTION, FUEL
TANK ..............................14-28
CHECK VALVE - DESCRIPTION, REAR....8R-34
CHECK VALVE - DESCRIPTION, VACUUM . . 24-28
CHECK VALVE - INSTALLATION, FRONT....8R-9
CHECK VALVE - INSTALLATION, FUEL
TANK ..............................14-28
CHECK VALVE - INSTALLATION, REAR....8R-35
CHECK VALVE - INSTALLATION, VACUUM . 24-28
CHECK VALVE - OPERATION, FRONT......8R-9
CHECK VALVE - OPERATION, FUEL TANK . . 14-28
CHECK VALVE - OPERATION, REAR......8R-34
CHECK VALVE - OPERATION, VACUUM....24-28
CHECK VALVE - REMOVAL, FRONT.......8R-9
CHECK VALVE - REMOVAL, FUEL TANK . . . 14-28
CHECK VALVE - REMOVAL, REAR.......8R-34
CHECK VALVE - REMOVAL, VACUUM.....24-28
CHECKING TRANSMISSION CLUTCH
OPERATION - DIAGNOSIS AND
TESTING, AIR.......................21-80
CHECKS - DIAGNOSIS AND TESTING,
PRELIMINARY.........................7-3
CHILD TETHER ANCHOR - DESCRIPTION . . 8O-13
CHILD TETHER ANCHOR - OPERATION . . . 8O-13
CHIME WARNING SYSTEM -
DESCRIPTION........................8B-1
CHIME WARNING SYSTEM - DIAGNOSIS
AND TESTING........................8B-6
CHIME WARNING SYSTEM - OPERATION . . . 8B-2
CHOKE AND RELAY - DESCRIPTION,
AMPLIFIER..........................8A-3
CHOKE AND RELAY - DIAGNOSIS AND
TESTING, AMPLIFIER..................8A-4
CHOKE AND RELAY - INSTALLATION,
AMPLIFIER..........................8A-4
CHOKE AND RELAY - OPERATION,
AMPLIFIER..........................8A-3
CHOKE AND RELAY - REMOVAL,
AMPLIFIER..........................8A-4
CIGAR LIGHTER OUTLET -
DESCRIPTION.....................8W-97-2
CIGAR LIGHTER OUTLET - DIAGNOSIS
AND TESTING.....................8W-97-2
CIGAR LIGHTER OUTLET - OPERATION . 8W-97-2
CLEVIS BRACKET - INSTALLATION........2-13
CLEVIS BRACKET - REMOVAL...........2-13
CLOCKSPRING - DESCRIPTION.........8O-13
CLOCKSPRING - INSTALLATION.........8O-16
CLOCKSPRING - OPERATION...........8O-14
CLOCKSPRING - REMOVAL............8O-15
CLOCKSPRING CENTERING - STANDARD
PROCEDURE........................8O-14
CLUSTER - ASSEMBLY, INSTRUMENT....8J-10
CLUSTER - DESCRIPTION, INSTRUMENT . . . 8J-2
CLUSTER - DIAGNOSIS AND TESTING,
INSTRUMENT........................8J-7
CLUSTER - DISASSEMBLY, INSTRUMENT . . . 8J-9
CLUSTER - INSTALLATION, INSTRUMENT . 8J-11
CLUSTER - OPERATION, INSTRUMENT.....8J-4
CLUSTER - REMOVAL, INSTRUMENT......8J-9
CLUSTER BEZEL - INSTALLATION.......23-147
CLUSTER BEZEL - REMOVAL..........23-147
CLUTCH - ASSEMBLY, LOW/REVERSE
. . . 21-146
CLUTCH - CLEANING, LOW/REVERSE
....21-146
CLUTCH - DESCRIPTION
.................6-1
CLUTCH - DIAGNOSIS AND TESTING
.......6-2
CLUTCH - DISASSEMBLY, LOW/REVERSE
. 21-145
CLUTCH - INSPECTION, A/C
COMPRESSOR
.......................24-14
CLUTCH - INSPECTION, LOW/REVERSE
. . 21-146
CLUTCH - INSTALLATION, A/C
COMPRESSOR
.......................24-14
CLUTCH - OPERATION
..................6-1
CLUTCH - REMOVAL, A/C COMPRESSOR
. . 24-13
CLUTCH - SPECIFICATIONS
...............6-5
CLUTCH - WARNING
....................6-2
CLUTCH ASSEMBLY - ASSEMBLY, INPUT
. 21-138CLUTCH ASSEMBLY - DESCRIPTION,
INPUT............................21-133
CLUTCH ASSEMBLY - DISASSEMBLY,
INPUT............................21-135
CLUTCH ASSEMBLY - OPERATION,
INPUT............................21-135
CLUTCH BREAK-IN - STANDARD
PROCEDURE, A/C COMPRESSOR........24-12
CLUTCH COIL - DIAGNOSIS AND
TESTING, A/C COMPRESSOR...........24-12
CLUTCH DISC - INSTALLATION............6-6
CLUTCH DISC - REMOVAL...............6-6
CLUTCH OPERATION - DIAGNOSIS AND
TESTING, AIR CHECKING
TRANSMISSION......................21-80
CLUTCH PEDAL - INSTALLATION.........6-10
CLUTCH PEDAL - REMOVAL.............6-10
CLUTCH PEDAL POSITION SWITCH -
DESCRIPTION........................6-11
CLUTCH PEDAL POSITION SWITCH -
DIAGNOSIS AND TESTING..............6-11
CLUTCH PEDAL POSITION SWITCH -
OPERATION..........................6-11
CLUTCH RELAY - DESCRIPTION, A/C
COMPRESSOR.......................24-15
CLUTCH RELAY - DIAGNOSIS AND
TESTING, COMPRESSOR...............24-15
CLUTCH RELAY - INSTALLATION, A/C
COMPRESSOR.......................24-16
CLUTCH RELAY - OPERATION, A/C
COMPRESSOR.......................24-15
CLUTCH RELAY - REMOVAL, A/C
COMPRESSOR........................24-16
CLUTCH RELEASE BEARING -
INSTALLATION.........................6-6
CLUTCH RELEASE BEARING - REMOVAL....6-6
CLUTCH SWITCH OVERRIDE RELAY -
DESCRIPTION........................6-10
CLUTCH SWITCH OVERRIDE RELAY -
INSTALLATION........................6-10
CLUTCH SWITCH OVERRIDE RELAY -
OPERATION..........................6-10
CLUTCH SWITCH OVERRIDE RELAY -
REMOVAL...........................6-10
CLUTCHES - DESCRIPTION, HOLDING . . . 21-131
CLUTCHES - OPERATION, HOLDING.....21-132
CMTC LAMP REPLACEMENT -
STANDARD PROCEDURE...............8M-2
COAT FINISH - DESCRIPTION, BASE
COAT/CLEAR.......................23-162
COAT/CLEAR COAT FINISH -
DESCRIPTION, BASE.................23-162
CODE - DESCRIPTION, PAINT..........23-162
CODES - DESCRIPTION, DIAGNOSTIC
TROUBLE............................25-2
CODES - SPECIFICATIONS, PAINT.......23-162
CODES - STANDARD PROCEDURE,
ERASING TRANSMITTER...............8M-8
CODES - STANDARD PROCEDURE,
SETTING TRANSMITTER...............8M-9
COIL - DESCRIPTION, IGNITION..........8I-9
COIL - DIAGNOSIS AND TESTING, A/C
COMPRESSOR CLUTCH...............24-12
COIL - INSTALLATION, IGNITION.........8I-10
COIL - OPERATION, IGNITION............8I-9
COIL - REMOVAL, IGNITION............8I-10
COIL CAPACITOR - DESCRIPTION,
IGNITION...........................8I-16
COIL CAPACITOR - INSTALLATION,
IGNITION...........................8I-16
COIL CAPACITOR - OPERATION,
IGNITION...........................8I-16
COIL CAPACITOR - REMOVAL, IGNITION . . . 8I-16
COIL RESISTANCE, 2.4L - IGNITION
.......8I-2
COIL RESISTANCE, 3.7L V-6 - IGNITION
....8I-3
COLLAPSIBLE SPACER - INSTALLATION
....3-70
COLLAPSIBLE SPACER - REMOVAL
.......3-70
COLUMN - DESCRIPTION
...............19-5
COLUMN - INSTALLATION
...............19-7
COLUMN - REMOVAL
..................19-5
COLUMN, SPECIAL TOOLS - STEERING
....19-8
COMBINATION FLASHER - DESCRIPTION
. . 8L-19
COMBINATION FLASHER - OPERATION
. . . 8L-19
COMBUSTION PRESSURE LEAKAGE -
DIAGNOSIS AND TESTING, CYLINDER
......9-8
COMMUNICATION - DESCRIPTION
........8E-8
COMMUNICATION - OPERATION
..........8E-8
KJINDEX 5
Description Group-Page Description Group-Page Description Group-Page
