Page 1732 of 1803
SPECIFICATIONS
TORQUE
DESCRIPTION N-m Ft. Lbs. In. Lbs.
Accelerator Pedal Bracket
Mounting Nuts12 - 105
Crankshaft Position Sensor - 2.4L 28 21 -
Crankshaft Position Sensor - 3.7L 28 21 -
Camshaft Position Sensor - 2.4L 12 - 106
Camshaft Position Sensor - 3.7L 12 - 106
Engine Coolant Temperature
Sensor11 - 9 6
EVAP Canister-to-Body Bolts 48 35 -
EVAP Canister-to-Canis. Bracket
Bolt/Nut11 - 100
Fuel Filler Hose Clamp at Tank 3 - 30
Fuel Filler Housing-to-Body
Screws2-17
Fuel Filter Mounting Nut at Tank 5.5 - 49
Fuel Pump Module Access Plate
Nuts3-26
Fuel Rail Mounting Bolts - 3.7L 11 - 100
Fuel Rail Mounting Bolts - 2.4L 28 - 250
Fuel Tank Heat Sheild Nuts 5.5 - 49
Fuel Tank Mounting Strap Bolts 61 45 -
Fuel Tank Skid Plate and Trailer
Hitch88 65 -
IAC Motor Mounting Screws 7 - 60
Leak Detection Pump Mounting
Bracket-to-Fuel Tank Nuts5.5 - 49
Leak Detection Pump-to-Bracket
Nuts1.2 - 11
Map Sensor Mounting Screws 3 - 25
PCM-to-Mounting Bracket
Mounting Screws4-35
Power Steering Pressure Switch 14-22 - 124-195
TPS Mounting Screws 7 - 60
Throttle Body Mounting Bolts 11 - 100
Oxygen Sensors 30 22 -
25 - 26 EVAPORATIVE EMISSIONSKJ
EVAPORATIVE EMISSIONS (Continued)
Page 1740 of 1803
ABS - DESCRIPTION, BRAKES...........5-32
ABS - OPERATION, BRAKES.............5-32
ABS - SPECIFICATIONS, BRAKES.........5-33
ABS BRAKE BLEEDING - STANDARD
PROCEDURE.........................5-33
ABS INDICATOR - DESCRIPTION.........8J-11
ABS INDICATOR - OPERATION..........8J-11
A/C APPLICATION TABLE,
SPECIFICATIONS......................24-9
A/C COMPRESSOR CLUTCH -
INSPECTION........................24-14
A/C COMPRESSOR CLUTCH -
INSTALLATION.......................24-14
A/C COMPRESSOR CLUTCH - REMOVAL . . 24-13
A/C COMPRESSOR CLUTCH BREAK-IN -
STANDARD PROCEDURE...............24-12
A/C COMPRESSOR CLUTCH COIL -
DIAGNOSIS AND TESTING.............24-12
A/C COMPRESSOR CLUTCH RELAY -
DESCRIPTION.......................24-15
A/C COMPRESSOR CLUTCH RELAY -
INSTALLATION.......................24-16
A/C COMPRESSOR CLUTCH RELAY -
OPERATION.........................24-15
A/C COMPRESSOR CLUTCH RELAY -
REMOVAL..........................24-16
A/C COMPRESSOR NOISE - DIAGNOSIS
AND TESTING.......................24-42
A/C CONDENSER - DESCRIPTION........24-45
A/C CONDENSER - INSTALLATION.......24-46
A/C CONDENSER - OPERATION...........24-45
A/C CONDENSER - REMOVAL...........24-45
A/C DISCHARGE LINE - INSTALLATION . . . 24-47
A/C DISCHARGE LINE - REMOVAL.......24-46
A/C EVAPORATOR - DESCRIPTION.......24-49
A/C EVAPORATOR - INSTALLATION......24-49
A/C EVAPORATOR - OPERATION.........24-49
A/C EVAPORATOR - REMOVAL..........24-49
A/C HEATER CONTROL - DESCRIPTION . . . 24-16
A/C HEATER CONTROL - INSTALLATION . . . 24-17
A/C HEATER CONTROL - REMOVAL......24-17
A/C HIGH PRESSURE SWITCH -
DESCRIPTION.......................24-17
A/C HIGH PRESSURE SWITCH -
DIAGNOSIS AND TESTING.............24-18
A/C HIGH PRESSURE SWITCH -
INSTALLATION.......................24-18
A/C HIGH PRESSURE SWITCH -
OPERATION.........................24-18
A/C HIGH PRESSURE SWITCH -
REMOVAL..........................24-18
A/C LIQUID LINE - INSTALLATION.......24-47
A/C LIQUID LINE - REMOVAL...........24-47
A/C LOW PRESSURE SWITCH -
DESCRIPTION.......................24-18
A/C LOW PRESSURE SWITCH -
DIAGNOSIS AND TESTING.............24-19
A/C LOW PRESSURE SWITCH -
INSTALLATION.......................24-19
A/C LOW PRESSURE SWITCH -
OPERATION.........................24-18
A/C LOW PRESSURE SWITCH -
REMOVAL..........................24-19
A/C ORIFICE TUBE - DESCRIPTION.......24-50
A/C ORIFICE TUBE - INSTALLATION......24-50
A/C ORIFICE TUBE - OPERATION........24-50
A/C ORIFICE TUBE - REMOVAL..........24-50
A/C PERFORMANCE - DIAGNOSIS AND
TESTING............................24-2
A/C SUCTION LINE - INSTALLATION......24-49
A/C SUCTION LINE - REMOVAL.........24-48
ACCELERATOR PEDAL - INSTALLATION . . . 14-30
ACCELERATOR PEDAL - REMOVAL.......14-29
ACCESS PANEL - DESCRIPTION, LATCH . . 23-139
ACCESS PANEL - INSTALLATION, LATCH . 23-139
ACCESS PANEL - REMOVAL, LATCH.....23-139
ACCUMULATOR - DESCRIPTION.........24-51
ACCUMULATOR - INSTALLATION........24-51
ACCUMULATOR - OPERATION..........24-51
ACCUMULATOR - REMOVAL
............24-51
ACTUATION TEST MODE - DESCRIPTION,
CIRCUIT
.............................25-2
ACTUATOR - INSTALLATION, BLEND
DOOR
.............................24-20
ACTUATOR - INSTALLATION, FLOOR -
DEFROST DOOR
.....................24-25
ACTUATOR - INSTALLATION, PANEL
DOOR
.............................24-25ACTUATOR - INSTALLATION,
RECIRCULATION DOOR................24-26
ACTUATOR - REMOVAL, BLEND DOOR....24-20
ACTUATOR - REMOVAL, FLOOR -
DEFROST DOOR.....................24-24
ACTUATOR - REMOVAL, PANEL DOOR....24-24
ACTUATOR - REMOVAL, RECIRCULATION
DOOR.............................24-26
ADAPTER - INSTALLATION, DISC BRAKE
CALIPER............................5-18
ADAPTER - REMOVAL, DISC BRAKE
CALIPER............................5-18
ADAPTER HOUSING SEAL -
INSTALLATION......................21-124
ADAPTER HOUSING SEAL - REMOVAL . . . 21-124
ADAPTOR - REMOVAL, DEFROST
DUCT/DEMISTER.....................24-32
ADHESIVE LOCATIONS -
SPECIFICATIONS, WELD AND
STRUCTURAL........................23-9
ADJUSTER - DIAGNOSIS AND TESTING,
HYDRAULIC LASH.................9-19,9-30
ADJUSTER - INSTALLATION, SEAT BELT
TURNING LOOP.....................8O-38
ADJUSTER - REMOVAL, SEAT BELT
TURNING LOOP.....................8O-37
ADJUSTMENT - STANDARD
PROCEDURE, CAMBER AND CASTER.......2-5
ADJUSTMENT - STANDARD
PROCEDURE, CAMBER, CASTER AND
TOE .................................2-5
ADJUSTMENT - STANDARD
PROCEDURE, COMPASS VARIATION......8M-3
ADJUSTMENT - STANDARD
PROCEDURE, TOE......................2-5
ADJUSTMENT, ADJUSTMENTS . . . 23-119,23-124,
23-131
ADJUSTMENT, ADJUSTMENTS...........3-55
ADJUSTMENT, ADJUSTMENTS -
SUNROOF GLASS PANEL.............23-178
ADJUSTMENT, FRONT FOG LAMP UNIT . . . 8L-25
ADJUSTMENT, HEADLAMP UNIT.........8L-42
ADJUSTMENT, LOCK OUT...............5-30
ADJUSTMENT, REAR DRUM BRAKE.......5-12
ADJUSTMENTS - ADJUSTMENT . . 23-119,23-124,
23-131
ADJUSTMENTS - ADJUSTMENT..........3-55
ADJUSTMENTS - SUNROOF GLASS
PANEL ADJUSTMENT................23-178
ADJUSTMENTS, FRONT AXLE - 186FIA....3-25
ADJUSTMENTS, GEARSHIFT CABLE.....21-130
ADJUSTMENTS, PARK-INTERLOCK
CABLE............................21-154
ADJUSTMENTS, REAR AXLE - 8 1/4 .......3-92
AFTER A SUPPLEMENTAL RESTRAINT
DEPLOYMENT - STANDARD
PROCEDURE, SERVICE.................8O-6
AIR CHECKING TRANSMISSION CLUTCH
OPERATION - DIAGNOSIS AND
TESTING...........................21-80
AIR CONDITIONER - DESCRIPTION,
HEATER .............................24-1
AIR CONDITIONER - OPERATION,
HEATER .............................24-2
AIR CONTROL MOTOR - DESCRIPTION,
IDLE...............................14-35
AIR CONTROL MOTOR - INSTALLATION,
IDLE...............................14-36
AIR CONTROL MOTOR - OPERATION,
IDLE...............................14-35
AIR CONTROL MOTOR - REMOVAL, IDLE . . 14-36
AIR TEMPERATURE SENSOR -
DESCRIPTION, INTAKE................14-36
AIR TEMPERATURE SENSOR -
INSTALLATION, INTAKE................14-38
AIR TEMPERATURE SENSOR -
OPERATION, INTAKE..................14-36
AIR TEMPERATURE SENSOR -
REMOVAL, INTAKE...................14-37
AIRBAG - DESCRIPTION, DRIVER........8O-17
AIRBAG - DESCRIPTION, PASSENGER....8O-27
AIRBAG - DESCRIPTION, SIDE CURTAIN . . 8O-38
AIRBAG - INSTALLATION, DRIVER.......8O-20
AIRBAG - INSTALLATION, PASSENGER
. . . 8O-29
AIRBAG - INSTALLATION, SIDE CURTAIN
. . 8O-41
AIRBAG - OPERATION, DRIVER
.........8O-18
AIRBAG - OPERATION, PASSENGER
......8O-27
AIRBAG - OPERATION, SIDE CURTAIN
....8O-39AIRBAG - REMOVAL, DRIVER...........8O-19
AIRBAG - REMOVAL, PASSENGER.......8O-28
AIRBAG - REMOVAL, SIDE CURTAIN.....8O-40
AIRBAG CONTROL MODULE -
DESCRIPTION........................8O-9
AIRBAG CONTROL MODULE -
DESCRIPTION, SIDE IMPACT...........8O-43
AIRBAG CONTROL MODULE -
INSTALLATION......................8O-12
AIRBAG CONTROL MODULE -
INSTALLATION, SIDE IMPACT...........8O-45
AIRBAG CONTROL MODULE -
OPERATION.........................8O-10
AIRBAG CONTROL MODULE -
OPERATION, SIDE IMPACT.............8O-43
AIRBAG CONTROL MODULE - REMOVAL . . 8O-11
AIRBAG CONTROL MODULE - REMOVAL,
SIDE IMPACT.......................8O-44
AIRBAG DOOR - INSTALLATION,
PASSENGER........................8O-30
AIRBAG DOOR - REMOVAL, PASSENGER . . 8O-29
AIRBAG INDICATOR - DESCRIPTION......8J-12
AIRBAG INDICATOR - OPERATION.......8J-12
AIRBAG MOUNTING BRACKET -
INSTALLATION, PASSENGER...........8O-31
AIRBAG MOUNTING BRACKET -
REMOVAL, PASSENGER...............8O-31
AJAR INDICATOR - DESCRIPTION, DOOR . . 8J-17
AJAR INDICATOR - DESCRIPTION, GATE . . 8J-20
AJAR INDICATOR - DESCRIPTION,
GLASS..............................8J-21
AJAR INDICATOR - OPERATION, DOOR . . . 8J-17
AJAR INDICATOR - OPERATION, GATE....8J-20
AJAR INDICATOR - OPERATION, GLASS . . . 8J-21
AJAR SWITCH - DESCRIPTION, DOOR....8L-77
AJAR SWITCH - DESCRIPTION, FLIP-UP
GLASS.............................8L-77
AJAR SWITCH - DESCRIPTION, HOOD....8Q-11
AJAR SWITCH - DESCRIPTION,
TAILGATE...........................8L-82
AJAR SWITCH - DIAGNOSIS AND
TESTING, HOOD.....................8Q-12
AJAR SWITCH - INSTALLATION, HOOD . . . 8Q-12
AJAR SWITCH - OPERATION, DOOR......8L-77
AJAR SWITCH - OPERATION, FLIP-UP
GLASS.............................8L-77
AJAR SWITCH - OPERATION, HOOD.....8Q-12
AJAR SWITCH - OPERATION, TAILGATE . . . 8L-82
AJAR SWITCH - REMOVAL, HOOD.......8Q-12
AJAR SWITCH BRACKET -
INSTALLATION, HOOD.................8Q-13
AJAR SWITCH BRACKET - REMOVAL,
HOOD.............................8Q-13
AJAR SWITCH STRIKER -
INSTALLATION, HOOD.................8Q-14
AJAR SWITCH STRIKER - REMOVAL,
HOOD.............................8Q-13
ALIGNMENT - DESCRIPTION, WHEEL.......2-3
ALIGNMENT - OPERATION, WHEEL........2-3
ALIGNMENT, SPECIFICATIONS............2-6
ALUMINUM THREAD REPAIR -
STANDARD PROCEDURE...............21-81
AMBIENT TEMP SENSOR - DESCRIPTION . . 8M-9
AMBIENT TEMP SENSOR - OPERATION . . . 8M-9
AMBIENT TEMPERATURE SENSOR -
DIAGNOSIS AND TESTING..............8M-9
AMBIENT TEMPERATURE SENSOR
CIRCUIT - DIAGNOSIS AND TESTING.....8M-9
AMPERAGE TEST - DIAGNOSIS AND
TESTING, FUEL PUMP.................14-16
AMPLIFIER CHOKE AND RELAY -
DESCRIPTION........................8A-3
AMPLIFIER CHOKE AND RELAY -
DIAGNOSIS AND TESTING..............8A-4
AMPLIFIER CHOKE AND RELAY -
INSTALLATION.......................8A-4
AMPLIFIER CHOKE AND RELAY -
OPERATION..........................8A-3
AMPLIFIER CHOKE AND RELAY -
REMOVAL...........................8A-4
ANCHOR - DESCRIPTION, CHILD TETHER
. 8O-13
ANCHOR - OPERATION, CHILD TETHER
. . . 8O-13
ANGLE - STANDARD PROCEDURES,
PROPELLER SHAFT
.....................3-3
ANTENNA BODY & CABLE -
DESCRIPTION
........................8A-4
ANTENNA BODY & CABLE -
INSTALLATION
.......................8A-6
KJINDEX 1
Description Group-Page Description Group-Page Description Group-Page
Page 1741 of 1803
ANTENNA BODY & CABLE - OPERATION . . . 8A-5
ANTENNA BODY & CABLE - REMOVAL.....8A-6
ANTENNA BODY AND CABLE -
DIAGNOSIS AND TESTING..............8A-5
ANTENNA CABLE - INSTALLATION,
INSTRUMENT PANEL..................8A-8
ANTENNA CABLE - REMOVAL,
INSTRUMENT PANEL..................8A-7
ANTILOCK BRAKE - INSTALLATION,
CONTROLLER.......................8E-10
ANTILOCK BRAKE - REMOVAL,
CONTROLLER.......................8E-10
ANTILOCK BRAKING SYSTEM -
DIAGNOSIS AND TESTING..............5-33
A-PILLAR SEAL - INSTALLATION.......23-185
A-PILLAR SEAL - REMOVAL...........23-185
A-PILLAR TRIM AND GRAB HANDLE -
INSTALLATION......................23-156
A-PILLAR TRIM AND GRAB HANDLE -
REMOVAL.........................23-156
A-PILLAR WEATHERSTRIP/RETAINER -
INSTALLATION, WINDSHIELD..........23-187
A-PILLAR WEATHERSTRIP/RETAINER -
REMOVAL, WINDSHIELD..............23-186
APPLICATION TABLE, SPECIFICATIONS -
A/C ................................24-9
AREA LEAKS - DIAGNOSIS AND
TESTING, REAR SEAL..................9-61
ARM - DESCRIPTION, FRONT WIPER.....8R-12
ARM - DESCRIPTION, LOWER CONTROL . . . 2-21
ARM - DESCRIPTION, REAR WIPER......8R-37
ARM - DESCRIPTION, ROCKER......9-29,9-37
ARM - INSTALLATION, FRONT WIPER....8R-13
ARM - INSTALLATION, LOWER CONTROL . . 2-10,
2-21
ARM - INSTALLATION, REAR WIPER.....8R-38
ARM - INSTALLATION, ROCKER..........9-37
ARM - INSTALLATION, UPPER CONTROL . . . 2-21
ARM - OPERATION, FRONT WIPER......8R-12
ARM - OPERATION, LOWER CONTROL.....2-21
ARM - OPERATION, REAR WIPER.......8R-38
ARM - REMOVAL, FRONT WIPER........8R-12
ARM - REMOVAL, LOWER CONTROL . . 2-10,2-21
ARM - REMOVAL, REAR WIPER.........8R-38
ARM - REMOVAL, ROCKER..............9-37
ARM - REMOVAL, UPPER CONTROL......2-20
ARM, BUSHINGS, AND BALL JOINT -
DESCRIPTION, UPPER SUSPENSION......2-20
ARM, BUSHINGS, AND BALL JOINT -
OPERATION, UPPER SUSPENSION........2-20
ARM PARK RAMP - INSTALLATION,
WIPER.............................8R-43
ARM PARK RAMP - REMOVAL, WIPER . . . 8R-43
ASD AND FUEL PUMP RELAYS -
DIAGNOSIS AND TESTING...............8I-4
ASD SENSE - PCM INPUT - OPERATION....8I-4
ASH RECEIVER LAMP BULB -
INSTALLATION.......................8L-71
ASH RECEIVER LAMP BULB - REMOVAL . . 8L-71
ASH RECEIVER LAMP UNIT -
INSTALLATION.......................8L-72
ASH RECEIVER LAMP UNIT - REMOVAL . . 8L-72
ASSEMBLY - ASSEMBLY, INPUT CLUTCH . 21-138
ASSEMBLY - DESCRIPTION, INPUT
CLUTCH...........................21-133
ASSEMBLY - DESCRIPTION,
TRANSMISSION SOLENOID/TRS........21-169
ASSEMBLY - DISASSEMBLY, INPUT
CLUTCH...........................21-135
ASSEMBLY - INSTALLATION.........8W-97-11
ASSEMBLY - INSTALLATION, GUIDE.....23-179
ASSEMBLY - INSTALLATION,
INSTRUMENT PANEL.................23-151
ASSEMBLY - INSTALLATION, MODULE . . . 23-181
ASSEMBLY - INSTALLATION,
TRANSMISSION SOLENOID/TRS........21-170
ASSEMBLY - OPERATION, INPUT
CLUTCH...........................21-135
ASSEMBLY - OPERATION,
TRANSMISSION SOLENOID/TRS........21-169
ASSEMBLY - POWER DISTRIBUTION
CENTER ASSEMBLY
...............8W-97-10
ASSEMBLY - REMOVAL, GUIDE
........23-179
ASSEMBLY - REMOVAL, INSTRUMENT
PANEL
............................23-149
ASSEMBLY - REMOVAL, MODULE
......23-181
ASSEMBLY - REMOVAL, TRANSMISSION
SOLENOID/TRS
.....................21-170ASSEMBLY, 4C RETAINER/BULKHEAD....21-123
ASSEMBLY, ASSEMBLY - POWER
DISTRIBUTION CENTER............8W-97-10
ASSEMBLY, DIAGNOSIS AND TESTING....21-90
ASSEMBLY, DIFFERENTIAL.........3-105,3-41
ASSEMBLY, DIFFERENTIAL - TRAC-LOK . . . 3-109,
3-77
ASSEMBLY, DISC BRAKE CALIPERS.......5-16
ASSEMBLY, HVAC HOUSING............24-34
ASSEMBLY, INPUT CLUTCH ASSEMBLY . . 21-138
ASSEMBLY, INSTRUMENT CLUSTER......8J-10
ASSEMBLY, LOW/REVERSE CLUTCH.....21-146
ASSEMBLY, MANUAL - NV1500.........21-13
ASSEMBLY, MANUAL - NV3550.........21-48
ASSEMBLY, OIL PUMP.................9-67
ASSEMBLY, OIL PUMP...............21-151
ASSEMBLY, PLANETARY GEARTRAIN....21-160
ASSEMBLY, SINGLE CARDAN
UNIVERSAL JOINTS....................3-9
ASSEMBLY, TRANSFER CASE - NV231 . . . 21-194
ASSEMBLY, TRANSFER CASE - NV242 . . . 21-230
ASSEMBLY, VALVE BODY.............21-176
ASSEMBLY, WHEEL CYLINDERS..........5-29
ASSEMBLY WINDOW DEFOGGER
FUNCTION - DIAGNOSIS AND TESTING,
REAR HVAC CONTROL.................8G-9
ASSIST HANDLE - INSTALLATION.......23-157
ASSIST HANDLE - REMOVAL............23-157
AUDIO - DESCRIPTION.................8A-1
AUDIO - DIAGNOSIS AND TESTING.......8A-2
AUDIO - OPERATION...................8A-1
AUTOMATIC TRANSMISSION - 45RFE -
DESCRIPTION.......................21-76
AUTOMATIC TRANSMISSION - 45RFE -
OPERATION.........................21-77
AUTOMATIC TRANSMISSION -
DIAGNOSIS AND TESTING.............21-77
AUTOMATIC TRANSMISSION FLUID -
DESCRIPTION.........................0-2
AUTOMATIC TRANSMISSION FLUID -
OPERATION...........................0-4
AXLE - 186FIA - ADJUSTMENTS, FRONT . . . 3-25
AXLE - 186FIA - DESCRIPTION, FRONT....3-19
AXLE - 186FIA - INSTALLATION, FRONT....3-24
AXLE - 186FIA - OPERATION, FRONT......3-19
AXLE - 186FIA - REMOVAL, FRONT.......3-24
AXLE - 198RBI - DESCRIPTION, REAR.....3-49
AXLE - 198RBI - INSTALLATION, REAR....3-54
AXLE - 198RBI - OPERATION, REAR.......3-49
AXLE - 198RBI - REMOVAL, REAR........3-54
AXLE - 8 1/4 - ADJUSTMENTS, REAR.....3-92
AXLE - 8 1/4 - DESCRIPTION, REAR......3-86
AXLE - 8 1/4 - INSTALLATION, REAR......3-91
AXLE - 8 1/4 - OPERATION, REAR........3-86
AXLE - 8 1/4 - REMOVAL, REAR..........3-91
AXLE - DESCRIPTION...................0-2
AXLE - DIAGNOSIS AND TESTING....3-20,3-51,
3-88
AXLE - INSTALLATION, 198 RBI..........5-28
AXLE - INSTALLATION, 8 1/4............5-28
AXLE - REMOVAL, 198 RBI..............5-27
AXLE - REMOVAL, 8 1/4................5-27
AXLE - SPECIFICATIONS, FRONT.........3-33
AXLE - SPECIFICATIONS, REAR..........3-62
AXLE BEARINGS - INSTALLATION....3-102,3-38
AXLE BEARINGS - REMOVAL.......3-102,3-38
AXLE BEARING/SEAL - INSTALLATION.....3-67
AXLE BEARING/SEAL - REMOVAL.........3-66
AXLE SHAFT SEALS - INSTALLATION . 3-102,3-38
AXLE SHAFT SEALS - REMOVAL....3-101,3-37
AXLE SHAFTS - INSTALLATION . . 3-101,3-37,3-65
AXLE SHAFTS - REMOVAL.....3-101,3-37,3-65
AXLE, SPECIAL TOOLS - 8 1/4 ...........3-98
AXLE, SPECIAL TOOLS - FRONT..........3-34
AXLE, SPECIAL TOOLS - REAR...........3-63
AXLE, SPECIFICATIONS - REAR..........3-98
BACK - FRONT - INSTALLATION, SEAT . . . 23-166
BACK - FRONT - REMOVAL, SEAT.......23-166
BACK - REAR - INSTALLATION, SEAT....23-168
BACK - REAR - REMOVAL, SEAT.......23-168
BACK COVER - FRONT - INSTALLATION,
SEAT
.............................23-167
BACK COVER - FRONT - REMOVAL, SEAT
. 23-166
BACK COVER - REAR - INSTALLATION,
SEAT
.............................23-169
BACK COVER - REAR - REMOVAL, SEAT
. 23-169
BACK CUSHION - FRONT -
INSTALLATION, SEAT
.................23-167BACK CUSHION - FRONT - REMOVAL,
SEAT .............................23-167
BACK CUSHION - REAR - INSTALLATION,
SEAT .............................23-170
BACK CUSHION - REAR - REMOVAL,
SEAT .............................23-170
BACK FRAME - REAR - INSTALLATION,
SEAT .............................23-171
BACK FRAME - REAR - REMOVAL, SEAT . 23-171
BACK LATCH / LOCK - INSTALLATION,
FOLDING REAR SEAT................23-170
BACK LATCH / LOCK - REMOVAL,
FOLDING REAR SEAT................23-170
BACK LATCH STRIKER - INSTALLATION,
REAR SEAT........................23-171
BACK LATCH STRIKER - REMOVAL,
REAR SEAT........................23-170
BACK RECLINER - FRONT -
INSTALLATION, SEAT.................23-166
BACK RECLINER - FRONT - REMOVAL,
SEAT .............................23-166
BACKUP LAMP SWITCH - DESCRIPTION . . 8L-15
BACKUP LAMP SWITCH - DIAGNOSIS
AND TESTING.......................8L-15
BACKUP LAMP SWITCH - OPERATION....8L-15
BAFFLE SEAL - INSTALLATION,
COWL/PLENUM WINDOW.............23-187
BAFFLE SEAL - REMOVAL, COWL/
PLENUM WINDOW..................23-187
BALANCE SHAFT - INSTALLATION........9-74
BALANCE SHAFT - REMOVAL............9-74
BALANCING - STANDARD PROCEDURE,
WHEEL.............................22-4
BALL JOINT - DESCRIPTION, UPPER
SUSPENSION ARM, BUSHINGS..........2-20
BALL JOINT - DIAGNOSIS AND TESTING,
LOWER.............................2-10
BALL JOINT - INSTALLATION, UPPER.....2-20
BALL JOINT - OPERATION, UPPER
SUSPENSION ARM, BUSHINGS..........2-20
BALL JOINT - REMOVAL, UPPER.........2-20
BAR - INSTALLATION, STABILIZER....2-14,2-19
BAR - REMOVAL, STABILIZER.......2-14,2-19
BAR BUSHINGS - INSTALLATION,
STABILIZER...........................2-9
BAR BUSHINGS - REMOVAL, STABILIZER . . . 2-9
BARRELS - INSTALLATION, PANEL
OUTLET............................24-29
BARRELS - REMOVAL, PANEL OUTLET . . . 24-29
BASE - DESCRIPTION, BRAKES...........5-2
BASE - WARNING, BRAKES..............5-2
BASE BRAKE SYSTEM - DIAGNOSIS AND
TESTING.............................5-3
BASE BRAKES, SPECIAL TOOLS...........5-7
BASE COAT/CLEAR COAT FINISH -
DESCRIPTION......................23-162
BATTERIES - STANDARD PROCEDURE,
RKE TRANSMITTER...................8N-8
BATTERY - DESCRIPTION...............8F-7
BATTERY - DIAGNOSIS AND TESTING.....8F-8
BATTERY CABLES - DESCRIPTION.......8F-18
BATTERY CABLES - DIAGNOSIS AND
TESTING...........................8F-19
BATTERY CABLES - OPERATION.........8F-18
BATTERY CHARGING - STANDARD
PROCEDURE.........................8F-8
BATTERY HOLDDOWN - DESCRIPTION....8F-17
BATTERY HOLDDOWN - INSTALLATION . . . 8F-17
BATTERY HOLDDOWN - OPERATION.....8F-17
BATTERY HOLDDOWN - REMOVAL.......8F-17
BATTERY SYSTEM - CLEANING...........8F-5
BATTERY SYSTEM - DESCRIPTION........8F-1
BATTERY SYSTEM - DIAGNOSIS AND
TESTING............................8F-2
BATTERY SYSTEM - INSPECTION.........8F-6
BATTERY SYSTEM - OPERATION.........8F-2
BATTERY SYSTEM - SPECIAL TOOLS......8F-7
BATTERY SYSTEM - SPECIFICATIONS......8F-6
BATTERY TEMPERATURE SENSOR -
DESCRIPTION.......................8F-24
BATTERY TEMPERATURE SENSOR -
INSTALLATION
.......................8F-24
BATTERY TEMPERATURE SENSOR -
OPERATION
.........................8F-24
BATTERY TEMPERATURE SENSOR -
REMOVAL
..........................8F-24
BATTERY TRAY - DESCRIPTION
.........8F-21
BATTERY TRAY - INSTALLATION
.........8F-21
2 INDEXKJ
Description Group-Page Description Group-Page Description Group-Page
Page 1745 of 1803
COMPASS CALIBRATION - STANDARD
PROCEDURE.........................8M-2
COMPASS DEMAGNETIZING -
STANDARD PROCEDURE...............8M-2
COMPASS MINI-TRIP COMPUTER -
DIAGNOSIS AND TESTING..............8M-6
COMPASS MINI-TRIP ILLUMINATION
BULB - INSTALLATION................8L-75
COMPASS MINI-TRIP ILLUMINATION
BULB - REMOVAL....................8L-74
COMPASS VARIATION ADJUSTMENT -
STANDARD PROCEDURE...............8M-3
COMPASS/MINI-TRIP COMPUTER -
DESCRIPTION........................8M-4
COMPASS/MINI-TRIP COMPUTER -
INSTALLATION.......................8M-8
COMPASS/MINI-TRIP COMPUTER -
OPERATION.........................8M-5
COMPASS/MINI-TRIP COMPUTER -
REMOVAL...........................8M-7
COMPRESSION PRESSURE - DIAGNOSIS
AND TESTING, CYLINDER................9-8
COMPRESSOR CLUTCH - INSPECTION,
A/C................................24-14
COMPRESSOR CLUTCH - INSTALLATION,
A/C................................24-14
COMPRESSOR CLUTCH - REMOVAL, A/C . . 24-13
COMPRESSOR CLUTCH BREAK-IN -
STANDARD PROCEDURE, A/C...........24-12
COMPRESSOR CLUTCH COIL -
DIAGNOSIS AND TESTING, A/C..........24-12
COMPRESSOR CLUTCH RELAY -
DESCRIPTION, A/C...................24-15
COMPRESSOR CLUTCH RELAY -
DIAGNOSIS AND TESTING.............24-15
COMPRESSOR CLUTCH RELAY -
INSTALLATION, A/C...................24-16
COMPRESSOR CLUTCH RELAY -
OPERATION, A/C.....................24-15
COMPRESSOR CLUTCH RELAY -
REMOVAL, A/C......................24-16
COMPRESSOR NOISE - DIAGNOSIS AND
TESTING, A/C.......................24-42
COMPUTER - DESCRIPTION, COMPASS/
MINI-TRIP..........................8M-4
COMPUTER - DIAGNOSIS AND TESTING,
COMPASS MINI-TRIP..................8M-6
COMPUTER - INSTALLATION, COMPASS/
MINI-TRIP..........................8M-8
COMPUTER - OPERATION, COMPASS/
MINI-TRIP..........................8M-5
COMPUTER - REMOVAL, COMPASS/
MINI-TRIP..........................8M-7
CONDENSER - DESCRIPTION, A/C.......24-45
CONDENSER - INSTALLATION, A/C.......24-46
CONDENSER - OPERATION, A/C.........24-45
CONDENSER - REMOVAL, A/C..........24-45
CONDITIONER - DESCRIPTION, HEATER
AND AIR ............................24-1
CONDITIONER - OPERATION, HEATER
AND AIR ............................24-2
CONDITIONS - DIAGNOSIS AND
TESTING, SPARK PLUG................8I-13
CONNECT FITTING - DESCRIPTION,
QUICK.............................14-10
CONNECTING ROD - DESCRIPTION,
PISTON.............................9-49
CONNECTING ROD BEARING - FITTING -
STANDARD PROCEDURE................9-40
CONNECTING ROD BEARING, FITTING.....9-49
CONNECTOR - DESCRIPTION, DATA LINK . 8E-10
CONNECTOR - INSTALLATION
.......8W-01-11
CONNECTOR - INSTALLATION, TRAILER
TOW
..............................8L-61
CONNECTOR - OPERATION, DATA LINK
. . . 8E-10
CONNECTOR - REMOVAL
...........8W-01-11
CONNECTOR - REMOVAL, TRAILER TOW
. . 8L-61
CONNECTOR, GROUND AND SPLICE
INFORMATION - DESCRIPTION
........8W-01-7
CONNECTOR/GROUND/SPLICE LOCATION
- DESCRIPTION
....................8W-91-1
CONSOLE - DESCRIPTION, OVERHEAD
....8M-1
CONSOLE - INSTALLATION, FLOOR
.....23-158
CONSOLE - OPERATION, OVERHEAD
......8M-2
CONSOLE - REMOVAL, FLOOR
.........23-158
CONSOLE DUCT - INSTALLATION, FLOOR
. 24-31
CONSOLE DUCT - REMOVAL, FLOOR
.....24-31CONSOLE LID LATCH - INSTALLATION,
FLOOR............................23-158
CONSOLE LID LATCH - REMOVAL,
FLOOR............................23-158
CONSOLE, REMOVAL - OVERHEAD.......8M-4
CONTAINER - DESCRIPTION, COOLANT
RECOVERY PRESS....................7-19
CONTAINER - OPERATION, COOLANT
RECOVERY PRESS....................7-19
CONTAMINATION - DIAGNOSIS AND
TESTING, BRAKE FLUID................5-26
CONTAMINATION - DIAGNOSIS AND
TESTING, FLUID....................21-125
CONTINUITY - STANDARD PROCEDURE,
TESTING.........................8W-01-9
CONTROL - DESCRIPTION, A/C HEATER . . . 24-16
CONTROL - DESCRIPTION, IGNITION......8I-1
CONTROL - DESCRIPTION, SPEED........8P-1
CONTROL - INSTALLATION, A/C HEATER . . 24-17
CONTROL - OPERATION, IGNITION........8I-1
CONTROL - OPERATION, SPEED..........8P-1
CONTROL - REMOVAL, A/C HEATER......24-17
CONTROL - TORQUE, SPEED............8P-2
CONTROL ARM - DESCRIPTION, LOWER . . . 2-21
CONTROL ARM - INSTALLATION, LOWER . . 2-10,
2-21
CONTROL ARM - INSTALLATION, UPPER . . . 2-21
CONTROL ARM - OPERATION, LOWER.....2-21
CONTROL ARM - REMOVAL, LOWER . . 2-10,2-21
CONTROL ARM - REMOVAL, UPPER......2-20
CONTROL ASSEMBLY WINDOW
DEFOGGER FUNCTION - DIAGNOSIS
AND TESTING, REAR HVAC.............8G-9
CONTROL CABLE - INSTALLATION,
THROTTLE..........................14-46
CONTROL CABLE - REMOVAL,
THROTTLE..........................14-45
CONTROL ILLUMINATION BULB -
INSTALLATION, HEATER-A/C............8L-78
CONTROL ILLUMINATION BULB -
REMOVAL, HEATER-A/C...............8L-78
CONTROL INFORMATION (VECI) LABEL -
DESCRIPTION, VEHICLE EMISSION.....Intro.-8
CONTROL MODULE - DESCRIPTION,
AIRBAG.............................8O-9
CONTROL MODULE - DESCRIPTION,
BODY...............................8E-2
CONTROL MODULE - DESCRIPTION,
SIDE IMPACT AIRBAG.................8O-43
CONTROL MODULE - DESCRIPTION,
TRANSMISSION......................8E-18
CONTROL MODULE - DIAGNOSIS AND
TESTING, BODY.......................8E-7
CONTROL MODULE - INSTALLATION....23-183
CONTROL MODULE - INSTALLATION,
AIRBAG............................8O-12
CONTROL MODULE - INSTALLATION,
BODY...............................8E-7
CONTROL MODULE - INSTALLATION,
SIDE IMPACT AIRBAG.................8O-45
CONTROL MODULE - OPERATION,
AIRBAG............................8O-10
CONTROL MODULE - OPERATION, BODY . . . 8E-5
CONTROL MODULE - OPERATION, SIDE
IMPACT AIRBAG.....................8O-43
CONTROL MODULE - OPERATION,
TRANSMISSION......................8E-18
CONTROL MODULE - REMOVAL........23-183
CONTROL MODULE - REMOVAL, AIRBAG . 8O-11
CONTROL MODULE - REMOVAL, BODY....8E-7
CONTROL MODULE - REMOVAL, SIDE
IMPACT AIRBAG.....................8O-44
CONTROL MOTOR - DESCRIPTION, IDLE
AIR ...............................14-35
CONTROL MOTOR - INSTALLATION, IDLE
AIR ...............................14-36
CONTROL MOTOR - OPERATION, IDLE
AIR ...............................14-35
CONTROL MOTOR - REMOVAL, IDLE AIR . . 14-36
CONTROL RELAY - DESCRIPTION,
TRANSMISSION.....................21-168
CONTROL RELAY - OPERATION,
TRANSMISSION
.....................21-168
CONTROL SWITCH - DESCRIPTION
.....23-184
CONTROL SWITCH - DIAGNOSIS AND
TESTING
..........................23-184
CONTROL SWITCH - INSTALLATION
.....23-184
CONTROL SWITCH - OPERATION
.......23-184CONTROL SWITCH - REMOVAL........23-184
CONTROL SYSTEM - DESCRIPTION,
EMISSION...........................25-1
CONTROL SYSTEM - DESCRIPTION,
EVAPORATION.......................25-24
CONTROLLER ANTILOCK BRAKE -
INSTALLATION.......................8E-10
CONTROLLER ANTILOCK BRAKE -
REMOVAL..........................8E-10
CONVERTER - DESCRIPTION, CATALYTIC . . . 11-2
CONVERTER - DESCRIPTION, TORQUE . . . 21-162
CONVERTER - INSPECTION, CATALYTIC....11-3
CONVERTER - INSTALLATION, CATALYTIC . . 11-3
CONVERTER - INSTALLATION, TORQUE . . 21-167
CONVERTER - OPERATION, TORQUE....21-166
CONVERTER - REMOVAL, CATALYTIC......11-2
CONVERTER - REMOVAL, TORQUE......21-167
CONVERTER HOUSING FLUID LEAK -
DIAGNOSIS AND TESTING.............21-80
COOLANT - DESCRIPTION, ENGINE........0-3
COOLANT LOW INDICATOR -
DESCRIPTION.......................8J-15
COOLANT LOW INDICATOR - OPERATION . 8J-16
COOLANT RECOVERY PRESS
CONTAINER - DESCRIPTION.............7-19
COOLANT RECOVERY PRESS
CONTAINER - OPERATION...............7-19
COOLANT TEMPERATURE SENSOR -
DESCRIPTION, ENGINE.................7-19
COOLANT TEMPERATURE SENSOR -
INSTALLATION, ENGINE................7-21
COOLANT TEMPERATURE SENSOR -
OPERATION, ENGINE...................7-20
COOLANT TEMPERATURE SENSOR -
REMOVAL, ENGINE....................7-20
COOLANT THERMOSTAT - OPERATION,
ENGINE.............................7-21
COOLER - DESCRIPTION, FLUID.........19-20
COOLER - DESCRIPTION, TRANS.........7-32
COOLER - INSTALLATION, FLUID........19-20
COOLER - OPERATION, FLUID..........19-20
COOLER - REMOVAL, FLUID............19-20
COOLING, SPECIAL TOOLS..............7-14
COOLING SYSTEM - OPERATION..........7-2
COOLING SYSTEM - REVERSE
FLUSHING - STANDARD PROCEDURE.....7-12
COOLING SYSTEM 3.7L ENGINE -
DESCRIPTION.........................7-1
COOLING SYSTEM 3.7L ENGINE -
STANDARD PROCEDURE, DRAINING......7-12
COOLING SYSTEM 3.7L ENGINE -
STANDARD PROCEDURE, REFILLING......7-12
COOLING SYSTEM DIAGNOSIS CHART -
DIAGNOSIS AND TESTING...............7-6
COOLING SYSTEM LEAKS - DIAGNOSIS
AND TESTING.........................7-4
COOLING SYSTEM REQUIREMENTS -
DESCRIPTION........................24-1
COOLING SYSTEM ROUTING 3.7L
ENGINE - DESCRIPTION.................7-2
CORE - DESCRIPTION, HEATER.........24-52
CORE - INSTALLATION, HEATER.........24-53
CORE - OPERATION, HEATER...........24-52
CORE - REMOVAL, HEATER............24-52
CORE AND OIL GALLERY PLUGS -
STANDARD PROCEDURE, ENGINE........9-10
COURTESY LAMP BULB - INSTALLATION . . 8L-76
COURTESY LAMP BULB - REMOVAL.....8L-75
COURTESY LAMP REPLACEMENT -
STANDARD PROCEDURE...............8M-2
COURTESY LAMP UNIT - INSTALLATION . . 8L-77
COURTESY LAMP UNIT - REMOVAL......8L-76
COVER - DESCRIPTION, STRUCTURAL.....9-55
COVER - FRONT - INSTALLATION, SEAT
BACK.............................23-167
COVER - FRONT - INSTALLATION, SEAT
CUSHION..........................23-167
COVER - FRONT - REMOVAL, SEAT BACK . 23-166
COVER - FRONT - REMOVAL, SEAT
CUSHION..........................23-167
COVER - INSTALLATION, COWL TRIM . . . 23-157
COVER - INSTALLATION, INSTRUMENT
PANEL TOP
........................23-153
COVER - INSTALLATION, STRUCTURAL
....9-55
COVER - OPERATION, STRUCTURAL
......9-55
COVER - REAR - INSTALLATION, SEAT
BACK
.............................23-169
COVER - REAR - REMOVAL, SEAT BACK
. 23-169
6 INDEXKJ
Description Group-Page Description Group-Page Description Group-Page
Page 1746 of 1803
COVER - REMOVAL, COWL TRIM.......23-157
COVER - REMOVAL, INSTRUMENT
PANEL TOP........................23-152
COVER - REMOVAL, STRUCTURAL........9-55
COVER(S) - DESCRIPTION, CYLINDER
HEAD...............................9-25
COVER(S) - INSTALLATION, CYLINDER
HEAD...........................9-26,9-34
COVER(S) - INSTALLATION, TIMING
BELT / CHAIN........................9-76
COVER(S) - REMOVAL, CYLINDER HEAD . . 9-25,
9-34
COVER(S) - REMOVAL, TIMING BELT /
CHAIN..............................9-74
COWL GRILLE - INSTALLATION........23-140
COWL GRILLE - REMOVAL............23-140
COWL TRIM COVER - INSTALLATION....23-157
COWL TRIM COVER - REMOVAL.......23-157
COWL WEATHERSTRIP - INSTALLATION . 23-185
COWL WEATHERSTRIP - REMOVAL.....23-185
COWL/PLENUM SEAL - INSTALLATION . . . 23-187
COWL/PLENUM SEAL - REMOVAL......23-187
COWL/PLENUM WINDOW BAFFLE SEAL -
INSTALLATION......................23-187
COWL/PLENUM WINDOW BAFFLE SEAL -
REMOVAL.........................23-187
CRADLE CROSSMEMBER -
INSTALLATION, ENGINE................13-6
CRADLE CROSSMEMBER - REMOVAL,
ENGINE.............................13-6
CRANKSHAFT - DESCRIPTION...........9-42
CRANKSHAFT - INSPECTION.............9-43
CRANKSHAFT - INSTALLATION...........9-43
CRANKSHAFT - REMOVAL..............9-43
CRANKSHAFT OIL SEAL - FRONT -
INSTALLATION........................9-47
CRANKSHAFT OIL SEAL - FRONT -
REMOVAL...........................9-46
CRANKSHAFT OIL SEAL - REAR -
INSTALLATION........................9-48
CRANKSHAFT OIL SEAL - REAR -
REMOVAL...........................9-48
CRANKSHAFT POSITION SENSOR -
DESCRIPTION.......................14-30
CRANKSHAFT POSITION SENSOR -
INSTALLATION.......................14-32
CRANKSHAFT POSITION SENSOR -
OPERATION.........................14-31
CRANKSHAFT POSITION SENSOR -
REMOVAL..........................14-31
CROSSMEMBER - INSTALLATION,
ENGINE CRADLE......................13-6
CROSSMEMBER - INSTALLATION,
RADIATOR.........................23-146
CROSSMEMBER - INSTALLATION, REAR . . . 13-7
CROSSMEMBER - REMOVAL, ENGINE
CRADLE.............................13-6
CROSSMEMBER - REMOVAL, RADIATOR . 23-146
CROSSMEMBER - REMOVAL, REAR.......13-7
CROSS-OVER PIPE - INSTALLATION.......11-3
CROSS-OVER PIPE - REMOVAL..........11-3
CRUISE INDICATOR - DESCRIPTION......8J-16
CRUISE INDICATOR - OPERATION.......8J-17
CURTAIN AIRBAG - DESCRIPTION, SIDE . . 8O-38
CURTAIN AIRBAG - INSTALLATION, SIDE . . 8O-41
CURTAIN AIRBAG - OPERATION, SIDE....8O-39
CURTAIN AIRBAG - REMOVAL, SIDE.....8O-40
CUSHION - FRONT - INSTALLATION,
SEAT .............................23-167
CUSHION - FRONT - INSTALLATION,
SEAT BACK........................23-167
CUSHION - FRONT - REMOVAL, SEAT . . . 23-167
CUSHION - FRONT - REMOVAL, SEAT
BACK.............................23-167
CUSHION - REAR - INSTALLATION, SEAT . 23-171
CUSHION - REAR - INSTALLATION, SEAT
BACK.............................23-170
CUSHION - REAR - REMOVAL, SEAT....23-171
CUSHION - REAR - REMOVAL, SEAT
BACK
.............................23-170
CUSHION COVER - FRONT -
INSTALLATION, SEAT
.................23-167
CUSHION COVER - FRONT - REMOVAL,
SEAT
.............................23-167
CUSHION SIDE SHIELDS -
INSTALLATION, SEAT
.................23-167
CUSHION SIDE SHIELDS - REMOVAL,
SEAT
.............................23-167CUSTOMER PREFERENCES - STANDARD
PROCEDURE, RKE TRANSMITTER........8N-8
CV JOINT/BOOT-INNER - INSTALLATION . . . 3-17
CV JOINT/BOOT-INNER - REMOVAL.......3-15
CV JOINT/BOOT-OUTER - INSTALLATION . . . 3-13
CV JOINT/BOOT-OUTER - REMOVAL.......3-12
CYLINDER - DESCRIPTION, MASTER......5-24
CYLINDER - INSPECTION, MASTER........6-9
CYLINDER - INSTALLATION, FLIP-UP
GLASS SUPPORT...................23-139
CYLINDER - INSTALLATION, LOCK......23-125,
23-138
CYLINDER - INSTALLATION, LOCK.......19-11
CYLINDER - INSTALLATION, MASTER.....5-25
CYLINDER - INSTALLATION, SUPPORT . . . 23-120
CYLINDER - OPERATION, MASTER........5-24
CYLINDER - REMOVAL, FLIP-UP GLASS
SUPPORT.........................23-139
CYLINDER - REMOVAL, LOCK....23-125,23-137
CYLINDER - REMOVAL, LOCK...........19-10
CYLINDER - REMOVAL, MASTER.........5-25
CYLINDER - REMOVAL, SUPPORT......23-120
CYLINDER BLEEDING - STANDARD
PROCEDURE, MASTER.................5-24
CYLINDER BORE HONING - STANDARD
PROCEDURE.........................9-39
CYLINDER COMBUSTION PRESSURE
LEAKAGE - DIAGNOSIS AND TESTING......9-8
CYLINDER COMPRESSION PRESSURE -
DIAGNOSIS AND TESTING...............9-8
CYLINDER FLUID LEVEL - STANDARD
PROCEDURES, MASTER................5-26
CYLINDER HEAD - DESCRIPTION.........9-30
CYLINDER HEAD COVER(S) -
DESCRIPTION........................9-25
CYLINDER HEAD COVER(S) -
INSTALLATION....................9-26,9-34
CYLINDER HEAD COVER(S) - REMOVAL . . . 9-25,
9-34
CYLINDER HEAD GASKET - DIAGNOSIS
AND TESTING....................9-19,9-30
CYLINDER LOCK SWITCH -
DESCRIPTION, DOOR..................8Q-9
CYLINDER LOCK SWITCH -
DESCRIPTION, TAILGATE...............8N-9
CYLINDER LOCK SWITCH - DIAGNOSIS
AND TESTING, DOOR.................8Q-10
CYLINDER LOCK SWITCH - DIAGNOSIS
AND TESTING, TAILGATE...............8N-9
CYLINDER LOCK SWITCH -
INSTALLATION, DOOR.................8Q-10
CYLINDER LOCK SWITCH -
INSTALLATION, TAILGATE..............8N-10
CYLINDER LOCK SWITCH - OPERATION,
DOOR.............................8Q-10
CYLINDER LOCK SWITCH - OPERATION,
TAILGATE...........................8N-9
CYLINDER LOCK SWITCH - REMOVAL,
DOOR.............................8Q-10
CYLINDER LOCK SWITCH - REMOVAL,
TAILGATE..........................8N-10
CYLINDER/POWER BOOSTER -
DIAGNOSIS AND TESTING, MASTER . . 5-21,5-24
CYLINDERS - ASSEMBLY, WHEEL.........5-29
CYLINDERS - CLEANING, WHEEL.........5-28
CYLINDERS - DISASSEMBLY, WHEEL......5-28
CYLINDERS - INSPECTION, WHEEL.......5-29
CYLINDERS - INSTALLATION, WHEEL
.....5-29
CYLINDERS - REMOVAL, WHEEL
.........5-28
DAMAGED OR WORN THREADS -
STANDARD PROCEDURE, REPAIR
.........9-9
DAMPER - INSTALLATION, VIBRATION
.....9-55
DAMPER - REMOVAL, VIBRATION
........9-54
DATA LINK CONNECTOR - DESCRIPTION
. . 8E-10
DATA LINK CONNECTOR - OPERATION
....8E-10
DAYTIME RUNNING LAMP RELAY -
DESCRIPTION
.......................8L-20
DAYTIME RUNNING LAMP RELAY -
INSTALLATION
.......................8L-21
DAYTIME RUNNING LAMP RELAY -
OPERATION
.........................8L-20
DAYTIME RUNNING LAMP RELAY -
REMOVAL
..........................8L-21
DECOUPLER - DIAGNOSIS AND
TESTING, GENERATOR
................8F-27
DECOUPLER PULLEY - DESCRIPTION,
GENERATOR
........................8F-26DECOUPLER PULLEY - INSTALLATION,
GENERATOR........................8F-30
DECOUPLER PULLEY - OPERATION,
GENERATOR........................8F-27
DECOUPLER PULLEY - REMOVAL,
GENERATOR........................8F-27
DEFINITION - DESCRIPTION, TRIP.......25-19
DEFLECTOR - INSTALLATION, WIND.....23-180
DEFLECTOR - REMOVAL, WIND........23-180
DEFOGGER - DESCRIPTION, REAR
WINDOW............................8G-3
DEFOGGER - OPERATION, REAR
WINDOW............................8G-3
DEFOGGER FUNCTION - DIAGNOSIS AND
TESTING, REAR HVAC CONTROL
ASSEMBLY WINDOW..................8G-9
DEFOGGER GRID - DESCRIPTION, REAR
WINDOW............................8G-5
DEFOGGER GRID - DIAGNOSIS AND
TESTING, REAR WINDOW..............8G-5
DEFOGGER GRID - OPERATION, REAR
WINDOW............................8G-5
DEFOGGER RELAY - DESCRIPTION,
REAR WINDOW.......................8G-6
DEFOGGER RELAY - DIAGNOSIS AND
TESTING, REAR WINDOW..............8G-6
DEFOGGER RELAY - INSTALLATION,
REAR WINDOW.......................8G-7
DEFOGGER RELAY - OPERATION, REAR
WINDOW............................8G-6
DEFOGGER RELAY - REMOVAL, REAR
WINDOW............................8G-7
DEFOGGER SWITCH - DESCRIPTION,
REAR WINDOW.......................8G-8
DEFOGGER SWITCH - DIAGNOSIS AND
TESTING, REAR WINDOW..............8G-8
DEFOGGER SWITCH - OPERATION, REAR
WINDOW............................8G-8
DEFOGGER SYSTEM - DIAGNOSIS AND
TESTING, REAR WINDOW..............8G-4
DEFROST DOO - INSTALLATION, FLOOR . . 24-37
DEFROST DOOR - REMOVAL...........24-35
DEFROST DOOR - REMOVAL, FLOOR.....24-36
DEFROST DOOR ACTUATOR -
INSTALLATION, FLOOR................24-25
DEFROST DOOR ACTUATOR - REMOVAL,
FLOOR.............................24-24
DEFROST DUCT/DEMISTER ADAPTOR -
REMOVAL..........................24-32
DEFROST/DEMISTER DUCT -
INSTALLATION.......................24-32
DELIVERY - DESCRIPTION, FUEL.........14-2
DELIVERY - OPERATION, FUEL...........14-3
DEMAGNETIZING - STANDARD
PROCEDURE, COMPASS...............8M-2
DEMISTER OUTLETS - DESCRIPTION.....24-29
DEPLOYMENT - STANDARD
PROCEDURE, SERVICE AFTER A
SUPPLEMENTAL RESTRAINT............8O-6
DETECTION PUMP - DESCRIPTION, LEAK . 25-27
DETECTION PUMP - INSTALLATION,
LEAK..............................25-28
DETECTION PUMP - OPERATION, LEAK . . . 25-28
DETECTION PUMP - REMOVAL, LEAK....25-28
DEVICES - STANDARD PROCEDURE,
ELECTROSTATIC DISCHARGE (ESD)
SENSITIVE........................8W-01-8
DIAGNOSIS CHART - DIAGNOSIS AND
TESTING, COOLING SYSTEM.............7-6
DIAGNOSIS, DIAGNOSIS AND TESTING -
WATER DRAINAGE AND WIND NOISE . . . 23-176
DIAGNOSTIC PROCEDURES, DIAGNOSIS
AND TESTING......................23-176
DIAGNOSTIC TROUBLE CODES -
DESCRIPTION........................25-2
DIAGNOSTICS (OBD) - DIAGNOSIS AND
TESTING, ON-BOARD...................7-3
DIAGRAMS - DESCRIPTION, HOW TO
USE WIRING......................8W-01-1
DIAGRAMS - HYDRAULIC SCHEMATICS,
SCHEMATICS.......................21-100
DIESEL - TORQUE, EXCEPT.............8F-23
DIFFERENTIAL - ASSEMBLY
........3-105,3-41
DIFFERENTIAL - DISASSEMBLY
.....3-105,3-41
DIFFERENTIAL - INSTALLATION
. 3-105,3-42,3-73
DIFFERENTIAL - REMOVAL
.....3-104,3-40,3-71
DIFFERENTIAL - TRAC-LOK - ASSEMBLY
. . 3-109,
3-77
KJINDEX 7
Description Group-Page Description Group-Page Description Group-Page
Page 1748 of 1803
ENGINE - DESCRIPTION, COOLING
SYSTEM 3.7L.........................7-1
ENGINE - DESCRIPTION, COOLING
SYSTEM ROUTING 3.7L.................7-2
ENGINE - INSTALLATION, 3.7L . . . 7-17,7-18,7-22
ENGINE - REMOVAL, 3.7L...........7-17,7-21
ENGINE - STANDARD PROCEDURE,
DRAINING COOLING SYSTEM 3.7L........7-12
ENGINE - STANDARD PROCEDURE,
REFILLING COOLING SYSTEM 3.7L.......7-12
ENGINE BLOCK - CLEANING.............9-39
ENGINE BLOCK - DESCRIPTION..........9-39
ENGINE BLOCK - INSPECTION...........9-40
ENGINE COOLANT - DESCRIPTION.........0-3
ENGINE COOLANT TEMPERATURE
SENSOR - DESCRIPTION...............7-19
ENGINE COOLANT TEMPERATURE
SENSOR - INSTALLATION...............7-21
ENGINE COOLANT TEMPERATURE
SENSOR - OPERATION.................7-20
ENGINE COOLANT TEMPERATURE
SENSOR - REMOVAL...................7-20
ENGINE COOLANT THERMOSTAT -
OPERATION..........................7-21
ENGINE CORE AND OIL GALLERY PLUGS
- STANDARD PROCEDURE..............9-10
ENGINE CRADLE CROSSMEMBER -
INSTALLATION........................13-6
ENGINE CRADLE CROSSMEMBER -
REMOVAL...........................13-6
ENGINE DIAGNOSIS - INTRODUCTION -
DIAGNOSIS AND TESTING.................9-4
ENGINE DIAGNOSIS - LUBRICATION -
DIAGNOSIS AND TESTING...............9-7
ENGINE DIAGNOSIS - MECHANICAL -
DIAGNOSIS AND TESTING...............9-6
ENGINE DIAGNOSIS - PERFORMANCE -
DIAGNOSIS AND TESTING...............9-4
ENGINE FIRING ORDER, 2.4L 4-
CYLINDER...........................8I-2
ENGINE FIRING ORDER, 3.7L V-6.........8I-2
ENGINE GASKET SURFACE
PREPARATION - STANDARD
PROCEDURE..........................9-9
ENGINE OIL - STANDARD PROCEDURE....9-61
ENGINE OIL LEAK - DIAGNOSIS AND
TESTING............................9-60
ENGINE OIL PRESSURE - DIAGNOSIS
AND TESTING........................9-60
ENGINE, SPECIAL TOOLS - 3.7L..........9-15
ENGINE, SPECIFICATIONS - 3.7L.........9-12
ENGINE TEMPERATURE GAUGE -
DESCRIPTION.......................8J-18
ENGINE TEMPERATURE GAUGE -
OPERATION.........................8J-18
ENGINES - GENERATOR RATINGS, GAS . . . 8F-23
ENTRY MODULE - DESCRIPTION,
REMOTE KEYLESS....................8N-7
ENTRY MODULE - DIAGNOSIS AND
TESTING, REMOTE KEYLESS............8N-7
ENTRY MODULE - INSTALLATION,
REMOTE KEYLESS....................8N-7
ENTRY MODULE - OPERATION, REMOTE
KEYLESS............................8N-7
ENTRY MODULE - REMOVAL, REMOTE
KEYLESS............................8N-7
ENTRY TRANSMITTER - DIAGNOSIS AND
TESTING, REMOTE KEYLESS............8N-8
ENTRY TRANSMITTER -
SPECIFICATIONS, REMOTE KEYLESS......8N-9
EQUIPMENT - STANDARD PROCEDURE,
REFRIGERANT SYSTEM SERVICE........24-40
ERASING TRANSMITTER CODES -
STANDARD PROCEDURE...............8M-8
EVACUATE - STANDARD PROCEDURE,
REFRIGERANT SYSTEM...............24-41
EVAPORATION CONTROL SYSTEM -
DESCRIPTION.......................25-24
EVAPORATOR - DESCRIPTION, A/C.......24-49
EVAPORATOR - INSTALLATION, A/C......24-49
EVAPORATOR - OPERATION, A/C........24-49
EVAPORATOR - REMOVAL, A/C..........24-49
EVAP/PURGE SOLENOID - DESCRIPTION . . 25-27
EVAP/PURGE SOLENOID - INSTALLATION
. 25-27
EVAP/PURGE SOLENOID - OPERATION
....25-27
EVAP/PURGE SOLENOID - REMOVAL
.....25-27
EXCEPT DIESEL - TORQUE
.............8F-23
EXHAUST MANIFOLD - DESCRIPTION
.....9-69EXHAUST MANIFOLD - INSTALLATION.....9-70
EXHAUST MANIFOLD - REMOVAL.........9-69
EXHAUST SYSTEM - DESCRIPTION.......11-1
EXHAUST SYSTEM - DIAGNOSIS AND
TESTING............................11-2
EXTENSION HOUSING BUSHING -
NV3550 - INSTALLATION...............21-74
EXTENSION HOUSING BUSHING -
NV3550 - REMOVAL..................21-73
EXTENSION HOUSING SEAL - NV1500 -
INSTALLATION.......................21-32
EXTENSION HOUSING SEAL - NV1500 -
REMOVAL..........................21-32
EXTENSION HOUSING SEAL - NV3550 -
INSTALLATION.......................21-74
EXTENSION HOUSING SEAL - NV3550 -
REMOVAL..........................21-74
EXTERIOR - DESCRIPTION, LAMPS/
LIGHTING...........................8L-2
EXTERIOR - DIAGNOSIS AND TESTING,
LAMPS/LIGHTING.....................8L-7
EXTERIOR - OPERATION, LAMPS/
LIGHTING...........................8L-5
EXTERIOR - SPECIFICATIONS,
LAMPS/LIGHTING....................8L-15
EXTERIOR HANDLE - INSTALLATION....23-123,
23-130,23-136
EXTERIOR HANDLE - REMOVAL . 23-123,23-130,
23-136
EXTERIOR NAME PLATES -
INSTALLATION......................23-141
EXTERIOR NAME PLATES - REMOVAL . . . 23-140
FAN - ELECTRIC - DESCRIPTION,
RADIATOR...........................7-26
FAN - ELECTRIC - INSTALLATION,
RADIATOR...........................7-27
FAN - ELECTRIC - OPERATION,
RADIATOR...........................7-26
FAN - ELECTRIC - REMOVAL, RADIATOR . . . 7-26
FAN - VISCOUS - CLEANING, RADIATOR . . . 7-29
FAN - VISCOUS - DESCRIPTION,
RADIATOR...........................7-27
FAN - VISCOUS - INSPECTION,
RADIATOR...........................7-29
FAN - VISCOUS - INSTALLATION,
RADIATOR...........................7-29
FAN - VISCOUS - OPERATION,
RADIATOR...........................7-27
FAN - VISCOUS - REMOVAL, RADIATOR....7-28
FAN DRIVE - DIAGNOSIS AND TESTING,
VISCOUS............................7-28
FASCIA - INSTALLATION, FRONT.........13-2
FASCIA - INSTALLATION, REAR..........13-2
FASCIA - REMOVAL, FRONT.............13-1
FASCIA - REMOVAL, REAR..............13-2
FASCIA SUPPORT - INSTALLATION,
REAR...............................13-3
FASCIA SUPPORT - REMOVAL, REAR......13-3
FASTENER IDENTIFICATION -
DESCRIPTION......................Intro.-1
FENDER - INSTALLATION, FRONT.......23-141
FENDER - REMOVAL, FRONT..........23-141
FILL - STANDARD PROCEDURE, FLUID
DRAIN......................21-208,21-246
FILL - STANDARD PROCEDURE,
TRANSMISSION.....................21-128
FILL DOOR/HOUSING - INSTALLATION,
FUEL.............................23-141
FILL DOOR/HOUSING - REMOVAL, FUEL . 23-141
FILL/CHECK LOCATIONS - DESCRIPTION,
FLUID...............................0-4
FILLER CAP - DESCRIPTION, FUEL.......25-27
FILLER CAP - OPERATION, FUEL........25-27
FILTER - DESCRIPTION, FUEL............14-7
FILTER - INSTALLATION, FUEL...........14-8
FILTER - INSTALLATION, INLET..........14-28
FILTER - INSTALLATION, OIL............9-63
FILTER - REMOVAL, FUEL...............14-7
FILTER - REMOVAL, INLET.............14-28
FILTER - REMOVAL, OIL
................9-63
FILTER REPLACEMENT - STANDARD
PROCEDURE, FLUID
.................21-126
FINESSE SANDING/BUFFING &
POLISHING - DESCRIPTION
...........23-163
FINISH - DESCRIPTION, BASE
COAT/CLEAR COAT
..................23-162
FIRING ORDER, 2.4L 4-CYLINDER -
ENGINE
..............................8I-2FIRING ORDER, 3.7L V-6 - ENGINE........8I-2
FITTING - CONNECTING ROD BEARING....9-49
FITTING - DESCRIPTION, QUICK
CONNECT...........................14-10
FITTING - MAIN BEARING...............9-45
FITTING - STANDARD PROCEDURE,
CONNECTING ROD BEARING............9-40
FITTING - STANDARD PROCEDURE,
PISTON.............................9-50
FITTING - STANDARD PROCEDURE,
PISTON RING........................9-52
FITTINGS - STANDARD PROCEDURE,
QUICK-CONNECT.....................14-10
FLARE MOLDINGS - INSTALLATION,
FRONT WHEEL OPENING.............23-145
FLARE MOLDINGS - INSTALLATION,
REAR WHEEL OPENING..............23-145
FLARE MOLDINGS - REMOVAL, FRONT
WHEEL OPENING...................23-145
FLARE MOLDINGS - REMOVAL, REAR
WHEEL OPENING...................23-145
FLARING - STANDARD PROCEDURE,
DOUBLE INVERTED.....................5-8
FLARING - STANDARD PROCEDURE, ISO....5-8
FLASHER - DESCRIPTION, COMBINATION . 8L-19
FLASHER - OPERATION, COMBINATION . . . 8L-19
FLEX PLATE - INSTALLATION............9-49
FLEX PLATE - REMOVAL................9-49
FLIP-UP GLASS - INSTALLATION.......23-136
FLIP-UP GLASS - REMOVAL...........23-136
FLIP-UP GLASS AJAR SWITCH -
DESCRIPTION.......................8L-77
FLIP-UP GLASS AJAR SWITCH -
OPERATION.........................8L-77
FLIP-UP GLASS LATCH - INSTALLATION . 23-136
FLIP-UP GLASS LATCH - REMOVAL.....23-136
FLIP-UP GLASS RELEASE SWITCH -
DIAGNOSIS AND TESTING..............8N-5
FLIP-UP GLASS SUPPORT CYLINDER -
INSTALLATION......................23-139
FLIP-UP GLASS SUPPORT CYLINDER -
REMOVAL.........................23-139
FLOOR - DEFROST DOO - INSTALLATION . . 24-37
FLOOR - DEFROST DOOR - REMOVAL....24-36
FLOOR - DEFROST DOOR ACTUATOR -
INSTALLATION.......................24-25
FLOOR - DEFROST DOOR ACTUATOR -
REMOVAL..........................24-24
FLOOR CONSOLE - INSTALLATION......23-158
FLOOR CONSOLE - REMOVAL..........23-158
FLOOR CONSOLE DUCT - INSTALLATION . . 24-31
FLOOR CONSOLE DUCT - REMOVAL.....24-31
FLOOR CONSOLE LID LATCH -
INSTALLATION......................23-158
FLOOR CONSOLE LID LATCH - REMOVAL . 23-158
FLOOR DUCT - INSTALLATION..........24-32
FLOOR DUCT - REMOVAL..............24-32
FLOOR MATS - INSTALLATION, CARPETS . 23-158
FLOOR MATS - REMOVAL, CARPETS....23-158
FLOOR SHIFT BOOT - INSTALLATION,
4WD .............................23-156
FLOOR SHIFT BOOT - REMOVAL, 4WD . . . 23-156
FLOW AND PRESSURE - DIAGNOSIS
AND TESTING, POWER STEERING........19-3
FLOW MANAGEMENT VALVE -
DESCRIPTION........................14-6
FLOW MANAGEMENT VALVE -
INSTALLATION........................14-7
FLOW MANAGEMENT VALVE -
OPERATION..........................14-6
FLOW MANAGEMENT VALVE - REMOVAL . . . 14-6
FLUID - DESCRIPTION, AUTOMATIC
TRANSMISSION.......................0-2
FLUID - DIAGNOSIS AND TESTING,
CAUSES OF BURNT..................21-125
FLUID - OPERATION, AUTOMATIC
TRANSMISSION.......................0-4
FLUID AND FILTER REPLACEMENT -
STANDARD PROCEDURE..............21-126
FLUID CAPACITIES - SPECIFICATIONS......0-4
FLUID CONTAMINATION - DIAGNOSIS
AND TESTING......................21-125
FLUID CONTAMINATION - DIAGNOSIS
AND TESTING, BRAKE
..................5-26
FLUID COOLER - DESCRIPTION
.........19-20
FLUID COOLER - INSTALLATION
.........19-20
FLUID COOLER - OPERATION
...........19-20
FLUID COOLER - REMOVAL
............19-20
KJINDEX 9
Description Group-Page Description Group-Page Description Group-Page
Page 1749 of 1803
FLUID DRAIN AND FILL - STANDARD
PROCEDURE.................21-208,21-246
FLUID FILL/CHECK LOCATIONS -
DESCRIPTION.........................0-4
FLUID INDICATOR - DESCRIPTION,
WASHER...........................8J-35
FLUID INDICATOR - DIAGNOSIS AND
TESTING, WASHER...................8J-36
FLUID INDICATOR - OPERATION,
WASHER...........................8J-36
FLUID LEAK - DIAGNOSIS AND TESTING,
CONVERTER HOUSING................21-80
FLUID LEVEL - DIAGNOSIS AND
TESTING, EFFECTS OF INCORRECT......21-125
FLUID LEVEL - STANDARD
PROCEDURES, MASTER CYLINDER.......5-26
FLUID LEVEL CHECK - STANDARD
PROCEDURE.......................21-126
FLUID LEVEL SWITCH - DESCRIPTION,
WASHER...........................8R-17
FLUID LEVEL SWITCH - INSTALLATION,
WASHER...........................8R-18
FLUID LEVEL SWITCH - OPERATION,
WASHER...........................8R-17
FLUID LEVEL SWITCH - REMOVAL,
WASHER...........................8R-17
FLUID RESERVOIR - INSTALLATION.......5-26
FLUID RESERVOIR - REMOVAL..........5-26
FLUID, SPECIFICATIONS - BRAKE.........5-27
FLUID TYPES - DESCRIPTION.............0-1
FLUSH - SPECIFICATIONS, GAP........23-116
FLUSHING - STANDARD PROCEDURE,
COOLING SYSTEM - REVERSE...........7-12
FLYWHEEL - DESCRIPTION...............6-7
FLYWHEEL - DIAGNOSIS AND TESTING.....6-8
FLYWHEEL - OPERATION................6-7
FOG LAMP BULB - INSTALLATION,
FRONT.............................8L-22
FOG LAMP BULB - REMOVAL, FRONT....8L-21
FOG LAMP INDICATOR - DESCRIPTION,
FRONT.............................8J-19
FOG LAMP INDICATOR - DESCRIPTION,
REAR..............................8J-27
FOG LAMP INDICATOR - OPERATION,
FRONT.............................8J-19
FOG LAMP INDICATOR - OPERATION,
REAR..............................8J-27
FOG LAMP RELAY - DESCRIPTION,
FRONT.............................8L-22
FOG LAMP RELAY - DESCRIPTION, REAR . 8L-56
FOG LAMP RELAY - DIAGNOSIS AND
TESTING, FRONT.....................8L-23
FOG LAMP RELAY - DIAGNOSIS AND
TESTING, REAR......................8L-57
FOG LAMP RELAY - INSTALLATION,
FRONT.............................8L-24
FOG LAMP RELAY - INSTALLATION,
REAR..............................8L-58
FOG LAMP RELAY - OPERATION, FRONT . . 8L-22
FOG LAMP RELAY - OPERATION, REAR . . . 8L-57
FOG LAMP RELAY - REMOVAL, FRONT . . . 8L-24
FOG LAMP RELAY - REMOVAL, REAR....8L-58
FOG LAMP UNIT - ADJUSTMENT, FRONT . . 8L-25
FOG LAMP UNIT - INSTALLATION,
FRONT.............................8L-25
FOG LAMP UNIT - REMOVAL, FRONT.....8L-25
FOLDING REAR SEAT BACK LATCH /
LOCK - INSTALLATION
...............23-170
FOLDING REAR SEAT BACK LATCH /
LOCK - REMOVAL
...................23-170
FOUR LOW MODE INDICATOR -
DESCRIPTION
.......................8J-29
FOUR LOW MODE INDICATOR -
OPERATION
.........................8J-30
FRAME - REAR - INSTALLATION, SEAT
BACK
.............................23-171
FRAME - REAR - REMOVAL, SEAT BACK
. 23-171
FRAME DIMENSIONS - SPECIFICATIONS
. . . 13-3
FRONT - DESCRIPTION
..................2-7
FRONT - INSTALLATION, CRANKSHAFT
OIL SEAL
............................9-47
FRONT - INSTALLATION, PROPELLER
SHAFT
...............................3-6
FRONT - INSTALLATION, SEAT
.........23-165
FRONT - INSTALLATION, SEAT BACK
....23-166
FRONT - INSTALLATION, SEAT BACK
COVER
............................23-167FRONT - INSTALLATION, SEAT BACK
CUSHION..........................23-167
FRONT - INSTALLATION, SEAT BACK
RECLINER.........................23-166
FRONT - INSTALLATION, SEAT CUSHION . 23-167
FRONT - INSTALLATION, SEAT CUSHION
COVER............................23-167
FRONT - REMOVAL, CRANKSHAFT OIL
SEAL...............................9-46
FRONT - REMOVAL, PROPELLER SHAFT....3-6
FRONT - REMOVAL, SEAT.............23-165
FRONT - REMOVAL, SEAT BACK........23-166
FRONT - REMOVAL, SEAT BACK COVER . . 23-166
FRONT - REMOVAL, SEAT BACK
CUSHION..........................23-167
FRONT - REMOVAL, SEAT BACK
RECLINER.........................23-166
FRONT - REMOVAL, SEAT CUSHION.....23-167
FRONT - REMOVAL, SEAT CUSHION
COVER............................23-167
FRONT - WARNING.....................2-7
FRONT AXLE - 186FIA - ADJUSTMENTS....3-25
FRONT AXLE - 186FIA - DESCRIPTION.....3-19
FRONT AXLE - 186FIA - INSTALLATION....3-24
FRONT AXLE - 186FIA - OPERATION......3-19
FRONT AXLE - 186FIA - REMOVAL........3-24
FRONT AXLE - SPECIFICATIONS..........3-33
FRONT AXLE, SPECIAL TOOLS...........3-34
FRONT BRAKE HOSE - INSTALLATION.......5-10
FRONT BRAKE PADS - INSTALLATION.....5-11
FRONT BRAKE PADS - REMOVAL.........5-11
FRONT CHECK VALVE - DESCRIPTION.....8R-8
FRONT CHECK VALVE - INSTALLATION....8R-9
FRONT CHECK VALVE - OPERATION.......8R-9
FRONT CHECK VALVE - REMOVAL........8R-9
FRONT DOOR OUTER BELT MOLDING -
INSTALLATION......................23-186
FRONT DOOR OUTER BELT MOLDING -
REMOVAL.........................23-186
FRONT FASCIA - INSTALLATION..........13-2
FRONT FASCIA - REMOVAL..............13-1
FRONT FENDER - INSTALLATION.......23-141
FRONT FENDER - REMOVAL...........23-141
FRONT FOG LAMP BULB -
INSTALLATION.......................8L-22
FRONT FOG LAMP BULB - REMOVAL.....8L-21
FRONT FOG LAMP INDICATOR -
DESCRIPTION.......................8J-19
FRONT FOG LAMP INDICATOR -
OPERATION.........................8J-19
FRONT FOG LAMP RELAY -
DESCRIPTION.......................8L-22
FRONT FOG LAMP RELAY - DIAGNOSIS
AND TESTING.......................8L-23
FRONT FOG LAMP RELAY -
INSTALLATION.......................8L-24
FRONT FOG LAMP RELAY - OPERATION . . 8L-22
FRONT FOG LAMP RELAY - REMOVAL....8L-24
FRONT FOG LAMP UNIT - ADJUSTMENT . . 8L-25
FRONT FOG LAMP UNIT - INSTALLATION . . 8L-25
FRONT FOG LAMP UNIT - REMOVAL.....8L-25
FRONT HOSE - REMOVAL................5-9
FRONT IMPACT SENSOR - DESCRIPTION . 8O-21
FRONT IMPACT SENSOR -
INSTALLATION......................8O-22
FRONT IMPACT SENSOR - OPERATION . . . 8O-21
FRONT IMPACT SENSOR - REMOVAL....8O-22
FRONT LAMP BULB - INSTALLATION.....8L-27
FRONT LAMP BULB - REMOVAL.........8L-26
FRONT LAMP UNIT - INSTALLATION.....8L-28
FRONT LAMP UNIT - REMOVAL.........8L-27
FRONT MOUNT - INSTALLATION..........9-57
FRONT MOUNT - REMOVAL.............9-56
FRONT OUTPUT SHAFT SEAL -
INSTALLATION................21-208,21-246
FRONT OUTPUT SHAFT SEAL -
REMOVAL...................21-208,21-246
FRONT POSITION LAMP BULB -
INSTALLATION.......................8L-28
FRONT POSITION LAMP BULB -
REMOVAL
..........................8L-28
FRONT SEAL - INSTALLATION, OIL
PUMP
............................21-152
FRONT SEAL - REMOVAL, OIL PUMP
....21-152
FRONT SEAT BELT & RETRACTOR -
INSTALLATION
......................8O-24
FRONT SEAT BELT & RETRACTOR -
REMOVAL
..........................8O-23FRONT SEAT BELT BUCKLE -
INSTALLATION......................8O-26
FRONT SEAT BELT BUCKLE - REMOVAL . . 8O-25
FRONT SKID PLATE - INSTALLATION......13-6
FRONT SKID PLATE - REMOVAL..........13-6
FRONT SUSPENSION, SPECIAL TOOLS.....2-8
FRONT TOW HOOK - INSTALLATION......13-8
FRONT TOW HOOK - REMOVAL..........13-8
FRONT WASHER HOSES/TUBES -
DESCRIPTION.......................8R-10
FRONT WASHER HOSES/TUBES -
OPERATION.........................8R-10
FRONT WASHER NOZZLE -
DESCRIPTION.......................8R-11
FRONT WASHER NOZZLE -
INSTALLATION......................8R-11
FRONT WASHER NOZZLE - OPERATION . . . 8R-11
FRONT WASHER NOZZLE - REMOVAL....8R-11
FRONT WHEEL OPENING FLARE
MOLDINGS - INSTALLATION...........23-145
FRONT WHEEL OPENING FLARE
MOLDINGS - REMOVAL..............23-145
FRONT WHEEL SPEED SENSOR -
INSTALLATION........................5-34
FRONT WHEEL SPEED SENSOR -
REMOVAL...........................5-34
FRONT WHEELHOUSE SPLASH SHIELD -
INSTALLATION......................23-143
FRONT WHEELHOUSE SPLASH SHIELD -
REMOVAL.........................23-143
FRONT WIPER & WASHER SYSTEM -
CLEANING...........................8R-7
FRONT WIPER & WASHER SYSTEM -
DIAGNOSIS AND TESTING..............8R-6
FRONT WIPER & WASHER SYSTEM -
INSPECTION.........................8R-7
FRONT WIPER ARM - DESCRIPTION.....8R-12
FRONT WIPER ARM - INSTALLATION.....8R-13
FRONT WIPER ARM - OPERATION.......8R-12
FRONT WIPER ARM - REMOVAL........8R-12
FRONT WIPER BLADE - DESCRIPTION....8R-13
FRONT WIPER BLADE - INSTALLATION . . . 8R-14
FRONT WIPER BLADE - OPERATION.....8R-14
FRONT WIPER BLADE - REMOVAL.......8R-14
FRONT WIPER MODULE - DESCRIPTION . . 8R-15
FRONT WIPER MODULE - INSTALLATION . 8R-16
FRONT WIPER MODULE - OPERATION....8R-15
FRONT WIPER MODULE - REMOVAL.....8R-16
FRONT WIPERS/WASHERS -
DESCRIPTION........................8R-2
FRONT WIPERS/WASHERS - OPERATION . . 8R-4
FRONT WIPER/WASHER SWITCH -
DESCRIPTION.......................8R-16
FRONT WIPER/WASHER SWITCH -
OPERATION.........................8R-16
FUEL DELIVERY - DESCRIPTION..........14-2
FUEL DELIVERY - OPERATION...........14-3
FUEL FILL DOOR/HOUSING -
INSTALLATION......................23-141
FUEL FILL DOOR/HOUSING - REMOVAL . . 23-141
FUEL FILLER CAP - DESCRIPTION.......25-27
FUEL FILLER CAP - OPERATION.........25-27
FUEL FILTER - DESCRIPTION............14-7
FUEL FILTER - INSTALLATION............14-8
FUEL FILTER - REMOVAL...............14-7
FUEL GAUGE - DESCRIPTION...........8J-19
FUEL GAUGE - OPERATION.............8J-20
FUEL INDICATOR - DESCRIPTION, LOW
. . . 8J-22
FUEL INDICATOR - OPERATION, LOW
.....8J-22
FUEL INJECTION - DESCRIPTION
........14-29
FUEL INJECTOR - DESCRIPTION
.........14-33
FUEL INJECTOR - DIAGNOSIS AND
TESTING
...........................14-33
FUEL INJECTOR - OPERATION
..........14-33
FUEL LEVEL SENDING UNIT -
DIAGNOSIS AND TESTING
..............14-9
FUEL LEVEL SENDING UNIT / SENSOR -
DESCRIPTION
........................14-9
FUEL LEVEL SENDING UNIT / SENSOR -
INSTALLATION
.......................14-10
FUEL LEVEL SENDING UNIT / SENSOR -
OPERATION
..........................14-9
FUEL LEVEL SENDING UNIT / SENSOR -
REMOVAL
...........................14-9
FUEL LINES - DESCRIPTION
............14-10
FUEL PRESSURE LEAK DOWN TEST -
DIAGNOSIS AND TESTING
..............14-3
10 INDEXKJ
Description Group-Page Description Group-Page Description Group-Page
Page 1751 of 1803
HEAD GASKET - DIAGNOSIS AND
TESTING, CYLINDER...............9-19,9-30
HEADLAMP BULB - INSTALLATION.......8L-32
HEADLAMP BULB - REMOVAL..........8L-31
HEADLAMP HIGH BEAM RELAY -
DESCRIPTION.......................8L-33
HEADLAMP HIGH BEAM RELAY -
DIAGNOSIS AND TESTING.............8L-34
HEADLAMP HIGH BEAM RELAY -
INSTALLATION.......................8L-35
HEADLAMP HIGH BEAM RELAY -
OPERATION.........................8L-33
HEADLAMP HIGH BEAM RELAY -
REMOVAL..........................8L-34
HEADLAMP LEVELING MOTOR -
DESCRIPTION.......................8L-35
HEADLAMP LEVELING MOTOR -
INSTALLATION.......................8L-36
HEADLAMP LEVELING MOTOR -
OPERATION.........................8L-36
HEADLAMP LEVELING MOTOR -
REMOVAL..........................8L-36
HEADLAMP LEVELING SWITCH -
DESCRIPTION.......................8L-37
HEADLAMP LEVELING SWITCH -
DIAGNOSIS AND TESTING.............8L-37
HEADLAMP LEVELING SWITCH -
INSTALLATION.......................8L-38
HEADLAMP LEVELING SWITCH -
OPERATION.........................8L-37
HEADLAMP LEVELING SWITCH -
REMOVAL..........................8L-38
HEADLAMP LOW BEAM RELAY -
DESCRIPTION.......................8L-39
HEADLAMP LOW BEAM RELAY -
DIAGNOSIS AND TESTING.............8L-40
HEADLAMP LOW BEAM RELAY -
INSTALLATION.......................8L-41
HEADLAMP LOW BEAM RELAY -
OPERATION.........................8L-39
HEADLAMP LOW BEAM RELAY -
REMOVAL..........................8L-40
HEADLAMP UNIT - ADJUSTMENT........8L-42
HEADLAMP UNIT - INSTALLATION.......8L-42
HEADLAMP UNIT - REMOVAL...........8L-41
HEADLINER - INSTALLATION..........23-159
HEADLINER - REMOVAL..............23-159
HEADREST - INSTALLATION...........23-164
HEADREST - REMOVAL...............23-164
HEADREST SLEEVE - INSTALLATION....23-164
HEADREST SLEEVE - REMOVAL........23-164
HEAT SHIELDS - DESCRIPTION..........11-4
HEAT STAKING - STANDARD
PROCEDURE.........................23-3
HEATED MIRRORS - DESCRIPTION.......8G-1
HEATED MIRRORS - DIAGNOSIS AND
TESTING............................8G-1
HEATED MIRRORS - OPERATION.........8G-1
HEATED SEAT ELEMENT - DESCRIPTION . . 8G-13
HEATED SEAT ELEMENT - DIAGNOSIS
AND TESTING.......................8G-13
HEATED SEAT ELEMENT - OPERATION....8G-13
HEATED SEAT MODULE - DESCRIPTION . . . 8E-21
HEATED SEAT MODULE - DIAGNOSIS
AND TESTING.......................8E-22
HEATED SEAT MODULE - INSTALLATION . . 8E-24
HEATED SEAT MODULE - OPERATION....8E-21
HEATED SEAT MODULE - REMOVAL......8E-24
HEATED SEAT SENSOR - DIAGNOSIS
AND TESTING.......................8G-14
HEATED SEAT SWITCH - DIAGNOSIS
AND TESTING
..................8G-12,8G-14
HEATED SEAT SYSTEM - DESCRIPTION
. . . 8G-10
HEATED SEAT SYSTEM - DIAGNOSIS
AND TESTING
.......................8G-11
HEATED SEAT SYSTEM - OPERATION
....8G-10
HEATER AND AIR CONDITIONER -
DESCRIPTION
........................24-1
HEATER AND AIR CONDITIONER -
OPERATION
..........................24-2
HEATER CONTROL - DESCRIPTION, A/C
. . . 24-16
HEATER CONTROL - INSTALLATION, A/C
. . 24-17
HEATER CONTROL - REMOVAL, A/C
......24-17
HEATER CORE - DESCRIPTION
..........24-52
HEATER CORE - INSTALLATION
.........24-53
HEATER CORE - OPERATION
............24-52
HEATER CORE - REMOVAL
.............24-52HEATER PERFORMANCE - DIAGNOSIS
AND TESTING........................24-6
HEATER SWITCH - DESCRIPTION,
DRIVER SEAT.......................8G-11
HEATER SWITCH - DESCRIPTION,
PASSENGER SEAT....................8G-14
HEATER SWITCH - INSTALLATION,
DRIVER SEAT.......................8G-13
HEATER SWITCH - INSTALLATION,
PASSENGER SEAT....................8G-15
HEATER SWITCH - OPERATION, DRIVER
SEAT ..............................8G-12
HEATER SWITCH - OPERATION,
PASSENGER SEAT....................8G-14
HEATER SWITCH - REMOVAL, DRIVER
SEAT ..............................8G-13
HEATER SWITCH - REMOVAL,
PASSENGER SEAT....................8G-15
HEATER-A/C CONTROL ILLUMINATION
BULB - INSTALLATION................8L-78
HEATER-A/C CONTROL ILLUMINATION
BULB - REMOVAL....................8L-78
HEATING GRID REPAIR - STANDARD
PROCEDURE, REAR GLASS.............8G-4
HEIGHT MEASUREMENT - STANDARD
PROCEDURE..........................2-4
HIGH AND LOW LIMITS - DESCRIPTION . . 25-20
HIGH BEAM INDICATOR - DESCRIPTION . . 8J-22
HIGH BEAM INDICATOR - OPERATION....8J-22
HIGH BEAM RELAY - DESCRIPTION,
HEADLAMP.........................8L-33
HIGH BEAM RELAY - DIAGNOSIS AND
TESTING, HEADLAMP...................8L-34
HIGH BEAM RELAY - INSTALLATION,
HEADLAMP.........................8L-35
HIGH BEAM RELAY - OPERATION,
HEADLAMP.........................8L-33
HIGH BEAM RELAY - REMOVAL,
HEADLAMP.........................8L-34
HIGH MOUNTED STOP LAMP BULB -
INSTALLATION, CENTER...............8L-19
HIGH MOUNTED STOP LAMP BULB -
REMOVAL, CENTER...................8L-18
HIGH MOUNTED STOP LAMP UNIT -
INSTALLATION, CENTER...............8L-19
HIGH MOUNTED STOP LAMP UNIT -
REMOVAL, CENTER...................8L-19
HIGH PRESSURE RELIEF VALVE -
DESCRIPTION.......................24-42
HIGH PRESSURE RELIEF VALVE -
OPERATION.........................24-42
HIGH PRESSURE SWITCH -
DESCRIPTION, A/C...................24-17
HIGH PRESSURE SWITCH - DIAGNOSIS
AND TESTING, A/C...................24-18
HIGH PRESSURE SWITCH -
INSTALLATION, A/C...................24-18
HIGH PRESSURE SWITCH - OPERATION,
A/C................................24-18
HIGH PRESSURE SWITCH - REMOVAL,
A/C................................24-18
HIGH/LOW RELAY - DESCRIPTION,
WIPER.............................8R-23
HIGH/LOW RELAY - DIAGNOSIS AND
TESTING, WIPER.....................8R-24
HIGH/LOW RELAY - INSTALLATION,
WIPER.............................8R-24
HIGH/LOW RELAY - OPERATION, WIPER . . 8R-23
HIGH/LOW RELAY - REMOVAL, WIPER . . . 8R-24
HINGE - INSTALLATION . . 23-119,23-123,23-131,
23-137
HINGE - REMOVAL......23-119,23-123,23-131,
23-137
HITCH - INSTALLATION, TRAILER.........13-9
HITCH - REMOVAL, TRAILER............13-9
HOISTING RECOMMENDATIONS -
STANDARD PROCEDURE.................0-4
HOLDDOWN - DESCRIPTION, BATTERY . . . 8F-17
HOLDDOWN - INSTALLATION, BATTERY . . . 8F-17
HOLDDOWN - OPERATION, BATTERY.....8F-17
HOLDDOWN - REMOVAL, BATTERY......8F-17
HOLDING CLUTCHES - DESCRIPTION
....21-131
HOLDING CLUTCHES - OPERATION
.....21-132
HOLE REPAIR - DESCRIPTION,
THREADED
........................Intro.-4
HONING - STANDARD PROCEDURE,
CYLINDER BORE
......................9-39
HOOD - INSTALLATION
...............23-119HOOD - REMOVAL...................23-119
HOOD AJAR SWITCH - DESCRIPTION....8Q-11
HOOD AJAR SWITCH - DIAGNOSIS AND
TESTING...........................8Q-12
HOOD AJAR SWITCH - INSTALLATION....8Q-12
HOOD AJAR SWITCH - OPERATION......8Q-12
HOOD AJAR SWITCH - REMOVAL.......8Q-12
HOOD AJAR SWITCH BRACKET -
INSTALLATION......................8Q-13
HOOD AJAR SWITCH BRACKET -
REMOVAL..........................8Q-13
HOOD AJAR SWITCH STRIKER -
INSTALLATION......................8Q-14
HOOD AJAR SWITCH STRIKER -
REMOVAL..........................8Q-13
HOOK - INSTALLATION, FRONT TOW......13-8
HOOK - INSTALLATION, REAR TOW.......13-8
HOOK - REMOVAL, FRONT TOW..........13-8
HOOK - REMOVAL, REAR TOW...........13-8
HORN - DIAGNOSIS AND TESTING.......8H-2
HORN - INSTALLATION.................8H-3
HORN - REMOVAL....................8H-3
HORN RELAY - DIAGNOSIS AND
TESTING............................8H-3
HORN RELAY - INSTALLATION...........8H-3
HORN RELAY - REMOVAL..............8H-3
HORN SWITCH - DESCRIPTION..........8H-4
HORN SWITCH - DIAGNOSIS AND
TESTING..............................8H-4
HORN SYSTEM - DESCRIPTION..........8H-1
HORN SYSTEM - DIAGNOSIS AND
TESTING............................8H-1
HORN SYSTEM - OPERATION............8H-1
HOSE - INSTALLATION, FRONT BRAKE.....5-10
HOSE - INSTALLATION, PRESSURE......19-21
HOSE - INSTALLATION, REAR BRAKE......5-10
HOSE - REMOVAL, FRONT...............5-9
HOSE - REMOVAL, PRESSURE..........19-21
HOSE - REMOVAL, REAR BRAKE..........5-9
HOSE CLAMPS - DESCRIPTION...........7-2
HOSE CLAMPS - OPERATION.............7-3
HOSE (GEAR TO THE COOLER) -
INSTALLATION, RETURN...............19-22
HOSE (GEAR TO THE COOLER) -
REMOVAL, RETURN..................19-21
HOSE (RESERVOIR TO THE COOLER) -
INSTALLATION, RETURN...............19-22
HOSE (RESERVOIR TO THE COOLER) -
REMOVAL, RETURN..................19-21
HOSES - DIAGNOSIS AND TESTING,
BRAKE LINE..........................5-8
HOSES/LINES/TUBES PRECAUTIONS -
CAUTION, REFRIGERANT
..............24-40
HOSES/TUBES - DESCRIPTION, FRONT
WASHER
...........................8R-10
HOSES/TUBES - DESCRIPTION, REAR
WASHER
...........................8R-35
HOSES/TUBES - OPERATION, FRONT
WASHER
...........................8R-10
HOSES/TUBES - OPERATION, REAR
WASHER
...........................8R-36
HOUSING - ASSEMBLY, HVAC
...........24-34
HOUSING - DISASSEMBLY, HVAC
........24-34
HOUSING - INSTALLATION, HVAC
........24-34
HOUSING - REMOVAL, HVAC
...........24-33
HOUSING BUSHING - NV3550 -
INSTALLATION, EXTENSION
............21-74
HOUSING BUSHING - NV3550 -
REMOVAL, EXTENSION
................21-73
HOUSING FLUID LEAK - DIAGNOSIS AND
TESTING, CONVERTER
................21-80
HOUSING SEAL - INSTALLATION,
ADAPTER
..........................21-124
HOUSING SEAL - NV1500 -
INSTALLATION, EXTENSION
............21-32
HOUSING SEAL - NV1500 - REMOVAL,
EXTENSION
.........................21-32
HOUSING SEAL - NV3550 -
INSTALLATION, EXTENSION
............21-74
HOUSING SEAL - NV3550 - REMOVAL,
EXTENSION
.........................21-74
HOUSING SEAL - REMOVAL, ADAPTER
. . 21-124
HOW TO USE WIRING DIAGRAMS -
DESCRIPTION
.....................8W-01-1
HUB / BEARING - INSTALLATION
..........2-9
HUB / BEARING - REMOVAL
..............2-9
12 INDEXKJ
Description Group-Page Description Group-Page Description Group-Page
Page 1752 of 1803
HVAC CONTROL ASSEMBLY WINDOW
DEFOGGER FUNCTION - DIAGNOSIS
AND TESTING, REAR..................8G-9
HVAC HOUSING - ASSEMBLY...........24-34
HVAC HOUSING - DISASSEMBLY........24-34
HVAC HOUSING - INSTALLATION........24-34
HVAC HOUSING - REMOVAL............24-33
HYDRAULIC LASH ADJUSTER -
DIAGNOSIS AND TESTING..........9-19,9-30
HYDRAULIC PRESSURE TEST -
DIAGNOSIS AND TESTING.............21-79
HYDRAULIC SCHEMATICS, SCHEMATICS
AND DIAGRAMS....................21-100
HYDROMETER TEST - STANDARD
PROCEDURE........................8F-11
IDENTIFICATION - DESCRIPTION,
FASTENER.........................Intro.-1
IDENTIFICATION AND INFORMATION -
DESCRIPTION, SECTION.............8W-01-6
IDENTIFICATION NUMBER -
DESCRIPTION, VEHICLE..............Intro.-8
IDLE AIR CONTROL MOTOR -
DESCRIPTION.......................14-35
IDLE AIR CONTROL MOTOR -
INSTALLATION.......................14-36
IDLE AIR CONTROL MOTOR -
OPERATION.........................14-35
IDLE AIR CONTROL MOTOR - REMOVAL . . 14-36
IDLER SHAFT - INSTALLATION...........9-77
IDLER SHAFT - REMOVAL...............9-77
IGNITION CIRCUIT SENSE -
DESCRIPTION.........................8E-13
IGNITION CIRCUIT SENSE - OPERATION . . 8E-15
IGNITION COIL - DESCRIPTION...........8I-9
IGNITION COIL - INSTALLATION.........8I-10
IGNITION COIL - OPERATION.............8I-9
IGNITION COIL - REMOVAL.............8I-10
IGNITION COIL CAPACITOR -
DESCRIPTION........................8I-16
IGNITION COIL CAPACITOR -
INSTALLATION.......................8I-16
IGNITION COIL CAPACITOR - OPERATION . . 8I-16
IGNITION COIL CAPACITOR - REMOVAL . . . 8I-16
IGNITION COIL RESISTANCE, 2.4L.........8I-2
IGNITION COIL RESISTANCE, 3.7L V-6.....8I-3
IGNITION CONTROL - DESCRIPTION.......8I-1
IGNITION CONTROL - OPERATION.........8I-1
IGNITION SWITCH - DESCRIPTION........19-8
IGNITION SWITCH - DESCRIPTION,
KEY-IN.............................19-10
IGNITION SWITCH - DIAGNOSIS AND
TESTING............................19-8
IGNITION SWITCH - DIAGNOSIS AND
TESTING, KEY-IN.....................19-10
IGNITION SWITCH INSTALLATION,
INSTALLATION........................19-9
IGNITION SWITCH REMOVAL, REMOVAL . . . 19-9
IGNITION SYSTEM - TORQUE............8I-3
IGNITION TIMING - SPECIFICATIONS......8I-2
IGNITION-OFF DRAW TEST - STANDARD
PROCEDURE........................8F-14
ILLUMINATION BULB - INSTALLATION,
COMPASS MINI-TRIP
.................8L-75
ILLUMINATION BULB - INSTALLATION,
HEATER-A/C CONTROL
................8L-78
ILLUMINATION BULB - INSTALLATION,
TRANSMISSION RANGE INDICATOR
......8L-83
ILLUMINATION BULB - REMOVAL,
COMPASS MINI-TRIP
.................8L-74
ILLUMINATION BULB - REMOVAL,
HEATER-A/C CONTROL
................8L-78
ILLUMINATION BULB - REMOVAL,
TRANSMISSION RANGE INDICATOR
......8L-82
IMMOBILIZER MODULE - DESCRIPTION,
SENTRY KEY
........................8E-15
IMMOBILIZER MODULE - INSTALLATION,
SENTRY KEY
........................8E-18
IMMOBILIZER MODULE - OPERATION,
SENTRY KEY
........................8E-16
IMMOBILIZER MODULE - REMOVAL,
SENTRY KEY
........................8E-17
IMPACT AIRBAG CONTROL MODULE -
DESCRIPTION, SIDE
..................8O-43
IMPACT AIRBAG CONTROL MODULE -
INSTALLATION, SIDE
.................8O-45
IMPACT AIRBAG CONTROL MODULE -
OPERATION, SIDE
....................8O-43IMPACT AIRBAG CONTROL MODULE -
REMOVAL, SIDE.....................8O-44
IMPACT SENSOR - DESCRIPTION,
FRONT.............................8O-21
IMPACT SENSOR - INSTALLATION,
FRONT.............................8O-22
IMPACT SENSOR - OPERATION, FRONT . . . 8O-21
IMPACT SENSOR - REMOVAL, FRONT....8O-22
INCORRECT FLUID LEVEL - DIAGNOSIS
AND TESTING, EFFECTS OF............21-125
INDICATOR - DESCRIPTION, ABS........8J-11
INDICATOR - DESCRIPTION, AIRBAG.....8J-12
INDICATOR - DESCRIPTION, BRAKE/
PARK BRAKE........................8J-13
INDICATOR - DESCRIPTION, CHARGING . . . 8J-15
INDICATOR - DESCRIPTION, COOLANT
LOW...............................8J-15
INDICATOR - DESCRIPTION, CRUISE.....8J-16
INDICATOR - DESCRIPTION, DOOR AJAR . . 8J-17
INDICATOR - DESCRIPTION, FOUR LOW
MODE.............................8J-29
INDICATOR - DESCRIPTION, FRONT FOG
LAMP..............................8J-19
INDICATOR - DESCRIPTION, FULL TIME . . . 8J-29
INDICATOR - DESCRIPTION, GATE AJAR . . 8J-20
INDICATOR - DESCRIPTION, GLASS
AJAR..............................8J-21
INDICATOR - DESCRIPTION, HIGH BEAM . . 8J-22
INDICATOR - DESCRIPTION, LOW FUEL . . . 8J-22
INDICATOR - DESCRIPTION, LOW OIL
PRESSURE..........................8J-23
INDICATOR - DESCRIPTION, OVERDRIVE
OFF ...............................8J-26
INDICATOR - DESCRIPTION, PART TIME . . 8J-29
INDICATOR - DESCRIPTION, REAR FOG
LAMP..............................8J-27
INDICATOR - DESCRIPTION, SEATBELT . . . 8J-27
INDICATOR - DESCRIPTION, SECURITY . . . 8J-28
INDICATOR - DESCRIPTION, SKIS........8J-31
INDICATOR - DESCRIPTION, TRANS
TEMP..............................8J-33
INDICATOR - DESCRIPTION, TURN
SIGNAL............................8J-34
INDICATOR - DESCRIPTION, WAIT-TO-
START .............................8J-35
INDICATOR - DESCRIPTION, WASHER
FLUID..............................8J-35
INDICATOR - DESCRIPTION, WATER-IN-
FUEL..............................8J-37
INDICATOR - DIAGNOSIS AND TESTING,
BRAKE.............................8J-14
INDICATOR - DIAGNOSIS AND TESTING,
WASHER FLUID......................8J-36
INDICATOR - OPERATION, ABS..........8J-11
INDICATOR - OPERATION, AIRBAG.......8J-12
INDICATOR - OPERATION, BRAKE/PARK
BRAKE.............................8J-13
INDICATOR - OPERATION, CHARGING....8J-15
INDICATOR - OPERATION, COOLANT
LOW...............................8J-16
INDICATOR - OPERATION, CRUISE.......8J-17
INDICATOR - OPERATION, DOOR AJAR . . . 8J-17
INDICATOR - OPERATION, FOUR LOW
MODE.............................8J-30
INDICATOR - OPERATION, FRONT FOG
LAMP..............................8J-19
INDICATOR - OPERATION, FULL TIME....8J-30
INDICATOR - OPERATION, GATE AJAR....8J-20
INDICATOR - OPERATION, GLASS AJAR . . . 8J-21
INDICATOR - OPERATION, HIGH BEAM
....8J-22
INDICATOR - OPERATION, LOW FUEL
.....8J-22
INDICATOR - OPERATION, LOW OIL
PRESSURE
..........................8J-23
INDICATOR - OPERATION, OVERDRIVE
OFF
...............................8J-26
INDICATOR - OPERATION, PART TIME
....8J-29
INDICATOR - OPERATION, REAR FOG
LAMP
..............................8J-27
INDICATOR - OPERATION, SEATBELT
.....8J-28
INDICATOR - OPERATION, SECURITY
.....8J-28
INDICATOR - OPERATION, SKIS
.........8J-31
INDICATOR - OPERATION, TRANS TEMP
. . 8J-34
INDICATOR - OPERATION, TURN SIGNAL
. . 8J-34
INDICATOR - OPERATION, WAIT-TO-
START
.............................8J-35
INDICATOR - OPERATION, WASHER
FLUID
..............................8J-36INDICATOR - OPERATION, WATER-IN-
FUEL..............................8J-37
INDICATOR ILLUMINATION BULB -
INSTALLATION, TRANSMISSION
RANGE.............................8L-83
INDICATOR ILLUMINATION BULB -
REMOVAL, TRANSMISSION RANGE......8L-82
INDICATOR LAMP (MIL) - DESCRIPTION,
MALFUNCTION.......................8J-24
INDICATOR LAMP (MIL) - OPERATION,
MALFUNCTION.......................8J-24
INDICATOR TEST - STANDARD
PROCEDURE, BUILT-IN................8F-10
INDICATORS - DIAGNOSIS AND
TESTING, TREAD WEAR................22-8
INFLATION - DIAGNOSIS AND TESTING,
TIRE................................22-7
INITIAL OPERATION - STANDARD
PROCEDURE, POWER STEERING
PUMP.............................19-18
INITIALIZATION - STANDARD
PROCEDURE, SKIS....................8Q-8
INJECTION - DESCRIPTION, FUEL........14-29
INJECTOR - DESCRIPTION, FUEL........14-33
INJECTOR - DIAGNOSIS AND TESTING,
FUEL..............................14-33
INJECTOR - OPERATION, FUEL..........14-33
INLET FILTER - INSTALLATION..........14-28
INLET FILTER - REMOVAL..............14-28
INPUT - OPERATION, ASD SENSE - PCM . . . 8I-4
INPUT CLUTCH ASSEMBLY - ASSEMBLY . 21-138
INPUT CLUTCH ASSEMBLY -
DESCRIPTION......................21-133
INPUT CLUTCH ASSEMBLY -
DISASSEMBLY......................21-135
INPUT CLUTCH ASSEMBLY - OPERATION . 21-135
INPUT SPEED SENSOR - DESCRIPTION . . 21-143
INPUT SPEED SENSOR - INSTALLATION . 21-143
INPUT SPEED SENSOR - OPERATION....21-143
INPUT SPEED SENSOR - REMOVAL.....21-143
INSTRUMENT CLUSTER - ASSEMBLY.....8J-10
INSTRUMENT CLUSTER - DESCRIPTION . . . 8J-2
INSTRUMENT CLUSTER - DIAGNOSIS
AND TESTING........................8J-7
INSTRUMENT CLUSTER - DISASSEMBLY . . . 8J-9
INSTRUMENT CLUSTER - INSTALLATION . . 8J-11
INSTRUMENT CLUSTER - OPERATION.....8J-4
INSTRUMENT CLUSTER - REMOVAL......8J-9
INSTRUMENT PANEL ANTENNA CABLE -
INSTALLATION.......................8A-8
INSTRUMENT PANEL ANTENNA CABLE -
REMOVAL...........................8A-7
INSTRUMENT PANEL ASSEMBLY -
INSTALLATION......................23-151
INSTRUMENT PANEL ASSEMBLY -
REMOVAL.........................23-149
INSTRUMENT PANEL CENTER BEZEL -
INSTALLATION......................23-154
INSTRUMENT PANEL CENTER BEZEL -
REMOVAL.........................23-154
INSTRUMENT PANEL DRIVER SIDE
BEZELS - INSTALLATION..............23-154
INSTRUMENT PANEL DRIVER SIDE
BEZELS - REMOVAL.................23-153
INSTRUMENT PANEL END CAP -
INSTALLATION
......................23-153
INSTRUMENT PANEL END CAP -
REMOVAL
.........................23-153
INSTRUMENT PANEL PASSENGER SIDE
BEZEL - INSTALLATION
...............23-154
INSTRUMENT PANEL PASSENGER SIDE
BEZEL - REMOVAL
..................23-154
INSTRUMENT PANEL TOP COVER -
INSTALLATION
......................23-153
INSTRUMENT PANEL TOP COVER -
REMOVAL
.........................23-152
INTAKE AIR TEMPERATURE SENSOR -
DESCRIPTION
.......................14-36
INTAKE AIR TEMPERATURE SENSOR -
INSTALLATION
.......................14-38
INTAKE AIR TEMPERATURE SENSOR -
OPERATION
.........................14-36
INTAKE AIR TEMPERATURE SENSOR -
REMOVAL
..........................14-37
INTAKE MANIFOLD - DESCRIPTION
.......9-68
INTAKE MANIFOLD - INSTALLATION
.......9-69
INTAKE MANIFOLD - REMOVAL
..........9-68
KJINDEX 13
Description Group-Page Description Group-Page Description Group-Page
Page 1753 of 1803
INTAKE MANIFOLD LEAKS - DIAGNOSIS
AND TESTING........................9-68
INTAKE/EXHAUST VALVES & SEATS -
DESCRIPTION........................9-26
INTAKE/EXHAUST VALVES & SEATS -
INSTALLATION....................9-28,9-36
INTAKE/EXHAUST VALVES & SEATS -
REMOVAL.......................9-27,9-35
INTERIOR - DESCRIPTION, LAMPS/
LIGHTING..........................8L-65
INTERIOR - DIAGNOSIS AND TESTING,
LAMPS/LIGHTING....................8L-68
INTERIOR - OPERATION, LAMPS/
LIGHTING..........................8L-67
INTERIOR - SPECIFICATIONS,
LAMPS/LIGHTING....................8L-71
INTERLOCK CABLE - INSTALLATION,
PARK .............................21-153
INTERLOCK CABLE - REMOVAL, PARK . . . 21-153
INTERLOCK SYSTEM - DESCRIPTION,
BRAKE TRANSMISSION SHIFT.........21-124
INTERLOCK SYSTEM - DIAGNOSIS AND
TESTING, BRAKE TRANSMISSION
SHIFT.............................21-125
INTERLOCK SYSTEM - OPERATION,
BRAKE TRANSMISSION SHIFT.........21-125
INTERMEDIATE SHAFT - INSTALLATION . . . 19-11
INTERMEDIATE SHAFT - REMOVAL......19-11
INTERNATIONAL SYMBOLS -
DESCRIPTION......................Intro.-4
INTERNATIONAL SYMBOLS -
DESCRIPTION.........................0-1
INTRODUCTION - DIAGNOSIS AND
TESTING, ENGINE DIAGNOSIS............9-4
INTRUSION TRANSCEIVER MODULE -
DESCRIPTION.......................8Q-14
INTRUSION TRANSCEIVER MODULE -
INSTALLATION......................8Q-16
INTRUSION TRANSCEIVER MODULE -
OPERATION.........................8Q-15
INTRUSION TRANSCEIVER MODULE -
REMOVAL..........................8Q-15
INVERTED FLARING - STANDARD
PROCEDURE, DOUBLE..................5-8
IOD FUSE - DESCRIPTION...........8W-97-3
IOD FUSE - INSTALLATION...........8W-97-3
IOD FUSE - OPERATION.............8W-97-3
IOD FUSE - REMOVAL..............8W-97-3
ISO FLARING - STANDARD PROCEDURE....5-8
JOINT - DESCRIPTION, UPPER
SUSPENSION ARM, BUSHINGS, AND
BALL...............................2-20
JOINT - DIAGNOSIS AND TESTING,
LOWER BALL........................2-10
JOINT - INSTALLATION, UPPER BALL.....2-20
JOINT - OPERATION, UPPER
SUSPENSION ARM, BUSHINGS, AND
BALL...............................2-20
JOINT - REMOVAL, UPPER BALL.........2-20
JOINT/BOOT-INNER - INSTALLATION, CV . . . 3-17
JOINT/BOOT-INNER - REMOVAL, CV.......3-15
JOINT/BOOT-OUTER - INSTALLATION, CV . . . 3-13
JOINT/BOOT-OUTER - REMOVAL, CV......3-12
JOINTS - ASSEMBLY, SINGLE CARDAN
UNIVERSAL...........................3-9
JOINTS - DISASSEMBLY, SINGLE
CARDAN UNIVERSAL...................3-8
JOUNCE BUMPER - INSTALLATION.......2-19
JOUNCE BUMPER - REMOVAL...........2-19
JUMP STARTING PROCEDURE -
STANDARD PROCEDURE
.................0-5
JUNCTION BLOCK - DESCRIPTION
.....8W-97-4
JUNCTION BLOCK - DESCRIPTION
........5-20
JUNCTION BLOCK - DIAGNOSIS AND
TESTING
.........................8W-97-4
JUNCTION BLOCK - INSTALLATION
.......5-20
JUNCTION BLOCK - OPERATION
......8W-97-4
JUNCTION BLOCK - OPERATION
..........5-20
JUNCTION BLOCK - REMOVAL
...........5-20
KEY - DESCRIPTION, TRANSPONDER
....8Q-18
KEY - OPERATION, TRANSPONDER
......8Q-18
KEY IMMOBILIZER MODULE -
DESCRIPTION, SENTRY
................8E-15
KEY IMMOBILIZER MODULE -
INSTALLATION, SENTRY
...............8E-18
KEY IMMOBILIZER MODULE -
OPERATION, SENTRY
.................8E-16KEY IMMOBILIZER MODULE - REMOVAL,
SENTRY............................8E-17
KEY TRANSPONDER PROGRAMMING -
STANDARD PROCEDURE, SENTRY........8Q-8
KEY-IN IGNITION SWITCH -
DESCRIPTION.......................19-10
KEY-IN IGNITION SWITCH - DIAGNOSIS
AND TESTING.......................19-10
KEYLESS ENTRY MODULE -
DESCRIPTION, REMOTE................8N-7
KEYLESS ENTRY MODULE - DIAGNOSIS
AND TESTING, REMOTE................8N-7
KEYLESS ENTRY MODULE -
INSTALLATION, REMOTE...............8N-7
KEYLESS ENTRY MODULE - OPERATION,
REMOTE............................8N-7
KEYLESS ENTRY MODULE - REMOVAL,
REMOTE............................8N-7
KEYLESS ENTRY TRANSMITTER -
DIAGNOSIS AND TESTING, REMOTE......8N-8
KEYLESS ENTRY TRANSMITTER -
SPECIFICATIONS, REMOTE..............8N-9
KNEE BLOCKER - INSTALLATION.......23-155
KNEE BLOCKER - REMOVAL...........23-155
KNOCK SENSOR - DESCRIPTION.........8I-11
KNOCK SENSOR - INSTALLATION........8I-12
KNOCK SENSOR - OPERATION..........8I-11
KNOCK SENSOR - REMOVAL............8I-12
KNUCKLE - INSTALLATION...............2-9
KNUCKLE - REMOVAL...................2-9
LABEL - DESCRIPTION, VEHICLE
EMISSION CONTROL INFORMATION
(VECI)............................Intro.-8
LABEL - DESCRIPTION, VEHICLE SAFETY
CERTIFICATION.....................Intro.-9
LACE - INSTALLATION, OPENING TRIM . . 23-180
LACE - REMOVAL, OPENING TRIM......23-180
LAMP BULB - INSTALLATION, ASH
RECEIVER..........................8L-71
LAMP BULB - INSTALLATION, CARGO....8L-73
LAMP BULB - INSTALLATION, CENTER
HIGH MOUNTED STOP................8L-19
LAMP BULB - INSTALLATION,
COURTESY.........................8L-76
LAMP BULB - INSTALLATION, FRONT....8L-27
LAMP BULB - INSTALLATION, FRONT
FOG ...............................8L-22
LAMP BULB - INSTALLATION, FRONT
POSITION..........................8L-28
LAMP BULB - INSTALLATION, LICENSE
PLATE .............................8L-45
LAMP BULB - INSTALLATION, READING . . . 8L-79
LAMP BULB - INSTALLATION, REAR.....8L-59
LAMP BULB - INSTALLATION, REPEATER . . 8L-60
LAMP BULB - INSTALLATION, VANITY....8L-84
LAMP BULB - REMOVAL, ASH RECEIVER . . 8L-71
LAMP BULB - REMOVAL, CARGO........8L-72
LAMP BULB - REMOVAL, CENTER HIGH
MOUNTED STOP.....................8L-18
LAMP BULB - REMOVAL, COURTESY.....8L-75
LAMP BULB - REMOVAL, FRONT........8L-26
LAMP BULB - REMOVAL, FRONT FOG....8L-21
LAMP BULB - REMOVAL, FRONT
POSITION..........................8L-28
LAMP BULB - REMOVAL, LICENSE
PLATE .............................8L-44
LAMP BULB - REMOVAL, READING......8L-79
LAMP BULB - REMOVAL, REAR.........8L-58
LAMP BULB - REMOVAL, REPEATER.....8L-60
LAMP BULB - REMOVAL, VANITY........8L-83
LAMP INDICATOR - DESCRIPTION,
FRONT FOG.........................8J-19
LAMP INDICATOR - DESCRIPTION, REAR
FOG ...............................8J-27
LAMP INDICATOR - OPERATION, FRONT
FOG ...............................8J-19
LAMP INDICATOR - OPERATION, REAR
FOG ...............................8J-27
LAMP (MIL) - DESCRIPTION,
MALFUNCTION INDICATOR.............8J-24
LAMP (MIL) - OPERATION,
MALFUNCTION INDICATOR
.............8J-24
LAMP RELAY - DESCRIPTION, DAYTIME
RUNNING
...........................8L-20
LAMP RELAY - DESCRIPTION, FRONT
FOG
...............................8L-22
LAMP RELAY - DESCRIPTION, PARK
.....8L-54
LAMP RELAY - DESCRIPTION, REAR FOG
. 8L-56LAMP RELAY - DIAGNOSIS AND
TESTING, FRONT FOG.................8L-23
LAMP RELAY - DIAGNOSIS AND
TESTING, PARK......................8L-55
LAMP RELAY - DIAGNOSIS AND
TESTING, REAR FOG..................8L-57
LAMP RELAY - INSTALLATION, DAYTIME
RUNNING...........................8L-21
LAMP RELAY - INSTALLATION, FRONT
FOG ...............................8L-24
LAMP RELAY - INSTALLATION, PARK.....8L-56
LAMP RELAY - INSTALLATION, REAR
FOG ...............................8L-58
LAMP RELAY - OPERATION, DAYTIME
RUNNING...........................8L-20
LAMP RELAY - OPERATION, FRONT FOG . . 8L-22
LAMP RELAY - OPERATION, PARK.......8L-54
LAMP RELAY - OPERATION, REAR FOG . . . 8L-57
LAMP RELAY - REMOVAL, DAYTIME
RUNNING...........................8L-21
LAMP RELAY - REMOVAL, FRONT FOG . . . 8L-24
LAMP RELAY - REMOVAL, PARK........8L-55
LAMP RELAY - REMOVAL, REAR FOG....8L-58
LAMP REPLACEMENT - STANDARD
PROCEDURE, CMTC...................8M-2
LAMP REPLACEMENT - STANDARD
PROCEDURE, COURTESY...............8M-2
LAMP SWITCH - DESCRIPTION, BACKUP . . 8L-15
LAMP SWITCH - DESCRIPTION, BRAKE . . . 8L-16
LAMP SWITCH - DIAGNOSIS AND
TESTING, BACKUP.....................8L-15
LAMP SWITCH - DIAGNOSIS AND
TESTING, BRAKE.....................8L-17
LAMP SWITCH - INSTALLATION, BRAKE . . 8L-18
LAMP SWITCH - INSTALLATION, CARGO . . 8L-74
LAMP SWITCH - INSTALLATION,
READING...........................8L-80
LAMP SWITCH - OPERATION, BACKUP . . . 8L-15
LAMP SWITCH - OPERATION, BRAKE.....8L-16
LAMP SWITCH - REMOVAL, BRAKE......8L-17
LAMP SWITCH - REMOVAL, CARGO......8L-73
LAMP SWITCH - REMOVAL, READING....8L-80
LAMP UNIT - ADJUSTMENT, FRONT FOG . . 8L-25
LAMP UNIT - INSTALLATION, ASH
RECEIVER..........................8L-72
LAMP UNIT - INSTALLATION, CARGO.....8L-74
LAMP UNIT - INSTALLATION, CENTER
HIGH MOUNTED STOP................8L-19
LAMP UNIT - INSTALLATION, COURTESY . . 8L-77
LAMP UNIT - INSTALLATION, FRONT.....8L-28
LAMP UNIT - INSTALLATION, FRONT
FOG ...............................8L-25
LAMP UNIT - INSTALLATION, LICENSE
PLATE .............................8L-46
LAMP UNIT - INSTALLATION, READING . . . 8L-81
LAMP UNIT - INSTALLATION, REAR......8L-60
LAMP UNIT - INSTALLATION, REPEATER . . 8L-61
LAMP UNIT - REMOVAL, ASH RECEIVER . . 8L-72
LAMP UNIT - REMOVAL, CARGO........8L-74
LAMP UNIT - REMOVAL, CENTER HIGH
MOUNTED STOP.....................8L-19
LAMP UNIT - REMOVAL, COURTESY.....8L-76
LAMP UNIT - REMOVAL, FRONT.........8L-27
LAMP UNIT - REMOVAL, FRONT FOG.....8L-25
LAMP UNIT - REMOVAL, LICENSE PLATE . . 8L-45
LAMP UNIT - REMOVAL, READING.......8L-81
LAMP UNIT - REMOVAL, REAR..........8L-59
LAMP UNIT - REMOVAL, REPEATER......8L-60
LAMPS/LIGHTING - EXTERIOR -
DESCRIPTION........................8L-2
LAMPS/LIGHTING - EXTERIOR -
DIAGNOSIS AND TESTING..............8L-7
LAMPS/LIGHTING - EXTERIOR -
OPERATION..........................8L-5
LAMPS/LIGHTING - EXTERIOR -
SPECIFICATIONS.....................8L-15
LAMPS/LIGHTING - INTERIOR -
DESCRIPTION.......................8L-65
LAMPS/LIGHTING - INTERIOR -
DIAGNOSIS AND TESTING.............8L-68
LAMPS/LIGHTING - INTERIOR -
OPERATION
.........................8L-67
LAMPS/LIGHTING - INTERIOR -
SPECIFICATIONS
.....................8L-71
LASH ADJUSTER - DIAGNOSIS AND
TESTING, HYDRAULIC
..............9-19,9-30
LATCH - ACCESS PANEL - DESCRIPTION
. 23-139
LATCH - ACCESS PANEL - INSTALLATION
. 23-139
14 INDEXKJ
Description Group-Page Description Group-Page Description Group-Page
