TOWING A DISABLED
VEHICLE
This section describes procedures for towing a
disabled vehicle using a commercial towing
service.
Towing ConditionWheels OFF the
GroundManual
Transmission6-Speed Automatic
(FWD Only)6-Speed Automatic
4WDCVT Automatic
Transmission
Flat Tow NONE
•Transmission in
NEUTRAL
•Key in ACC or
ON/RUN position
If transmission is
operable:
•Transmission in
NEUTRAL
•Key in ACC or
ON/RUN position
•25 mph (40 km/h)
maxspeed
•15 miles (24 km)
maxdistance
If transmission is
operable:
•Transmission in
NEUTRAL
•Key in ACC or
ON/RUN position
•25 mph (40 km/h)
maxspeed
•15 miles (24 km)
maxdistance
NOT ALLOWED
Wheel Lift or Dolly
To wRearNOT ALLOWED NOT ALLOWED NOT ALLOWED
Front FWD ModelsONLY OK NOT ALLOWEDFWD ModelsONLY
FlatbedALL BEST METHOD BEST METHOD BEST METHOD BEST METHOD
247

With Ignition Key
Automatic Transmission
•Front Wheel Drive (FWD) vehicles can be
towed with the front wheels elevated, or on a
flatbed truck (all four wheelsOFFthe
ground).
•Four-Wheel Drive (4WD) vehicles can be
towed on a flatbed truck (all four wheelsOFF
the ground).
If the transmission is operable, Front Wheel
Drive (FWD) and Four Wheel Drive (4WD)
vehicles, with the 6-speed automatic transmis-
sion only (NOTthe Continuously Variable auto-
matic transmission [CVT]), may be flat towed
(with all four wheels on the ground) under the
following conditions:
•The transmission must be in NEUTRAL.
•The key must be in the ACC or ON/RUN
position.
•The towing speed must not exceed 25 mph
(40 km/h).
•The towing distance must not exceed 15
miles (24 km).Front Wheel Drive (FWD) models (with 6-speed
automaticonly) may also be towed (under the
same limitations shown above) with the rear
wheels elevated.
CAUTION!
DO NOT flat tow any vehicle equipped with a
CVT automatic transmission. Damage to the
drivetrain will result. If these vehicles require
towing, make sure all drive wheels are OFF
the ground.
Towing this vehicle in violation of the above
requirements can cause severe transmission
and/or transfer case damage. Damage from
improper towing is not covered under the
New Vehicle Limited Warranty..
If the vehicle’s battery is discharged, refer to
“Gear Selector Override” in this section for
instructions on shifting the automatic transmis-
sion out of PARK for towing.Manual Transmission
•Front Wheel Drive (FWD) or Four-Wheel
Drive (4WD) vehicles can be flat towed (all
four wheels on the ground) with the transmis-
sion in NEUTRAL and the key in the ACC or
ON/RUN position.
•FWD vehicles can be towed with the front
wheels elevated.
•FWD or 4WD vehicles can be towed on a
flatbed truck (all wheelsOFFthe ground).
CAUTION!
•DO NOTflat tow any disabled vehicle if
condition is related to the clutch, transmis-
sion or driveline. Additional damage to the
drivetrain could result.
•
Towing this vehicle in violation of the above
requirements can cause severe engine,
transmission, or drivetrain damage. Damage
from improper towing is not covered under
the New Vehicle Limited Warranty.
248

All Transmissions
If you must use the accessories (wipers, de-
froster, etc.) while being towed, the key must be
in the ON/RUN position, not the ACC position.
Make certain the transmission remains in
NEUTRAL.
CAUTION!
•Do not use sling-type equipment when
towing. Vehicle damage may occur.
•When securing the vehicle to a flatbed
truck, do not attach to front or rear suspen-
sion components. Damage to your vehicle
may result from improper towing.Without The Ignition Key
Special care must be taken when the vehicle is
towed with the ignition in the LOCK/OFF posi-
tion. The only approved method of towing with-
out the ignition key is with a flatbed truck.
Proper towing equipment is necessary to pre-
vent damage to the vehicle.
249

250

7
MAINTAINING YOUR VEHICLE
•ENGINE COMPARTMENT — 2.0L . . . . . . . . . . . . .. . . . . .253
•ENGINE COMPARTMENT — 2.4L . . . . . . . . . . . . .. . . . . .254
•ONBOARD DIAGNOSTIC SYSTEM — OBD II . . ..........255
•Onboard Diagnostic System (OBD II) Cybersecurity.......255
•Loose Fuel Filler Cap Message...................256
•REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . .256
•MAINTENANCE PROCEDURES . . . . . . . . . . . . . . ......256
•Engine Oil................................256
•Engine Oil Filter............................258
•Engine Air Cleaner Filter.......................258
•Maintenance-Free Battery.......................258
•Air Conditioner Maintenance.....................259
•Body Lubrication............................261
•Windshield Wiper Blades.......................261
•Adding Washer Fluid.........................261
•Exhaust System............................262
•Cooling System............................263
•Brake System..............................266
•Automatic Transmission (6-Speed) — If Equipped........267
251

•Automatic Transmission (CVT) — If Equipped.............268
•Manual Transmission — If Equipped..................269
•Rear Drive Assembly (RDA) — AWD/4WD Models Only.......270
•Power Transfer Unit (PTU) — AWD/4WD Models Only........270
•Appearance Care And Protection From Corrosion..........271
•FUSES......................................274•Integrated Power Module (IPM)......................275•VEHICLE STORAGE . . . . . . . . . . . . . . ...............278
•REPLACEMENT BULBS...........................279
•BULB REPLACEMENT . . . . . . . . . . . . . . . .............279
•Headlamps..................................279
•Fog Lamps.................................279
•Side Repeater Lamps...........................279
•Rear Tail/Stop Lamps...........................280
•Rear Turn Signal And Backup Lamps..................280
•License Lamps...............................280
•Center High-Mounted Stoplamp.....................280
•FLUID CAPACITIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .280
•FLUIDS, LUBRICANTS, AND GENUINE PARTS.............281
•Engine....................................281
•Chassis...................................282
252

ENGINE COMPARTMENT — 2.0L
1 — Washer Fluid Reservoir 6 — Air Cleaner Filter
2 — Power Steering Fluid Reservoir 7 — Coolant Pressure Cap
3 — Engine Oil Fill 8 — Engine Oil Dipstick
4 — Brake Fluid Reservoir 9 — Engine Coolant Reservoir
5 — Integrated Power Module (Fuses)
253

ENGINE COMPARTMENT — 2.4L
1 — Washer Fluid Reservoir 6 — Air Cleaner Filter
2 — Power Steering Fluid Reservoir 7 — Coolant Pressure Cap
3 — Engine Oil Fill 8 — Engine Oil Dipstick
4 — Brake Fluid Reservoir 9 — Engine Coolant Reservoir
5 — Integrated Power Module (Fuses)
254

ONBOARD DIAGNOSTIC
SYSTEM — OBD II
Your vehicle is equipped with a sophisticated
onboard diagnostic system called OBD II. This
system monitors the performance of the emis-
sions, engine, and automatic transmission con-
trol systems. When these systems are operat-
ing properly, your vehicle will provide excellent
performance and fuel economy, as well as
engine emissions well within current govern-
ment regulations.
If any of these systems require service, the
OBD II system will turn on the “Malfunction
Indicator Light” (MIL). It will also store diagnos-
tic codes and other information to assist your
service technician in making repairs. Although
your vehicle will usually be drivable and not
need towing, see your authorized dealer for
service as soon as possible.
CAUTION!
•Prolonged driving with the MIL on could
cause further damage to the emission con-
trol system. It could also affect fuel
economy and driveability. The vehicle
must be serviced before any emissions
tests can be performed.
•If the MIL is flashing while the engine is
running, severe catalytic converter dam-
age and power loss will soon occur. Imme-
diate service is required.
Onboard Diagnostic System (OBD II)
Cybersecurity
Your vehicle is required to have an Onboard
Diagnostic system (OBD II) and a connection
port to allow access to information related to the
performance of your emissions controls. Autho-
rized service technicians may need to access
this information to assist with the diagnosis and
service of your vehicle and emissions system.
WARNING!
•ONLY an authorized service technician
should connect equipment to the OBD II
connection port in order to diagnose or
service your vehicle.
•If unauthorized equipment is connected to
the OBD II connection port, such as a
driver-behavior tracking device, it may:
•Be possible that vehicle systems, in-
cluding safety related systems, could be
impaired or a loss of vehicle control
could occur that may result in an acci-
dent involving serious injury or death.
•Access, or allow others to access, infor-
mation stored in your vehicle systems,
including personal information.
For further information, refer to “Cybersecurity”
in the “Understanding Your Instrument Panel”
section.
255

Loose Fuel Filler Cap MessageAfter fuel is added, the vehicle diagnostic sys-
tem can determine if the fuel filler cap is possi-
bly loose or improperly installed. A “gASCAP”
message will be displayed in the instrument
cluster. Tighten the gas cap until a “clicking”
sound is heard. This is an indication that the gas
cap is properly tightened. Push the trip odom-
eter RESET button to turn off the message. If
the problem persists, the message will appear
the next time the vehicle is started. This might
indicate a damaged cap. If the problem is
detected twice in a row, the system will turn on
the MIL. Resolving the problem will turn the MIL
light off.
REPLACEMENT PARTS
Use of genuine MOPAR parts for normal/
scheduled maintenance and repairs is highly
recommended to ensure the designed perfor-
mance. Damage or failures caused by the use
of non-MOPAR parts for maintenance and re-
pairs will not be covered by the New Vehicle
Limited Warranty.
MAINTENANCE PROCEDURES
The pages that follow contain therequired
maintenance services determined by the engi-
neers who designed your vehicle.
Besides those maintenance items specified in
the fixed “Maintenance Schedule”, there are
other components which may require servicing
or replacement in the future.
CAUTION!
•Failure to properly maintain your vehicle or
perform repairs and service when neces-
sary could result in more costly repairs,
damage to other components or negatively
impact vehicle performance. Immediately
have potential malfunctions examined by
an authorized dealer or qualified repair
center.
(Continued)
CAUTION!(Continued)
•Your vehicle has been built with improved
fluids that protect the performance and
durability of your vehicle and also allow
extended maintenance intervals. Do not
use chemical flushes in these components
as the chemicals can damage your engine,
transmission, or air conditioning. Such
damage is not covered by the New Vehicle
Limited Warranty. If a flush is needed
because of component malfunction, use
only the specified fluid for the flushing
procedure.
Engine Oil
Checking Oil Level
To assure proper engine lubrication, the engine
oil must be maintained at the correct level.
Check the oil level at regular intervals, such as
every fuel stop.
The best time to check the engine oil level is
about five minutes after a fully warmed engine is
shut off. Do not check oil level before starting
256
