302 SERVICING AND MAINTENANCE
(Continued)
Keep the front of the radiator clean. If your
vehicle is equipped with air conditioning, keep
the front of the condenser clean.
Do not change the thermostat for Summer or
Winter operation. If replacement is ever neces-
sary, install ONLY the correct type thermostat.
O ther

designs may result in unsatisfactory
engine cooling performance, poor gas mileage,
and increased emissions.
BRAKE SYSTEM
In order to ensure brake system performance, all
brake system components should be inspected
periodically Ú page 287.
Brake Master Cylinder
The fluid level in the master cylinder should be
checked when performing under hood services, or
immediately if the Brake Warning Light is on.
Be sure to clean the top of the master cylinder area
before

removing the cap. If necessary, add fluid to
bring the fluid level up to the requirements
described on the brake fluid reservoir. Fluid level
can be expected to fall as the brake pads wear. The
brake fluid level should be checked when the pads
are replaced. However, low fluid level may be
caused by a leak and a checkup may be needed.
Use only manufacturer's recommended brake fluid
Ú page 345.
WARNING!
Riding the brakes can lead to brake failure and
possibly a collision. Driving with your foot resting
or riding on the brake pedal can result in
abnormally high brake temperatures, excessive
lining wear, and possible brake damage. Riding
the brakes may also reduce braking capacity in
an emergency.WARNING!
Use only manufacturer’s recommended brake
fluid
Ú page 345. Using the wrong type of
brake fluid can severely damage your brake
system
and/or impair its performance. The
proper type of brake fluid for your vehicle is
also identified on the original factory installed
hydraulic master cylinder reservoir.
To avoid contamination from foreign matter or
moisture, use only new brake fluid or fluid that
has been in a tightly closed container. Keep
the master cylinder reservoir cap secured at
all times. Brake fluid in an open container
absorbs moisture from the air resulting in a
lower boiling point. This may cause it to boil
unexpectedly during hard or prolonged
braking, resulting in sudden brake failure. This
could result in a collision.
Overfilling the brake fluid reservoir can result
in spilling brake fluid on hot engine parts,
causing the brake fluid to catch fire. Brake
fluid can also damage painted and vinyl
surfaces, care should be taken to avoid its
contact with these surfaces.
CAUTION!
Use of improper brake fluids will affect overall
clutch system performance. Improper brake
fluids may damage the clutch system resulting in
loss of clutch function and the ability to shift the
transmission.
WARNING!

SERVICING AND MAINTENANCE 303
(Continued)
AUTOMATIC TRANSMISSION
Special Additives
The manufacturer strongly recommends against
using any special additives in the transmission.
Automatic Transmission Fluid (ATF) is an
engine
ered product and its performance may be
impaired by supplemental additives. Therefore, do
not add any fluid additives to the transmission. The
only exception to this policy is the use of special
dyes for diagnosing fluid leaks. Avoid using
transmission sealers as they may adversely affect
seals.
Fluid Level Check
The fluid level is preset at the factory and does not
require adjustment under normal operating
conditions. Routine fluid level checks are not
required; therefore the transmission has no
dipstick. An authorized dealer can check your
transmission fluid level using special service tools.
If you notice fluid leakage or transmission
malfunction, visit an authorized dealer immediately to have the transmission fluid level
checked. Operating the vehicle with an improper
fluid level can cause severe transmission damage.
Fluid And Filter Changes
Under normal operating conditions, the fluid
installed at the factory will provide satisfactory
lubrication for the life of the vehicle.
Routine fluid and filter changes are not required.
However
,

change the fluid and filter if the fluid
becomes contaminated (with water, etc.), or if the
transmission is disassembled for any reason.
Selection Of Lubricant
It is important to use the proper transmission fluid
to ensure optimum transmission performance and
life. Use the manufacturer specified transmission
fluid Ú page 345. It is important to maintain the
transmission fluid at the correct level using the
r ecomme

nded fluid.
NOTE:
No chemical flushes should be used in any trans -
mission; only the approved lubricant should be
u sed.
FUSES
General InformationCAUTION!
Do not use chemical flushes in your
transmission as the chemicals can damage your
transmission components. Such damage is not
covered by the New Vehicle Limited Warranty.
CAUTION!
If a transmission fluid leak occurs, visit an
authorized dealer immediately. Severe
transmission damage may occur. An authorized
dealer has the proper tools to adjust the fluid
level accurately.CAUTION!
Using a transmission fluid other than the
manufacturer recommended fluid may cause
deterioration in transmission shift quality and/or
torque converter shudder Ú page 345.
WARNING!
When replacing a blown fuse, always use an
appropriate replacement fuse with the same
amp rating as the original fuse. Never replace
a fuse with another fuse of higher amp rating.
Never replace a blown fuse with metal wires or
any other material. Failure to use proper fuses
may result in serious personal injury, fire and/
or property damage.
Before replacing a fuse, make sure that the
ignition is off and that all the other services
are switched off and/or disengaged.
8

304 SERVICING AND MAINTENANCE
The fuses protect electrical systems against
excessive current.
When a device does not work, you must check the
electr

ical circuit inside the fuse for a break/melt.
Also please be aware that using power outlets for
extend
ed periods of time with the engine off may
result in vehicle battery discharge.
Blade Fuses

Access To The Fuses
The fuses are grouped into four controllers located
in the engine compartment, under the instrument
panel and on the inside of the left side cargo trim
panel.If the replaced fuse blows again, contact an
authorized dealer.
If a general protection fuse for safety systems
(air bag system, braking system), power unit
systems (engine system, gearbox system) or
steering system blows, contact an authorized
dealer.
WARNING!
1 — Fuse Element
2 — Blade Fuse with a good/functional fuse

element
3 — Blade fuse with a bad/not functional fuse
element (blown fuse)

342 TECHNICAL SPECIFICATIONS
Tighten the wheel bolts in a star pattern until each
bolt has been tightened twice. Ensure that the
socket is fully engaged on the lug nut/bolt.

Torque Patterns

After 25 miles (40 km), check the wheel bolt
torque

to be sure that all the lug nuts/bolts are
properly tightened.
FUEL REQUIREMENTS
While operating on gasoline with the required
octane number, hearing a light knocking sound
from the engine is not a cause for concern.
However, if the engine is heard making a heavy
knocking sound, see an authorized dealer
immediately. Use of gasoline with a lower than
recommended octane number can cause engine
failure and may void or not be covered by the New
Vehicle Limited Warranty.
Poor quality gasoline can cause problems such as
hard s

tarting, stalling, and hesitations. If you
experience these symptoms, try another brand of
gasoline before considering service for the vehicle.
1.3L TURBO ENGINE
This engine is designed to meet all
emission regulations, and provide
s a t
is
f
actory fuel economy and
performance, when using high-quality
unleaded regular gasoline having an octane rating
of 87, as specified by the (R+M)/2 Method.
The use of a 91 or higher octane premium gasoline
will a

llow these engines to operate to optimal
performance. This increase in performance is most
noticeable in hot weather or other heavier load
conditions, such as towing.
REFORMULATED GASOLINE
Many areas of the country require the use of
cleaner burning gasoline referred to as
“reformulated gasoline”. Reformulated gasoline
contains oxygenates and are specifically blended
to reduce vehicle emissions and improve air
quality.
The use of reformulated gasoline is recommended.
Proper l

y blended reformulated gasoline will
provide improved performance and durability of
engine and fuel system components.
GASOLINE/OXYGENATE BLENDS
Some fuel suppliers blend unleaded gasoline with
oxygenates such as ethanol.
WARNING!
To avoid the risk of forcing the vehicle off the
jack, do not fully tighten the wheel bolts until the
vehicle has been lowered. Failure to follow this
warning may result in serious injury.
CAUTION!
DO NOT use E-85, gasoline containing methanol,
or gasoline containing more than 15% ethanol
(E-15). Use of these blends may result in starting
and drivability problems, damage critical fuel
system components, cause emissions to exceed
the applicable standard, and/or cause the
Malfunction Indicator Light to illuminate. Please
observe pump labels as they should clearly
communicate if a fuel contains greater than
15% ethanol (E-15).

351
INDEX
A
About Your Brakes.........................................341Adding Engine Coolant (Antifreeze)...............300Adding Fuel....................................................122Adding Washing Fluid....................................294Additives, Fuel...............................................343Advance Phone Connectivity.........................172Air Bag...........................................................247Advance Front Air Bag...............................247Air Bag Operation......................................248Air Bag Warning Light................................246Driver Knee Air Bag...................................249Enhanced Accident Response.........252, 285Event Data Recorder (EDR).......................285Front Air Bag.............................................247If Deployment Occurs................................252Knee Impact Bolsters................................249Maintaining Your Air Bag System..............255Maintenance.............................................255Redundant Air Bag Warning Light.............247Side Air Bags.............................................249Transporting Pets......................................265Air Bag Light..................................70, 246, 265Air Cleaner, Engine (Engine Air Cleaner
Filter).............................................................296Air Conditioner Maintenance.........................296
Air Conditioner Refrigerant..................296, 297Air Conditioning.............................................297Air Conditioning Filter..............................48, 297Air Conditioning System................................296Air Conditioning, Operating Tips.......................47Air Pressure Tires.........................................................329AlarmArm The System..........................................20Disarm The System.....................................21Security Alarm......................................20, 72Alterations/ModificationsVehicle.........................................................10Android Auto........................................174, 176Android Auto™
S
.......................................174Antifreeze (Engine Coolant).................300, 344Disposal...................................................301Anti-Lock Brake System (ABS)......................221Anti-Lock Warning Light............................72, 76Apple CarPlay.......................................174, 178Apple CarPlay®
S
......................................176Assist, Hill Start.............................................227Audio Settings...............................................160Audio Systems (Radio)..................................133Auto Down Power Windows.............................53Auto Up Power Windows..................................53
Automatic Headlights.......................................38Automatic High Beams.....................................37Automatic Temperature Control (ATC)..............47Automatic Transmission.........................85, 303Adding Fluid.....................................303, 345Autostick......................................................87Fluid And Filter Change.............................303Fluid Change.............................................303Fluid Level Check......................................303Fluid Type........................................303, 345Special Additives......................................303Auxiliary Electrical Outlet (Power Outlet)..........50Auxiliary Power Outlet......................................50Axle Fluid.......................................................345Axle Lubrication............................................345
B
Back-Up Camera...........................................121Battery...................................................70, 294Charging System Light.................................70Keyless Key Fob Replacement....................15Belts, Seat....................................................265Blind Spot Monitoring...................................228BluetoothConnecting To A Particular Mobile Phone
Or Audio Device After Pairing
................168
11

352
Body Mechanism Lubrication........................297Brake Assist System......................................222Brake Control System, Electronic..................222Brake Fluid....................................................345Brake System......................................302, 341Anti-Lock (ABS)..........................................341Fluid Check...............................................345Master Cylinder.........................................302Warning Light..............................................70Brakes...........................................................302Brightness, Interior Lights................................40Bulbs, Light....................................................267
C
Camera..........................................................121Camera, Rear................................................121Capacities, Fluid............................................344Caps, Filler
Oil (Engine)................................................293Radiator (Coolant Pressure)......................301Car Washes...................................................338Carbon Monoxide Warning............................267CD..................................................................162Cellular Phone...............................................220Certification Label.........................................123Changing A Flat Tire.......................................271Chart, Tire Sizing............................................323Check Engine Light (Malfunction Indicator
Light)...............................................................78
Checking Your Vehicle For Safety..................265
Checks, Safety..............................................265Child Restraint..............................................255Child Restraints Booster Seats...........................................258Child Seat Installation..............................263How To Stow An unused ALR Seat Belt....262Infant And Child Restraints.......................257LATCH Positions.......................................259Locating The LATCH Anchorages..............260Lower Anchors And Tethers For Children..259Older Children And Child Restraints.........257Seating Positions......................................258Child Safety Locks...........................................25Clean Air Gasoline.........................................342CleaningWheels.....................................................334Climate Control................................................44Clutch...........................................................302Fluid.........................................................302Coin Holder......................................................49Cold Weather Operation..................................81Compact Spare Tire......................................333Connected Services......................................202Connected Services FAQ...............................215Connected Services Features.......................205Connected Services, Getting Started............203Connected Services, Introduction.................202ConnectorUCI...............................................................50
Universal Consumer Interface (UCI).............50
Console............................................................49Floor............................................................49Contract, Service...........................................347Controls........................................................151Cooling Pressure Cap (Radiator Cap)............301Cooling System.............................................299Adding Coolant (Antifreeze)......................300Coolant Level...................................299, 301Cooling Capacity.......................................344Disposal Of Used Coolant.........................301Drain, Flush, And Refill.............................300Inspection.................................................301Points To Remember................................301Pressure Cap............................................301Radiator Cap.............................................301Selection Of Coolant
(Antifreeze).........................300, 344, 345Corrosion Protection.....................................338Cruise Control (Speed Control).........................95Cruise Light...............................................76, 77Customer Assistance....................................346Customer Programmable Features...............134Cybersecurity................................................133
D
Daytime Running Lights...................................37Dealer Service...............................................295Defroster, Rear Window...................................43Defroster, Windshield...................................265
De-Icer, Remote Start......................................20

353
Deleting A Phone...........................................168Dimmer SwitchHeadlight.....................................................37DipsticksOil (Engine)................................................294Disabled Vehicle Towing................................283Disc Drive......................................................162Disconnecting................................................168DisposalAntifreeze (Engine Coolant).......................301Disturb...........................................................171Door Ajar..........................................................71Door Ajar Light.................................................71Door Locks......................................................24Drag & Drop...................................................149Driver Memory Presets..................................160Driver’s Seat Back Tilt..............................26, 27Driving...........................................................130
E
Electric Brake Control System.......................222Anti-Lock Brake System.............................221Electric Park Brake..........................................82Electric Parking Brake.....................................82Electrical Outlet, Auxiliary (Power Outlet).........50Electronic Roll Mitigation (ERM)....................222Electronic Speed Control (Cruise Control)........95Electronic Stability Control (ESC)...................223Electronic Throttle Control Warning Light........71
Emergency Gas Can Refueling......................280
Emergency, In Case OfHazard Warning Flasher...........................268Jacking.....................................................271Jump Starting...........................................278Overheating..............................................281Tow Hooks................................................284Towing......................................................283Emission Control System Maintenance...........78Engine...........................................................293Air Cleaner................................................296Break-In Recommendations........................82Checking Oil Level....................................294Compartment...........................................293Coolant (Antifreeze)..................................345Cooling.....................................................299Exhaust Gas Caution................................267Fails To Start...............................................80Flooded, Starting.........................................80Fuel Requirements...................................342Jump Starting...........................................278Oil...........................................295, 344, 345Oil Filler Cap.............................................293Oil Filter....................................................296Oil Selection....................................295, 344Oil Synthetic.............................................295Overheating..............................................281Starting........................................................80Enhanced Accident Response
Feature................................................252, 285
Ethanol.........................................................342
Exhaust Gas Cautions...................................267Exhaust System...................................267, 298Exterior Lighting...............................................36Exterior Lights........................................36, 267
F
Family Alerts.................................................214Filters Air Cleaner................................................296Air Conditioning...........................................48Engine Oil........................................296, 345Engine Oil Disposal...................................296FlashersHazard Warning........................................268Turn Signals................................39, 76, 267Flash-To-Pass...................................................37Flat Tire Changing.........................................271Flat Tire Stowage..........................................273Flooded Engine Starting...................................80Floor Console...................................................49Fluid Capacities............................................344Fluid Leaks....................................................267Fluid Level ChecksEngine Oil.................................................294Fluid, Brake...................................................345Fog Lights........................................................38Fold-Flat Seats.................................................26Forward Collision Warning...................228, 232Freeing A Stuck Vehicle.................................282
11

355
Key Fob Programming (Remote Keyless
Entry)...............................................................16Keyless Enter-N-Go..........................................22Enter The Trunk...........................................22Lock The Vehicle’s Doors............................22Passive Entry...............................................22Passive Entry Programming.........................22Remote Control...........................................22Unlock From The Driver’s Side....................22Unlock From The Passenger’s Side.............22Keyless Entry...................................................14Keys.................................................................14
L
Lane Change And Turn Signals........................39LaneSense....................................................117Lap/Shoulder Belts.......................................241Latches..........................................................267Lead Free Gasoline........................................342Leaks, Fluid...................................................267Life Of Tires...................................................331Liftgate.....................................................57, 58Closing........................................................58Opening.......................................................57Liftgate Window Wiper/Washer.......................43Light Bulbs.....................................................267Lights.............................................................267Air Bag.......................................70, 246, 265Automatic Headlights..................................38
Automatic High Beam..................................37
Brake Assist Warning...............................225Brake Warning.............................................70Cruise...................................................76, 77Daytime Running.........................................37Dimmer Switch, Headlight...........................37Exterior.....................................................267Fog..............................................................38Hazard Warning Flasher...........................268Headlight Switch..........................................36Headlights...................................................36Headlights On Reminder.............................38High Beam...................................................37High Beam/Low Beam Select......................37Hill Descent Control Indicator...................226Instrument Cluster.......................................36Intensity Control..........................................40Interior.........................................................39Lights On Reminder.....................................38Malfunction Indicator (Check Engine)..........73Park.............................................................76Passing........................................................37Seat Belt Reminder.....................................72Security Alarm.............................................72Tire Pressure Monitoring (TPMS)..............235Traction Control........................................225Turn Signals................................39, 76, 267Vanity Mirror................................................34Warning Instrument Cluster
Descriptions.....................................71, 76
Loading Vehicle.............................................123Tires..........................................................326Locks Child Protection...........................................25Power Door..................................................22Low Tire Pressure System.............................235Lubrication, Body..........................................297Lug Nuts........................................................341Luggage Carrier................................................61
M
Maintenance....................................................56Maintenance Free Battery............................294Maintenance Schedule.................................286Malfunction Indicator Light (Check
Engine)......................................................73, 78Manual Service......................................................348Master CylinderBrakes......................................................302Media Mode..................................................162Methanol.......................................................342MirrorsHeated.........................................................36Outside........................................................35Rearview............................................34, 268Vanity...........................................................34Mobile App....................................................20311

356
Modifications/Alterations
Vehicle........................................................10Monitor, Tire Pressure System.......................235Mopar Parts...................................................348
N
NavigationBefore Route Guidance
.............................190Map Updates.............................................200View Map...................................................191View Map — Main Menu............................191View Map — Settings.................................192View Map — Settings — Guidance..............196View Map — Settings — Map Setup...........193Where To?.................................................180Where To? — City Center...........................189Where To? — Go Home..............................188Where To? — Main Menu...........................180Where To? — Phone..................................189Where To? — Point of Interest...................185Where To? — Point on Map........................187Where To? — Trips.....................................187Navigation Mode...........................................180Navigation, Emergency..................................200Navigation, Information Menu.......................199New Vehicle Break-In Period............................82
O
Occupant Restraints.....................................240Octane Rating, Gasoline (Fuel)............342, 345Oil Change Indicator........................................65Reset...........................................................65Oil Filter, Change..........................................296Oil Filter, Selection........................................296Oil Pressure Light......................................71, 72Oil, Engine............................................295, 345Capacity....................................................344Checking...................................................294Dipstick....................................................294Disposal...................................................296Filter................................................296, 345Filter Disposal...........................................296Identification Logo....................................295Materials Added To..................................296Pressure Warning Light........................71, 72Recommendation............................295, 344Synthetic..................................................295Viscosity...................................................344Onboard Diagnostic System.............................77Operating Navigation....................................180Operating Precautions.....................................77Operator ManualOwner's Manual........................................348Outside Rearview Mirrors................................35Overheating, Engine......................................281
P
Paint Care.....................................................338Pair (Link) Uconnect Phone To A Mobile
Phone
S
.....................................................166Parking Brake..................................................82ParkSense Front And Rear..........................................105ParkSense Active Park Assist........................111Personalized Main Menu Bar........................149Pets...............................................................265Phone Mode..................................................164Placard, Tire And Loading Information..........326Point of InterestAll Points of Interest..................................186Restaurants..............................................186Spell Name...............................................186PowerBrakes......................................................341Door Locks...................................................22Inverter........................................................51Outlet (Auxiliary Electrical Outlet).................50Sunroof........................................................54Windows......................................................52Power SeatsRecline.........................................................29Pregnant Women And Seat Belts..................245Preparation For Jacking................................271Presets..........................................................160PretensionersSeat Belts
.................................................245
