engine JEEP WRANGLER 2006 TJ / 2.G Owners Manual

Schedule “B”
Follow this schedule if you usually operate your vehicle
under one or more of the following conditions.
•Day or night temperatures are below 32°F (0°C)
•Stop and go driving
•Excessive engine idling
•Driving in dusty conditions
•Short trips of less than 10 miles (16.2 km)
•More than 50% of your driving is at sustained high
speeds during hot weather, above 90°F (32°C)
•Trailer towing
•Taxi, police, or delivery service (commercial service)
•Off-road or desert driving
•If equipped for and operated with E-85 (ethanol)
fuel.
NOTE: IfANY of these apply to you then change your
engine oil every 3,000 miles (5 000 km) or 3 months,
whichever comes first and follow “Schedule B” of the
“Maintenance Schedules” section of this manual.
NOTE: IfANY of these apply to you then flush and
replace your engine coolant/anti-freeze every 102,000
miles (170 000 km) or 60 months, whichever comes first,
and follow “Schedule B” of the “Maintenance Schedules”
section of this manual.
SCHEDULE “B” 321
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 3,000 6,000 9,000 12,000 15,000
(Kilometers) (5 000) (10 000) (15 000) (20 000) (25 000)
Change the engine oil and engine oil filter, if not
replaced at 3 months. X X XXX
Rotate the tires. X X
Inspect the engine air filter element, replace if
necessary. X
Lubricate the steering linkage tie rod ends. X X X X X
Lubricate the steering and suspension ball joints. X X
Inspect the brake linings. X
Drain and refill the front and rear axle fluid‡ X
322 SCHEDULE “B”
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 18,000 21,000 24,000 27,000 30,000
(Kilometers) (30 000) (35 000) (40 000) (45 000) (50 000)
Change the engine oil and engine oil filter, if not
replaced at 3 months. X X XXX
Rotate the tires. X X X
Inspect the engine air filter element, replace if
necessary. X
Inspect the PCV Valve, and replace if necessary.  X
Replace the spark plugs. X
Lubricate the steering linkage tie rod ends. X X X X X
Lubricate the steering and suspension ball joints. X X X
Inspect the brake linings. X
Drain and refill the front and rear axle fluid‡ X
Inspect the manual transmission fluid, add as nec-
essary. X
Inspect the transfer case fluid, add if necessary. X
SCHEDULE “B” 323
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 33,000 36,000 39,000 42,000 45,000
(Kilometers) (55 000) (60 000) (65 000) (70 000) (75 000)
Change the engine oil and engine oil filter, if not
replaced at 3 months. X X XXX
Rotate the tires. X X
Inspect the engine air filter element, replace if
necessary. X
Lubricate the steering linkage tie rod ends. X X X X X
Lubricate the steering and suspension ball joints. X X
Inspect the brake linings. X
Drain and refill the front and rear axle fluid‡ X
Inspect the drive belt and replace as needed. X
324 SCHEDULE “B”
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 48,000 51,000 54,000 57,000 60,000
(Kilometers) (80 000) (85 000) (90 000) (95 000) (100 000)
Change the engine oil and engine oil filter, if not
replaced at 3 months. X X XXX
Rotate the tires. X X X
Inspect the engine air filter element, replace if
necessary. X
Inspect the PCV Valve, and replace if necessary.  X
Replace the ignition cables (2.4L Only). X
Replace the spark plugs. X
Lubricate the steering linkage tie rod ends. X X X X X
Lubricate the steering and suspension ball joints. X X X
Inspect the brake linings. X X
Drain and refill the front and rear axle fluid‡ X X
Inspect manual transmission fluid, add as neces-
sary. X
Drain and refill the automatic transmission fluid,
and change filter.† X
SCHEDULE “B” 325
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 48,000 51,000 54,000 57,000 60,000
(Kilometers) (80 000) (85 000) (90 000) (95 000) (100 000)
Inspect the drive belt and replace as needed. Not
required if belt was previously. X
Drain and refill the transfer case fluid. X
Flush and replace the engine coolant/anti-freeze. X
326 SCHEDULE “B”
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 63,000 66,000 69,000 72,000 75,000
(Kilometers) (105 000) (110 000) (115 000) (120 000) (125 000)
Change the engine oil and engine oil filter, if not
replaced at 3 months. X X XXX
Rotate the tires. X X
Inspect the engine air filter element, replace if
necessary. X
Lubricate the steering linkage tie rod ends. X X X X X
Lubricate the steering and suspension ball joints. X X
Inspect the brake linings. X
Drain and refill the front and rear axle fluid‡ X
Inspect the drive belt and replace as needed. Not
required if belt was previously replaced. X
SCHEDULE “B” 327
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 78,000 81,000 84,000 87,000 90,000
(Kilometers) (130 000) (135 000) (140 000) (145 000) (150 000)
Change the engine oil and engine oil filter, if not replaced
at 3 months. X X XXX
Rotate the tires. X X X
Inspect the engine air filter element, replace if necessary. X
Inspect the PCV Valve, and replace if necessary.  X
Replace the spark plugs. X
Lubricate the steering linkage tie rod ends. X X X X X
Lubricate the steering and suspension ball joints. X X X
Replace the timing belt (2.4L Only) . X
Inspect the brake linings. X
Drain and refill the front and rear axle fluid‡ X
Inspect the drive belt and replace as needed. Not required
if belt was previously replaced. X
Inspect the manual transmission fluid, add as necessary. X
Inspect the transfer case fluid, add if necessary. X
328 SCHEDULE “B”
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 93,000 96,000 99,000 102,000 105,000
(Kilometers) (155 000) (160 000) (165 000) (170 000) (175 000)
Change the engine oil and engine oil filter, if not
replaced at 3 months. X X XXX
Rotate the tires. X X
Inspect the engine air filter element, replace if
necessary. X
Lubricate the steering linkage tie rod ends. X X X X X
Lubricate the steering and suspension ball joints. X X
Inspect the brake linings. X
Drain and refill the front and rear axle fluid‡ X
Inspect the drive belt and replace as needed. Not
required if belt was previously replaced. X
Flush and replace the engine coolant/anti-freeze, if
not done at 60,000 miles (96 000 km). X
SCHEDULE “B” 329
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 108,000 111,000 114,000 117,000 120,000
(Kilometers) (180 000) (185 000) (190 000) (195 000) (200 000)
Change the engine oil and engine oil filter, if not
replaced at 3 months. X X XXX
Rotate the tires. X X X
Inspect the engine air filter element, replace if
necessary. X
Inspect the PCV Valve, and replace if necessary.  X
Replace the spark plugs. X
Replace the ignition cables (2.4L Only). X
Lubricate the steering linkage tie rod ends. X X X X X
Lubricate the steering and suspension ball joints. X X X
Inspect the brake linings. X X
Drain and refill the front and rear axle fluid‡ X X
Inspect the manual transmission fluid, add as nec-
essary. X
Drain and refill the automatic transmission fluid,
and replace main sump filter.† X
