engine JEEP WRANGLER 2006 TJ / 2.G Owners Manual

Miles 108,000 111,000 114,000 117,000 120,000
(Kilometers) (180 000) (185 000) (190 000) (195 000) (200 000)
Inspect the drive belt and replace as needed. Not
required if belt was previously replaced. X
Drain and refill the transfer case fluid. X
Flush and replace the engine coolant/anti-freeze, if
not replaced at 102,000 miles (170 000 km). X
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
† Applies only if vehicle is used for frequent trailer
towing or fleet/commercial service.
 This maintenance is recommended by the manufac-
turer to the owner, but is not required to maintain
emissions warranty. ‡Off-highway operation, trailer towing, taxi, limousine,
bus, snow plowing, or other types of commercial service
or prolonged operation with heavy loading, especially in
hot weather, require front and rear axle service indicated
witha‡in Schedule “B”. Perform these services if the
vehicle is usually operated under these conditions.
SCHEDULE “B” 331
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Schedule “A”
Miles 6,000 12,000 18,000 24,000 30,000
(Kilometers) (10 000) (20 000) (30 000) (40 000) (50 000)
[Months] [6] [12] [18] [24] [30]
Change the engine oil and engine oil filter. X X X X X
Rotate the tires. X X X X X
Inspect the engine air filter element, and replace
if necessary. X
Replace the spark plugs. X
Lubricate the steering linkage joints and outer tie
rod ends. X X XXX
Lubricate the steering and suspension ball joints. X X
Inspect the brake linings. X
Inspect the manual transmission fluid, add as nec-
essary. X
Inspect the transfer case fluid. X
332 SCHEDULE “A”
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 36,000 42,000 48,000 54, 000
(Kilometers) (60 000) (70 000) (80 000) (90 000)
[Months] [36] [42] [48] [54]
Change the engine oil and engine oil filter. X X X X
Rotate the tires. X X X X
Lubricate the steering and suspension ball joints. X X
Lubricate the steering linkage joints and outer tie rod
ends. XXXX
Inspect the brake linings. X X
SCHEDULE “A” 333
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 60,000 66,000 72,000 78,000
(Kilometers) (100 000) (110 000) (120 000) (130 000)
[Months] [60] [66] [72] [78]
Change the engine oil and engine oil filter. X X X X
Rotate the tires. X X X X
Inspect the engine air filter element, and replace if nec-
essary. X
Inspect the PCV Valve, and replace if necessary.  X
Replace the ignition cables (2.4L Only). X
Replace the spark plugs. X
Lubricate the steering linkage joints and outer tie rod
ends. XXXX
Lubricate the steering and suspension ball joints. X X
Inspect the brake linings. X
Inspect the drive belt, and replace as needed. X
Inspect the drive belt, and replace as needed. Not re-
quired if belt was previously replaced. X
334 SCHEDULE “A”
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 60,000 66,000 72,000 78,000
(Kilometers) (100 000) (110 000) (120 000) (130 000)
[Months] [60] [66] [72] [78]
Flush and replace the engine coolant/anti-freeze. X
Inspect the manual transmission fluid, add as necessary. X
Inspect transfer case fluid. X
SCHEDULE “A” 335
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 84,000 90,000 96,000 102, 000
(Kilometers) (140 000) (150 000) (160 000) (170 000)
[Months] [84] [90] [96] [102]
Change the engine oil and engine oil filter. X X X X
Rotate the tires. X X X X
Inspect the engine air filter element, and replace if necessary. X
Inspect the PCV Valve, and replace if necessary.  X
Replace the spark plugs. X
Lubricate the steering linkage joints and outer tie rod ends. X X X X
Lubricate the steering and suspension ball joints. X X
Inspect the brake linings. X
Inspect the drive belt, and replace as needed. Not required if
previously replaced. XX
Flush and replace the engine coolant/anti-freeze if not done at
60 months. X
Inspect the manual transmission fluid, add as necessary. X
Inspect the transfer case fluid. X
336 SCHEDULE “A”
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 108,000 114,000 120,000
(Kilometers) (180 000) (190 000) (200 000)
[Months] [108] [114] [120]
Change the engine oil and engine oil filter. X X X
Rotate the tires. X X X
Inspect the engine air filter element, and replace if necessary. X
Replace the ignition cables (2.4L Only). X
Inspect the PCV Valve, and replace if necessary.  X
Replace the spark plugs. X
Lubricate the steering linkage joints and outer tie rod ends. X X X
Lubricate the steering and suspension ball joints. X X
Inspect the brake linings. X
Replace the timing belt (2.4L Only).  X
Inspect the drive belt, and replace as needed. Not required if pre-
viously replaced. X
SCHEDULE “A” 337
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 108,000 114,000 120,000
(Kilometers) (180 000) (190 000) (200 000)
[Months] [108] [114] [120]
Inspect the manual transmission fluid, add as necessary. X
Drain and refill the transfer case fluid. X
Flush and replace the engine coolant/anti-freeze, if not done at
102,000 miles (170 000 km). X
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
 This maintenance is recommended by the manufac-
turer to the owner, but is not required to maintain
emissions warranty.
338 SCHEDULE “A”
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

PUBLICATION ORDER FORMS
To order the following manuals, you may use either the
website or the phone numbers listed below. Visa, Mas-
tercard, American Express, and Discover orders are ac-
cepted. If you prefer mailing your payment, please call
for an order form.
NOTE: A street address is required when ordering
manuals. (No P.O. Boxes).
•Service Manuals.
These comprehensive service manuals provide the
information that students and professional technicians
need in diagnosing/troubleshooting, problem solving,
maintaining, servicing and repairing DaimlerChrysler
Corporation vehicles. A complete working knowledge
of the vehicle, system and/or components is written in
straightforward language with illustrations, diagrams
and charts.
•Diagnostic Procedure Manuals.
Filled with diagrams, charts and detailed illustrations,
these practical manuals make it easy for students and
technicians to find and fix problems on computer-
controlled vehicle systems and features. They show
exactly how to find and correct problems the first time,
using step-by-step troubleshooting and driveability
procedures, proven diagnostic tests and a complete list
of all tools and equipment.
•Owner’s Manuals.
These manuals have been prepared with the assistance
of service and engineering specialists to acquaint you
with specific Chrysler group vehicles. Included are
starting, operating, emergency and maintenance pro-
cedures as well as specifications, capabilities and
safety tips.
