door lock JEEP WRANGLER 2006 TJ / 2.G Owners Manual

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
CONTENTS

A Word About Your Keys ..................13
▫ Ignition Key ..........................13
▫ Key-In-Ignition Reminder ................14

Sentry Key Immobilizer System — If Equipped . .14
▫ Important Note About Service .............16
▫ Replacement Keys ......................16
▫ Customer Key Programming ..............16
▫ General Information ....................17

Illuminated Entry — If Equipped ............17

Steering Wheel Lock — If Equipped ..........17
▫ To Manually Lock The Steering Wheel .......18
▫ To Release The Steering Wheel Lock .........18

Doors And Locks ........................18
▫ Door Locks ...........................19

Occupant Restraints ......................19
▫ Lap/Shoulder Belts .....................20
▫ Adjustable Upper Shoulder Belt Anchorage ....25
▫ Seat Belts And Pregnant Women ............26
2

To remove the ignition key on models with a manual
transmission, depress and hold the key release button,
turn the ignition key to LOCK, and remove the key.Key-In-Ignition Reminder
Opening the driver’s door when the key is in the ignition,
sounds a signal to remind you to remove the key.
CAUTION!
Always remove the key from the ignition, and lock
all doors when leaving the vehicle unattended.
SENTRY KEY IMMOBILIZER SYSTEM — IF
EQUIPPED
The Sentry Key Immobilizer System (SKIM) prevents
unauthorized operation of the vehicle by disabling the
engine. The system will shut the engine down after 2
seconds of running if an invalid key is used to start the
vehicle. This system utilizes ignition keys which have an
electronic chip (transponder) embedded into them. Only
Ignition Key Removal
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

3. Insert the second valid key and turn the ignition
switch ON within 15 seconds. After ten seconds, a chime
will sound and the SKIM indicator light will begin to
flash. Turn the ignition switch OFF and remove the
second key.
4. Insert a blank Sentry Key into the ignition switch and
turn the ignition switch ON within 60 seconds. After 10
seconds, a single chime will sound. The SKIM indicator
light will stop flashing, turn on for 3 seconds; then turn
off.
The new Sentry Key has been programmed. Repeat this
process to program up to a total of 8 keys.
General Information
The Sentry Key Immobilizer System complies with FCC
rules part 15 and with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference. 2. This device must accept any interference that may be
received, including interference that may cause undes-
ired operation.
ILLUMINATED ENTRY — IF EQUIPPED
The interior lights will come on when you open any door.
The lights will remain on after all of the doors are closed,
and then fade to off or they will immediately fade to off
once the ignition switch is turned on.
STEERING WHEEL LOCK — IF EQUIPPED
Your vehicle may be equipped with a passive steering
wheel lock (manual transmission only). This lock pre-
vents steering the vehicle without the ignition key. If the
steering wheel is moved a half turn in either direction
and the key is not in the ignition, the steering wheel will
lock.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17
2

To Manually Lock the Steering Wheel
With the engine running, rotate the steering wheel 1/2
revolution from straight ahead position, turn off the
engine and remove the key. Rotate the steering wheel
slightly in both directions until the lock engages.
To Release the Steering Wheel Lock
Insert the key in the ignition and turn the wheel slightly
to the right or left to disengage the lock.
NOTE: If you turned the wheel to the right to engage
the lock, you must turn the wheel slightly to the right to
disengage it. If you turned the wheel to the left to engage
the lock, turn the wheel slightly to the left to disengage it.
DOORS AND LOCKS
NOTE: The ignition key that is used to start the vehicle
is used to lock or unlock the doors, tailgate, and console
storage.
To unlock doors and tailgate insert the key and turn.
Once unlocked, the tailgate can be opened or closed
without using the key.
To open the tailgate, lift the latch release and swing open
the tailgate.
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Door Locks
Doors on both hard-top and soft-top models are
equipped with a rocker-type interior door lock. To lock a
door when leaving your vehicle, press to the “Lock”
position and close the door.WARNING!
•For personal security reasons and safety in an
accident, lock the vehicle doors when you drive as
well as when you park and leave the vehicle.
•When leaving the vehicle always remove the key
from the ignition lock, and lock your vehicle. Do
not leave children unattended in the vehicle, or
with access to an unlocked vehicle. Unsupervised
use of vehicle equipment may cause severe per-
sonal injuries and death.
OCCUPANT RESTRAINTS
Some of the most important safety features in your
vehicle are the restraint systems. These include the front
and rear seat belts for the driver and all passengers, and
front airbags for both the driver and front passenger. If
Door Lock Knob
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19
2

15. Grasp the drip rail retainers and untuck them from
the door frame. The soft top fabric should cover the
header completely from one side to the other. This may
require you to pull some of the fabric down and around
the corners. Repeat this step for the other side. For Unlimited Models
— Pull the side bow forward and
down. Make certain the blocks on the side bows line up
with the retainers on the door rails. Ensure the blocks are
locked in place.
NOTE: Do not tuck the drip rail retainers into the frame
at this time.
82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

8. Disconnect the wire harness from the hard top by
pressing the tab at the side of the connector and pulling
to disconnect.
NOTE: If the red latch on the connector is locked, push
the red latch to the right until you can only see the latch
on one end (right) of the connector. This will unlock
connector tab, allowing the tab to be pressed down and
enabling the harness to be disconnected from the hard
top.
9. Remove the hard top from the vehicle.
NOTE: If the doors are to be removed, pull the #4 fuse
from the fuse block to prevent dome lamp illumination.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93
3

WARNING!
•Do not drive vehicle with rear window curtain up
unless side curtains are also open. Dangerous
exhaust gases which can kill could enter the
vehicle.
•The fabric upper doors and fabric top are de-
signed only for protection against the elements.
Do not rely on them to contain occupants within
the vehicle or to protect against injury during an
accident. Remember, always wear seat belts.
Folding Down The Soft Top
NOTE: Clean side and rear windows before removal to
assist in preventing scratching during removal of the soft
top. If zippers are difficult to operate due to road dust,
etc., clean them with a mild soap solution and a small
brush. Cleaning products are available through your
authorized dealer.
NOTE: Make sure the plastic sleeves are slid rearward
to keep the Sunrider feature locked.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113
3

10. Release the Sunrider pins to release the top bows
from the brackets located on both door rails. Push up and
back on the bow slightly so it does not fall back and lock
into the brackets. 11. Grasp the side bow behind the header and lift the top
back.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117
3

5. Pull the side bow forward and down. Make certain the
blocks on the side bows line up with the retainers on the
door rails. Lock the blocks in place.
NOTE: Check to make certain the check straps are not
tangled on any of the other top hardware. This will
prevent the top from being put all the way up. 6. Move to the rear of the vehicle and gently pull the sail
panels over the 3 bow.
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
