Electrical Outlet Use With Engine Off
WARNING!
•Many accessories that can be plugged in draw power
from the vehicle’s battery, even when not in use (i.e.
cellular phones, etc.). Eventually, if plugged in long
enough, the vehicle’s battery will discharge sufficiently
to degrade battery life and/or prevent engine starting.
•Accessories that draw higher power (i.e. coolers,
vacuum cleaners, lights, etc.), will degrade the battery
even more quickly. Only use these intermittently and
with greater caution.
•After the use of high power draw accessories, or long
periods of the vehicle not being started (with accesso-
ries still plugged in), the vehicle must be driven a
sufficient length of time to allow the alternator to
recharge the vehicle’s battery.
•Power outlets are designed for accessory plugs only.
Do not hang any type of accessory or accessory bracket
from the plug.
CUP HOLDERS
In the center console there are two cup holders for the
front seat passengers.
NOTE: The cup holder insert is removable from the
console, for cleaning.
Front Cup Holders
72 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

7. High Beam Indicator Light This light shows that the headlights are on high
beam. Pull the turn signal lever towards the
steering wheel to switch the headlights from high or low.
If the driver’s door is open, and the headlights or
parklights are left on, the “High Beam Indicator Light”
will flash and a chime will sound.
8. Seat Belt Indicator Light A warning chime and an indicator light will alert
you to buckle the seat belts. When the belt is
buckled, the chime will stop, but the light will stay
on until it times out (about 6 seconds).
9. Speedometer
Indicates vehicle speed. 10. Front Axle Lock Indicator Light — If Equipped
Indicates when the front axle lock has been
activated. (See page 199 for more information.)
11. Rear Axle Lock Indicator Light — If Equipped Indicates when the rear axle lock has been
activated. (See page 199 for more information.)
12. 4WD Indicator Light This light alerts the driver that the vehicle is in
the four-wheel drive mode, and the front and
rear driveshafts are mechanically locked to-
gether forcing the front and rear wheels to
rotate at the same speed. (See page 194 for more infor-
mation.)
148 UNDERSTANDING YOUR INSTRUMENT PANEL

13. Oil Pressure Gauge Indicates engine oil pressure. This gauge does not
indicate oil level, and pressure varies with engine
speed, temperature and oil viscosity. Consistent lower
readings indicate possible malfunction. Seek authorized
service.
14. Coolant Temperature Gauge Indicates engine coolant temperature. The red
zone to the far right indicates possible overheat-
ing. Seek authorized service immediately if the
gauge operates in the red zone. In U.S. vehicles, tempera-
ture is indicated in degrees fahrenheit; in Canadian
vehicles in degrees centigrade.
15. Airbag Warning Light This indicator lights and remains lit for 6 to 8
seconds when the ignition is first turned on. If
the light does not come on for 6 to 8 seconds, stays on or comes on while driving, have the airbag
system checked by an authorized dealer.
16. Check Gauges Warning Light
This light monitors the engine coolant tem-
perature, engine oil pressure, and voltage
gauges. If it detects an extreme condition a
chime will sound and the light will come on. If the light
comes on, check the operation of these gauges for a
malfunction condition.
17. Malfunction Indicator Light This light is a part of an Onboard Diagnostic
System called OBD II that monitors engine, and
automatic transmission control systems. The light
will illuminate when the ignition is in the ON position
before engine start. If the bulb does not come on when
turning the key from OFF to ON, have the condition
checked promptly.
UNDERSTANDING YOUR INSTRUMENT PANEL 149
4

WARNING!
Remember to disconnect the cord before driving.
Damage to the 110-115 volt AC electrical cord could
cause electrocution.
Use the heater when temperatures below 0°F (-18°C) are
expected to last for several days.
TRANSMISSION SHIFTING
6-Speed Manual Transmission
Follow the shift pattern on the gearshift knob.
NOTE: The backup lights will come on when your
vehicle is in reverse gear and the ignition is in the ON
position.Manual Shift Controls
STARTING AND OPERATING 185
5

•Vehicle speed should be 10 mph (16 km/h) or less.
To activate the system, press the switch once to lock the
rear axle only (the REAR LOCK indicator light will
illuminate), press the switch again to lock the front axle
(the FRONT LOCK indicator light will illuminate). Once
the rear axle is locked, pressing the switch again will lock
or unlock the front axle.
NOTE: The indicator lights will flash until the axles are
fully locked or unlocked. A chime will sound three times
and the indicator lights will continue to flash at a
different rate if the key is removed while the axles are still
in the locked position.
To unlock the axles, pull up on the switch.
Axle lock will disengage if vehicle is taken out of 4L
(Low) range.PARKING BRAKE
To set the parking brake, pull the lever up as firmly as
possible. When the parking brake is applied with the
ignition ON, the BRAKE warning light in the instrument
cluster will light.
NOTE: The BRAKE warning light indicates only that
the parking brake is applied. It does not indicate the
degree of brake application.
NOTE: If the parking brake is applied and the vehicle is
in motion, the BRAKE warning light will flash and a
chime will sound.
To release the parking brake, pull up slightly, press center
button, then lower lever completely.
200 STARTING AND OPERATING

CAUTION!
If the trailer weighs more than 1,000 lbs (454 kg)
loaded, it should have its own brakes and they
should be of adequate capacity. Failure to do this
could lead to accelerated brake lining wear, higher
brake pedal effort, and longer stopping distances.
WARNING!
Do not connect trailer brakes to your vehicle’s hy-
draulic brake lines. It can overload your brake sys-
tem and cause it to fail. You might not have brakes
when you need them and could have an accident.
Towing any trailer will increase your stopping dis-
tance. When towing you should allow for additional
space between your vehicle and the vehicle in front
of you. Failure to do so could result in an accident.
Towing Requirements — Trailer Lights & Wiring
Whenever you pull a trailer, regardless of the trailer size,
stop lights and turn signals on the trailer are required for
motoring safety.
The Trailer Tow Package may includ ea4and7pin
wiring harness. Use a factory approved trailer harness
and connector.
STARTING AND OPERATING 245
5

Set the parking brake, place an automatic transmission in
P (Park) (or N (Neutral) for a manual transmission). Turn
off lights, heater, and other electrical loads. Observe
charge indicator in the battery. If indicator is light or
yellow, replace the battery.
CAUTION!
Use the “Jump Starting” procedure only when the
charge indicator is dark in the center. Do not attempt
jump starting when the battery charge indicator is
bright or yellow. If the charge indicator is dark and
has a green dot in the center, failure to start is not
due to a discharged battery and the cranking system
should be checked.
1. Attach one end of the jumper cable to the positive
terminal of the discharged battery and the other end of
the same cable to the positive terminal of the booster
battery.
WARNING!
Do not permit vehicles to touch each other as this
could establish a ground connection and personal
injury could result.
2. Connect one end of the other jumper cable to the
negative terminal of the booster battery. Connect the
other end of the jumper cable to a good ground on the
vehicle with the discharged battery. Make sure a good
connection is made, free of dirt and grease.
WHAT TO DO IN EMERGENCIES 259
6

Oil Filter............................ 274
Oil Pressure Gauge ..................... 149
Oil Selection .......................... 314
Overheating .......................... 253
Starting ............................. 182
Temperature Gauge ..................... 149
Timing Belt .......................... 277
Engine Oil Viscosity ...................... 274
Engine Oil Viscosity Chart ................. 274
Entry System, Illuminated .................. 17
Exhaust Gas Caution ................... 45,232
Exhaust System ......................... 283
Extender, Seat Belt ........................ 26
Exterior Finish Care ...................... 298
Fabric Care ......................... 300,302
Fabric Top ............................. 302
Filters Air Cleaner .......................... 278 Engine Fuel
.......................... 278
Engine Oil ........................... 274
Finish Care ............................ 298
Flashers Hazard Warning ....................... 252
Turn Signal ..................... 147,311,313
Flooded Engine Starting ................... 183
Fluid Capacities ......................... 314
Fluid Level Checks ...................... 296
Automatic Transmission ................. 292
Engine Oil ........................... 271
Manual Transmission ................... 294
Power Steering ........................ 281
Fluids, Lubricants and Genuine Parts .......... 315
Fog Light Service ........................ 311
Fog Lights ........................... 66,311
Folding Rear Seat ........................ 59
Folding Windshield ...................... 132
Four Wheel Drive ....................... 194
352 INDEX

Shifting............................. 196
Four Wheel Drive Operation .............194,195
Front Axle (Differential) ................... 296
Fuel ................................. 229
Filler Cap (Gas Cap) .................... 233
Filter ............................... 278
Gasoline ............................ 229
Gauge .............................. 152
Materials Added ....................... 231
Octane Rating ........................ 230
Requirements ......................... 314
Tank Capacity ........................ 314
Fuel System Caution ................... 232,234
Fuses ................................ 305
Gas Cap (Fuel Filler Cap) .................. 233
Gasoline (Fuel) ......................... 229
Gasoline, Reformulated ................... 230
Gasoline/Oxygenate Blends ................ 230 Gauges
Coolant Temperature .................... 149
Fuel ................................ 152
Odometer ........................... 150
Oil Pressure .......................... 149
Speedometer ......................... 148
Tachometer .......................... 147
Voltmeter ............................ 147
Gear Ranges ........................ 187,189
Glass Cleaning .......................... 300
Glove Compartment ...................... 73
Gross Axle Weight Rating .................. 237
Gross Vehicle Weight Rating ................ 236
HardTop .............................. 89
Hard Top Removal ....................... 90
Hazard Warning Flasher ................... 252
Headlights Bulb Replacement ...................... 310
INDEX 353
10

Key-In Reminder......................... 14
Keys ................................. 13
Lane Change and Turn Signals .............. 147
Lap Belts .............................. 20
Lap/Shoulder Belts ....................... 20
LATCH
(Lower Anchors and Tether for CHildren) .....38,39
Lead Free Gasoline ...................... 229
Lights ................................. 64
Airbag ............................ 34,149
Anti-Lock ........................... 151
Anti-Lock Warning ..................... 151
Back-Up ............................. 313
Brake Warning ........................ 151
Bulb Replacement ...................... 310
Center Mounted Stop ................... 313
Check Engine (Malfunction Indicator) ........ 149
Check Gauges ........................ 149 Cruise
.............................. 147
Daytime Running ....................... 66
Dimmer Switch, Headlight ................ 65
Fog .............................. 66,311
Headlight Switch ....................... 64
Headlights ........................... 310
High Beam ........................... 148
High Beam Indicator .................... 148
Instrument Cluster ...................... 64
Interior .............................. 64
Lights On Reminder ..................... 65
Low Fuel ............................ 151
Passing .............................. 65
Rear Servicing ........................ 313
Rear Tail ............................ 313
Seat Belt Reminder ..................... 148
Sentry Key ........................... 147
Service .............................. 310
Side Marker .......................... 313
INDEX 355
10
