JEEP WRANGLER 2007 JK / 3.G Owner's Manual

NOTE:The line of transmission must not be blocked
with metal objects.
To Unlock the Doors and Swing Gate
Press and release the “Unlock” button on the key fob
once to unlock only the driver’s door or twice to unlock
all the doors and swing gate. When the “Unlock” button
is pressed, the illuminated entry will initiate, and the
parking lights will flash on twice.
The system can be programmed to unlock all the doors
upon the first “Unlock” button press by using the follow-
ing procedure:
1. Press and hold the “Lock” button on a programmed
key fob.
2. Continue to hold the “Lock” button at least 4 seconds,
but not longer than 10 seconds, then press and hold the
“Unlock” button.
3. Release both buttons at the same time.4. Test the feature while outside of the vehicle, by
pressing the “Lock/Unlock” button on the keyfob.
NOTE:Pressing the “Lock” button on the keyfob while
you are inside the vehicle will activate the Security
Alarm. Opening a door with the Security Alarm activated
will cause the alarm to sound. Press the “Unlock” button
to deactivate the Security Alarm.
5. If the desired programming was not achieved or to
reactivate this feature, repeat the above steps.
To Lock the Doors and Swing Gate
Press and release the “Lock” button on the transmitter to
lock all doors. The turn signal lights will flash and the
horn will chirp once to acknowledge the lock signal. If
desired, the “Sound Horn On Lock” feature can be
turned on or off by performing the following steps:
1. Press the “Lock” button for 4 to 10 seconds.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21
2

2. While the “Lock” button is pressed (after 4 seconds),
press the PANIC button. Release both buttons.
The “Sound Horn On Lock” feature can be reactivated by
repeating this procedure.
Using The Panic Alarm
To turn the panic alarm feature ON or OFF, press and
hold the PANIC button on the transmitter for at least one
second and release. When the panic alarm is on, the
headlights and park lights will flash, the horn will pulse
on and off and the interior lights will turn on.
The panic alarm will stay on for 3 minutes unless you
turn it off by pressing the PANIC button a second time or
if the vehicle speed is 5 mph (8 km/h) or greater.
NOTE:When you turn off the panic alarm by pressing
the PANIC button a second time, you may have to be
closer to the vehicle due to the radio frequency noises of
the system.
To Turn Off “Flash Lights With Lock”
NOTE:The Flash Lights With Lock feature can be
turned on or off by performing the following steps:
1. Press the “Unlock” button for 4 to 10 seconds.
2. While the “Unlock” button is pressed, (after 4 seconds)
press the “Lock” button. Release both buttons.
3. Test the flash lamps with LOCK feature while outside
of the vehicle, by pressing the “Lock” button on the key
fob with the ignition in the LOCK position, and the key
removed.
NOTE:Pressing the “Lock” button on the key fob, while
you are in the vehicle, will activate the Security Alarm.
Opening a door with the Security Alarm activated will
cause the alarm to sound. Press the “Unlock” button to
deactivate the Security Alarm.
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

The “Flash Lights On Lock/Unlock” feature can be
reactivated by repeating this procedure.
Programming Additional Transmitters
Vehicles will be shipped from the assembly plants with
two key fob transmitters programmed only for that
vehicle. A total of eight fobs can be programmed for your
vehicle. Additional fobs can be programmed to your
vehicle through the use of a currently programmed fob.
NOTE:When entering program mode using that fob, all
other programmed fobs will be erased and you will have
to reprogram them for your vehicle.
Use the Following procedure to program additional key
fobs if the vehicle is not equipped with Sentry Key:
1. Enter your vehicle and close all doors.
2. Fasten your seat belt (Fastening the seatbelt will cancel
any chiming that may confuse you during this program-
ming procedure).3. Place the key into the ignition.
4. Turn the ignition to the ON position (Do not start the
engine).
5. Press and hold the “Unlock” button on the key fob.
6. After holding the “Unlock” button for four seconds,
also press the PANIC button within 6 seconds.
7. When a single chime is heard release both buttons. The
chime is an indication that you have successfully entered
program mode. All fobs that are to be programmed must
be done so within 60 seconds of when the chime was
heard.
8. Using the fob to be programmed, press and release
both the “Lock” and “Unlock” buttons, simultaneously.
9. A single chime will be heard.
10. Within four seconds of hearing the chime, press and
release the “Unlock” button on the fob.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23
2

11. A single chime will be heard.
12. Repeat steps 8 through 10 to program up to six
additional fobs.
13. Turn the ignition to the OFF position.
14. Your vehicle will remain in program mode up to 60
seconds from when the original chime was heard. After
60 seconds, all programmed fobs function normally.
NOTE:If you do not have a programmed transmitter,
contact your dealer for details.
General Information
This device complies with part 15 of FCC rules and with
RS-210 of Industry Canada. Operation is subject to the
following conditions:
1. This device may not cause harmful interference.2. This device must accept any interference that may be
received including interference that may cause undesired
operation.
NOTE:Changes or modifications not expressly ap-
proved by the party responsible for compliance could
void the user’s authority to operate the equipment.
If your Remote Lock Control fails to operate from a
normal distance, check for these two conditions.
1. Weak batteries in transmitter. The expected life of
batteries is five years.
2. Closeness to a radio transmitter such as a radio station
tower, airport transmitter, military base, and some mobile
or CB radios.
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Battery Replacement
The recommended replacement battery is CR2032.
NOTE:
Perchlorate Material – special handling may apply,
See www.dtsc.ca.gov/hazardouswaste/perchlorate
1. If the key fob is equipped with a screw, remove the
screw. With the transmitter buttons facing down, use a
flat blade (screw driver) to pry the two halves of the
transmitter apart. Useextreme carenot to damage the
seal or internal components.
2. Remove and replace the batteries. Avoid touching the
new batteries with your fingers. Skin oils may cause
battery deterioration. If you touch a battery, clean it with
rubbing alcohol.
Separating Transmitter Halves
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25
2

3. To assemble the transmitter case, snap the two halves
together.
NOTE:If the key fob is equipped with a screw, reinstall
and tighten the screw until snug.
DOORS
The vacuum fluorescent (VF) display located in the
odometer area displays the word “door” as an indication
of a door ajar or door not completely closed. When the
vehicle is not moving and the door is ajar or not
completely closed, the VF display will show the word
“door.”
If any other active warnings including “GATE”, “GAS-
CAP”, “NOFUSE”, or “ESPOFF” are present, they will be
shown in the VF display and will also continue to cycle.
If the vehicle is moving, three single chimes will occur
(One chime for each complete display cycle (three cycles
total). After this, the display will continue to cycle only
(no chimes).If the trip/reset button is pressed while the VF warnings
are being displayed, the VF display will revert back to
only displaying the odometer/trip odometer mileage.
Front Door Removal
1. Remove the hinge pin screws from the upper and
lower outside hinges (using a #T50 Torxhead driver).
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

2. Unplug wiring harness connector under instrument
panel.
3. Unhook door strap from the body hook. Be careful not
to allow door to swing fully open as mirror may damage
paint.
4. With the door open, lift the door to clear hinge pins
from their hinges, and remove door.To reinstall the door(s), perform the above steps in the
opposite order.
Rear Door Removal (4 Door Models)
1. Remove the hinge pin screws from the upper and
lower outside hinges (using a #T50 Torxhead driver).
2. Slide front seat(s) fully forward.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27
2

3. Remove interior B-pillar trim access door at bottom of
B-pillar.
4. Unplug wiring harness connector.5. Unhook door strap from the body hook.
6. With the door open, lift the door to clear hinge pins
from their hinges, and remove door.
To reinstall the door(s), perform the above steps in the
opposite order.
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

DOOR LOCKS
The vacuum fluorescent (VF) display located in the
odometer area displays the word “door” as an indication
of a door ajar or door not completely closed. When the
vehicle is not moving and the door is ajar or not
completely closed, the VF display will show the word
“door.”
If any other active warnings including “GATE”, “GAS-
CAP”, “NOFUSE”, or “ESPOFF” are present, they will be
shown in the VF display and will also continue to cycle.
If the vehicle is moving, three single chimes will occur(One chime for each complete display cycle (three cycles
total). After this, the display will continue to cycle only
(no chimes).
If the trip/reset button is pressed while the VF warnings
are being displayed, the VF display will revert back to
only displaying the odometer/trip odometer mileage.
NOTE:The ignition key that is used to start the vehicle
is used to lock or unlock the doors, glove box, swing gate,
and console storage.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29
2

Manual Door Locks
The front (2 Door Models) and rear doors (4 Door
Models) are equipped with a rocker-type interior door
lock. To lock a door when leaving your vehicle, press to
the “Lock” position (flush) and close the door.WARNING!
•For personal security reasons and safety in an
accident, lock the vehicle doors when you drive as
well as when you park and leave the vehicle.
•Never leave children alone in a vehicle. Leaving
children in a vehicle unattended is dangerous for a
number of reasons. A child or others could be
seriously or fatally injured. Do not leave the keys
in the ignition. A child could operate power win-
dows, other controls, or move the vehicle.
Manual Door Lock
