NOTE:When releasing the sail panel retainers, it is
helpful to pull down on the rear roof bow. 5. As you begin to lower the top, fold the sail panels so
that they rest on top of the soft top.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 229

6. Release the Sunrider® latch (both sides).
7. Open the swing gate and lower the top.NOTE:
Ensure fabric does not overhang the sides of the
vehicle.
230 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Quick Steps To Raising The Soft Top
Refer to “Raising The Soft Top” in this section for further
information.
1. Open the swing gate and raise the top, engaging theSunrider® latches (another person may be needed to
help with this operation).
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 231

2. Engage header latches.3. Install rear corner panels.
232 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

4. Install the back window.5. Install the side windows.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 233

6.Insert the front retainer of the window into the door
channel, making sure the retainer is fully seated and
properly positioned on the door frame. Failure to do so can
result in wind and water leaks or damage to the window.7. Insert the retainer along the bottom edge of thewindow into the bottom side channel, beginning at the
front and working to the rear of the vehicle. Finish by
closing the zipper completely and attaching the Vel-
cro® along the top and rear of the window. Repeat this
step for the opposite side.
1 — Incorrect Insertion
2 — Correct Insertion
234 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Lowering The Soft Top
1 — Header Bow6 — Quarter Window
2 — 2–Bow 7 — Check Strap
3 — 3–Bow 8 — Front Retainer — Quarter Window
4 — Sail Panel 9 — Bottom Retainer — Quarter Window
5 — Body Side Retainer
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 235

1 — Zipper Start
2 — Zipper Finish
3 — Swing Gate Bar
4 — Swing Gate Brackets
5 — Sail Panels 236 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

NOTE:Clean side and rear windows before removal to
assist in preventing scratching during removal of the soft
top. If zippers are difficult to operate due to road dust,
etc., clean them with a mild soap solution and a small
brush. Cleaning products are available through your
authorized dealer.
1. If your vehicle has half doors, remove each half-door window by opening the door and lifting the half-door
window out.
NOTE: Stow the half-door windows carefully outside of
the vehicle, never inside, to avoid scratches.
2. Unclip and move the sun visors to the side.
3. Release the header latches and leave the hooks in the loops on the windshield. 4. Open the swing gate.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 237

5. Before unzipping the rear window, release the first 3 in(7.6 cm) of both sail panels from the channel. Remove
the swing gate bar by pulling it straight rearward out
of the swing gate brackets. •
Unzip the rear window starting at the right lower
corner of the window. Pull the zipper up, across the
top and down to the left lower corner. Zipper pulls
will stay on the rear window. Pull down on the rear
window to disengage it from the zipper on the top
cover.
