4. Release the sail panel retainers from the body sidechannel at the rear corners of the vehicle. NOTE:
When releasing the sail panel retainers, it is
helpful to pull down on the rear roof bow.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 259

5. Fold the sail panels so that they rest on top of the softtop. 6. Fold header rearward, pulling the fabric to the rear.
260 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

7. Release Sunrider® latch (both sides).8. Open the swing gate and lower the top.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 261

NOTE:Ensure the fabric does not overhang the sides of
the vehicle.
Quick Steps For Raising The Soft Top
1. Open the swing gate and raise the top, engaging the Sunrider® latches (another person may be needed to
help with this operation).
262 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

2. Install rear corner panels.3. Rotate the header forward.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 263

4. Engage the header latches.5. Install the back window.
264 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

6. Install the side windows.7. To install the side windows, affix the window tempo-
rarily by attaching to the Velcro® in the rear corner.
Start the zipper but close only about 1 in (2.5 cm).
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 265

8. Insert the front retainer of the window into the doorchannel, making sure the retainer is fully seated and
properly positioned on the door frame. Failure to do
so can result in wind and water leaks or damage to the
window.1 — Incorrect Insertion
2 — Correct Insertion
266 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

9. Insert the retainer along the bottom edge of thewindow into the bottom side channel, beginning at the
front and working to the rear of the vehicle. Finish by
closing the zipper completely and attaching the Vel-
cro® along the top and rear of the window. Repeat this
step for the opposite side.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 267

Folding Down The Soft Top
1 — Header Bow6 — Body Side Retainer
2 — 2–Bow 7 — Quarter Window
3 — 3–Bow 8 — Check Strap
4 — 4–Bow 9 — Front Retainer — Quarter Window
5 — Sail Panel 10 — Bottom Retainer — Quarter Window
268 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
