Two Door Soft Top Down
Follow these simple steps to lower the Two Door soft top.
1. Remove the side and back windows.
2. Fold and place the Sail Panels on top of your Wrangler.
Step 1
Step 2
OPERATING YOUR VEHICLE
39

3. Release header latches from the windshield frame.
4. Make sure the plastic sleeves are slid rearward over the Sunrider link to lock in thelink (Sunrider Models only).
Step 3
Step 4
OPERATING YOUR VEHICLE
40

5. Release the Sunrider latch (both sides).
6. Open the swing gate and lower the top.
NOTE:
Ensure the fabric does not overhang the
sides of the vehicle.
• To raise the soft top, perform theabove steps in the opposite order.
Step 5
Step 6
OPERATING YOUR VEHICLE
41

Four Door Sunrider Down
Follow these simple steps to open the Sunrider feature.
1. Unclip and move the sun visors to the side.
2. Release the header latches from the loops on the windshield frame.
3. Grasp the front side bow behind the header, and lift the top.
Step 2
Step 3
OPERATING YOUR VEHICLE
42

4. Fold the top so that the material forms a "W" as shown. Enter the vehicle and movethe material into two folds.
5. Fold back the front section of the top and gently rest the header on top of the rear portion of the deck.
Step 4
Step 5
OPERATING YOUR VEHICLE
43

6. Secure the top by using the two provided straps. Each strap will wrap around theside bow and Velcro to itself; use one strap on each side of the vehicle.
NOTE:
• Failure to fold the fabric rearward will allow the material to sag and may
block the rearview mirror.
• If you are going to be driving faster than 40 mph (64 km/h) with the Sun-
rider feature open, it is recommended
that you remove the rear window of the
vehicle.
• To close the Sunrider feature, perform the above steps in the opposite order.
Four Door Soft Top Down
Follow these simple steps to lower the Four Door soft top.
1. Remove the side and back windows.
Step 6
Step 1
OPERATING YOUR VEHICLE
44

2. Fold and place the Sail Panels on top of your Wrangler.
3. Release header latches from the windshield frame.
Step 2
Step 3
OPERATING YOUR VEHICLE
45

4. Fold header rearward, pulling the fabric to the rear.
5. Fold the top so that the material forms a "W" as shown. Enter the vehicle and movethe material into two folds.
Step 4
Step 5
OPERATING YOUR VEHICLE
46

6. Release Sunrider latch (both sides).
Step 6
Step 6
OPERATING YOUR VEHICLE
47

7. Open the swing gate and lower the top.
NOTE:
Ensure the fabric does not overhang the
sides of the vehicle.
• To raise the soft top, perform theabove steps in the opposite order.
CAUTION!
• Do not run a fabric top through an automatic car wash. Window scratches and
wax buildup may result.
• Do not lower the top when the temperature is below 41°F (5°C). Damage to the
top may result.
• Do not lower the top when the windows are dirty. Grit may scratch the window.
• Do not move your vehicle until the top has been either fully attached to the
windshield frame, or fully lowered.
• The soft top is not designed to carry any additional loads such as roof racks,
spare tires, building, hunting, or camping supplies, and/or luggage, etc. Also,
it was not designed as a structural member of the vehicle and, thus, cannot
properly carry any additional loads other than environmental (rain, snow, etc.).
WARNING!
• Do not drive the vehicle with the rear window curtain up unless the sidecurtains are also open. Dangerous exhaust gases which can kill could enter the
vehicle.
• The fabric upper doors and fabric top are designed only for protection against
the elements. Do not rely on them to contain occupants within the vehicle or to
protect against injury during an accident. Remember, always wear seat belts.
