18. Before lowering the top, open the swing gate to preventpossible damage to the rear center high-mounted brake
light. Move to the front of the vehicle. Grasp the side
bow behind the header and lift the top, folding it
toward the rear of the vehicle.
NOTE: Help from another person will ease this operation. 19. Tuck the fabric and the check straps between the bows
and as far inward as possible. This will keep any
portion of the top from flapping outside of the vehicle.
20. Close the front header latches.
21. Remove the door frames, if desired. Refer to “Door Frame” in this section for further information.
Step Eighteen
Step Nineteen
3
GETTING TO KNOW YOUR VEHICLE 119

Raising The Soft Top
1. Unclip and move the sun visors to the side.
2. Install door frames, if removed. Refer to “Door Frame”in this section for further information.
3. Make sure the plastic sleeve is slid over Sunrider link (Sunrider Models only). 4. Standing on the side of the vehicle, lift the top by the
side bow and the 2–bow (middle bow) up and over the
sports bar until the header rests on the top of the
windshield frame.
Step Three
Step Four
120 GETTING TO KNOW YOUR VEHICLE

5. Make sure the Sunrider bracket on the side bows latchesto the door rails (Sunrider Models only). 6. Open the header latches and engage the hook on each
side onto the windshield loops (do not close the latches).
Step Five
Step Six
3
GETTING TO KNOW YOUR VEHICLE 121

7. If the swing gate brackets were removed, install them byhooking the rear edge of the bracket on the interior side
of the body channel. Then, rotate it rearward and over
the channel until it snaps onto the exterior part of the
rail. To be properly located, the bracket must only be
clipped to the shortened rail edge. 8. Move to the rear of the vehicle and gently pull the sail
panels over the rear roof bow.
Step Seven
Step Eight
122 GETTING TO KNOW YOUR VEHICLE

9. Partially install the sail panel retainers into the bodyside channel, leaving the last 3 in (7.6 cm) toward the
rear window loose (on both sides). Pulling down on the
rear roof bow (3–bow) will aid to reach the channel with
the retainers. 10. To install the side windows, affix the window tempo-
rarily by attaching to the Velcro in the rear corner. Start
the zipper but close only about 1 in (2.5 cm).
Step Nine
Step Ten
3
GETTING TO KNOW YOUR VEHICLE 123

11. Insert the front retainer of the window into the doorchannel, making sure the retainer is fully seated and
properly positioned on the door frame. Failure to do so
can result in wind and water leaks or damage to the
window.
Step Eleven
Retainer Insertion
1 — Incorrect Insertion
2 — Correct Insertion
124 GETTING TO KNOW YOUR VEHICLE

12. Insert the retainer along the bottom edge of the win-dow into the bottom side channel, beginning at the
front and working to the rear of the vehicle. Finish by
closing the zipper completely and attaching the Velcro
along the top and rear of the window. Repeat this step
for the opposite side.
Step Twelve
Step Twelve
3
GETTING TO KNOW YOUR VEHICLE 125

13. Locate the black swing gate bar. Slide the swing gatebar over the receiver at the bottom inside of the rear
window. The spongy part of the seal should be down
and pointed outward to seal with the swing gate when
closed. 14. Install the rear window by starting both zipper ends at
the lower left corner of the rear window opening.
Ensure that the zippers are properly started and
aligned before zipping to prevent damage.
Step Thirteen
Step Fourteen
126 GETTING TO KNOW YOUR VEHICLE

15. Run the zipper fully around to the right side of thewindow. 16. Grasp the swing gate bar and position it into the swing
gate brackets.
Step Fourteen
Step Sixteen
3
GETTING TO KNOW YOUR VEHICLE 127

17. Insert the rear window retainer into the swing gatebracket on both the left and right sides.
18. Apply downward pressure on the top corner of the rear soft top bow (3–bow), then complete attaching the sail
panel retainers into the body side channel. 19. Close the header latches and return the sun visors to
their secured position.
Step SeventeenStep Nineteen
