JEEP WRANGLER 2017 JK / 3.G Owners Manual

2. Install rear corner panels.
Step One
Step Two
3
GETTING TO KNOW YOUR VEHICLE 139

3. Rotate the header forward.4. Engage the header latches.
Step ThreeStep Four
140 GETTING TO KNOW YOUR VEHICLE

5. Install the back window.6. Install the side windows.
Step FiveStep Six
3
GETTING TO KNOW YOUR VEHICLE 141

7. To install the side windows, affix the window tempo-rarily by attaching to the Velcro in the rear corner. Start
the zipper but close only about 1 in (2.5 cm). 8. Insert the front retainer of the window into the door
channel, making sure the retainer is fully seated and
properly positioned on the door frame. Failure to do so
can result in wind and water leaks or damage to the
window.
Step Seven
Retainer Insertion
1 — Incorrect Insertion
2 — Correct Insertion
142 GETTING TO KNOW YOUR VEHICLE

9. Insert the retainer along the bottom edge of the windowinto the bottom side channel, beginning at the front and
working to the rear of the vehicle. Finish by closing the
zipper completely and attaching the Velcro along the top
and rear of the window. Repeat this step for the opposite
side.
Step Nine
3
GETTING TO KNOW YOUR VEHICLE 143

Folding Down The Soft Top
Side View Top And Components
1 — 4– Bow6 — Quarter Window
2 — 3–Bow 7 — Body Side Retainer
3 — 2–Bow 8 — Bottom Retainer — Quarter Window
4 — Header Bow 9 — Sail Panel
5 — Front Retainer — Quarter Window 10 — Check Strap
144 GETTING TO KNOW YOUR VEHICLE

Rear View Top And Components
1 — Sail Panels
2 — Zipper Finish
3 — Swing Gate Bar
4 — Zipper Start
5 — Swing Gate Brackets
3
GETTING TO KNOW YOUR VEHICLE 145

NOTE:Clean side and rear windows before removal to
assist in preventing scratching during removal of the soft
top. If zippers are difficult to operate due to road dust, etc.,
clean them with a mild soap solution and a small brush.
Cleaning products are available through your authorized
dealer.
1. If your vehicle has half-doors, remove each half-door window by opening the door and lifting the half-door
window out.
NOTE: Stow half-door windows carefully outside of the
vehicle, never inside, to avoid scratches.
2. Unclip and move the sun visors to the side. 3. Release the header latches and hooks from the loops on
the windshield frame.
Step Three
146 GETTING TO KNOW YOUR VEHICLE

4. Open the swing gate.
5. Before unzipping the rear window, release the first 3 in(7.6 cm) of both sail panels from the channel. Remove
the swing gate bar by pulling it straight rearward out of
the swing gate brackets. 6. Unzip the rear window starting at the right lower corner
of the window. Pull the zipper up, across the top and
down to the left lower corner. Zipper pulls will stay on
the rear window. Pull down on the rear window to
disengage it from the zipper on the top cover.
Step FiveStep Six
3
GETTING TO KNOW YOUR VEHICLE 147

7. Remove the rear window retainer from the swing gatebracket on both the left and right sides.
8. Stow the windows carefully to avoid scratching.
9. Undo the Velcro that runs along the top and rear edge of the side window. 10. Beginning from the rear lower corner, completely un-
zip the window.
11. Once unzipped, remove the side window retainers from the door channel and body side channel. Repeat
this step on the opposite side.
Step SevenStep Ten
