JEEP WRANGLER UNLIMITED 2013 Owners Manual

▫ Front Panel(s) Installation With Rear Hard
Top Removed ....................... .210
▫ Rear Hard Top Removal ............... .210
▫ Rear Hard Top Installation .............. .213
 DOOR FRAME ........................ .214
▫ Door Frame Removal .................. .215
▫ Door Frame Installation
— Two-Door Models .................. .217
▫ Door Frame Installation
— Four-Door Models .................. .218
 SOFT TOP — TWO-DOOR MODELS ....... .221
▫ Quick Steps To Lowering The Soft Top ..... .223
▫ Quick Steps To Raising The Soft Top ....... .227
▫ Lowering The Soft Top ................. .231 ▫ Raising The Soft Top .................. .240
 SOFT TOP — FOUR-DOOR MODELS ....... .249
▫ Quick Steps For Lowering The Soft Top ..... .252
▫ Quick Steps For Raising The Soft Top ...... .256
▫ Folding Down The Soft Top ............. .261
▫ Putting Up The Soft Top ................ .271
 SUNRIDER  (TWO-DOOR MODELS) — IF
EQUIPPED .......................... .280
▫ Opening The Sunrider  ................ .281
▫ Closing The Sunrider  ................. .283
 SUNRIDER  (FOUR-DOOR MODELS) — IF
EQUIPPED .......................... .283
▫ Opening The Sunrider  ................ .284
▫ Closing The Sunrider  ................. .2863 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109

 FOLDING WINDSHIELD ................ .286
▫ Lowering The Windshield And Removing
Side Bars .......................... .288
▫ Raising The Windshield And Replacing
Side Bars .......................... .291  REAR WINDOW FEATURES
— HARD TOP ONLY .................. .293
▫ Rear Window Wiper/Washer — If Equipped . .293
▫ Rear Window Defroster — If Equipped ..... .294110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

MIRRORS
Inside Day/Night Mirror
A two-point pivot system allows for horizontal and
vertical adjustment of the mirror. Adjust the mirror to
center on the view through the rear window.
Headlight glare can be reduced by moving the small
control lever under the mirror to the night position (lever
flipped toward the rear of vehicle). The mirror should be
adjusted while set in the day position (toward the wind-
shield). Adjusting Rearview Mirror
3 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111

Outside Mirrors
To receive maximum benefit, adjust the outside mirror(s)
to center on the adjacent lane of traffic with a slight
overlap of the view obtained on the inside mirror.
WARNING!Vehicles and other objects seen in the passenger side
convex mirror will look smaller and farther away
than they really are. Relying too much on your
passenger side mirror could cause you to collide with
another vehicle or other object. Use your inside
mirror when judging the size or distance of a vehicle
seen in the passenger side mirror.
Outside Rearview Mirror112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Power Mirrors — If Equipped
The power mirror switch is located on the center of the
instrument panel, below the climate controls. A rotary
knob selects the left mirror, right mirror or off position. After selecting a mirror, move the knob in the same
direction you want the mirror to move. Use the center off
position to guard against accidentally moving a mirror
position.
Heated Mirrors — If Equipped
These mirrors are heated to melt frost or ice. This
feature is activated whenever you turn on the rear
window defroster. Refer to “Rear Window Features” in
“Understanding The Features Of Your Vehicle” for fur-
ther information.
Power Mirror Switch
3 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113

Vanity Mirrors
Vanity mirrors are located on the sun visors. To use the
mirrors, rotate the sun visor down and swing the mirror
cover upward. Uconnect™ Phone — IF EQUIPPED
Uconnect™ Phone is a voice-activated, hands-free, in-
vehicle communications system. Uconnect™ Phone allows
you to dial a phone number with your mobile phone using
simple voice commands (e.g., “Call”  “Mike”  “Work” or
“Dial”  “248-555-1212”). Your mobile phone’s audio is
transmitted through your vehicle’s audio system; the sys-
tem will automatically mute your radio when using the
Uconnect™ Phone.
NOTE: The Uconnect™ Phone requires a mobile phone
equipped with the Bluetooth  “Hands-Free Profile”, Ver-
sion 0.96 or higher. See the Uconnect™ website for
supported phones.
Vanity Mirror114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

For Uconnect™ customer support, visit the following
websites:
• www.chrysler.com/uconnect
• www.dodge.com/uconnect
• www.jeep.com/uconnect
• or call 1–877–855–8400
Uconnect™ Phone allows you to transfer calls between
the system and your mobile phone as you enter or exit
your vehicle and enables you to mute the system’s
microphone for private conversation.
The Uconnect™ Phone is driven through your Bluetooth
“Hands-Free Profile” mobile phone. Uconnect™ features
Bluetooth  technology - the global standard that enables
different electronic devices to connect to each other without
wires or a docking station, so Uconnect™ Phone works no
matter where you stow your mobile phone (be it your purse, pocket, or briefcase), as long as your phone is turned
on and has been paired to the vehicle’s Uconnect™ Phone.
The Uconnect™ Phone allows up to seven mobile phones
to be linked to the system. Only one linked (or paired)
mobile phone can be used with the system at a time. The
system is available in English, Spanish, or French lan-
guages.
WARNING!Any voice commanded system should be used only
in safe driving conditions following all applicable
laws, including laws regarding phone use. All atten-
tion should be kept on the roadway ahead. Failure to
do so may result in a collision causing serious injury
or death.
3 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115

Uconnect™ Phone Button
The radio or steering wheel controls (if
equipped) will contain the two control buttons
(Uconnect™ Phone button and Voice
Command button) that will enable you to
access the system. When you press the button you will
hear the word Uconnect™ followed by a BEEP. The beep
is your signal to give a command.
NOTE: The driver side upper windshield trim contains
the microphone for the Uconnect™ Phone.
Voice Command Button
Actual button location may vary with the ra-
dio. The individual buttons are described in the
“Operation” section. The Uconnect™ Phone can be used with any Hands-Free
Profile certified Bluetooth  mobile phone. See the
Uconnect™ website for supported phones. Refer to your
mobile service provider or the phone manufacturer for
details.
The Uconnect™ Phone is fully integrated with the vehi-
cle’s audio system. The volume of the Uconnect™ Phone
can be adjusted either from the radio volume control
knob or from the steering wheel radio control (right
switch), if so equipped.
The radio display will be used for visual prompts from
the Uconnect™ Phone such as “CELL” or caller ID on
certain radios.116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Operation
Voice commands can be used to operate the Uconnect™
Phone and to navigate through the Uconnect™ Phone
menu structure. Voice commands are required after most
Uconnect™ Phone prompts. You will be prompted for a
specific command and then guided through the available
options.
• Prior to giving a voice command, one must wait for the
beep, which follows the “Ready” prompt or another
prompt.
• For certain operations, compound commands can be
used. For example, instead of saying “Setup” and then
“Phone Pairing”, the following compound command
can be said: “Setup Phone Pairing”. • For each feature explanation in this section, only the
compound form of the voice command is given. You
can also break the commands into parts and say each
part of the command when you are asked for it. For
example, you can use the compound form voice com-
mand “Phonebook New Entry”, or you can break the
compound form command into two voice commands:
“Phonebook” and “New Entry”. Please remember, the
Uconnect™ Phone works best when you talk in a
normal conversational tone, as if speaking to someone
sitting a few feet/meters away from you.
Voice Command Tree
Refer to “Voice Tree” in this section.
3 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117

Help Command
If you need assistance at any prompt, or if you want to
know your options at any prompt, say “Help” following
the beep. The Uconnect™ Phone will play all the options
at any prompt if you ask for help.
To activate the Uconnect™ Phone from idle, simply press
the button and follow the audible prompts for
directions. All Uconnect™ Phone sessions begin with a
press of the button on the radio control head.
Cancel Command
At any prompt, after the beep, you can say “Cancel” and
you will be returned to the main menu. However, in a
few instances the system will take you back to the
previous menu. Pair (Link) Uconnect™ Phone to a Mobile Phone
To begin using your Uconnect™ Phone, you must pair
your compatible Bluetooth  enabled mobile phone.
To complete the pairing process, you will need to reference
your mobile phone Owner’s Manual. The Uconnect™
website may also provide detailed instructions for pairing.
The following are general phone to Uconnect™ Phone
pairing instructions:
• Press the button to begin.
• After the “Ready” prompt and the following beep, say
“Setup Phone Pairing”.
• When prompted, after the beep, say “Pair a Phone”
and follow the audible prompts.118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
