Page 351 of 354
83
1
2
3
4
5
6
7
8
9
Specifications
Engine
Electrical system
Item 2.0L
Engine
2.7L
Engine
BoreXStroke 82 mm X 93.5 mm (3.23 in X 3.68 in) 86.7 mm X 75 mm (3.41 in X 2.95 in)
Displacement 1975 cc (120.5 cu.in) 2656 cc (1621 cu.in)
Compression Ratio 10 ± 0.2 : 1 10 ± 0.2 : 1
Size 2.0L
Engine
2.7L
Engine
Battery 12V / 60AH (20HR) 12V / 68AH (20HR)
Generator 13.5V / 90A 13.5V / 120A
Starter 12V-1.2kW 12V-1.2kW
Gap 1.0 mm ~ 1.1 mm (0.039 ~ 0.043 in) 1.0 mm ~ 1.1 mm (0.039 ~ 0.043 in)
Platinum coated PFR5N-11, RC10PYPB4 -
Iridium coated
- IFR5G-11
Spark
Plug
Spec.
KM CAN (ENG) 8.qxd 9/13/2004 4:04 PM Page 3
Page 352 of 354
Specifications4 8
1
2
3
4
5
6
7
8
9
Gear ratioTires
Item Inflation Pressure
Wheel lug nut torque
Tire Wheel kPa (psi) kg·m (lb·ft, N·m)
P215/65R16 96T 6.5J x 16 210 (30)9~11
(65~79, 88~107)
P235/60R16 99T 6.5J x 16 210 (30)9~11
(65~79, 88~107)
Compact spare tire
T155/90R16 110M 4.0T x 16 420 (60)9~11
(65~79, 88~107)
Engine 2.0L
Engine
2.7L
Engine
Gear Manual transaxle Automatic transaxle Automatic transaxle
1st 3.636 2.842 2.842
2nd 2.056 1.529 1.529
3rd 1.333 1.000 1.000
4th 1.061 0.712 0.712
5th 0.821 - -
Reverse 3.455 2.480 2.480
F.G.R2WD
4.533 4.6264.042
4WD 4.407
KM CAN (ENG) 8.qxd 9/13/2004 4:04 PM Page 4
Page 353 of 354
85
1
2
3
4
5
6
7
8
9
Specifications
*1Refer to the recommended SAE viscosity numbers on the page 7-50.Lubricant Volume Classification
Engine oil
*1
4.0 l(4.2 qts.) API Service SJ, SL or above,
(with filter change) 4.5 l(4.8 qts.) ILSAC GF-3 or above
Manual transaxle fluid 2.10 l (2.22 qts.) API Service GL-4 (SAE 75W-85, fill for-life)
Automatic transaxle fluid 7.8 l (8.2 qts.) DIAMOND ATF SP-III or SK ATF SP-III
Transfer case fluid (4WD) 0.8 l (0.85 qts.) API Service GL-5 or above
Rear differential fluid (4WD) 0.75 l (0.79 qts.) (SAE 80W-90, SHELL SPIRAX AX or equivalent)
Power steering 0.9 l (0.95 qts.) PSF-III
Coolant 7.0 l (7.4 qts.) Ethylene glycol base for aluminum radiator
Brake/Clutch fluid 0.7~0.8 l(0.7~0.8 qts.) FMVSS116 DOT-3 or DOT-4
Fuel58 l (15 gal.)
Unleaded gasoline with AKI 87 or higher
65 l (17 gal.)
2.0L2.7L2.0L2.7L
Capacities
KM CAN (ENG) 8.qxd 9/13/2004 4:04 PM Page 5
Page 354 of 354
Specifications6 8
1
2
3
4
5
6
7
8
9
Light Bulb Wattage
Headlights (Low/High) 55/60
Front turn signal lights 27
Position lights 5
Front fog lights (if equipped) 35
Stop and tail lights 28/8
Rear turn signal lights 27
Back-up lights 17
Rear side mark light 5
High mounted stop light LED
*1
License plate lights 5
Front map lamp 10
Center dome lamp 10
Rear dome lamp 10
Door courtesy lamps (if equipped) 5
Cargo area lamp 5
Glove box lamp 5Light bulbs*1LED : Light-emitting diode
KM CAN (ENG) 8.qxd 9/13/2004 4:04 PM Page 6
