PASSENGER SEAT COMPLIANCE WITH REGULATIONS ON UNIVERSAL ISOFIX CHILD SEAT USE
The table below shows the different installation possibilities of Isofix restraint systems on seats fitted with Universal
Isofix fasteners in compliance with European standard ECE 16.
Weight group Orientation Class Isofix positionchild seat Isofix size rear side
Group 0 up to 10 kg
Group 0+ up to 13 kg
Group 1 from 9
up to 18 kg
Facing backwards
Facing backwards
Facing backwards
Facing backwards
Facing backwards
Facing backwards
Facing forwards
Facing forwards
Facing forwards E
E
D
C
D
C
B
B1
AIL
IL
IL
IL (*)
IL
IL (*)
IUF
IUF
IUF
IUF suitable for Isofix child restraint systems facing forwards, universal class (fitted with third upper fastener),
type-approved for the relevant weight group.
IL: suitable for special child restraint systems, specific Isofix type, and type-approved for this type of car. The seat
can be installed by moving the front seat forward.
(*) The Isofix child seat can be installed by moving the front seat all the way up.
095-112 MUSA 3ed GB 12-11-2007 11:36 Pagina 107

108
STARTING
AND
DRIVING
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
MAINTENANCE
AND CARE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
FRONT AIRBAGS
The car is supplied with front airbags
for both the driver and passenger, and
window bags (head protection sys-
tem). On driver’s request, it can be
supplied with front side airbags.
The front airbags (for driver and pas-
senger) have been designed to protect
the passengers sitting on the front
seats in the event of head-on crashes
of medium-high severity, by placing
the bag between the person and the
steering wheel or dashboard.
Non-deployment of the airbags dur-
ing other types of collisions (side col-
lisions, rear shunts, roll-overs, etc.)
does not necessarily indicate a system
malfunction.
An electronic control unit causes the
bag to inflate in the event of a frontal
crash. The bag inflates instanta-
neously placing itself between the
front passenger’s body and the struc-
tures which could cause injury. It de-
flates immediately afterwards.
Driver and passenger front airbags are
not a replacement of, but comple-
mentary to the seat belts, which you
are always recommended to wear, as
specified by law in Europe and most
non-European countries.
In the event of a collision, a person
not wearing the seat belt may bethrown forward and come into con-
tact with the bag before it has fully
opened. The protection offered by the
bag is reduced in such a case.
Front airbags may not be activated in
the following situations:
❒during collisions against highly de-
formable objects that do not affect
the car front surface (e.g. bumper
collision against guard rail, heaps
of gravel, etc.);
❒jamming of the car underneath
other vehicles or protective barri-
ers (e.g. underneath a truck or a
guard rail); in this case, the bags
would offer no additional protec-
tion with respect to the seat belt
and their deployment is unneces-
sary. In these cases non-deploy-
ment of the airbag does not neces-
sarily indicate a system malfunc-
tion.
The front airbags on the driver’s and
passenger’s sides are designed and cal-
ibrated to protect the front seat pas-
sengers who wear the safety belts. The
volume of front airbags at max. infla-
tion fills most of the space between
the steering wheel and the driver and
between the dashboard and the pas-
senger.FRONT AIRBAG ON DRIVER’S
SIDE fig. 17
It consists of an instant-inflating bag
contained in a special recess in the
centre of the steering wheel.
fig. 17L0C0416m
095-112 MUSA 3ed GB 12-11-2007 11:36 Pagina 108

109
STARTING
AND
DRIVING
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
MAINTENANCE
AND CARE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
fig. 18L0C0145m
FRONT AIRBAG ON
PASSENGER’S SIDE fig. 18
It consists of an instant-inflating bag
contained into a special recess Ain the
dashboard. The bag is larger in vol-
ume than the airbag on the driver’s
side. The airbags are not deployed in
the event of collisions of low severity
(for which the withholding action of
the seat belts is sufficient). For this
reason, the seat belt must be worn at
all times. During side collisions the
seat belts hold passengers in the cor-
rect position and prevent ejection
from the car during very violent col-
lisions.
Do not apply stickers/de-
cals or other objects on the
steering wheel, in area A-fig. 18 on
the passenger side airbag or side
upholstery on the roof side. Do not
place objects (e.g. cell phones) on
the passenger side dashboard, be-
cause they could interfere with cor-
rect deployment of the passenger
airbag and cause severe injury to
the persons in the car.
WARNING
SEVERE DANGER: do not
arrange child seats facing
backwards if the front airbag on
the passenger’s side is enabled.
Airbag deployment during a crash
may cause fatal injuries to the
child.
WARNING
If the car is equipped with
a deactivation system for
the front passenger
airbag, disable it when-
ever the child seat needs to
be mounted on the front
seat. Move the passenger’s seat as
far back as possible to avoid con-
tact between the child seat and the
dashboard. Although this is not
mandatory by law, the airbag
should be immediately reactivated
when children are no longer car-
ried to ensure better protection to
adults.
WARNING
095-112 MUSA 3ed GB 12-11-2007 11:37 Pagina 109

110
STARTING
AND
DRIVING
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
MAINTENANCE
AND CARE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
MANUAL DEACTIVATION OF
FRONT AIRBAG AND SIDE BAG
ON PASSENGER’S SIDE
(where provided)
Whenever a child needs to be carried
on the front seat, the passenger’s front
airbag and the Side Bag (where pro-
vided) must be deactivated.
The warning light “on the instru-
ment panel stays on steadily until the
passenger’s front airbag and the Side
Bag (where provided) are re-acti-
vated.SIDE BAGS
(window bag)
(where provided)
SIDE BAG (where provided)
fig. 19
It consists of an instant-inflating bag
housed in the front seat backrest. It
protects the chest of the passengers in
the event of a side crash of medium-
high severity.
To manually deactivate
the passenger’s front
airbag and the Side Bag (where
provided), refer to paragraph
“Multifunctional reconfigurable
display” in section “Dashboard
and controls”.
WARNING
Do not cover the front seat
backrest with upholstery
or seat covers that hinder deploy-
ment of the side bag.
WARNING
fig. 19L0C0147m
fig. 20L0C0148m
WINDOW BAG
(where provided) fig. 20
It consists of two “drop-down” bags
housed behind the side upholstery of
the roof and covered with finishing el-
ements that protect the head of front
and rear passengers in the event of a
side crash thanks to a wide bag de-
ployment area. Lineaccessori Lancia includes seat
covers enabling side bag deployment.
095-112 MUSA 3ed GB 12-11-2007 11:37 Pagina 110

111
STARTING
AND
DRIVING
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
MAINTENANCE
AND CARE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
Side bags are not a replacement of,
but complementary to the seat belts,
which you are always recommended
to wear, as specified by law in Europe
and in most non-European countries.
IMPORTANT In the event of a side
crash, the system provides best pro-
tection if the passenger sits on the seat
in a correct position, thus allowing
correct window bag deployment.
IMPORTANT The front airbags
and/or side bags are deployed also if
the car is subject to strong collisions
or accidents involving the underbody
area, such as violent shocks against
steps, kerbs or low obstacles, falling
of the car in big holes or sags in the
road.
IMPORTANT A small amount of dust
is released when the airbags are de-
ployed. The dust is not harmful and
does not indicate the beginning of a
fire. Furthermore, the surface of the
deployed bag and the interior of the
car may be covered with residual
dust. This dust may irritate the skin
and the eyes. Use mild soap and wa-
ter to wash the parts of your body ex-
posed to this dust.The pyrotechnic charge of the airbag
system lasts for 14 years; the spiral
contact 10 years. Go to a Lancia
Dealership to have the devices re-
placed when the expiration date ap-
proaches.
IMPORTANT Should an accident oc-
cur activating any of the safety de-
vices, take the car to a Lancia Deal-
ership to have the activated devices
replaced and the system checked.
Airbag checking, repair and replace-
ment must only be carried out c/o the
Lancia Dealership.
If you are having the car scrapped,
have the airbag system deactivated at
a Lancia Dealership first. If the car
changes ownership, the new owner
must be informed of how to use the
airbags and the above warnings: s/he
must also be given this “Owner’s
Handbook”.
IMPORTANT Pretensioners, front
airbags and front side bags are de-
ployed differently according to the
type of collision. Non-deployment of
one of the devices does not necessar-
ily indicate a system malfunction.
Do not rest the head, arms
or elbows on the door, win-
dows and window bag area to avoid
possible injuries during inflation.
Never lean head, arms and elbows
out of the window.
WARNING
If the warning light ¬
does not turn on or stays
on during car travel when turning
the key to MAR, a failure may be
present in the restraint systems. If
this is the case, the airbags or pre-
tensioners may not be deployed af-
ter an impact or, in a minor num-
ber of cases, they may be deployed
accidentally. Contact a Lancia
Dealership immediately to have
the system checked.
Do not cover the front seat backrest
with upholstery or seat covers that
hinder deployment of the side bag.
WARNING
GENERAL WARNINGS
095-112 MUSA 3ed GB 12-11-2007 11:37 Pagina 111

112
STARTING
AND
DRIVING
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
MAINTENANCE
AND CARE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
Always drive keeping your
hands on the steering
wheel so that the airbag can inflate
without obstacles if it is deployed.
Do not drive with your body bent
forward. Keep your back straight
against the backrest. If the car is
stolen or an attempt is made to
steal it, or if the car has been sub-
jected to illegal attacks or flooding,
have the airbag system checked by
a Lancia Dealership.
WARNING
Do not travel carrying ob-
jects on your lap or oppo-
site the chest and keeping a pipe,
pencils, etc. between your lips in
order to avoid serious injuries due
to deployment of the airbag after a
collision.
WARNING
The front airbag is de-
ployed in the event of col-
lisions having a more severe nature
than those required to activate the
pretensioners. For collisions in
the range between the two activa-
tion thresholds, pretensioner acti-
vation is normal.
WARNING
Turning the ignition key to
MAR, the warning light “
(airbag on passenger’s side en-
abled) goes on and flashes for a
few seconds, thus reminding the
passenger that the airbag on
his/her side will deploy in the
event of a collision. After this time,
the light goes off.
WARNING
Do not wash the car seats
with water or pressurised
steam (both by hand or at auto-
matic washing stations).
WARNING
The airbag does not re-
place the safety belts, it
increases their effectiveness. Fur-
thermore, since front airbags are
not deployed after low speed colli-
sions, side collisions, rear-end
shunts or roll-overs, the passen-
gers are only protected by the seat
belts which must be fastened at all
times.
WARNING
Do not hook rigid objects
to cloth hangers and to the
support handles.
WARNING
If the ignition key is in
place and in the MAR po-
sition, the airbags are deployed
even with the engine off in the event
of a car crash against another
moving vehicle. For this reason,
children must never sit on the front
seat, even if the car is not moving.
On the other hand, whenever the
key is positioned on STOP, the
safety devices (airbags or preten-
sioners) do not deploy after a col-
lision. In this case non-deployment
of these devices does not indicate a
system malfunction.
WARNING
095-112 MUSA 3ed GB 12-11-2007 11:37 Pagina 112

113
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
MAINTENANCE
AND CARE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
STARTING
AND
DRIVING
STARTING AND DRIVING
ENGINE STARTING ......................................... 114
PARKING THE CAR ......................................... 116
USING THE MECHANICAL GEARBOX............117
CONTAINING RUNNING COSTS ..................... 118
TOWING TRAILERS ........................................ 119
SNOW TYRES .................................................. 122
SNOW CHAINS ................................................ 123
CAR INACTIVITY ............................................ 124
113-124 MUSA 3ed GB 12-11-2007 11:37 Pagina 113

114
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
MAINTENANCE
AND CARE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
STARTING
AND
DRIVING
STARTING
THE ENGINE
The car is provided with an electronic
engine lock device: refer to “The Lan-
cia CODE system” paragraph in
“Dashboard and controls” if you can-
not start the engine. The engine may
be noisier during the first seconds of
operation, particularly after a long pe-
riod of inactivity. This does not impair
functionality and reliability and is
typical of hydraulic tappets: the dis-
tribution system selected for the petrol
engines of your car in order to limit
the maintenance required.
STARTING PROCEDURE FOR
PETROL VERSIONS
Proceed as follows:
❒ensure that the handbrake is up;
❒put the gear lever into neutral;
❒press the clutch pedal down to the
floor without touching the accel-
erator;
❒turn the ignition to AV Vand re-
lease the key as soon as the engine
starts.If the engine does not start at the first
attempt, return the ignition key to
STOPbefore repeating starting.
If, when the ignition key is on MAR,
the instrument panel warning light
Yremains on together with the
warning light U, turn the key to
STOPand then back to MAR; if the
warning light remains on, try with the
other keys provided with the car.
Is is dangerous to let the
engine run in enclosed
spaces. The engine depletes the
oxygen and discharges carbon
dioxide, carbon monoxide and
other toxic gases.
WARNING
In the first period of use, we
recommend to avoid exces-
sive stress for the car (for
instance excessive acceler-
ations, extended travel at maximum
speed, sudden braking etc.).
With engine off, do not leave
the key in the ignition
switch on MAR to prevent
draining the battery.
If you still cannot start the engine,
perform emergency start (see “Emer-
gency start” in chapter “In an emer-
gency”) and then contact a Lancia
Dealership.
IMPORTANT Never leave the ignition
key to MARwhen the engine is off.
STARTING PROCEDURE FOR
MULTIJET VERSIONS
Proceed as follows:
❒ensure that the handbrake is up;
❒put the gear lever into neutral;
❒turn the ignition key to MAR; the
instrument panel warning lights
m,
UandY;
113-124 MUSA 3ed GB 12-11-2007 11:37 Pagina 114

115
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
MAINTENANCE
AND CARE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
STARTING
AND
DRIVING
❒turn on; wait for the warning light
Yand
mto turn off (the hot-
ter the engine the shorter the time
it takes to turn off);
❒press the clutch pedal down to the
floor without touching the accel-
erator;
❒turn the ignition key to AV Vas
soon as the warning light
mturns
off. Waiting too long will waste the
work done by the glow plugs. Re-
lease the key as soon as the engine
starts.
IMPORTANT When the engine is
cold, rotating the ignition key to AV V,
the accelerator pedal must be com-
pletely released.
If the engine does not start at the first
attempt, return the ignition key to
STOP before repeating starting.
If, when the ignition key is on MAR,
the instrument panel warning light
Yremains on, turn the key to STOP
and then back to MAR; if the warn-
ing light remains on, try with the
other keys provided with the car.
If you still cannot start the engine,
contact the Lancia Dealership.HOW TO WARM UP THE
ENGINE AFTER IT HAS JUST
STARTED (petrol and Multijet
engines)
Proceed as follows:
❒drive off slowly, letting the engine
turn at medium speed. Do not ac-
celerate abruptly;
❒do not demand maximum perfor-
mance for the first few kilometres.
Wait until the engine coolant
gauge starts moving.Warning light
mwill
blink for 60 seconds after
starting or during pro-
longed cranking to indicate
a fault to the glow plug heating sys-
tem. Use the car normally if the en-
gine starts and contact the Lancia
Dealership as soon as possible.
EMERGENCY START
If the instrument panel warning light
Ystays on steadily, you can perform
emergency start using the code on the
CODE card (see chapter “In an emer-
gency”).
STOPPING THE ENGINE
Turn the ignition to STOPwhile the en-
gine is idling.
IMPORTANT After a taxing drive,
you should allow the engine to “catch
its breath” before turning it off by let-
ting it idle to allow the temperature in
the engine compartment to fall.
Never jump start the engine
by pushing, towing or dri-
ving downhill. These ac-
tions could cause the fuel to
flow into the catalytic converter and
damage it beyond repair.
Revving up before stopping
the engine is useless, it
causes unnecessary fuel
consumption and can dam-
age the engine, in particular engines
equipped with turbocharger.
IMPORTANT With engine off, do not
leave the key in the ignition switch on
MAR.
113-124 MUSA 3ed GB 12-11-2007 11:37 Pagina 115

116
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
MAINTENANCE
AND CARE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
STARTING
AND
DRIVING
PARKING THE CAR
Proceed as follows:
❒stop the engine and engage the
handbrake;
❒when on a slope, engage a gear
(engage first gear if the car is
faced uphill or reverse if it is faced
downhill) and leave the wheels
steered.
When parking the car on a steep
slope, it is advisable to also place a
wedge or a rock under the wheels.
PROLONGED parking with a wheel
on the pavement or steered against a
step should be avoided. Do not leave
the ignition key on MARto prevent
draining the battery. Always remove
the key when you leave the car.
HANDBRAKE
The handbrake lever is located be-
tween the two front seats.
Pull the lever upwards to operate the
handbrake.
Four or five notches are normally suf-
ficient to lock the car on flat terrain,
while nine or ten may be necessary on
a steep slope with the car loaded. IMPORTANT If this is not the case,
contact a Lancia Dealership to have
the handbrake adjusted.
When the handbrake lever is pulled
up and the ignition key is on MAR,
the instrument panel warning light
xwill turn on.
Proceed as follows to release the
handbrake:
❒slightly lift the handbrake and
press release button A-fig. 1;
❒keep button Apressed and lower
the lever. Warning light
xwill
turn off.
Press the brake pedal when carrying
out this operation to prevent the car
from moving accidentally.
IMPORTANT If the handbrake lever
tends to reach end of its stroke
(groove on the central console), con-
tact a Lancia Dealership to have the
handbrake adjusted.
fig. 1L0D0149m
Never leave children unat-
tended in the car. Always
remove the ignition key
when leaving the car and
take it out with you.
113-124 MUSA 3ed GB 12-11-2007 11:37 Pagina 116
