CONTENTS
CONTENTS 3
MAINTENANCE ........................................................................................ 10-1
PROCEDURES
V8 engine underbonnet view .......................................................................................................... 10-1
Diesel underbonnet view ................................................................................................................. 10-2
Seats and seat belts ...................................................................................................................... 10-3
Lamps, horns and warning indicators ............................................................................................. 10-5
Wipers and washers ...................................................................................................................... 10-5
Handbrake .................................................................................................................................. 10-6
Alarm handset battery ..................................................................................................................... 10-6
Road wheels ................................................................................................................................... 10-6
Tyres .............................................................................................................................................. 10-6
Brake pads, discs and calipers ....................................................................................................... 10-6
Road wheel speed sensors ............................................................................................................. 10-7
Brake fluid ....................................................................................................................................... 10-7
Fuel filter - diesel engine ................................................................................................................. 10-7
Fuel filter sedimenter ...................................................................................................................... 10-7
Road wheels ................................................................................................................................... 10-8
Radiator/Intercooler ........................................................................................................................ 10-8
Ambient air Temperature and pressure sensor .............................................................................. 10-8
Doors, bonnet and fuel filler flap ..................................................................................................... 10-8
Air suspension intake filter .............................................................................................................. 10-9
Anti-freeze....................................................................................................................................... 10-9
Cooling system ............................................................................................................................... 10-9
Spark plugs - V8 engine.................................................................................................................. 10-10
Air cleaner - V8 engine ................................................................................................................... 10-10
Air cleaner and dump valve - diesel engine .................................................................................... 10-10
Auxiliary drive belt ........................................................................................................................... 10-11
Auxiliary drive belt - V8 engine ....................................................................................................... 10-11
Auxiliary drive belt - diesel engine .................................................................................................. 10-11
Fluid reservoirs ............................................................................................................................... 10-12
Steering box .................................................................................................................................... 10-13
Battery ............................................................................................................................................. 10-13
Intercooler - diesel engine............................................................................................................... 10-14
Engine oil - V8 engine ..................................................................................................................... 10-14
Engine oil - diesel engine ................................................................................................................ 10-15
Centrifuge rotor – diesel engine ...................................................................................................... 10-15
Engine oil filter - diesel engine ........................................................................................................ 10-16
Engine oil filter – V8 engine ............................................................................................................ 10-16
Manual gearbox .............................................................................................................................. 10-17
Automatic gearbox ......................................................................................................................... 10-18
Transfer box .................................................................................................................................... 10-19
Front and rear axle .......................................................................................................................... 10-20
Propeller shafts ............................................................................................................................... 10-20
Anti-roll bar links ............................................................................................................................. 10-22
ACE actuators ................................................................................................................................. 10-23
ACE filter ......................................................................................................................................... 10-23

CONTENTS
6CONTENTS
EMISSION CONTROL - V8 ....................................................................... 17-2-1
DESCRIPTION AND OPERATION
Crankcase emission control system ............................................................................................... 17-2-1
Exhaust emission control ................................................................................................................ 17-2-2
Evaporative emission system component layout ............................................................................ 17-2-3
Evaporative emission system (with positive pressure leak detection) component layout (NAS only) 17-2-4
Evaporative emission system control diagram ............................................................................... 17-2-5
Secondary air injection system component layout.......................................................................... 17-2-6
Secondary air injection system control diagram ............................................................................. 17-2-8
Emission Control Systems .............................................................................................................. 17-2-9
Crankcase Emission Control System ............................................................................................. 17-2-10
Exhaust Emission Control System.................................................................................................. 17-2-11
Evaporative Emission Control System............................................................................................ 17-2-15
Secondary Air Injection System ...................................................................................................... 17-2-26
Crankcase Emission Control Operation.......................................................................................... 17-2-34
Exhaust Emission Control Operation .............................................................................................. 17-2-35
Evaporative Emission Control Operation ........................................................................................ 17-2-39
Secondary Air Injection System Operation ..................................................................................... 17-2-43
SAI System Fault Finding and Check Malfunctions ........................................................................ 17-2-44
REPAIRS
Canister - EVAP ............................................................................................................................ 17-2-51
Canister - EVAP - Models with Fuel Leak Detection Pump - up to 03MY ...................................... 17-2-52
Canister - EVAP - Models with Fuel Leak Detection Pump - from 03MY ....................................... 17-2-53
Valve - purge control ..................................................................................................................... 17-2-54
Solenoid - evap canister vent solenoid (CVS) valve ..................................................................... 17-2-55
Sensor - heated oxygen (HO2S) - pre-catalytic converter .............................................................. 17-2-56
Sensor - heated oxygen (HO2S) - post-catalytic converter ............................................................ 17-2-57
Control Valve - Secondary Air Injection (SAI) ............................................................................... 17-2-58
Reservoir - Vacuum - Secondary Air Injection (SAI) - up to 03MY ................................................. 17-2-58
Reservoir - vacuum - Secondary Air Injection (SAI) - from 03MY .................................................. 17-2-59
Pump - Air - Secondary Air Injection (SAI) ..................................................................................... 17-2-59
Air Manifold - LH - Secondary Air Injection (SAI) ........................................................................... 17-2-60
Air Manifold - RH - Secondary Air Injection (SAI) .......................................................................... 17-2-61
Solenoid - Vacuum - Secondary Air Injection (SAI) ...................................................................... 17-2-62
Pipe - Secondary Air Injection (SAI) .............................................................................................. 17-2-62
Pump - Fuel Leak Detection - up to 03MY...................................................................................... 17-2-64
Pump - fuel leak detection - from 03MY ......................................................................................... 17-2-64
Filter - fuel leak detection pump - up to 03MY ................................................................................ 17-2-65
Filter - fuel leak detection pump - from 03MY ................................................................................. 17-2-65

GENERAL INFORMATION
03-5
Checklist
Always adhere to the following.
Electricity and heating:
lkeep doors and windows closed in the winter;
lswitch off machinery or lights when not needed;
luse energy efficient heating systems;
lswitch off computers and photocopiers when
not needed.
Fuel:
ldon't run engines unnecessarily;
lthink about whether journeys are necessary and
drive to conserve fuel.
Water:
ldon't leave taps and hose pipes running;
lmend leaks quickly, don't be wasteful.
Compressed air:
ldon't leave valves open;
lmend leaks quickly;
ldon't leave the compressor running when not
needed.
Use of environmentally damaging materials:
lcheck whether a less toxic material is available.
Handling and storage of materials:
lhave the correct facilities available for handling
liquids to prevent spillage and wastage as listed
above;
lprovide suitable locations for storage to prevent
frost damage or other deterioration.
Waste Management
One of the major ways that pollution can be reduced
is by the careful handling, storage and disposal of all
waste materials that occur on sites. Legislation
makes it illegal to dispose of waste materials other
than to licensed waste carriers and disposal sites.
This means that it is necessary to not only know what
the waste materials are, but also to have the
necessary documentation and licenses.
Handling and storage of waste
Ensure that waste materials are not poured down the
drain or onto soils. They should be stored in such a
way as to prevent the escape of the material to land,
water or air.
They must also be segregated into different types of
waste e.g. oil, metals, batteries, used vehicle
components. This will prevent any reaction between
different materials and assist in disposal.Disposal of waste
Disposal of waste materials must only be to waste
carriers who are licensed to carry those particular
waste materials and all the necessary
documentation must be completed. The waste
carrier is responsible for ensuring that the waste is
taken to the correct disposal sites.
Dispose of waste in accordance with the following
guidelines.
lFuel, hydraulic fluid, anti-freeze and oil: keep
separate and dispose of to specialist contractor.
lRefrigerant: collect in specialist equipment and
reuse.
lDetergents: safe to pour down the foul drain if
diluted.
lPaint, thinners: keep separate and dispose of
to specialist contractor.
lComponents: send back to supplier for
refurbishment, or disassemble and reuse any
suitable parts. Dispose of the remainder in
ordinary waste.
lSmall parts: reuse any suitable parts, dispose
of the remainder in ordinary waste.
lMetals: can be sold if kept separate from
general waste.
lTyres: keep separate and dispose of to
specialist contractor.
lPackaging: compact as much as possible and
dispose of in ordinary waste.
lAsbestos-containing: keep separate and
dispose of to specialist contractor.
lOily and fuel wastes (e.g. rags, used spill kit
material): keep separate and dispose of to
specialist contractor.
lAir filters: keep separate and dispose of to
specialist contractor.
lRubber/plastics: dispose of in ordinary waste.
lHoses: dispose of in ordinary waste.
lBatteries: keep separate and dispose of to
specialist contractor.
lAirbags - explosives: keep separate and
dispose of to specialist contractor.
lElectrical components: send back to supplier
for refurbishment, or disassemble and reuse
any suitable parts. Dispose of the remainder in
ordinary waste.
lElectronic components: send back to supplier
for refurbishment, or disassemble and reuse
any suitable parts. Dispose of the remainder in
ordinary waste.
lCatalysts: can be sold if kept separate from
general waste
lUsed spill-absorbing material: keep separate
and dispose of to specialist contractor.
lOffice waste: recycle paper and toner and ink
cartridges, dispose of the remainder in ordinary
waste.

GENERAL DATA
04-5
Idle speed:
⇒ All loads off 660 ± 50 rev/min
⇒ Base idle speed Non-adjustable
⇒ Idle air control (IAC) valve position Checked via TestBook
CO at idle:
⇒ Catalyst vehicles 0.5 %
⇒ Non-catalyst vehicles 0.5 - 1.0 %
Valve timing
Inlet valves:
⇒ Opens 28° BTDC
⇒ Closes 77° ABDC
Exhaust valves:
⇒ Opens 66° BBDC
⇒ Closes 39° ATDC
Fuel grade:
⇒ High compression catalyst vehicles 95 RON minimum unleaded
⇒ Low compression catalyst vehicles 91 RON minimum unleaded
⇒Non-catalyst vehicles 97 RON leaded
Lubrication
Type Wet sump, pressure fed
Pump type Crankshaft driven eccentric rotor
Oil filter Disposable canister with full flow by-pass
Pressure at idle - minimum 0.7 bar (10 lbf.in
2)
Pressure at 2000 rev/min (hot) 3.4 bar (50 lbf.in
2)
Relief valve opening pressure 3.4 bar (50 lbf.in
2)
Low oil pressure switch opening pressure 0.24-0.41 bar (3.5-6.0 lbf.in
2)
Crankshaft
Main journal diameter 63.487 - 63.500 mm (2.4995 - 2.520 in)
Crankpin journal diameter 55.500 - 55.513 mm (2.20 - 2.22 in)
End float 0.08 - 0.26 mm (0.003 - 0.010 in)
Maximum ovality 0.040 mm (0.002 in)
Main bearings
Quantity 5
Material Glacier Vandervell / AS 15
Diametrical clearance 0.015 - 0.016 mm (0.00059 - 0.00063 in)
Connecting Rods
Type Horizontally split big-end, plain small end
Distance between centres 155.120 - 155.220 mm (6.1071 - 6.1110 in)
Big-end bearings
Quantity 8
Material Glacier Vandervell GPL 2120/AS 124A
Diametrical clearance 0.015 - 0.016 mm (0.00059 - 0.00063 in)
End float 0.15 - 0.35 mm (0.0006 - 0.0138 in)

GENERAL DATA
04-8
Fuel system - Td5
Fuel system - V8
Type Direct injection from pressure regulated supply with cooled return flow
and in-line pressure regulator
Pressure regulator setting 4 bar (58 lbf.in
2)
Pump Electric two stage submersible
Pump output:
⇒ Low pressure 30 l/h (6.6 gal/h) (7.93 US gal/h) at 0.5 bar (7.25 lbf.in
2)
⇒ High pressure 180 l/h (39.6 gal/h) (47.55 US gal/h) at 4 bar (58 lbf.in
2)
Maximum consumption 30 l/h (6.6 gal/h) (7.93 US gal/h)
Injectors Make/type Lucas EV1/Dual stage
Injector operating pressures:
Pre EU3 models
⇒ Initial opening pressure 270 bar (3915 lbf.in
2)
⇒ Fully opened pressure 440 bar (6380 lbf.in
2)
⇒ Maximum pressure 1560 bar (22620 lbf.in
2)
EU3 models:
⇒ Initial opening pressure 270 bar (3915 lbf.in
2)
⇒ Fully opened pressure 440 bar (6380 lbf.in
2)
⇒ Maximum pressure 1750 bar (25375 lbf.in
2)
Filter In-line canister filter/water separator with water detection
Air cleaner Mann and Hummell P0037
Type Multiport injection from pressure regulated, returnless supply
Pump Electric submersible
Regulated pump output pressure 3.5 bar (50.75 lbf.in
2)
Fuel pump delivery 120 litres/hr (211 pints/hr) (234 US pints/hr)
Filter In-line canister
Air filter Mann and Hummell P0036

TORQUE WRENCH SETTINGS
06-2
Engine Td5
TORQUE DESCRIPTION METRIC IMPERIAL
ACE pump bolts25 Nm (18 lbf.ft)
A/C compressor bolts 25 Nm (18 lbf.ft)
Alternator support bracket to cylinder head bolts 25 Nm (18 lbf.ft)
Alternator/vacuum pump oil feed pipe union 10 Nm (7 lbf.ft)
Camshaft cover to camshaft carrier bolts 10 Nm (7 lbf.ft)
Camshaft sprocket to camshaft bolts 37 Nm (27 lbf.ft)
Centrifuge cover bolts 10 Nm (7 lbf.ft)
Centrifuge oil drain pipe to sump bolts (or nuts) 10 Nm (7 lbf.ft)
Centrifuge to oil drain pipe bolts 10 Nm (7 lbf.ft)
Centrifuge to oil cooler housing bolts 25 Nm (18 lbf.ft)
CKP sensor bolt10 Nm (7 lbf.ft)
Coolant pipe bolt50 Nm (37 lbf.ft)
Connecting rod bolts, then a further 80°20 Nm (15 lbf.ft)
Crankshaft pulley bolt 460 Nm (340 lbf.ft)
Crankshaft pulley TV damper bolts 80 Nm (59 lbf.ft)
Crankshaft rear oil seal housing bolts 10 Nm (7 lbf.ft)
Cylinder head bolts initial tighten 30 Nm (22 lbf.ft)
Cylinder head bolts final tighten, then a further 90°, then a further 180° and finally a
further 45°65 Nm (48 lbf.ft)
Dipstick tube to camshaft carrier bolt 10 Nm (7 lbf.ft)
Drive plate (automatic transmission) to crankshaft bolts 115 Nm (85 lbf.ft)
EGR pipe clamp to cylinder head bolt - if fitted 25 Nm (18 lbf.ft)
EGR pipe Allen screws 10 Nm (7 lbf.ft)
Engine mounting (front) to cylinder block bolts 48 Nm (35 lbf.ft)
Engine mounting (front) to chassis nuts 85 Nm (63 lbf.ft)
Engine mounting bracket (rear, LH & RH) to gearbox bolts 85 Nm (63 lbf.ft)
Engine mounting bracket (rear, LH & RH) nuts 45 Nm (33 lbf.ft)
Flywheel to crankshaft (manual transmission) bolts, then a further 90°40 Nm (30 lbf.ft)
Front crossmember bolts 26 Nm (20 lbf.ft)
Fuel connector block bolts 25 Nm (18 lbf.ft)
Fuel cooler to inlet manifold bolts 25 Nm (18 lbf.ft)
Gearbox housing to engine bolts 50 Nm (37 lbf.ft)
Heater pipe to cylinder head bolts 25 Nm (18 lbf.ft)
Main bearing cap bolts then a further 90°33 Nm (24 lbf.ft)
Oil cooler housing to cylinder block bolts 25 Nm (18 lbf.ft)
Oil cooler pipe clip bolts 10 Nm (7 lbf.ft)
Oil filter adaptor housing to oil cooler housing bolts 25 Nm (18 lbf.ft)
Oil pick-up strainer Torx screws + 10 Nm (7 lbf.ft)
Oil pressure switch 15 Nm (11 lbf.ft)
Oil pump drive sprocket bolt + 25 Nm (18 lbf.ft)
Oil pump pressure relief valve plug + 25 Nm (18 lbf.ft)
Oil pump and stiffener assembly to cylinder block bolts 13 Nm (10 lbf.ft)
Oil sump to cylinder block bolts 25 Nm (18 lbf.ft)
Oil sump to gearbox bell housing bolts 13 Nm (10 lbf.ft)
PAS pump bracket bolts 27 Nm (20 lbf.ft)
PAS pump pulley bolts 27 Nm (20 lbf.ft)
Rocker arm adjusting screw locknuts 16 Nm (12 lbf.ft)

CAPACITIES, FLUIDS, LUBRICANTS AND SEALANTS
09-1
CAPACITIES, FLUIDS, LUBRICANTS AND SEALANTS
Capacities
The following capacities are only an approximation of
the amount of fluid required to fill the respective
system.
Capacities - UK EURO ROWCapacities - NAS
Refrigerant - A/C system
Component Metric Units
Fuel tank 95 litres
Engine - Td5:
⇒ Engine oil and filter change 7.2 litres
⇒ Fill from dry 8.2 litres
Engine - V8 with oil cooler:
⇒Engine oil and filter change 6.27 litres
⇒Engine oil refill from dry: 7 litres
Engine - V8 without oil cooler:
⇒Engine oil and filter change 5.8 litres
⇒ Engine oil refill from dry 6.5 litres
Manual gearbox without oil cooler:
⇒ Refill 2.3 litres
⇒ Fill from dry 2.6 litres
Manual gearbox with oil cooler:
⇒ Refill 2.8 litres
⇒ Fill from dry 3.1 litres
Automatic gearbox fill from dry 9.7 litres
Transfer box:
⇒ Refill 2.0 litres
⇒ Fill from dry 2.3 litres
Front and rear axle:
⇒ Refill 1.6 litres
⇒ Fill from dry 1.7 litres
Cooling system - Td5 Engine:
⇒ Refill 8 litres
⇒ Fill from dry 13 litres
Cooling system - V8 Engine:
⇒ Refill 12 litres
⇒ Fill from dry 13 litres
Component US Units
Fuel tank 25.5 gal
Engine - V8 with oil cooler:
⇒ Engine oil and filter change 6.6 qt
⇒ Engine oil refill from dry 7.4 qt
Engine - V8 without oil cooler:
⇒ Engine oil and filter change 6.1 qt
⇒ Engine oil refill from dry 6.9 qt
Automatic gearbox fill from dry
19.7 pt
Transfer box:
⇒ Refill 4.1 pt
⇒ Fill from dry 4.8 pt
Front and rear axle:
⇒ Refill 3.4 pt
⇒ Fill from dry 3.6 pt
Cooling system - V8 Engine:
⇒ Refill 24.2 pt
⇒ Fill from dry 26.2 pt
⇒Front A/C 700 ± 25 g
⇒Front/rear A/C 900 ± 25 g

MAINTENANCE
PROCEDURES 10-7
Road wheel speed sensors
Inspect
Front wheel
Rear wheel
1.Inspect each sensor harness for damage.
Brake fluid
Replace
1.Replace brake fluid.

+ BRAKES, ADJUSTMENTS, Brake
system bleeding.
Fuel filter - diesel engine
Replace
1.Replace filter element.

+ ENGINE MANAGEMENT SYSTEM -
Td5, REPAIRS, Element - fuel filter.
Fuel filter sedimenter
Drain
1.Position suitable container beneath fuel filter.
2.Disconnect multiplug from sedimenter.
3.Rotate sedimenter anti-clockwise until water
flows from drain tube.
4.Allow to drain until diesel fuel flows from drain
tube.
5.Rotate sedimenter fully clockwise.
6.Connect multiplug.

ENGINE - V8
12-2-26 REPAIRS
Engine assembly
$% 12.41.01.99
Remove
1.Drain engine oil and remove oil filter.
2.Remove radiator.

+ COOLING SYSTEM - V8, REPAIRS,
Radiator.
3.Remove upper inlet manifold.

+ MANIFOLDS AND EXHAUST
SYSTEMS - V8, REPAIRS, Gasket - inlet
manifold - upper - Without Secondary Air
Injection.
4.Remove ignition coil assemblies.
5.Position absorbent material to catch spillage
and disconnect fuel pipe from fuel rail.
CAUTION: Always fit plugs to open
connections to prevent contamination.
6.Release 2 hose clips and remove top hose.
7.Using a 15 mm spanner, release auxiliary drive
belt tension and remove drive belt. 8.Remove 3 bolts securing ACE pump, release
pump and tie aside.
9.Disconnect multiplug from A/C compressor.
10.Remove 4 bolts securing A/C compressor,
release compressor and tie aside.

ENGINE - V8
12-2-30 REPAIRS
Refit
1.Clean mating faces of engine and gearbox,
dowel and dowel holes.
2.Lubricate splines and bearing surface on first
motion shaft with grease.
3.With assistance position engine in engine bay,
align to gearbox and locate on dowels.
4.Position support brackets, fit bell housing bolts
and tighten to 50 Nm (37 lbf.ft).
5.Position engine mountings, fit nuts and tighten
to 85 Nm (63 lbf.ft).
6.Lower lifting equipment and remove from
engine.
7. Models with automatic gearbox: Align torque
converter to drive plate, fit bolts and tighten to
50 Nm (37 lbf.ft). Fit access plug.
8.Fit exhaust front pipe.

+ MANIFOLDS AND EXHAUST
SYSTEMS - V8, REPAIRS, Front pipe.
9.Position oil cooling pipe saddle clamps and
tighten bolts.
10.Position engine harness into foot well.
11.Connect 5 multiplugs to ECM.
12.Fit toe board and secure with trim fixings.
13.Connect engine harness earth to body and
secure with nut.
14.Connect engine harness to main harness
multiplug.
15.Connect multiplug to EVAP purge valve.
16.Connect engine harness multiplugs to fuse
box.
17.Connect starter lead to fuse box and secure
with nut.
18.Connect engine harness positive lead to
battery and tighten nut.
19.Fit fuse box cover.
20.Position engine earth lead and secure with
bolt.
21.Position coolant rail and secure with bolt.
22.Connect harness clips to coolant rail.
23.Connect hose to coolant rail and coolant pump
and secure with clips.
24.Connect PAS pump high and low pressure
pipes and secure with clips.
25.Position oil cooling pipe saddle clamp to PAS
pump housing and secure with bolt.
26.Clean A/C compressor and housing mating
faces, dowels and dowel holes.
27.Position A/C compressor, fit bolts and tighten
to 22 Nm (16 lbf.ft).
28.Connect multiplug to A/C compressor.
29.Clean ACE pump and housing mating faces,
dowels and dowel holes.
30.Position ACE pump, fit bolts and tighten to 22
Nm (16 lbf.ft). 31.Clean all pulley 'V's, fit auxiliary drive belt,
using a 15mm spanner, release belt tensioner
secure belt and re-tension drive belt .
32.Ensure auxiliary drive belt is correctly located
on all pulleys.
33.Fit radiator.

+ COOLING SYSTEM - V8, REPAIRS,
Radiator.
34.Fit top hose and secure with clips.
35.Connect fuel pipe to fuel rail.
36.Position ignition coils and connect ht leads.
37.Fit upper inlet manifold.

+ MANIFOLDS AND EXHAUST
SYSTEMS - V8, REPAIRS, Gasket - inlet
manifold - upper - Without Secondary Air
Injection.
38.Fit new oil filter and refill engine with oil.

+ ENGINE - V8, REPAIRS, Filter - oil.

+ MAINTENANCE, PROCEDURES,
Engine oil - V8 engine.
39.Top up gearbox oil.

+ MAINTENANCE, PROCEDURES,
Automatic gearbox.
