Page 16 of 1007
CONTENTS
CONTENTS 13
Remote control - front door ............................................................................................................. 76-1-30
Remote control - rear door .............................................................................................................. 76-1-30
Operating cable - lock remote control - 5 door ............................................................................... 76-1-31
Finisher - rear screen - side - 5 door .............................................................................................. 76-1-31
Handle - exterior - rear door ........................................................................................................... 76-1-32
Handle - exterior - tail door ............................................................................................................. 76-1-33
Handle - exterior - front door ........................................................................................................... 76-1-34
Door pull - 5 door - up to 04MY ....................................................................................................... 76-1-35
EXTERIOR FITTINGS ............................................................................... 76-2-1
REPAIRS
Wing - front ..................................................................................................................................... 76-2-1
Liner - front wheel arch ................................................................................................................... 76-2-2
Liner - rear wheel arch .................................................................................................................... 76-2-3
Panel - underbelly ........................................................................................................................... 76-2-4
Mirror - exterior - electric ................................................................................................................. 76-2-4
Mud flap - front ................................................................................................................................ 76-2-5
Mud flap - rear ................................................................................................................................. 76-2-5
Bracket - spare wheel mounting ..................................................................................................... 76-2-6
Side rail - integral roof rack - 5 door ................................................................................................ 76-2-7
Bonnet............................................................................................................................................. 76-2-7
Cable/rod - bonnet lock control ....................................................................................................... 76-2-8
Bumper - assembly - front - up to 04MY ......................................................................................... 76-2-10
Bumper - assembly - front - from 04MY .......................................................................................... 76-2-11
Bumper valance - rear - up to 04MY ............................................................................................... 76-2-13
Bumper valance - rear - from 04MY ................................................................................................ 76-2-13
Finisher - sill - lower ....................................................................................................................... 76-2-16
Moulding - roof - 5 door ................................................................................................................... 76-2-17
Wheelarch extension - rear wing part ............................................................................................. 76-2-18
Body quarter vent assembly - 3 door .............................................................................................. 76-2-19
Page 24 of 1007
CONTENTS
CONTENTS 21
WINDOWS ................................................................................................ 86-5-1
REPAIRS
Motor & control unit - front door - 3 door ......................................................................................... 86-5-1
Motor & control unit - front door - 5 door ......................................................................................... 86-5-2
Switch - master window - 5 door - from 04MY ................................................................................ 86-5-2
Relay - control - tail door glass ....................................................................................................... 86-5-3
Microswitch - hardtop sensing - 3 door ........................................................................................... 86-5-4
Relay - heated front screen ........................................................................................................... 86-5-5
Switch - backlight heater ................................................................................................................. 86-5-6
IN CAR ENTERTAINMENT ...................................................................... 86-6-1
REPAIRS
Radio - up to 04MY ......................................................................................................................... 86-6-1
Radio/CD - from 04MY .................................................................................................................... 86-6-2
Speaker - rear - 3 door .................................................................................................................... 86-6-3
Speaker - rear - 5 door .................................................................................................................... 86-6-3
Speaker - front ................................................................................................................................ 86-6-4
Aerial - manual - 3 door .................................................................................................................. 86-6-4
Aerial - manual - 5 door .................................................................................................................. 86-6-5
Coaxial lead - front aerial - 3 door ................................................................................................... 86-6-6
Coaxial lead - front aerial - 5 door ................................................................................................... 86-6-7
Speaker - tweeter - front ................................................................................................................. 86-6-8
Speaker - tweeter - rear - 3 door ..................................................................................................... 86-6-9
Amplifier - power ............................................................................................................................ 86-6-10
Sub-woofer assembly .................................................................................................................... 86-6-11
Coaxial lead - extension.................................................................................................................. 86-6-12
HARNESSES ............................................................................................ 86-7-1
REPAIRS
Fuse box - passenger compartment ............................................................................................... 86-7-1
Harness - main ................................................................................................................................ 86-7-2
Harness - tailgate ............................................................................................................................ 86-7-12
Harness - interior lights - 5 door ...................................................................................................... 86-7-15
Harness - front door - 5 door ........................................................................................................... 86-7-15
Harness - rear door ......................................................................................................................... 86-7-16
DRIVER CONTROLS ................................................................................ 86-8-1
REPAIRS
Switch - remote control - audio system .......................................................................................... 86-8-1
Switch - park distance control (PDC) - from 04 MY ........................................................................ 86-8-1
Control unit (ECU) - parking aid - from 04MY ................................................................................. 86-8-2
Sensor - parking aid - rear - from 04MY ......................................................................................... 86-8-2
Sounder - parking aid - rear - from 04MY ....................................................................................... 86-8-3
Switch - handbrake warning ............................................................................................................ 86-8-3
Switch - hazard warning - from 04MY ............................................................................................. 86-8-4
Cigar lighter - front .......................................................................................................................... 86-8-4
Switch - control - exterior mirror ...................................................................................................... 86-8-5
Page 25 of 1007
CONTENTS
22 CONTENTS
NAVIGATION SYSTEM ............................................................................ 87-1
REPAIRS
Interface unit - remote control ........................................................................................................ 87-1
Display unit - navigation system .................................................................................................... 87-1
INSTRUMENTS ......................................................................................... 88-1
REPAIRS
Clock .............................................................................................................................................. 88-1
Instrument panel - up to 04MY ....................................................................................................... 88-2
Instrument panel - from 04MY ........................................................................................................ 88-3
Cowl - instrument - up to 04MY ...................................................................................................... 88-4
Cowl - instrument - from 04MY ....................................................................................................... 88-5
Sender unit - fuel tank gauge.......................................................................................................... 88-6
Sender unit assembly - fuel tank - Td4 models - from 03MY.......................................................... 88-6
Page 74 of 1007
GENERAL DATA
04-11
Engine - KV6 Petrol
General
Type:
⇒ Up to 03 Model Year
⇒ From 03 Model Year2.5 litre V6, 24 valve, air assisted direct fuel injection petrol, water
cooled, transverse mounted
2.5 litre V6, 24 valve, direct fuel injection petrol, water cooled,
transverse mounted
Cylinder arrangement: 90° V6, numbered from the front of the engine
⇒ Left bank Cylinders 1, 3 and 5
⇒ Right bank Cylinders 2, 4 and 6
Bore (nominal) 80 mm (3.15 in.)
Stroke 82.8 mm (3.26 in.)
Capacity 2497 cm
3 (152.37 in3)
Firing order 1-6-5-4-3-2
Compression ratio 10.5 : 1 ± 0.5 : 1
Direction of rotation Clockwise viewed from front of engine
Maximum power 130 kW (177 bhp) @ 6500 rev/min.
Maximum torque 240.0 Nm (177 lbf.ft) @ 4000 rev/min.
Maximum engine speed:
⇒ Continuous 6500 rev/min.
⇒ Intermittent 6750 rev/min.
Idle speed 750 rev/min. ± 50 rev/min.
Weight (fully dressed, wet) 154 kg (340 lb)
Dimensions (dressed):
⇒ Length (nominal) 770 mm (30.3 in.)
⇒ Width (nominal) 750 mm (29.5 in.)
⇒ Height (nominal) 750 mm (29.5 in.)
Valve operation Self-adjusting lightweight hydraulic tappets operated directly by the
camshafts
Fuel injection system:
⇒ Make - Up to 03 Model Year
⇒ Make - From 03 Model YearSiemens engine management system
Siemens engine management system
⇒ Type - Up to 03 Model Year
⇒ Type - From 03 Model YearMulti-point, air assisted fuel injection controlled by ECM, electro-
mechanical injectors with twin sprays targeted on to back of inlet
valves
Multi-point fuel injection controlled by ECM, electro-mechanical
injectors with quadruple sprays targeted on to back of inlet valves
Inlet manifold Variable geometry
Spark plugs
⇒ Type
⇒ Plug gapNLP 100290
1.0 mm ± 0.05 mm (0.039 in. ± 0.002 in.)
Coils:
⇒ Make - Up to 03 Model Year
⇒ Make - From 03 Model Year
⇒ Type - Up to 03 Model Year
⇒ Type - From 03 Model YearBREMR
Champion BAE 403H
6 x coils (3 x plug top, 3 x remote mounted)
6 x coils (6 x plug top)
Emissions standard ECD3
Page 635 of 1007
DOORS
76-1-30 REPAIRS
Remote control - front door
$% 76.37.31
Remove
1.Remove front door plastic sheet.
+ DOORS, REPAIRS, Plastic sheet -
front door - 5 door.
2.Drill out 2 rivets from door release.
3.Remove door release.
4.Release cable from door release.
Refit
1.Connect cable to door release.
2.Position door release and secure with rivets.
3.Fit front door plastic sheet.
+ DOORS, REPAIRS, Plastic sheet -
front door - 5 door.
Remote control - rear door
$% 76.37.32
Remove
1.Remove rear door plastic sheet.
+ DOORS, REPAIRS, Plastic sheet -
rear door.
2.Release cable from door release.
3.Drill out 2 rivets from door release.
4.Remove door release.
Refit
1.Connect cable to door release.
2.Position door release and secure with rivets.
3.Fit rear door plastic sheet.
+ DOORS, REPAIRS, Plastic sheet -
rear door.
Page 636 of 1007
DOORS
REPAIRS 76-1-31
Operating cable - lock remote control - 5
door
$% 76.37.60
Remove
1.Remove door latch.
+ DOORS, REPAIRS, Latch - front
door - 5 door.
+ DOORS, REPAIRS, Latch - rear door.
2.Release cable from interior door release and
remove cable.
Refit
1.Connect cable to interior door release.
2.Fit door latch.
+ DOORS, REPAIRS, Latch - front
door - 5 door.
+ DOORS, REPAIRS, Latch - rear door.
Finisher - rear screen - side - 5 door
$% 76.43.81
Remove
1.Open tail door.
2.Release tail door glass seal from aperture for
access to side finisher fixings.
3.Using a suitable trim stud removal tool, release
3 side finisher fixings from studs on body.
4.Remove side finisher from upper fixing.
5.Remove and discard fixings from finisher.
Refit
1.Fit NEW fixings to finisher.
2.Fit door glass seal to flange.
3.Fit finisher and secure fixings.
Page 992 of 1007
DRIVER CONTROLS
REPAIRS 86-8-1
DRIV ER CONTROLS REPAIRS
Switch - remote control - audio system
$% 86.50.13
Remove
1.Remove drivers airbag.
+ RESTRAINT SYSTEMS, REPAIRS,
Air bag - steering wheel.
2.Release remote control switch leads and
disconnect multiplug.
3.Remove 2 screws securing remote control
switch and remove switch.
Refit
1.Fit remote control switch and secure with
screws.
2.Connect switch multiplug and fit leads in clip.
3.Fit drivers airbag.
+ RESTRAINT SYSTEMS, REPAIRS,
Air bag - steering wheel.
Switch - park distance control (PDC) -
from 04 MY
$% 86.54.02
Remove
1.Release 2 clips and remove fascia mounted
switch cover.
2.Remove 2 screws securing switch carrier to
fascia.
3.Release switch carrier from fascia and
disconnect PDC multiplug.
4.Remove switch assembly from carrier.
Refit
1.Fit PDC switch to carrier.
2.Connect multiplug to PDC switch.
3.Secure switch carrier to fascia with screws.
4.Fit and secure switch cover.
Page 998 of 1007
NAVIGATION SYSTEM
REPAIRS 87-1
NAVIGATION SYST EM REPAIRS
Interface unit - remote control
$% 86.53.15
Remove
1.Remove front console.
+ INTERIOR TRIM COMPONENTS,
REPAIRS, Console - front - up to 04MY.
2.Release interface ECU from bracket,
disconnect multiplug and remove ECU.
Refit
1.Secure interface ECU in bracket and connect
multiplug.
2.Fit front console.
+ INTERIOR TRIM COMPONENTS,
REPAIRS, Console - front - up to 04MY.
Display unit - navigation system
$% 86.53.20
Remove
1.Fit tool LRT-86-009 into slots, ensuring correct
handed tool is in correct slot.
The tools are stamped with 'TOP L' and 'TOP
R', ensure the stampings are facing upwards
when removing the unit.
2.Pull unit from fascia.
3.Disconnect 3 multiplugs and 2 coax cables,
remove unit.
4.Push retaining clips inwards and remove keys.
Refit
1.Position unit to fascia, connect multiplugs and
coax cables.
2.Slide unit in fascia until retaining clips engage.
3.Enter security code, check system is
operational.
M86 5745
M86 5741
